F@st PLUG 500 premium

Quick Installation Guide

Recommended use of a multiple plug adapter

For more information about the way to secure your network or to join a HomePlug AV network, please consult the User Guide

available on the http://support.sagemcom.com

website.

x 2

F@ST PLUG

500

premium

F@ST PLUG

500

premium

A B

Plug both

devices into the

mains

Connect your

equipments
