User's Manual

Wireless network setup_ 52
6. Follow the instructions in the window and complete the installation.
Starting the program
1. Connect your machine to the network with a network cable.
2. Tu
rned on the machine.
3. Fro
m the Windows Start menu, select All Programs > Samsung
Printers > SetIP > SetIP.
4. Cli
ck on the
icon (third from left) in the SetIP window to open the
TCP/IP configuration window.
5. Enter
the machine’s new information into the configuration window
as follows. In a corporate intranet, you may need to have this
information assigned by a network manager before proceeding.
• MAC Address: Find the machine’s MAC address from the
Network Configuration Report and enter it without the colons.
For example, 00:15:99:29:51:A8 becomes 0015992951A8.
• IP Addre
ss: Enter a new IP address for your printer.
For example, if your computer’s IP add
ress is 192.168.1.150,
enter 192.168.1.X. (X is number between 1 and 254 other than
the computer’s address.)
• Su
bnet Mask: Enter a Subnet Mask.
• Def
ault Gateway: Enter a Default Gateway.
6. Cli
ck Apply, and then click OK. The machine will automatically print
the Network Configuration Report. Confirm that all the settings are
correct.
7. Cli
ck Exit to close the SetIP program.
8. If nece
ssary, restart the computer’s firewall.
IP setting using SetIP Program (Macintosh)
For using SetIP program, disable the computer firewall before continuing
by performing the following:
The path and UIs may differ by Mac OS version. Refer to the Mac
OS manual.
1. Open System Preferences.
2. Cli
ck Security.
3. Cli
ck the Firewall menu.
4. Turn firewall
off.
The following instructions may vary for your model.
1. Con
nect your machine to the network with a network cable.
2. Insert
the Installation CD-ROM, and open the disk window, select
MAC_Installer > MAC_Printer > SetIP > SetIPApplet.html.
3. Double click the file and Safari will automatically open, then select
Trust. The browser will open the SetIPApplet.html page that shows
the printer’s name and IP address information.
4. Click on the
icon (third from left) in the SetIP window to open the
TCP/IP configuration window.
5. Enter the machine’s new information into the configuration window
as follows. In a corporate intranet, you may need to have this
information assigned by a network manager before proceeding.
• MAC Addres
s: Find the machine’s MAC address from the
Network Configuration Report and enter it without the colons.
For example, 00:15:99:29:51:A8 becomes 0015992951A8.
• IP
Address: Enter a new IP address for your printer.
For example, if your computer’s IP address is 192.168.1.150,
enter 192
.168.1.X. (X is number between 1 and 254 other than
the computer’s address.)
• Su
bnet Mask: Enter a Subnet Mask.
• Default Gateway:
Enter a Default Gateway.
6. Select Ap
ply, then OK, and OK again. The printer will automatically
print the configuration report. Confirm that all the settings are correct.
Quit Safari. You may close and eject the installation CD-ROM. If
necessary, restart the computer’s firewall. You have successfully
changed the IP address, subnet mask, and gateway.
Configuring the machine’s wireless network
Before starting you will need to know the network name(SSID) of your
wireless network and the network key if it is encrypted. This information was
set when the access point (or wireless router) was installed. If you do not
know about your wireless environment, please ask the person who has set
up your network.
To configure wireless parameters, you can use Sy
ncThru™ Web Service.
Using SyncThru™ Web Service
Before starting wireless parameter configuration, make sure cable
connection status.
1. Check whether the network cable is connected to the machine. If not,
connect the manchine with a standard network cable.
2. Start a web browser such as Internet Explorer, Safari or Firefox and
enter your machine’s new IP address in the browser window.
For example,
3. When the SyncThru™ Web Service window opens, click Network
Settings.
4. Click Wi
reless and select Wizard. Then, click Next.
Wizard will help you setup the wireless network configuration.
However, if you want to set the wireless network directly, select
