Section 15: Tail Wheel Installation
Step 4
Slide a clevis keeper onto a nylon clevis. Thread the
clevis onto the wire a minimum of 10 turns.
Step 5
Locate the tail gear steering arm. Use side cutters to
remove the outermost hole from the arm.
Step 6
Attach the clevis to the steering arm in the outer hole as
shown. Slide the clevis keeper onto the clevis to keep the
clevis from opening during flight.
Step 7
Position the steering arm in the center of the
pre-installed tail gear mount. Make sure the set screw
in the arm is facing forward.
Step 8
Slide the tail gear wire through the mount and steering
arm. Position the wire so there is 1/2" between the top
of the mount and the first bend in the wire. Tighten the
set screw in the arm.
