HW-D570 Crystal Surround Air Track (Active Speaker System) user manual imagine the possibilities Thank you for purchasing this Samsung product. To receive more complete service, please register your product at www.samsung.
features Active Speaker System This unit features an Active Speaker System that provides high sound quality in a single slim unit. This unit does not require any satellite loudspeakers or speaker cabling, which are normally associated with conventional surround sound systems. Multi-function Remote Control The supplied remote control can be used to control the TV connected to this unit. The remote control has a TV hotkey that enables you to perform various operations with the simple press of a button.
EnG WHAT’s inclUDED Check for the supplied accessories below. POWER TV POWER TV INFO VOL SOUND MODE INPUT SELECT S.
safety information Safety Warnings TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER(OR BACK). NO USER-SERVICEABLE PARTS ARE INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN This symbol indicates “dangerous voltage” inside the product that presents a risk of electric shock or personal injury. This symbol indicates important instructions accompanying the product.
EnG PREcAUTiOnS 2.7 inch 3.9 inch 3.9 inch 3.9 inch Ensure that the AC power supply in your house complies with the identification sticker located on the back of your product. Install your product horizontally, on a suitable base (furniture), with enough space around it for ventilation (3~4 inches). Make sure the ventilation slots are not covered. Do not place the unit on amplifiers or other equipment which may become hot. This unit is designed for continuous use.
contents features 2 3 Features What’s included safety information 4 5 Safety warnings Precautions getting started 7 Before reading the user’s manual descriptions 8 9 Front panel Rear panel remote control 10 Tour of the remote control connections 11 12 13 16 Installing the wall mount Connecting the wireless subwoofer Attaching the toroidal ferrite core to the power cord of the subwoofer Installing toroidal ferrite to subwoofer Use iPod/iPhone with a wireless dock cradle for iPod/iPhone How
EnG getting started Before Reading the User’s Manual Make sure to check the following terms before reading the user manual. Icons that will be used in manual Term Caution Note ● Getting Started Icon Definition This involves a case where a function does not operate or settings may be canceled. This involves tips or instructions on the page that help each function operate. About the use of this user’s manual 1) Be sure to be familiar with Safety Instructions before using this product.
descriptions Front Panel 1 2 3 4 5 DISPLAY Displays the current mode. INPUT MODE Selects the HDMI, Optical, Audio or W.iPod input. SOUND MODE Selects the sound mode. (MUSIC, NEWS, DRAMA, CINEMA, SPORTS, GAME, PASS (Original Sound)) VOLUME +/- Controls the volume level. POWER BUTTON Turns the Crystal Surround Air Track on and off. ▪ When you turn on the power of this unit, there will be a 4 to 5 second delay before it reproduces sound.
ONLY FOR UPDATE EnG Rear Panel 1 ONLY FOR UPDATE ● Description ONLY FOR UPDATE 6 2 AUDIO IN HDMI OUT (ARC) DIGITA L AUDIO IN 4 2 3 OPTICA L HDMI IN 2 DIGITA L AUDIO IN 1 (TV) 5 HDMI IN 1 USB PORT (FOR S/W UPDATES ONLY) You can update this unit's software through the USB port. AUDIO IN JACK Connect to the analog output of an external device. DIGITAL AUDIO IN 1,2 Connect to the digital (optical) output of an external device.
remote control Tour of the Remote Control POWER BUTTON Turns the Crystal Surround Air Track on and off. POWER TV INFO Use this to display the TV channel information. VOLUME Adjusts the volume level of the unit. MUTE Mutes the sound from the unit. Press again to restore the sound to the previous volume level. 3D SOUND This feature adds depth and spaciousness to the sound. SMART VOLUME Regulates and stabilizes the volume level against a drastic volume change.
EnG connections INSTAllING THE WAll MOUNT You can use the wall mount bracket to mount this unit on a wall. Installation Precautions ● connections • Do not install on a place other than a vertical wall. • For the installation, avoid a location with high temperature or humidity, or wall that cannot sustain the weight of the set. • Check the strength of the wall. If the strength of the wall is insufficient for the product installation, make sure to reinforce the wall before the installation.
CONNECTING THE WIrElESS SUBWOOFEr The Subwoofer's linking ID is preset at the factory and the main unit and sub should link (connect wirelessly) automatically when main unit is turned on. If the link indicator does not light when main unit and subwoofer are turned on, please set the ID by following the process below. 1. Plug the power cords of the main unit and subwoofer into an AC power supply. 2. Press the ID SET button on the back of the subwoofer with a small, pointed object for 5 seconds.
EnG attacHinG tHE toroidaL fErritE corE to tHE poWEr cord of tHE SuBWoofEr If you attach a Toroidal ferrite core to the power cord of the Subwoofer, it will help to prevent RF interference from radio signals. 1. Pull the fixing tab of the Toroidal ferrite core to open it. 2. Make three loops in the power cable of the subwoofer. ● connEctionS 3. Attach the Toroidal ferrite core to the Subwoofer power cord as the figure shows and press it until it clicks.
USE iPod/iPhone WiTH A WiRElESS DOcK cRADlE FOR iPod/iPhone You can enjoy finer quality of music through the speaker by sending iPod/iPhone’s audio signal using a Wireless Transmitter. To link the main unit with wireless transmitter, you have to make ID setting when both main unit and wireless transmitter are standby. Turn on the main unit and connect the iPod/iPhone to the Wireless transmitter. Then press InPUT SeleCT button on the remote control to select "W iPod" mode.
Set an ID of the Subwoofer before setting a Transmitter ID. (See page 12) POWER TV POWER ● connEctionS 1. Turn off your Home Theater (HW-D570). 2. Press the hold "3D Sound" button on the remote control for 5 seconds. 3. Connect the iPod/iPhone to the Wireless transmitter. 4. Turn on the iPod/iPhone. Press the "iD SET" button on the back of the Wireless transmitter for 5 seconds. The link light on the wireless transmitter will blink fast. 5.
connecting the CRYSTAL SURROUND AIR TRACK HDMI is a standard digital interface for connection to such devices as a TV, projector, DVD player, Blu-ray player, set top box and more. HDMI removes any loss of signal from analog conversion, enabling you to enjoy video and audio sound quality as it was originally created in the digital source.
EnG connecting the CRYSTAL SURROUND AIR TRACK This section explains two ways (digital and analog) of connecting the unit to the TV. This unit is equipped with two optical digital jacks and one audio analog jack for connecting a TV.
functions basic functions POWER TV POWER POWER TV POWER Turning the power on/off TV INFO VOL SOUND MODE 3D SOUND AUTO POWER DRC SPK CONTROL S/W LEVEL TV INFO INPUT SELECT S.VOL DIMMER TV CH MUTE HDMI VOL TV CH MUTE AV SYNC 1. Touch POWER ( ) on the front panel. or, Press POWER on the remote control to turn on the power. AUDIO 2. Touch POWER ( ) on the front panel. or, Press POWER on the remote control again to turn off the power. AH59-02330A SOUND MODE 3D SOUND INPUT SELECT S.
You can select from 7 different sound modes (MUSIC, NEWS, DRAMA, CINEMA, SPORTS, GAME, PASS (Original Sound)) depending on the type of sources you want to enjoy. Press SOUND MODE on the remote control , or touch SOUND MODE ( on the front panel repeatedly to select the sound mode you want. SOUND SOUND MODE MODE EnG Using the sound mode ) SOUND MODE • Select PASS mode if you want to enjoy the original sound. POWER TV POWER TV POWER TV INFO VOL SOUND MODE S.
POWER TV POWER TV INFO VOL POWER 3D SOUND SOUND MODE S.VOL INPUT SELECT TV POWER TV INFO VOL TV CH MUTE 3D SOUND SOUND MODE S.VOL INPUT SELECT DIMMER DIMMER POWER AUTO POWER DRC SPK CONTROL S/W LEVEL TV CH MUTE DRC TV POWER SPK CONTROL HDMI AUDIO S/W LEVEL VOL AH59-02330A AV TV SYNC INFO AUDIO TV CH MUTE TV POWER AUTO POWER DRC POWER INPUT SELECT S.
POWER TV POWER TV INFO VOL SOUND MODE 3D SOUND TV POWER INPUT SELECT S.VOL AUTO POWER DRC SPK CONTROL S/W LEVEL DIMMER AUTO POWER DRC SOUND MODE 3D SOUND DIMMER TV CH MUTE Using the Anynet+(HDMI-CEC) function INPUT SELECT S.VOL TV INFO VOL SPK CONTROL HDMI HDMI AV SYNC AUDIO S/W LEVEL AV SYNC AUDIO AH59-02330A AH59-02330A Anynet+ is a function that enables you to control other Samsung Devices with your Samsung TV's remote control.
troubleshooting Before requesting service, please check the following. Symptom Check Remedy The unit will not turn on. • Is the power cord plugged into the outlet? • Connect the power plug to the outlet. A function does not work when the button is pressed. • Is there static electricity in the air? • Disconnect the power plug and connect it again. Sound is not produced. • Is the unit properly connected to your TV? • Is the Mute function on? • Is the volume set to minimum? • Connect it correctly.
EnG appendix Specifications Model name HW-D570 0.75W Main unit Power consumption Subwoofer 45W Weight Dimensions (W x H x D) AMPLIFIER 20W Main unit 9.7 kg Subwoofer 5.4 kg Main unit 1058 x 80 x 40.1 mm Subwoofer 175 x 350 x 294.
Česky [Czech] Samsung tímto prohlašuje, že tento Crystal Surround Air Track je ve shodě se základními požadavky a dalšími příslušnými ustanoveními směrnice 1999/5/ES. Dansk [Danish] Undertegnede Samsung erklærer herved, at følgende udstyr Crystal Surround Air Track overholder de væsentlige krav og øvrige relevante krav i direktiv 1999/5/EF.
Contact SAMSUNG WORLD WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care centre. Area ` North America Contact Centre Web Site Canada Mexico U.S.A 1-800-SAMSUNG (726-7864) 01-800-SAMSUNG (726-7864) 1-800-SAMSUNG (726-7864) www.samsung.com www.samsung.com www.samsung.
Correct disposal of batteries in this product (Applicable in the European Union and other European countries with separate battery return systems.) This marking on the battery, manual or packaging indicates that the batteries in this product should not be disposed of with other household waste at the end of their working life. Where marked, the chemical symbols Hg, Cd or Pb indicate that the battery contains mercury, cadmium or lead above the reference levels in EC Directive 2006/66.
