3.6. Specifications
Product name Powered Lower Extremity Exoskeleton
Model
name
/
Type
Ref.
ExoAtlet®-II / EA2010
Protection
against
electric shock
INTERNALLY POWERED, B type applied part
Applied parts Corset and strap for fixing the body
Device classification
Class
IIa
(According to council Directive 93/42/EEC AnnexⅨ Rule 9)
Packing unit 1 set
Expected Life Time 5 years
Rated Power
1.
Main
Body
- Charger Input: 100-240 V~, 50-60 Hz, 3 A
- Input Power: 29.4 V-, max. 7.0 A
- Rechargeable batteries: 25.55 V-, 5700 mAh x 2PCs
2. Remote control crutch
- Charger Input: 100-240 V~, 50-60 Hz, 0.2 A
- Input Power: 5.0 V-, max. 1.0 A
- Rechargeable battery: 3.63 V , 2600 mAh
Communications Bluetooth Ver. 4.0, Wifi Ver. 802.11 b/g/n
Dimensions of outer
shape
1.
Main
body:
43~80
cm(W)
x
27~50
cm(D)
x
110~160
cm(H)
2. Crutch Size: 74 ~ 94 cm
Weight Main Body: Appr. 25 kg, Crutch: Appr. 615 g
Classification
of
installation and use
Body-Worn(신체착용형)
Maximum
continuous
operating time
< 4 hour
Charging time < 4 hour(At 100% full charge.)
Exercise range
specification
1.
Hip
joint
- Flexion 108°, Extension 21°
- Adjustment of abduction angle 0°-3°
- Adjustment of adduction angle 0°-4°
2. Knee joint
- Flexion 112°, Extension 2°
3. Ankle joint
- Plantar flexion 25°
