BD-C5500 BD-C5500C Blu-ray Disc Player user manual imagine the possibilities Thank you for purchasing this Samsung product. To receive more complete service, please register your product at www.samsung.com/register Downloaded From Disc-Player.
Key features Blu-ray Disc Features Blu-ray Discs support the highest quality HD video available in the industry - Large capacity means no compromise on video quality. Furthermore, a Blu-ray Disc has the same familiar size and look as a DVD. The following Blu-ray Disc features are disc dependant and will vary. Appearance and navigation of features will also vary from disc to disc. Not all discs will have the features described below.
Safety Information 02 Warning CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN The lighting flash and Arrowhead within the CAUTION: TO REDUCE THE RISK OF ELECTRIC The explanation point within the triangle triangle is a warning sign alerting you of SHOCK, DO NOT REMOVE COVER (OR BACK) is a warning sign alerting you of important dangerous voltage inside the product. NO USER SERVICEABLE PARTS INSIDE. REFER instructions accompanying the product. SERVICING TO QUALIFIED SERVICE PERSONNEL.
Safety Information Precautions Important Safety Instructions Read these operating instructions carefully before using the unit. Follow all the safety instructions listed below. Keep these operating instructions handy for future reference. 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings.
Handling Cautions • Do not write on the printed side with a ball-point pen or pencil. • Do not use record cleaning sprays or antistatic. Also, do not use volatile chemicals, such as benzene or thinner. • Do not apply labels or stickers to discs. (Do not use discs fixed with exposed tape adhesive or leftover peeled-off stickers.) • Do not use scratch-proof protectors or covers. • Do not use discs printed with label printers available on the market. • Do not load warped or cracked discs.
Contents Key features 2 2 Blu-ray Disc Features Blu-ray Disc Player Features Safety Information 3 4 4 4 4 Warning Precautions Important Safety Instructions Disc Storage & Management Disc Handling Getting Started 10 10 10 11 11 13 13 14 14 15 16 17 18 18 19 19 Before using the User Manual Disc Types and Contents that can be played.
26 26 27 Connecting to an Audio System Case 1 : Connecting to an Audio System (HDMI Supported Amplifier) - Best Quality (Recommended) Case 2 : Connecting to an Audio System (Dolby Digital, DTS Amplifier) - Better Quality Case 3 : Connecting to an Audio System (2 Channel Amplifier) - Good Quality Connecting to the Network Cable Network Wireless Network 28 29 30 30 30 30 32 32 32 32 32 32 32 33 34 34 34 34 34 34 34 35 35 35 36 36 36 39 40 Before Starting (Initial Settings) Setting the Menu Display TV Aspec
Contents Setup 40 40 40 40 41 41 41 41 41 41 41 42 Language Security Parental Rating Change Password General Background Energy Saving Front Display Power On/Off Sound Support Software Upgrade Contact Samsung Basic Functions 43 43 43 43 43 43 43 44 44 44 44 44 44 44 45 45 45 45 45 46 46 46 46 47 Playing a Disc Playback Disc Structure Using the Disc menu/Title menu/Popup menu Using the Disc Menu Using the Title Menu Playing the Title List Using the Popup Menu Using the Search and Skip Functions Searc
48 48 48 49 49 49 50 51 Listening to Music Buttons on the Remote Control used for Music Playback Playing an Audio CD (CD-DA)/MP3 Repeat an Audio CD (CD-DA)/MP3 Playlist Playing back a Picture Playing a JPEG Disc Using the TOOLS button Playing back a USB Storage Device Notes on USB connection Network Services 52 52 54 55 56 56 56 Using Internet@TV Getting Started with Internet@TV Settings Samsung Apps BD-LIVE™ Software Upgrade Notification Using the AllShare Function Appendix 58 61 62 63 63 64 65 Trou
Getting Started Before using the User Manual Disc Types and Contents that can be played. Term Logo Icon h � Z BD-ROM BD-RE/-R DVD-VIDEO Definition This involves a function available on a BD-ROM. This involves a function available on a BD-RE/-R disc recorded in the BD-RE format. This involves a function available on a DVD-VIDEO. DVD-RW(V) DVD-R � DVD+RW This involves a function available on recorded DVD+RW or DVD-RW(V)/DVD-R/+R discs that have been recorded and finalized.
