3.5. Frequently used functions
Primary function
SECONDARY FUNCTION
Exoskeleton:
- Execution of the
rehabilitation exercises
Back:
- Mechanical connection of the right and left femoral drive.
- Fastening of the spine-sacral corset.
- Fastening of shoulder straps.
- Battery placement.
- Location of the central microcontroller. Location of the
central computer module
- Placement of handles to insure the patient with an
accompanying person (assistent).
- Placing control buttons exoskeleton, incl. emergency stop
buttons.
- Placement of indicators of the state of the exoskeleton.
- Adjusting the height of the straps.
- Adjust the width of the pelvis.
- Adjustment of the angle of lead / hip reduction.
- Supporting element.
Thigh:
- Mechanical connection with back and shin.
- Flexion / extension of the legs of the patient in the knee
and hip joints
- Adjust the length of the thigh of the exoskeleton.
- Fixation of the thigh bindings.
- Adjustment of the position of the femoral mounts along
the sagittal axis (forward-backward).
- Mounting the sciatic harness.
- Supporting element.
Shin:
- Mechanical hip joint and exoskeleton foot.
- Adjustment of the length of the shin of the exoskeleton.
- Fixation the shin bindings.
- Adjustment of the position of the shin bindings along the
sagittal axis (forward-backward).
- Adjustment of the position of the shin bindings along the
front axis to the left and to the right).
- Providing a hinged connection with a stack of exoskeleton
with adjustable elasticity.
- Supporting element.
Foot:
