3. Components and Installation of S-PATCH3
3.1 Main Device Components
<S-PATCH3>
Label
Name
Description
1
Main Body1
Coin battery inset module
2
Main Body2
Main PCB module
3
Connect Cable
Cable between two main bodies
4
Power Button
Power On/Off button
5
LED
LED Lamp to indicate the states
6
Electrode connect hole
Holes for ECG electrodes connecting