▪ ▪ ▪ ▪ ▪ ▪ Do not allow the disc to become dirty or scratched. Fingerprints, dirt, dust, scratches or deposits of cigarette smoke on the recording surface may make it impossible to use the disc for playback. Discs with PAL programs recorded on them cannot be played using this player. This player is compatible with the NTSC color system only. When a BD-J title is played, loading may take longer than a normal title, or some functions may perform slowly.
Getting Started DVD+R • This player can play back a DVD+R disc recorded and finalized with a DVD Video recorder. Ability to play back may depend on recording conditions. Audio CD (CD-DA) • This player can play back CD-DA format audio CD-RW/-R discs. • The player may not be able to play some CD-RW/-R discs due to the condition of the recording. CD-RW/-R • Use a 700MB(80 minutes) CD-RW/-R disc. If possible, do not use a 800MB(90 minutes) or above disc, as the disc may not play back.
Disc Type Blu-ray Region Code DVD-VIDEO Area a North America, Central America, South America, Korea, Japan, Taiwan, Hong Kong and South East Asia. b Europe, Greenland, French territories, Middle East, Africa, Australia and New Zealand. c © 2010 Samsung Electronics Co.,Ltd. All rights reserved; No part or whole of this user’s manual may be reproduced or copied without the prior written permission of Samsung Electronics Co.,Ltd. India, China, Russia, Central and South Asia. 1 The U.S., U.S.
Getting Started Logos of Discs that can be played Blu-ray Disc DTS-HD Master Audio Dolby TrueHD NTSC broadcast system in U.S.A, Canada, Korea, Japan DivX BD-LIVE Java Accessories Check for the supplied accessories below.
03 Front Panel Getting Started a b c def g h 1 DISC TRAY Opens to accept a disc. 3 REMOTE CONTROL SENSOR Detects signals from the remote control. DISPLAY Displays the playing status, time, etc. OPEN/CLOSE BUTTON Opens and closes the disc tray. STOP BUTTON Stops disc playback. PLAY/PAUSE BUTTON Plays a disc or pauses playback. POWER BUTTON Turns the player on and off. USB HOST A USB memory flash stick can be connected here and used as storage when connected to BD-LIVE.
Getting Started Front Panel Display a b c 1 2 3 16 IN DISC INDICATOR Lights when a disc is inserted or played back. CURRENT TIME AND STATUS INDICATOR Displays the play time and the current status. WIFI INDICATOR Lights when the wireless network is connected. Downloaded From Disc-Player.
Getting Started ab c 03 Rear Panel d g f e 1 WIRELESS LAN ADAPTER Connect the optional Wireless LAN Adapter (WIS09ABGN) here to use the Wireless network. LAN Can be used for network based services (See pages 52~57), BD-LIVE and software upgrades using a network connection. HDMI OUT 4 Using an HDMI cable, connect this HDMI output terminal to the HDMI input terminal on your TV for the best quality picture or to your Receiver for the best quality sound.
Getting Started Remote Control Tour of the Remote Control Turn the player on and off. To open and close the disc tray. POWER TV POWER BONUSVIEW SOURCE Turn the TV on and off. (To operate your TV, please refer to page 19) After setup, allows you to set the input source on your TV. Press this to use Bonusview function. Press numeric buttons to operate options. Press this to switch the Blu-ray Disc/DVD’s subtitle language.
Button TV POWER TV SOURCE TV VOL (+/–) Function Used to switch the television on and off. Used to select an external source connected to the TV. Used to adjust the volume of the television. TV CH (,/.) Used to select the desired channel. TV MUTE ✎ Used to toggle the sound on and off. NOTE ▪ The functions listed above will not necessarily work on all televisions. If you encounter problems, operate the television directly.
