LCD MONITOR quick start guide 225UN ii
Package Contents Please make sure the following items are included with your monitor. If any items are missing, contact your dealer. Contact a local dealer to buy optional items.
Quick Setup Guide Warranty Card (Not available in all locations) User's Guide, Monitor Driver, Natural Color, MagicTuneTM Power Cord RGB-IN Cable USB Cable Cable Others Cleaning Cloth Will be applied to black and high gloss models only.
MENU button [ Opens the OSD menu. Also use to exit the OSD menu or return to the previous menu. ] Adjust buttons [ ] MagicBright™ button [ ] These buttons allow you to adjust items in the menu. MagicBright™ is a new feature providing optimum viewing environment depending on the contents of the image you are watching. Currently six different modes are available: Custom, Text, Internet, Game, Sports and Movie. Each mode has its own pre-configured brightness value.
The configuration at the back of the monitor may vary from product to product. POWER z POWER : Connect the power cord for your monitor to the POWER on the back of the monitor. RGB-IN / RGB-IN : Connect the signal cable to the 15-pin, RGB-IN port on the back of your monitor. : Connect the of the monitor and the USB of the computer with the USB cable. Kensington Lock z The Kensington lock is a device used to physically fix the system when using it in a public place.
/ MIC/ : Headphone output terminal MIC : Connect a microphone to the MIC terminal. : Connect the of the USB monitor and a USB device with the USB cable. See Connecting Cables for further information regarding cable connections.
Connecting Cables Connecting to a Computer Connect the power cord for your monitor to the power port on the back of the monitor. Plug the power cord for the monitor into a nearby outlet. Use appropriate connection for your computer. Using the RGB-IN (Analog) connector on the video card. - Connect the signal cable to the 15-pin, RGB-IN port on the back of your monitor. [ RGB-IN ] Connected to a Macintosh. Connect the monitor to the Macintosh computer using the RGB-IN connection cable.
Data Rate Connect the 480 Mbps 12 Mbps 1.5 Mbps port of the monitor and the USB port of the computer with the USB cable. To use port, you have to connect the to the PC. Make sure to use the USB cable supplied with this monitor to connect the monitor's port and your computer's USB port. Connect the port of the USB monitor and a USB device with the USB cable. The use procedures are as the same as those for using an external device connecting to the PC.
z z z The company is not liable for problems or damages to an external device caused by using an unauthorized cable for the connection. Some products do not follow the USB standard, and it may cause a malfunction of the device. If the device malfunctions even if it is connected to the computer, contact the service center of the device/computer. Using the Stand This monitor supports various types of VESA-standard bases. You need to either fold or remove the base in use to install a VESA base.
1. Turn off your monitor and unplug its power cord. 2. Lay the LCD monitor face-down on a flat surface with a cushion beneath it to protect the screen. 3. Remove four screws and then remove the stand from the LCD monitor. 4. Align the mounting interface Pad with the holes in the rear cover mounting pad and secure it with four screws that came with the arm-type base, wall mount hanger or other base.
Check List Before calling for service, check the information in this section to see if you can remedy any problems yourself. If you do need assistance, please call the phone number on the Information section or contact your dealer. Symptom No images on the screen. I cannot turn on the monitor. Check List Solutions Is the power cord connected properly? Check the power cord connection and supply.
monitor and restore the image on the screen. I cannot see the On Screen Display. Have you locked the On Screen Display (OSD) Menu to prevent changes? Unlock the OSD by pressing the [ 5 seconds. The screen shows strange colors or just black and white. Is the screen displaying only one color as if looking at the screen through a cellophane paper? Check the signal cable connection. Have the screen colors become strange after running a program or due to a crash between applications? Reboot the computer.
properly. Window OS that supports Plug and Play. Control Panel → Performance and Maintenance → System → Hardware → Device Manager → Monitors → After deleting Plug and Play monitor, find 'Plug and Play monitor' by searching new Hardware. MagicTune™ is an additional software for the monitor. Some graphic cards may not support your monitor. When you have a problem with the graphic card, visit our website to check the compatible graphic card list provided. http://www.samsung.
Set the resolution at the Control Panel → Display → Screen Saver. Set the function at BIOS-SETUP of the computer. Refer to Windows/Computer Manual How can I clean the outer case/LCD Panel? Disconnect the power cord and then clean the monitor with a soft cloth, using either a cleaning solution or plain water. Do not leave any remains of the detergent nor scratch the case. Do not allow any water to go inside the monitor.
Environment The location and the position of the monitor may influence the quality and other features of the monitor. If there are any sub woofer speakers near the monitor, unplug and relocate the woofer to another room. Remove all electronic devices such as radios, fans, clocks and telephones that are within 3 feet (one meter) of the monitor. Useful Tips A monitor recreates visual signals received from the computer.
