DIGITAL HOME CINEMA SYSTEM HT-WP30 THIS APPLIANCE IS MANUFACTURED BY: Instruction Manual COMPACT DIGITAL AUDIO AH68-01717B COMPACT DIGITAL VIDEO
Safety Warnings CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE REAR COVER. NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. CLASS 1 LASER PRODUCT This Compact Disc player is classified as a CLASS 1 LASER product. GB Use of controls, adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure.
Features Contents GB PREPARATION Multi-Disc Playback & FM Tuner DVD-Audio compatible Experience the super high-quality audio performance of DVD-Audio. The on-board 24-bit/192kHz DAC enables this player to deliver exceptional sound quality in terms of dynamic range, low-level resolution and high-frequency detail. USB HOST Function support You can connect and play files from external USB storage devices such as MP3 players, USB flash memory, etc. using the Home Theater's USB HOST function.
Notes on Discs GB Disc Recording Format PREPARATION DVD (Digital Versatile Disc) offers fantastic audio and video, thanks to Dolby Digital surround sound and MPEG-2 video compression technology. Now you can enjoy these realistic effects in the home, as if you were in a movie theater or concert hall. CD-R Discs • Some CD-R discs may not be playable depending on the disc recording device (CD-Recorder or PC) and the 1 ~ 6 DVD players and the discs are coded by region.
Description GB —Rear Panel— External Digital Optical Input Connector Use this to connect external equipment capable of digital output. Stop ( Power ( ) button Function button Open/Close button ) button Play/Pause ( ) button USB Connector Video Output Connector Connect the TV's video input jacks (VIDEO IN) to the VIDEO OUT connector. COMPONENT VIDEO OUTPUT jacks Connect a TV with component video inputs to these jacks.
Description GB PREPARATION —Remote Control— Insert Remote Batteries TV indicator TV, DVD POWER button MODE button SLEEP button DVD RECEIVER indicator OPEN/CLOSE button TV/VIDEO, DIMMER button DVD button RDS Selection button AUX button TUNER button 1 Remove the battery cover on the back of the remote by pressing down and sliding the cover in the direction of the arrow. 2 Insert two 1.5V AAA batteries, paying attention to the correct polarities (+ and –). 3 Replace the battery cover.
Connecting the Speakers GB Before moving or installing the product, be sure to turn off the power and disconnect the power cord. Center Speaker C Front Speaker (L) Front Speaker (R) SW L Green R Red White CONNECTIONS LS RS Purple Wireless receiver module Gray Position of the DVD Player • Place it on a stand or cabinet shelf, or under the TV stand. Front Speakers L R • Place these speakers in front of your listening position, facing inwards (about 45°) toward you.
GB Connecting Wireless Rear Speakers 1 2 Connect your pair of wireless rear speakers, (L) and (R), to the wireless receiver module. Connect the power cord of the wireless receiver module to the wall outlet and turn the power "ON". Resetting Wireless Communication Reset the system if a communication failure occurs, or if the synchronizing signal indicator does not light up and the "REAR CHK" message blinks on the main unit's display.
Connecting the Video Out to TV P.SCAN(Progressive Scan) Function Choose one of the three methods for connecting to a TV. GB Unlike regular Interlace Scan, in which two fields of picture information alternate to create the entire picture (odd scan lines, then even scan lines), Progressive Scan uses one field of information (all lines displayed in one pass) to create a clear and detailed picture without visible scan lines. 1 Press STOP button.
Connecting External Components Connecting the FM and AM Antennas GB If AM reception is poor, connect an outdoor AM antenna(not supplied). Connecting an External Digital / Analog Component Example: Digital signal components such as a Set-Top Box or CD Recorder. Analog signal components such as a VCR or TV. Audio Cable (not supplied) If the external analog component has only one Audio Out, connect either left or right.
Before Using Your Home Theater GB Disc terminology Your Home Theater is capable of playing DVD, CD, MP3, DivX and JPEG discs.Depending on the disc you are using, these instructions may vary slightly. Read the instructions carefully before using. Groups and tracks (DVD-AUDIO) • DVD-audio is divided into several large sections called "groups" and smaller sections called "tracks". Numbers are allotted to these sections. These numbers are called "group numbers" and "track numbers".
Disc Playback MP3-CD Playback GB Data CDs (CD-ROM, CD-R, CD-RW) encoded in MP3 format can be played. 1 Press OPEN/ CLOSE button to open the disc tray. MP3 2 Load a disc. 3 • Place a disc gently into the tray with the disc’s label facing up. Press OPEN/ CLOSE button to close the disc tray. DVD VCD 1 CD • Playback starts automatically. Press the OPEN/CLOSE button to open the disc tray, and then load the MP3 disc. 2 In Stop mode, use to select the album, and then press the ENTER button.
JPEG File Playback GB JPEG Images captured with a digital camera or camcorder, or JPEG files on a PC can be stored on a CD and then played back with this DVD player. Slide Mode Digest Function You can view 9 JPEG images on the TV screen. 1 1 Place the JPEG disc on the disc tray. Press DIGEST button during playback. 2 • JPEG files will be shown in • The selected image is played for 5 seconds before moving 9 windows. 2 to the next image. Press the OPEN/CLOSE button.
DivX Playback Press the SUBTITLE button. Skip Forward/Back During playback, press the button. • Go to the next file whenever you press • GB Subtitle Display button, if there are over 2 files in the disk. Go to the previous file whenever you press 2 files in the disk. • Each time you press the button, your selection will toggle between “SUBTITLE ON” (1/1, 1/2 ...) and “SUBTITLE OFF”. • If the disc has only one subtitle file, it will be played automatically.
Playing Media Files using the USB HOST feature GB Skip Forward/Back You can connect and play files from external USB storage devices such as MP3 players, USB flash memory, etc. using the Home Theater's USB HOST function. During playback, press the 1 Open the USB cap and connect the USB cable. 2 Press the FUNCTION button on the main unit or the AUX button on the remote control to select the USB mode. button, the next file is selected. button, the previous file is selected.
Displaying Disc Information Fast/Slow Playback GB You can view disc playback information on the TV screen. Fast Playback Press INFO button. • Each time the button is pressed, the display changes as follows: DVD VCD DVD CD MP3 DivX JPEG VCD CD Slow Playback MP3 Press and hold Press SLOW button. .
Repeat Playback A-B Repeat Playback Repeat playback allows you to repeatedly play a chapter, title, track (song), or directory (MP3 file). DVD VCD CD MP3 GB You can repetitively play back a designated section of a DVD. JPEG DVD Press REPEAT button. • Each time the button is pressed during playback, the repeat playback mode changes as follows: DVDVIDEO DVDAUDIO Repeat Playback Options CHAPTER Repeatedly plays the selected chapter. 1 VCD CD Press INFO button twice.
Step Function DVD Zoom (Screen Enlarge) Function VCD This function allows you to enlarge a particular area of the displayed image. DVD GB VCD Press STEP button. • The picture moves forward one frame each time the button is pressed during playback. Note • During fast playback of a CD or MP3-CD, sound is heard only at 2x speed, and not at 4x, 8x, and 32x speeds. 1 Press ZOOM button. 2 • No sound is heard during slow playback and step motion playback.
Bonus Group / Navigating Pages Bonus Group Selecting Audio/Subtitle Language Audio Language Selection Function DVDAUDIO Some DVD-Audio discs have an extra ‘bonus’ group that requires a 4-digit key number to access. See the disc packaging for details and the-key number. 1 Press INFO button twice. When you play a DVD-Audio disc that has a bonus group, the key number input screen appears automatically. 2 GB DVD Press Cursor , buttons or numeric buttons to select the desired audio language.
Moving Directly to a Scene/Song Using Disc Menu GB DVD You can use the menus for the audio language, subtitle language, profile, etc. DVD menu contents differ from disc to disc. DVD 1 VCD CD Moving to a Title/Track Press INFO button. 01/05 001/040 0:00:37 1/1 Press Cursor , buttons or numeric buttons to select the desired chapter and then press ENTER button. 01/05 025/040 0:00:01 03/05 001/002 0:00:01 1/1 Press Cursor , buttons to move to time display.
Setting the Language GB OSD (On-Screen Display) language is set to English by default. 1 In Stop mode, press MENU button. 2 Press Cursor button to move to ‘Setup’ and then press ENTER button. 3 Select ‘Language’ and then press ENTER button 4 Press Cursor , button to select ‘OSD Language’ and then press ENTER button. 5 Press Cursor , button to select the desired language and then press ENTER button.
Setting TV Screen type GB Depending on your TV type (Wide Screen or conventional 4:3), you can select the TV's aspect ratio. 1 In Stop mode, press MENU button. 2 Press Cursor button to move to ‘Setup’ and then press ENTER button. Adjusting the TV Aspect Ratio (Screen Size) The horizontal to vertical screen size ratio of conventional TVs is 4:3, while that of widescreen and high definition TVs is 16:9. This ratio is called the aspect ratio.
Setting Parental Controls (Rating Level) Use this to restrict playback of adult or violent DVDs you do not want children to view. 1 3 4 Press Cursor , button to select the desired rating level and then press ENTER button. • If you have selected Level 6, you • cannot view DVDs with Level 7 or higher. The higher the level, the closer the content is to violent or adult material. 2 5 You can set the password for the Parental (rating level) setting.
Setting the Wallpaper JPEG DVD GB VCD While watching a DVD, VCD or JPEG CD, you can set the image you like as background wallpaper. Setting the Wallpaper 1 During playback, press PLAY/PAUSE button when an image you like appears. To select one of the 3 wallpaper settings you've made Press LOGO button. 2 1 In Stop mode, press MENU button. 4 Press to select the desired ‘USER’, and then press ENTER. 2 Press Cursor button to move to ‘Setup’ and then press ENTER button.
DVD Audio Disc Playback Mode Some DVD-Audio discs contain DVD-Video as well as DVD-Audio. To play back the DVD-Video portion of the DVD-Audio disc, set the unit to DVD-Video mode. 1 3 Press the MENU button while the disc tray is open. Press Cursor button to move to ‘DVD TYPE’ and then press ENTER button. 2 Press Cursor button to move to ‘Setup’ and then press ENTER button. 4 Press Cursor , button to move to ‘DVD VIDEO’ and then press ENTER button.
Setting the Delay Time GB If the speakers cannot be placed at equal distances from the listening position, you can adjust the delay time of the audio signals from the center and rear speakers. 1 In Stop mode, press MENU button. 2 Press Cursor button to move to ‘Audio’ and then press ENTER button. 3 Press Cursor button to move to ‘DELAY TIME’ and then press ENTER button. 4 Press Cursor , , , buttons to move to the desired speaker and then press ENTER button.
Setting the Test Tone Setting the DRC (Dynamic Range Compression) Use the Test Tone feature to check the speaker connections. 1 In Stop or no disc mode, press MENU button. 2 GB You can use this function to enjoy Dolby Digital sound when watching movies at low volume at night. Press Cursor button to move to ‘Audio’ and then press ENTER button. 3 Press Cursor button to move to ‘TEST TONE’ and then press ENTER button. 1 In Stop mode, press MENU button.
Setting the Audio Quality GB You can adjust the balance and level for each speaker. Method 1 1 When adjusting the audio quality using the setup screen In Stop mode, press MENU button. 2 Press Cursor button to move to ‘Audio’ and then press ENTER button. When manually adjusting with the SOUND EDIT button Method 2 Adjusting Front Speaker Balance 1 TITLE Press SOUND EDIT button and then press Cursor , .
AV SYNC Setup Sound Field (DSP)/EQ Function Video may look slower than the audio if it is connected to a digital TV. If this occurs, adjust the audio delay time to to match the video. 1 Press the MENU button. • Setup menu appears. 3 • AV-SYNC screen appears. 2 • 'Audio' menu appears. 4 DSP(Digital Signal Processor) DSP modes have been designed to simulate different acoustic environments.
Dolby Pro Logic II Mode You can select the desired Dolby Pro Logic II audio mode. Press • PL II MODE button. Each time the button is pressed, the mode changes as follows. Dolby Pro Logic II Effect GB This function works only in Dolby Pro Logic MUSIC mode. 1 Press PL II MODE button to select ‘MUSIC’ mode. 2 Press PL II EFFECT button to select Panorama, then press Cursor , buttons to select the desired effect setting. • You can select either 0 or 1.
Listening to Radio You can listen to the chosen band (FM, AM broadcast stations) by using either the automatic or manual tuning operation. Remote Control Unit 1 Press TUNER button. • The selection toggles back and forth between "FM ➝ AM" each time the TUNER button is pressed. 2 Tune in to the desired station. Automatic Tuning 1 Automatic Tuning 2 When is pressed, a preset broadcast station is selected. Press and hold TUNING/CH to automatically search for active broadcasting stations.
About RDS broadcasting GB PTY (Program Type) indication and PTY-SEARCH function Using the RDS (Radio Data System) to receive FM stations RDS allows FM stations to send an additional signal along with their regular program signals. For example,the stations send their station names,as well as information about what type of program they broadcast, such as sports or music,etc. When tuned to an FM station which provides the RDS service,the RDS indicator lights up on the display.
Convenient Functions GB Sleep Timer Function You can set the time that the DVD player will shut itself off. Mute Function This is useful when answering a doorbell or telephone call. Press SLEEP button. Press MUTE button. • "SLEEP" will be displayed. Each time the button is pressed the preset time changes as follows: 10 ➝ 20 ➝ 30 ➝ 60 ➝ 90 ➝ 120 ➝ 150 ➝ OFF. TITLE CHAP PRGM RDS RT ST TUNED kHz MHz • ‘MUTE’ flash in the display.
Operating a TV with the Remote Control GB When operating a TV with the remote control 1 2 3 4 Press the MODE button to make the TV indicator on the remote control flash. TV No. Brand Code No.
Before Calling for Service GB Refer to the chart below when this unit does not function properly. If the problem you are experiencing is not listed below or if the instruction below does not help, turn off the unit, disconnect the power cord, and contact the nearest authorized dealer or Samsung Electronics Service Center. Symptom Disc tray does not open. Playback does not start. Check/Remedy • Is the power cord plugged securely into the outlet? • Turn off the power and then turn it back on.
Cautions on Handling and Storing Discs Small scratches on the disc may reduce sound and picture quality or cause skipping. Be especially careful not to scratch discs when handling them. Handling discs Do not touch the playback side of the disc. Hold the disc by the edges so that fingerprints will not get on the surface. Do not stick paper or tape on the disc. Disc Storage Keep in a cool ventilated area Do not keep in direct sunlight Caution Keep in a clean Protection jacket. Store vertically.
Specifications G E N E R A L Power Consumption Weight Dimensions (W x H x D) Operating Temperature Range Operating Humidity Range Power Consumption WIRELESS REAR Weight RECEIVER Dimensions (W x H x D) T Usable Sensitivity F U N S/N Ratio M E R Distortion T Usable Sensitivity A U N S/N Ratio M E R Distortion Composite Video V I D E O O U T P U T A M P L I F I E R Scart Jack Component Video Front speaker output Center speaker output Rear speaker output Subwoofer speaker output Frequency range S/N Ratio C
