4.6. Pelvic floor depth control
4.6.1. As shown in [Figure 11], Remove the previous back pad. Place the required back
pad.
[Figure
11]
[Figure
12]
4.7. Adjust pelvic floor area
4.7.1. As shown in [Figure 13], Pull out and loosen two cam levers.
4.7.2. As shown in [Figure 14], Pull out the lever. Rotate the lever to adjust the desired
width (rotating clockwise widens the pelvis).
[Figure
13]
lever
[Figure
14]
