31000 Cubbies
Installation Instructions
The flexibility of the wood cubby design allows multiple units to be connected vertically or horizontally with mounting hardware (provided). Before
connecting one cubby to a second cubby, or to a base, the appropriate connecting holes in the cubby must be cleared. This is done by pressing a
binding post (provided) into each partially pre-drilled hole from the outside of the cubby towards the inside of the cubby then removing the
excess material.
Connecting Cubbies Together
To connect cubbies together, clear the appropriate connecting holes
in each cubby. Then connect with binding posts and screws
(provided) through the sides and/or tops and bottoms. Fasten units
to the wall or floor using appropriate fasteners for the installation (not
provided).
Base Assembly (Optional)
After clearing the four holes in the bottom of the cubby, the cubby
can be assembled to the base by inserting binding posts through the
bottom of the cubby and through the base. Fasten with the provided
screws.
Compartment Shelf Assembly (Optional)
Assemble the compartment shelf by pressing the shelf supports into
the provided holes in the cubby. Slide the compartment shelf over
the shelf supports aligning the groves on the sides of the shelf with
the supports.
Wall Hook Assembly (Optional)
Install the wall hooks into the pre-drilled holes in the sides of the
cubby using the provided hardware.