Connections Connecting to a TV Case 1 : Connecting to a TV with an HDMI Cable - Best Quality (Recommended) 1. Using an HDMI cable, connect the HDMI OUT terminal on the rear of the player to the HDMI IN terminal of your TV. 2. Turn on the player and TV. 3. Press the input selector on your TV remote control until the HDMI signal from the player appears on your TV screen.
04 Case 2 : Connecting to a TV with DVI Cable - Best Quality (Recommended) 2. Using the audio cables, connect the AUDIO OUT (red and white) terminals on the rear of the player to the AUDIO IN (red and white) terminals of your TV. 3. Turn on the player and TV. 4. Press the input selector on your TV remote control until the HDMI-DVI signal from the player appears on your TV screen.
Connections Case 3 : Connecting to a TV (Component) - Better Quality - Connecting to your TV using Component video cables. - You will enjoy high quality images with accurate color reproduction. Component video separates the picture element into black and white(Y), blue(PB) and red(PR) signals to present clear and clean images. (Audio signals are delivered through the audio output.) 1.
04 Case 4 : Connecting to a TV (Video) - Good Quality 2. Turn on the player and TV. 3. Press the input selector on your TV remote control until the “VIDEO” signal from the player appears on the TV screen. • If you have set the remote control to operate your TV (See page 19), press the TV SOURCE button on the remote control and select VIDEO as the external source of the TV. Audio/Video cable Red White Yellow ✎ NOTE ▪ Noise may be generated if the audio cable is placed too close to the power cable.
Connections Connecting to an Audio System • Please turn the volume down when you turn on the Amplifier. Sudden loud sound may cause damage to the speakers and your ears. • Please set the audio in the menu screen according to the Amplifier. (See pages 32~34) • The position of HDMI terminals may vary depending on the Amplifier. Please refer to the user manual of your Amplifier. Case 1 : Connecting to an Audio System (HDMI Supported Amplifier) - Best Quality (Recommended) 1.
2. Using the video signal cable(s), connect the HDMI, COMPONENT or VIDEO OUT terminals on the rear of the player to the HDMI, COMPONENT or VIDEO IN terminal of your TV. (See pages 20~23) 2. Using the video signal cable(s), connect the HDMI, COMPONENT or VIDEO OUT terminals on the rear of the player to the HDMI, COMPONENT or VIDEO IN terminal of your TV. (See pages 20~23) 1.
Connections Connecting to the Network This player enables you to view network based services (See pages 52~57) such as Internet@TV and BD-LIVE, as well as receive software upgrades when a network connection is made. We recommend using an AP (Access Point) or IP router for the connection. For more information on router connection, refer to the user manual of the router or contact the router manufacturer for technical assistance. Cable Network 1.
04 Wireless Network 1. A wireless AP/IP router is required to make a wireless network connection. Connect the wireless LAN adapter to the Wireless LAN Adapter on the rear panel of the player. 2. Set the network options. (See pages 36~39) Broadband service Wireless IP sharer Wireless LAN Adapter (not included) Networking with PC for AllShare function (See pages 56~57) ✎ NOTE ▪ Use only the Samsung wireless LAN adapter with this player. (Model name: WIS09ABGN).
Setup Before Starting (Initial Settings) 1. Turn on your TV after connecting the player. (When the player is connected to TV for the first time, player will turn on automatically and the Initial Settings screen will be displayed.) Initial Settings I On-Screen Language Select a language for the on-screen displays. English 5. Press the ◄► buttons to the select the desired Network Settings: Wired, Wireless or PBC (WPS), then press the ENTER button.
TV POWER BONUSVIEW SOURCE DISC MENU MENU RETURN EXIT 4 MENU Button : Press this to move to the home menu. 79 2 RETURN Button : Return to the previous menu. MUTE VOL 3 4 2. Press the ◄► buttons to select Settings, then press the ENTER button. ✎ NOTE ▪ When the player is connected to the network, select INTERNET@ FULL SCREEN REPEAT 1 Displays buttons available. 5. Press the EXIT button to exit the menu. INFO 3 2 6 4.
Setup Display You can configure various display options such as the TV Aspect, Resolution, etc. TV Aspect Depending on the type of television you have, you may want to adjust the screen setting. • 16:9 Normal • 16:9 Wide Certain movies(4:3 source) will be displayed in 4:3 Pillarbox (black bars on sides of picture) if 16:9 normal is selected. You can view the full 16:9 picture on your widescreen TV. ▪ BD Wise (Samsung Players only) BD Wise is Samsung’s latest inter-connectivity feature.
Output Setup HDMI / connected Setup • Blu-ray Disc playback 05 Resolution according to the output mode HDMI / not connected HDMI Mode Component/VIDEO Mode Component Mode VIDEO Mode 1080p@60F 480i - - Auto Optimal Resolution 1080p/1080i, Movie Frame(24Fs) on 1080p@24F 480i - - 1080i, Movie Frame(24Fs) off 1080i 480i 1080i 480i 480p 480p 480i 480p 480i 1080p, Movie Frame(24Fs) off 720p 480i 720p Output HDMI / connected Component/VIDEO Mode 1080p@60F 480i 1080i 1080i 7
Setup HDMI Format You can optimize the color setting from the HDMI output. Select a connected device Type. • TV : Select if connected to a TV via HDMI. • Monitor : Select if connected to a Monitor via HDMI. Movie Frame (24Fs) Setting the Movie Frame (24Fs) feature to On allows you to adjust the player’s HDMI output to 24 frames per second for improved picture quality. You can enjoy the Movie Frame (24Fs) feature only on a TV supporting this frame rate.
Connection PCM Dolby Digital Dolby Digital Audio Stream Plus on Blu-ray Dolby TrueHD Disc DTS DTS-HD HRA DTS-HD MA PCM Audio Stream Dolby Digital on DVD DTS Definition for Blu-ray Disc Bitstream (Re-encode) PCM Any HDMI Receiver Up to 7.1ch Up to 5.1ch Bitstream (Audiophile) Optical HDMI Receiver or Optical HDMI Receiver PCM 2ch DTS re-encoded Dolby Digital PCM 2ch DTS re-encoded PCM Dolby Digital Plus Setup Setup 05 Digital Output Selection Optical PCM 2ch Dolby Digital Up to 7.
Setup HDMI • If your TV is not compatible with compressed multi-channel formats (Dolby Digital, DTS), the player may output PCM 2ch downmixed audio even though you set Bitstream(either Re-encode or Audiophile) on your setup menu. • If your TV is not compatible with PCM sampling rates over 48kHz, the player may output 48kHz downsampled PCM audio even though you set PCM Downsampling to Off. Dynamic Range Control You can listen at low volumes but still hear dialog clearly.
▪ If your Samsung TV has an n logo, then it supports the Anynet+ function. Depending on your TV, certain HDMI output resolutions may not work. Please refer to the user manual of your TV. BD Data Management Enables you to manage the downloaded contents from a Blu-ray disc that supports the BD-LIVE service. You can check the device information including the storage size, delete the BD data or change the Flash memory device.
Setup DivX(R) Deactivation Select this to get a new registration code. Settings Display Audio System Network Language Security General Support ✎ Initial Settings Audio : Subtitle : Do you want to deactivate your device? Yes No NOTE ▪ This function can be operated when DivX(R) Registration function is deactivated. Network To begin setting up the network connection for your player, follow these steps: 1. In the Home menu, press the ◄► buttons to select the Settings, and then press the ENTER button.
1. Right click the Network icon on the bottom right of the screen. 2. In the pop-up menu, click Status. 3. On the dialog that appears, click the Support tab. 4. On the Support tab, click the Details button. The Network settings are displayed. To enter the Network settings into your player, follow these steps: 1. On the Internet Protocol Setup screen, press the ENTER button. 2. Press the ▲▼ buttons to select Manual, and then press the ENTER button. 3.
Setup Setting Up the Wireless Network Connection - Auto Network Search Most wireless networks have an optional security system that requires devices that access the network to transmit an encrypted security code called an Access or Security Key. The Security Key is based on a Pass Phrase, typically a word or a series of letters and numbers of a specified length you were asked to enter when you set up security for your wireless network.
12. To test the connection, press the ▼ button to select Network Test, and then press the ENTER button. Setting Up the Wireless Network Connection - Manual If the Auto Setting does not work, you need to enter the Network settng values manually. To get the Network setting values from most Windows computers, follow these steps: 1. Right click the Network icon on the bottom right of the screen. 2. In the pop-up menu, click Status. 3. On the dialog that appears, click the Support tab. 4.
Setup BD-LIVE Internet Connection Set to allow internet connection when BD-LIVE service is used. • Allow (All) : The Internet connection will be allowed for all BD-LIVE contents. • Allow (Valid Only) : The Internet connection will be allowed only for BD-LIVE contents containing a valid certificate. • Prohibit : No Internet connection will be allowed for any BD-LIVE content.
Support Change the background theme of the menu screen. Settings Display Audio System Network Language Security General Support Background Skin 1 Skin 2 Skin 3 Skin 4 Skin 5 > Move " Select Software Upgrade This menu allows you to upgrade software for performance improvements or additional services. You can check the current software version, upgrade using the internet and set the Auto upgrade notification.
Setup You can also update software in any of the two ways as follows: Software update is the same as in the By Internet menu. • USB : Visit www.samsung.com/bluraysupport, then download and store the latest software (RUF file) into a USB flash drive. Connect the USB flash drive to the USB port of the player (disc tray must be empty) to update the software, then follow the on-screen instructions. • CD/DVD : Visit www.samsung.com/ bluraysupport, download and write the latest software (RUF file) onto a disc.
Basic Functions 1. Press the OPEN/CLOSE ( open the disc tray. ) button to 3. Press the OPEN/CLOSE ( close the disc tray. ) button to 2. Place a disc gently into the tray with the disc’s label facing up. 4. Press the PLAY ( ) button. Playback related buttons PLAY ( ) STOP ( ) PAUSE ( Stops playback. • If pressing the button once : The stop position will be memorized. • If pressing the button twice : The stop position will be not memorized. Pauses playback.
Basic Functions Using the Popup Menu h 1. During playback, press the POPUP MENU button on the remote control. 2. Press the ▲▼◄► buttons or ENTER button to select the desired menu. ✎ NOTE ▪ Depending on the disc, the menu items may differ and this menu may not be available. Using the Search and Skip Functions During play, you can search quickly through a chapter or track, and use the skip function to jump to the next selection.
hzZy Repeat the disc title or chapter. Depending on the disc, the Repeat function may not be available. 1. During playback, press the REPEAT button on the remote control. 2. Press the ▲▼ buttons to select Chapter or Title, then press the ENTER button. Repeat > Chapter 5. To return to normal play, press the REPEAT button again. 6. Press the ENTER button. ✎ NOTE ▪ If you set point (B) before 5 seconds has lapsed, the prohibition message will appear.
Basic Functions Selecting the Audio Language hzZx You can also operate this function by pressing the AUDIO button on the remote control. 1. During playback, press the TOOLS button. ✎ NOTE ▪ Depending on the Blu-ray Disc / DVD, you may be ▪ ▪ 2. Press the ▲▼ buttons to select Audio. ▪ ✎ NOTE ▪ The ◄► indicator will not be displayed on the ▪ 3. Press the ◄► buttons to select the desired audio language. ▪ ▪ ▪ ▪ ▪ screen if the BONUSVIEW section does not contain any BONUSVIEW audio settings.
• Movie : This is the best setting for watching movies. • User : The user can adjust the sharpness and noise reduction function respectively. Setting BONUSVIEW ow Buttons on the Remote Control used for Music Playback h You can also operate this function by pressing the BONUSVIEW button on the remote control. ! 9 3. Press the ◄► buttons to select the desired bonusview. ✎ NOTE ▪ If you switch from BONUSVIEW Video, BONUSVIEW Audio will change automatically in accordance with BONUSVIEW Video.
Basic Functions SKIP button : During playback, moves to the previous page in the Music List or moves to the previous track in the Playlist. If you press this button after three seconds of playback in the Playlist, the current track will be replayed from the beginning. But, if you press this button within three seconds after playback starts in the Playlist, the previous track will be played. ! NUMBER buttons : During the Playlist playback, press the desired track number. The selected track will be played.
Playing a JPEG Disc 1. Insert a JPEG disc into the disc tray. 3 files selected 1/2 Page TRACK 003 TRACK 001 TRACK 002 TRACK 003 TRACK 004 2. Press the ◄► buttons to select the Photos, and then press the ENTER button. 00:04:27 00:05:57 00:03:41 00:04:07 3. Press the ▲▼◄► buttons to select the folder you want to play, and then press the ENTER button.
Basic Functions • Zoom : Select this if you want to enlarge the current picture. (Enlarged up to 4 times) • Rotate : Select this if you to rotate the picture. (This will rotate the picture either clockwise or counter clockwise.) • Information : Shows the picture information including the name and size, etc. 5. Press the ▲▼ buttons to select the USB, then press the ENTER button. 6. Press the ◄► buttons to select the desired Videos, Music or Photos, then press the ENTER button. 4-1.
• • • • • • Supported devices: USB storage media, MP3 player, digital camera, USB card reader Does not support if a folder or file name is longer than 128 characters. A certain USB/digital camera device may not be compatible with the product. FAT16, FAT32 and NTFS file systems are supported. Connect directly to the product's USB port. Connecting through another cable may raise problems with USB compatibility. Inserting more than one memory device to a multi-card reader may not operate properly.
Network Services You can enjoy various network services such as Internet@TV or BD-LIVE by connecting the player to the network system. Check the following instructions before using any network service. 1. Connect the player to the network. (See pages 26~27) 2. Configure the network settings. (See pages 36~39) 4. When you have agreed on the service agreement, the Internet@TV service will start being updated. It takes several minutes. When the update is completed, you will see the Internet@TV menu screen.
1 4 7 2 5 ghi Input Mode 9 tuv 0 a 6 jkl 8 pqrs 3 abc A 1 def 13. Press the ENTER button. 14. The map and address appear on the screen. ✎ NOTE ▪ Samsung Electronics shall take no legal responsibility ▪ mno wxyz Delete For example, here is how to search an address in Google Maps: ▪ 1. Press the ENTER button on the remote at the Google Maps icon at the Internet@TV. ▪ 3. Press the ◄► buttons to move to the “Search or address” window. ▪ 5.
Network Services Account Login For a more enjoyable application experience, register and log in to your account. To do this, you must create an account first. (For instructions on creating an account, refer to Internet@TV ID on this page) 1. Press the ▲▼◄► buttons to select the desired application and press the RED(A) button.
Lock Lock the application. Accessing a locked application requires the password. Delete Internet@TV Services Available Delete the application. Properties Display information about Internet@TV. Use the “Check the speed of your internet connection” option to test your network connection. Samsung Apps Various applications are available from here, organized into different categories. Some applications have a download fee.
Network Services Using the AllShare Function BD-LIVE™ Once the player is connected to the network, you can enjoy various movie-related service contents using a BD-LIVE compliant disc. 1. Check the size of the remaining memory. The memory device must have at least 1GB of free space to accommodate the BD-LIVE services. 2. Insert a Blu-ray disc that supports BD-LIVE. 3. Select an item from various BD-LIVE service contents provided by the disc manufacturer.
4. Select a folder to share from the My computer pane, and click the Share Folder Enabled icon ( ). (To remove a shared folder : Select a folder to remove from the shared folders, and click the Share Folder Disabled icon ( ).) 5. To apply the updated sharing state to the server, click the Set Change State icon ( 6. To enable the player to locate a PC server, click Share from the menu bar. Click Set Device Policy and click Accept. ).
Appendix Troubleshooting Before requesting service, please check the following. PROBLEM SOLUTION No operation can be performed with the remote control. • Check the batteries in the remote control. They may need replacing. • Operate the remote control at a distance of no more than 20 feet. • Remove batteries and hold down one or more buttons for several minutes to drain the microprocessor inside the remote control to reset it. Reinstall batteries and try to operate the remote control again.
SOLUTION 08 • Press the STOP ( ) button (on front panel) for more than 5 seconds with no disc inside. All settings including the password will revert to the factory settings. Don’t use this unless absolutely necessary. • When the factory default settings are restored, all the user data stored in the BD data will be deleted. If you experience other problems.
Appendix PROBLEM BD-LIVE SOLUTION I cannot connect to the BD-LIVE server. • Check whether the network connection is successful or not by using Network Test menu. (See page 39) • Check whether the USB memory device is connected with player or not. • The memory device must have at least 1GB of free space to accommodate the BD-LIVE service. You can check the available size in BD Data Management. (See page 35) • Please check whether the BD-LIVE Internet Connection menu is set to Allow(All).
B BD Wise BD Data Management BD-LIVE BONUSVIEW Background Music C Component Cable Network Camera Angle 14 27 34 46 56~57 30 35 39, 56 47 49 22 26 46 D Digital Output 32~33 Dynamic Range Control 34 Downmixing Mode 34 DTS Neo:6 34 DST (Daylight Saving Time) 35 DivX 35~36 Disc Menu 43 Disc Structure 43 H HDMI 20, 34 HDMI Supported Amplifier 24 HDMI Deep Color 32 I Internet@TV Initial Settings JPEG M Movie Frame (24F) MP3 N Network Setup O Optimal Resolution P PCM Downsampling Popup Menu Pi
Appendix Specifications Power Requirements AC 120V, 60Hz Weight 3.8 Ibs Power Consumption General Dimensions Operating Temperature Range Operating Humidity Range BD (Blu-ray Disc) DVD (Digital Versatile Disc) Disc CD : 5 inches (COMPACT DISC) CD : 3 1/2 inches (COMPACT DISC) Composite Video Video Output Video/Audio Component Video HDMI 2 Channel Digital Audio Output Audio Output *Frequency Response *S/N Ratio *Dynamic Range *Total Harmonic Distortion 14W 17.1 (W) X 8.1 (D) X 1.
08 Compliance and Compatibility Notice Copy Protection • Because AACS (Advanced Access Content System) is approved as content protection system for Blu-ray Disc format, similar to use of CSS (Content Scramble System) for DVD format, certain restrictions are imposed on playback, analog signal output, etc., of AACS protected contents.
Appendix • Many Blu-ray Disc/DVD discs are encoded with copy protection. Because of this, you should only connect your Player directly to your TV, not to a VCR. Connecting to a VCR results in a distorted picture from copy-protected Blu-ray Disc/DVD discs. • This item incorporates copy protection technology that is protected by U.S. patents and other intellectual property rights of Rovi Corporation. Reverse engineering and disassembly are prohibited. • Under the U.S.
08 License Appendix • Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol are trademarks of Dolby Laboratories. • Manufactured under license under U.S. Patent #’s : 5,451,942; 5,956,674; 5,974,380; 5,978,762; 6,226,616; 6,487,535; 7,212,872; 7,333,929; 7,392,195; 7,272,567 & other U.S. and worldwide patents issued & pending. DTS and the Symbol are registered trademarks, & DTS-HD, DTS-HD Master Audio, and the DTS logos are trademarks of DTS, Inc. Product includes software.
LIMITED WARRANTY TO ORIGINAL PURCHASER This SAMSUNG brand product, as supplied and distributed by SAMSUNG ELECTRONICS AMERICA, INC.
Contact SAMSUNG WORLD WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. Area ` North America Contact Center Web Site Canada Mexico U.S.A 1-800-SAMSUNG (726-7864) 01-800-SAMSUNG (726-7864) 1-800-SAMSUNG (726-7864) www.samsung.com www.samsung.com www.samsung.
QUESTIONS OR COMMENTS? COUNTRY CALL OR VISIT US ONLINE AT IN THE US 1-800-SAMSUNG (7267864) www.samsung.com WRITE Samsung Electronics America, Inc. 85 Challenger Road Ridgefield Park, NJ 07660-2112 AK68-01854A-00 Downloaded From Disc-Player.
