SAMSUNG User Guide
Chapter 1.
Product Features PC in Hand Improved portability through its compact size and lightweight design Slim, Polished Design Small but Powerful PC An Intel “Atom” Processor with Low Power Consumption and Low Heat Extended Use Time through the use of PowerEfficient Parts Versatile and Convenient Use A Camera Module for Video Chatting or Conferencing (Optional) Wireless LAN and Bluetooth Function (Optional) Multi Card Slot Support (Optional) Easy-to-Use Keyboard Optional items may be changed or m
Before You Start Before reading the User Guide, first check the following information. Optional items, some devices and software referred to in the User Guide may not be provided and/or changed by upgrade. Note that the computer environment referred in the User Guide may not be the same as your own environment. Images used in this User Guide may differ from actual product. This guide decribes procedures for using both the mouse and the touchpad.
Text Notations Icon Notation Description Before You Start Content included in this section includes information required before using a function. Caution Content included in this section includes information required about the function. Note Content included in this section includes helpful information to use the function. Copyright © 2009 Samsung Electronics Co., Ltd. Samsung Electronics Co., Ltd. owns the copyright of this manual.
Performance Restrictions z Online games and some games(3D,2D) may not be supported and Full HD video and some high bit rate HD video playback may be slow and stutter on this computer. x There is one memory slot provided on this computer. It supports 2GB memory max. To upgrade to 2GB memory, replace the current memory with a 2GB memory module.
Recovery Solution Representation (Optional) Q. What is a Recovery Area? A. - Samsung computers have an additional partition to recover computers or save backup files. (Only for models with the Samsung Recovery Solution.) This partition is called a Recovery Area and it includes a recovery image that comprises of the OS and application programs. - You can either double-click the Samsung Recovery Solution icon on the desktop or press F4 while booting the computer to enter the Recovery Area.
Contents Chapter 1. Getting Started Product Features Before You Start Contents Safety Precautions Proper Posture During Computer Use Important Safety Information Replacement Parts and Accessories Regulatory Compliance Statements WEEE SYMBOL INFORMATION Overview Turning the Computer On and Off Chapter 3. Settings and Upgrade 2 3 7 8 24 27 30 33 48 50 56 LCD Brightness Control BIOS Setup Setting a Boot Password Changing the Boot Priority Upgrading Memory Battery Using the Security Lock Port Chapter 4.
Safety Precautions For your security and to prevent damage, please read the following safety instructions carefully. Since these are commonly applied to Samsung Computers, some figures may differ from the actual product. Warning Failing to follow instructions marked with this symbol may cause personal injury and even fatality. Installation Related Do not install the product in places exposed to humidity such as bathrooms. There is a danger of electric shock.
Warning Failing to follow instructions marked with this symbol may cause personal injury and even fatality. Power Related The power plug and wall outlet figures may differ depending on the country specifications and the product model. Avoid exposing any part of your body to the heat from the computer vent or AC adapter for a long time when the computer is on. Exposing a part of your body close to the heat from the vent or AC adapter for long periods of time may cause a burn.
Warning Failing to follow instructions marked with this symbol may cause personal injury and even fatality. If the power cord or power outlet makes a noise, disconnect the power cord from the wall outlet and contact a service center. This may result in electric shock or fire. Plug the power cord firmly into the power outlet and AC adapter. Failing to do so may result in electric shock or fire. Do not use a damaged or loose main plug or power cord or power outlet.
Warning Failing to follow instructions marked with this symbol may cause personal injury and even fatality. AC Adapter Usage Precautions If any foreign substance such as water enters the power input jack, AC adapter or the computer, disconnect the power cord and contact the service center. Damage to the device within the computer may result in electric shock or fire hazard. Connect the power cord to the AC adapter firmly. Otherwise, there is a danger of fire due to an incomplete contact.
Warning Failing to follow instructions marked with this symbol may cause personal injury and even fatality. Battery Usage Related Authorized Parts Keep the battery out of the reach of infants and pets, as they could put the battery into their mouths. There is a danger of electric shock or choking. Use an authorized battery and AC adapter only. Please use an authorized battery and adapter approved by Samsung Electronics.
Warning Failing to follow instructions marked with this symbol may cause personal injury and even fatality. Power Off Do not use the computer in a humid location such as a bathroom or sauna. Please use the computer within the recommended temperature and humidity range (10~32ºC, 0~80% RH). Do not close the LCD panel and put the computer into your bag to move it when it is still turned on.
Warning Failing to follow instructions marked with this symbol may cause personal injury and even fatality. Take care not to allow metal objects such as a key or clip to touch the battery terminal (metal parts). If a metal object touches the battery terminals, it may cause excessive current flow and it may damage the battery, or result in a fire. If liquid leaks out of the battery or there is a funny smell coming from the battery, remove the battery from the computer and contact a service center.
Warning Failing to follow instructions marked with this symbol may cause personal injury and even fatality. Usage Related Disconnect all cables connected to the computer before cleaning it. If you are cleaning a notebook computer, remove the battery. There is a danger of electric shock or damage to the product. Do not place any container filled with water or chemicals over or near the computer. If water or chemicals enter the computer, this may cause fire or electric shock.
Warning Failing to follow instructions marked with this symbol may cause personal injury and even fatality. Upgrade Related Never disassemble the power supply or AC adapter. There is a danger of electric shock. Use only authorized parts (multi-plug, battery and memory) and never disassemble parts. This may result in damage to the product, electric shock or fire. When removing the RTC (Real Time Clock) battery, keep it out of the reach of children as they could touch and/or swallow it.
Warning Failing to follow instructions marked with this symbol may cause personal injury and even fatality. Custody and Movement Related Follow the instructions for the relevant location (e.g. airplane, hospital, etc.) when using a wireless communication device (wireless LAN, Bluetooth, etc.). When carrying the notebook computer with other items, such as the adapter, mouse, books etc, take care not to press anything against the notebook computer.
Caution Failing to follow instructions marked with this symbol may cause slight injury or damage to the product. Installation Related Do not block the ports (holes), vents, etc. of the product and do not insert objects. Damage to a component within the computer may cause electric shock or fire. Do not place a heavy object over the product. This may cause a problem with the computer. In addition, the object may fall and cause injury, or damage the computer.
Caution Failing to follow instructions marked with this symbol may cause slight injury or damage to the product. Usage Related Use only a battery authorized by Samsung Electronics. Failing to do so may cause an explosion. Do not heat the battery or expose it to heat (e.g. inside a vehicle during the summer). There is a danger of explosion or fire. Do not place a candle, light cigar, etc. over or on the product. There is a danger of fire. Use a wall outlet or multi-plug with a grounding part.
Caution Failing to follow instructions marked with this symbol may cause slight injury or damage to the product. In case of lightning, immediately turn the system off, disconnect the power cord from the wall outlet and phone line from modem. Do not use a modem or phone. There is a danger of electric shock or fire. Do not use your computer and AC-Adapter on your lap or soft surfaces. If the computer temperature increases, there is a danger of burning yourself.
Caution Failing to follow instructions marked with this symbol may cause slight injury or damage to the product. Upgrade Related Do not use a damaged or modified CD/Floppy Disk. There is a danger of damaging the product or personal injury. Do not insert your fingers into the PC Card Slot. There is a danger of injury or electric shock. Use recommended computer cleansing solution when cleaning the product and only use the computer when it is completely dried.
Caution Failing to follow instructions marked with this symbol may cause slight injury or damage to the product. Custody and Movement Related Use parts authorized by Samsung Electronics only. Failing to do so, may cause fire or damage the product. Never disassemble or repair the product by yourself. There is a danger of electric shock or fire. To connect a device that is not manufactured or authorized by Samsung Electronics, enquire at your service center before connecting the device.
Caution Failing to follow instructions marked with this symbol may cause slight injury or damage to the product. Cautions on Preventing Data Loss (Hard Disk Management) Take care not to damage the data on a hard disk drive. Causes that may damage the data of a hard disk drive and the hard disk drive itself. A hard disk drive is so sensitive to external impact that an external impact may cause loss of data on the surface of the disk.
Proper Posture During Computer Use Maintaining a proper posture during computer use is very important to prevent physical harm. The following instructions are about maintaining a proper posture during computer use developed through human engineering. Please read and follow them carefully when using the computer. Otherwise, the probability of (RSI: Repetitive Strain Injury) from repeated operations may increase and serious physical harm may be caused.
Eye Position Hand Position Keep the monitor or LCD away from your eyes by at least 50cm. Keep your arm at a right angle as shown by the figure. 50c m Keep the line from your elbow to your hand straight. Do not place your palm over the keyboard while typing. Do not hold the mouse with excessive force. Do not press the keyboard, touchpad or mouse with excessive force. It is recommended connecting an external keyboard and mouse when using the computer for long periods of time.
Volume Control (Headphones and Speakers) Use Time (Break Time) Take a break for 10 minutes or more after a 50-minute period when working for more than one hour. Check your volume first to listen to music. Illumination Do not use the computer in dark locations. The illumination level for computer use must be as bright so for reading a book. Indirect illumination is recommended. Use a curtain to prevent reflection on the LCD screen.
Important Safety Information Ensure that the electrical outlet you are using to power your equipment is easily accessible in case of fire or short circuit. If your computer has a voltage selector switch, make sure that the switch is in the proper position for your area. Openings in the computer case are provided for ventilation. Do not block or cover these openings. Make sure you provide adequate space, at least 6 inches (15 cm), around the system for ventilation when you set up your work area.
Care During Use Do not walk on the power cord or allow anything to rest on it. Do not spill anything on the system. The best way to avoid spills is to not eat or drink near your system. Some products have a replaceable CMOS battery on the system board. There is a danger of explosion if the CMOS battery is replaced incorrectly. Replace the battery with the same or equivalent type recommended by the manufacturer. Dispose of batteries according to the manufacturers instructions.
The Instruction On Safety Operation of NotePC z When installing and operating devices please refer to safety requirements in the user guide. x Devices can be used only with the equipment specified in the technical specifications of the devices. c If any smell of burning or smoke is detected from the computer the unit should be switched off and battery removed. The unit should be checked by a qualified technician before reuse.
Replacement Parts and Accessories Use only replacement parts and accessories recommended by manufacturer. To reduce the risk of fire, use only No. 26 AWG or larger telecommunications line cord. Do not use this product in areas classified as hazardous. Such areas include patient care areas of medical and dental facilities, oxygen rich environments, or industrial areas. Battery Disposal Do not put rechargeable batteries or products powered by non-removable rechargeable batteries in the garbage.
Laser Safety All systems equipped with CD or DVD drives comply with the appropriate safety standards, including IEC 60825-1. The laser devices in these components are classified as “Class 1 Laser Products” under a US Department of Health and Human Services (DHHS) Radiation Performance Standard. Should the unit ever need servicing, contact an authorized service location.
Power Cord Requirements The power cord set (wall plug, cable and AC adapter plug) you received with your computer meets the requirements for use in the country where you purchased your equipment. Power cord sets for use in other countries must meet the requirements of the country where you use the computer. For more information on power cord set requirements, contact your authorized dealer, reseller, or service provider.
Regulatory Compliance Statements Wireless Guidance (If fitted with 2.4G band or 5G band) Low power, Radio LAN type devices (radio frequency (RF) wireless communication devices), operating in the 2.4GHz/5GHz Band, may be present (embedded) in your notebook system. The following section is a general overview of considerations while operating a wireless device. Additional limitations, cautions, and concerns for specific countries are listed in the specific country sections (or country group sections).
Radio frequency wireless communication can interfere with equipment on commercial aircraft. Current aviation regulations require wireless devices to be turned off while traveling in an airplane. 802.11ABGN (also known as wireless Ethernet or Wifi) and Bluetooth communication devices are examples of devices that provide wireless communication.
United States of America USA and Canada Safety Requirements and Notices Explosive Device Proximity Warning Do not operate a portable transmitter (such as a wireless network device) near unshielded blasting caps or in an explosive environment unless the device has been modified to be qualified for such use. Do not touch or move antenna while the unit is transmitting or receiving.
Unintentional Emitter per FCC Part 15 Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules.
Intentional emitter per FCC Part 15 This transmitter must not be collocated or operate in conjunction with any other antenna or transmitter except the installed Bluetooth transmitter. Operation of this device is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation of the device. (If fitted with 2.
An FCC compliant telephone cord and modular plug is provided with this equipment. This equipment is designed to be connected to the telephone network or promises wiring using a compatible modular jack which is Part 68 compliant. See Installation Instructions for details. The REN is used to determine the quantity of devices which may be connected to telephone line. Excessive RENs on the telephone line may result in the devices not ringing in response to an incoming call.
Canada Unintentional Emitter per ICES-003 The Telephone Consumer Protection Act of 1991 makes it unlawful for any person to use a computer or other electronic device, including fax machines, to send any message unless such message clearly contains in a margin at the top or bottom of each transmitted page or on the first page of the transmission, the date and time it is sent and an identification of the business or other entity, or other individual sending the message and the telephone number of the sending
Intentional Emitter per RSS 210 The power output of the wireless device (or devices), which may be embedded in your notebook, is well below the RF exposure limits as set by Industry Canada. This transmitter must not be collocated or operate in conjunction with any other antenna or transmitter except the installed Bluetooth transmitter.
Telecommunications per DOC notice (for products fitted with an IC-compliant modem) Users should make sure, for their own protection, that the electrical ground connections of the power utility, telephone lines, and internal metallic water pipe system, if present, are connected together. This precaution may be particularly important in rural areas. The Industry Canada label identifies certified equipment.
European Union European Union CE Marking and Compliance Notices Manufacturer Information Samsung Electronics Co., Ltd. 416, Maetan-3Dong, Yeongtong-Gu, Suwon-City, Gyeonggi-Do, 443-742, Korea Products intended for sale within the European Union are marked with the Conformité Européene (CE) Marking, which indicates compliance with the applicable Directives and European standards and amendments identified below. This equipment also carries the Class 2 identifier.
European Radio Approval Information (for products fitted with EU-approved radio devices) This Product is a Notebook computer; low power, Radio LAN type devices (radio frequency (RF) wireless communication devices), operating in the 2.4GHz/5GHz band, may be present (embedded) in your notebook system which is intended for home or office use. This section is only applicable if these devices are present. Refer to the system label to verify the presence of wireless devices.
EU R&TTE Compliance Statements Česky [Czech] Dansk [Danish] Deutsch [German] Eesti [Estonian] English Español [Spanish] Ελληνική [Greek] Français [French] Italiano [Italian] Latviski [Latvian] Lietuvių [Lithuanian] Samsung tímto prohlašuje, že tento Notebook PC je ve shodě se základními požadavky a dalšími příslušnými ustanoveními směrnice 1999/5/ES. Undertegnede Samsung erklærer herved, at følgende udstyr Notebook PC overholder de væsentlige krav og øvrige relevante krav i direktiv 1999/5/EF.
Hierbij verklaart Samsung dat het toestel Notebook PC in overeenstemming is met de essentiële eisen en de andere relevante bepalingen van richtlijn 1999/5/EG. Hawnhekk, Samsung, jiddikjara li dan Notebook PC jikkonforma malMalti ħtiāijiet essenzjali u ma provvedimenti oħrajn relevanti li hemm fid[Maltese] Dirrettiva 1999/5/EC. Alulírott, Samsung nyilatkozom, hogy a Notebook PC megfelel a Magyar vonatkozó alapvetõ követelményeknek és az 1999/5/EC irányelv egyéb [Hungarian] elõírásainak.
European Economic Area Restrictions Local Restriction of 802.11b/802.11g Radio Usage [Note to integrator: The following statements on local restrictions must be published in all end-user documentation provided with the system or product incorporating the wireless product.] The European variant is intended for use throughout the European Economic Area.
France For Metropolitan departments: 2.400 - 2.4835 GHz for indoor use. 2.400 - 2.454 GHz (channels 1 to 7) for outdoor use. supporting voice telephony services) in which network addressing, if provided, is by means of Dual Tone Multi-Frequency (DTMF) signaling. Although this equipment can use either loop disconnect (pulse) or DTMF (tone) signaling, only the performance of the DTMF signaling is subject to regulatory requirements for correct operation.
WEEE SYMBOL INFORMATION orrect disposal of this product C (Waste Electrical & Electronic Equipment) (Applicable in the European Union and other European countries with separate collection systems.) This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g. charger, headset, USB cable) should not be disposed of with other household waste at the end of their working life.
Correct disposal of batteries in this product Pb (Applicable in the European Union and other European countries with separate battery return systems.) This marking on the battery, manual or packaging indicates that the batteries in this product should not be disposed of with other household waste at the end of their working life. Where marked, the chemical symbols Hg, Cd or Pb indicate that the battery contains mercury, cadmium or lead above the reference levels in EC Directive 2006/66.
Overview Optional items may be changed or may not be provided depending on the computer model. The actual color and appearance of the computer may differ from the pictures used in this guide. Front View 1 1 8 8 2 7 6 5 2 7 6 5 3 4 (Model A) 3 (Model B) 4 1 Camera Lens (Optional) Using this lens, you can take still pictures and record video. 2 Keyboard A device to enter data by pressing the keys.
Status Indicators 1 2 3 4 1 5 (Model A) 1 Caps Lock 2 3 4 5 (Model B) This turns on when the Caps Lock key is pressed allowing capital letters to be typed without holding the Shift button down. 2 Hard Disk Drive Indicates that the hard disk drive is running. This turns on when the wireless LAN is operating. 3 Wireless LAN 4 Charge Status This shows the power source and the battery charge status. Green: When the battery is fully charged or the battery is not installed.
Right View 1 2 3 1 (Model A) 2 3 (Model B) 1 USB Port You can connect USB devices to the USB port such as a keyboard/mouse, digital camera, etc. 2 Security Lock Port You can connect a Kensington lock to the Security Lock Port to prevent the computer from being stolen. 3 DC Jack A jack to connect the AC adapter that supplies power to the computer.
Left View 1 2 3 4 5 6 1 (Model A) 2 3 4 5 6 (Model B) 1 Wired LAN Port 2 Monitor Port Connect the Ethernet cable to this port. 3 Fan Vents The internal heat of the computer is emitted through these holes. A port used to connect a monitor, TV or projector supporting a 15pin D-SUB interface. If the vents are blocked the computer may overheat. Avoid blocking the vents as this may be dangerous.
Back View 1 Battery 1 1 (Model A) (Model B) This is a Lithium-Ion rechargeable battery that supplies power to the computer.
Bottom View 1 2 2 3 3 (Model A) 1 Battery Latches 1 (Model B) The latch used to remove or install the battery. 2 Memory Compartment The main memory is installed inside the cover. Cover 3 Speaker A device used to generate sound. A Speaker(s) is optional. One (mono) or two (stereo) speakers are provided depending on the model.
Turning the Computer On and Off Turning the computer on Turning the computer off Install the battery and connect the 1 AC adapter. Since the procedures to turn the computer off may differ depending on the installed operating system, please turn the computer off according to the procedures for the purchased operating system. 2 Lift the LCD panel up. Slide the Power Switch to turn the 3 computer on. ▶ For Windows 7 Click the Start 1 taskbar. button on the Click Shut down 2 down the computer.
▶ For Windows XP Click the Start 1 taskbar. If the computer has not turned off properly due to a system error, press ++. When [Windows Task Manager] dialog box appears, click Shut Down > Turn Off to turn off the computer. Your unsaved work may be lost/damaged. button on the 2 Click Turn Off Computer. If ++ keys do not operate either, press the power button for more than 4 seconds to turn off the computer. Your unsaved work may be lost/ damaged.
Chapter 2.
Keyboard Shortcut key functions and procedures are discussed in the following sections. The keyboard is supplied according to the corresponding country. The keyboard may differ depending on your country. The following mainly describes the shortcut keys. Shortcut Keys You can use the following functions by pressing the keys below with the Fn key. Fn+ Name Function REST Switches to Sleep mode. To wake the computer up, press the (Sleep Mode) Power button. Shows the remaining battery charge.
Fn+ Name Samsung Support Center Easy SpeedUp Manager Function System diagnosis, recovery and Internet consultation program, Samsung Support Center, will be launched. (Optional) For some models, Samsung Magic Doctor is launched. You can select operation mode when you need maximum system performance or low-noise/low power consumption with one-click. Silent: Low-noise and low power consumption mode Normal: Normal Mode Speed: Maximum performance mode.
Fn+ Name Function Num Lock Turns the numeric keyboard on or off. Scroll Lock If you turn the Scroll Lock on, you can scroll the screen up or down without changing the cursor location in some applications. Screen Brightness Control Numeric Key To adjust the LCD brightness press the Fn + key combination or the Fn + key combination. The numbers are printed in blue on the numeric keys. If Num Lock is turned on by pressing the Fn + key combination, you can use the numeric keys to enter digits.
Touchpad The touchpad provides the same function as a mouse and the left and right buttons of the touchpad plays the role of the left and right buttons of a mouse. Use the Touchpad with your fingers. Using a sharp object may damage the Touchpad. If you touch the Touchpad or press the Touchpad buttons while booting up, the Windows boot time may be extended. Scroll Area Plays the role of the mouse wheel. You can scroll up and down using the Scroll Area. Touchpad Use to move the cursor.
Click Function Right Button Function Place your finger on the touchpad and tap your finger once over an item you want. Alternatively, press the left touchpad button once. This corresponds to clicking the right mouse button. Press the right touchpad button once. The corresponding pop-up menu appears. Tap or Click Click Double-Click Function Drag Function Put your finger on the touchpad and quickly tap twice with your finger on an item you want.
Touchpad Scroll Function The touchpad scroll area provides the mouse wheel function (scroll function). Place your finger on the touchpad’s right edge for vertical scrolling or the bottom edge for horizontal scrolling and then move your finger along the edge to scroll the screen vertically or horizontally. The Gesture Function of the Touchpad (Optional) The Touchpad Gesture function may not be provided and the version of the function may differ depending on the model.
Configuring the Gesture Function Zoom Functions If the Gesture function is not activated, you can activate it according to the following procedures. If you place two fingers over the Touchpad together or apart, the current image or text is zoomed in or out. the Start > Control Panel 1 Click > Hardware and Sound > Mouse Zoom-in > Device Settings tab > Settings button. Zoom-out or The Touchpad Settings window 2 appears.
Move Function Slide Show Function When watching a photo or surfing the Internet, you can move to the previous or next photo or Internet page without using the mouse or buttons. Place three fingers over the Touchpad and slightly touch the surface of the Touchpad with them in the left or right direction to move to the previous or next photo or Internet page. For example, if you touch the Touchpad in the left direction using three fingers while looking at a website, the previous page is displayed.
External-type CD drive (To be purchased) This computer supports an external USB CD-ROM drive (can be additionally purchased). Check if the interface type of the external CD-ROM drive is a USB type. For detailed specifications, refer to the catalog. Do not insert a cracked or scratched CD. Otherwise, the CD may break and damage the optical disk drive when the CD rotates at a high speed. When you clean a CD or DVD title, wipe with a soft cloth from inside to outside.
Inserting and Ejecting a CD Press the Eject button of the CD 1 drive. A CD drive’s reading and writing speed may differ depending on the condition and type of the media. To eject a CD when the CD drive does not work or the computer is off, place the end of a paper clip ) into the Emergency Hole ( until the CD tray is ejected. Status Indicator Emergency Hole Eject Button the CD tray opens, insert a CD 2 orWhen DVD and push the tray in until it clicks. Push the CD tray inward until it clicks.
Multi Card Slot (Optional) Using the multi card slot, you can read and write data from and to an SD card, SDHC card, MMC. You can use a card as a removable disk and conveniently exchange data with digital devices such as a digital camera, digital camcorder, MP3, etc. You have to additionally purchase a multi card with the necessary capacity depending on your requirements. You can use a multi card just like any data storage device. A copyright protection function is not supported.
The card drive appears. Click Open 2 folder and view files. can save, move and delete data 3 byYoudouble-clicking the corresponding drive. If the window does not appear, click Start > Computer. (For Windows XP, click Start > My Computer.) The device name of the card drive may differ depending on your computer model. You can only use the card after formatting it. Using a Mini SD snd RS-MMC Since the above cards are too small, you cannot insert the cards into the slot directly.
To remove a memory card To use a card to exchange data with a digital device such as a digital camera, formatting the data using the digital device is recommended. When you try to use a card, which is formatted in the computer, in another digital device, you may have to format the card again in the device. You cannot format, write or delete data from a SD, or SDHC card with a write protection tab when it is in the Lock position.
Connecting a monitor / TV Using an external display device is useful when you are giving a presentation or watching a video or movie through your monitor. You have to buy a connection cable additionally. Due to restrictions of the operating system the DualView function is not supported for Windows 7 Starter. Connecting to the Monitor / TV Connecting to the Monitor port Connect the computer to the RGB port of the monitor or TV using a monitor cable (15-pin).
Viewing Through a Monitor / TV You can switch the display device using the shortcut key. Switching the Display Device using the Shortcut Key LCD: Notebook Screen CRT: External Monitor Screen LCD+CRT Clone : Notebook+ External Monitor Screen LCD+CRT DualView: Notebook+ External Monitor Screen in Dual View Press the Fn + key combination once. Then the Easy Display Manager screen appears in which you can select a display device.
Using Dual View to View Extended Screen Dual View is a function that enables you to view a computer screen over two display devices. This is convenient when needing a wide screen for work. In Dual View mode, you can select the screen resolution and color quality for each display device, as if there were two separate graphics cards. Due to restrictions of the operating system the DualView function is not supported for Windows 7 Starter.
Adjusting the resolution of the auxiliary display device (Monitor Number 2) If the resolution of the auxiliary display device is output, you can adjust the resolution and color quality by clicking Start > Control Panel > Appearance and Personalization > Adjust screen resolution > Monitor Number 2. When the configuration is complete, 4 click Identify on the left side of ▶ For Windows XP Troubleshoot. The primary display device(the LCD) is indicated as 1, and the secondary display device is indicated as 2.
Canceling Dual View Adjusting the resolution of the auxiliary display device (Monitor Number 2) If the screen of the secondary display device is displayed, change the settings to the desired screen resolution and color quality in the [Display Properties] dialog box. ▶ For Windows 7 Click the Start > Control Panel > 1 Appearance and Personalization > Adjust screen resolution. Click the monitor number 2 icon and 2 select Show Desktop on 1 only in Using Window in Dual View the Multiple displays item.
Adjusting the Volume You can adjust the volume using the keyboard and the volume control program. Since these descriptions are written on the basis of the latest operating system, Windows 7, some of the content and the figures of the descriptions may differ depending on the operating system. Since the procedures for other Windows operating systems are similar, use the computer referring to these descriptions.
Using SRS x The SRS function enables you to experience more stereophonic sound by expanding the space-perception through the stereo speaker. z This function is available for specific models only. ▶ For Windows 7 Right-click over the Volume icon in 1 the Taskbar and select Play Device (P). Music: Select to listen to music. WOW HD technology has been used. Select Speaker in the Play tab and 2 click Properties. Movie: Select to watch a movie. TruSurround XT technology has been used.
Click on Control Panel > Sound, 3 Voice and Audio Device > SRS The SRS function is only supported for a computer's built-in speakers or headphones. It is recommended to unchecking the SRS option before recording, and to check it before play. It is to prevent sound distortion because of double application of SRS effect when user plays the file recorded by using stereo mix. Control Panel. Check the Enable checkbox and select a mode. Then you can listen to sound through the selected SRS effect.
Using Recorders This section describes how to perform recording on a computer by using Windows Recorder. ▶ For Windows 7 ▶ For Windows XP Connect a microphone to the 1 microphone jack. Connect a microphone to the 1 microphone jack. You can also use the internal MIC. 2 You can also use the internal MIC. Click Start > Control Panel > 2 Sounds, Speech, and Audio Right-click over the Volume icon on the taskbar and select Recording Device. Devices > Sounds and Audio Devices.
Select Realtek HD Audio input from Click Start > All Programs > 4 the 7 Accessories > Entertainment > mixer device to select Recording Sound Recorder. from Adjust Volume for. Click the Record button to perform 8 recording. The default recording duration of Windows is 60 seconds. Download a dedicated recording program from the Internet to record audio data for a long time. Mic Volume from Show the 5 Select following volume controls and click OK.
Wired Network A wired network is a network environment used for a company network or broadband internet connection at home. Since these descriptions are written on the basis of the latest operating system, Windows 7, some of the content and the figures of the descriptions may differ depending on the operating system. Since the procedures for other Windows operating systems are similar, use the computer referring to these descriptions. Connect a LAN cable to the 1 computer’s LAN port.
Select Local Area Connection and 3 click the right button of the touch pad and select Properties. The LAN Device name may differ depending on your computer’s Network Device. ▶ For Windows XP C lick General tab and select a LAN driver from Connect using:. Select Internet Protocol(TCP/IP) and click Properties. Windows 7 4 ▶ For S elect Internet Protocol Version 4 (TCP/IPv4) from the Networking tab and click Properties. The displayed LAN driver may vary depending on the LAN device type.
Configure IP settings. 5 Select Obtain an IP address Using both DHCP and a fixed IP simultaneously automatically when using DHCP. If you use a static IP, select Use the following IP address and enter the values. Using the Alternate Configuration provided by Windows, you can set both automatic and fixed IP addresses and then you can select to use either of them to connect to the Internet.
Windows 7, select Internet 3 For Protocol Version 4 (TCP/IPv4) from the Networking tab and select Properties. For Windows XP, select Internet Protocol (TCP/IP) and click Properties. Select the Alternate Configuration 4 tab, select User configured, fill in the corresponding fields and click the OK button.
Wireless Network A wireless network allows computers to share resources or an internet connection without using LAN cables between them. This description is applied only to the models equipped with wireless LAN cards or devices. Some of the pictures shown in this description may vary depending on the wireless LAN device. To use the wireless LAN, you have to turn the wireless LAN on first by pressing the Fn + keys. If the wireless LAN is turned on, the Wireless LAN LED is lit.
Connect. 2 IfClick a network key is set for the AP, ▶ For Windows 7 the Network Connections 1 If youiconclick in the system tray, a list of enter the network key and then click Connect. available APs appears. If you select an AP to connect to, the Connect button appears. AP List For the network key, please ask your network administrator. When Connected to the AP is 3 displayed, click the Close button. You can access the network.
Once Connected to AP is displayed, 3 you can use a wireless network. ▶ For Windows XP Click the Wireless Network 1 Connection icon from the Taskbar using the right button of the touch pad. Then, click View Available Wireless Networks. To check the network connections Place the mouse over the Wireless Network Connection icon (For Windows XP, ) from the Taskbar. Then, the status will appear. Select an AP to be connected and 2 click Connect.
Chapter ��� 3.
LCD Brightness Control You can adjust the LCD brightness in 8 levels. Controlling the Brightness Using the Keyboard Adjust the LCD brightness by pressing the Fn + key or the Fn + key. The LCD brightness can change up to 8 levels and the brightness increases by 1 level when pressing the Fn + key once.
Instructions for Cleaning the LCD Clean the LCD panel with a soft cloth lightly moistened with computer cleansing detergent moving in one direction. Cleaning the LCD panel with excessive force can damage the LCD.
BIOS Setup The BIOS Setup enables you to configure your computer hardware according to your needs. Use the BIOS setup to define a boot password, change the booting priority, or add a new device. Since incorrect settings may cause your system to malfunction or crash, take care when configuring the BIOS. The functions of the BIOS setup are subject to change for product function enhancement purposes. The BIOS Setup menus and items may differ depending on your computer model.
The BIOS Setup Screen XXXXXXXX Setup Menu System Time System Date [10:21:53] [07/30/200X] IDE Channel 0 Master XXXXXXXX CPU Type CPU Speed XXXXXXXX X.XX GHz Total Memory XXX MB Graphics Memory [Auto : Shared] BIOS Version MICOM Version XXXXXXXX XXXXXXXX Help Help for the selected item appears automatically. Setup Items Setup Menu Main Advanced Security Description Used to change the basic system and environment settings.
System Setup Keys In the Setup, you have to use the keyboard. F1 Press to view the Setup Help. Up & Down Keys Press to move up and down. F5/F6 F9 ESC Left & Right Keys Enter F10 Press to change the item value. Press to load the default Setup settings. Press to return to a higher level menu or to move to the Exit menu. Press to move to another menu. Press to select an item or to enter a sub menu. Press to save the changes and exit Setup.
Setting a Boot Password When setting a password, you have to enter the password to use the computer or enter the BIOS Setup. By configuring a password, you can restrict system access to authorized users only and protect data and files saved on the computer. Do not lose or forget your password. If you have forgotten your password, contact a Samsung service center. In this case, a service fee will be charged. In the Set Supervisor Password 2 item, press .
Enter a password, press , re3 enter the password for confirmation, Setting a User Password The User Password restricts access to the computer or for configuring the BIOS Setup, like a Supervisor Password. However, the Setup items that can be configured with a User Password are restricted, unlike for a Supervisor Password. Before configuring a user password, a supervisor password must have been configured. Deactivating the supervisor password also deactivates the user password.
Setting up a Hard Disk Drive Password (Optional) Deactivating the Password on the password 1 toPress be deactivated. For example, to A supervisor password must be set using the Set Supervisor Password menu. If you set a password for a hard disk drive, it cannot be accessed from another computer. Press in the Set HDD Password item and define a password as described in Step 3 of the Setting up the Supervisor Password.
Changing the Boot Priority This computer is configured to boot from an external-type ODD first. This chapter describes how to change the boot priority so that the computer boots from the hard disk drive first. Select the Boot menu in the BIOS 1 Setup. Press the down key (↓) to move to the 3 IDE HDD item and press the F6 key to move the item to the top. Press on the Boot Device 2 Priority item. Boot Device Priority [Boot priority order] 1. USB CD : N/A 2. IDE HDD : XXXXXXXX 3. PCI BEV : N/A 4.
Upgrading Memory A memory is installed in the memory slot at the bottom of this computer. The procedures to replace the memory are described below. Replace new memory only after shutting the computer down completely. Do not replace memory when the computer is in Sleep mode. Disconnect main power plug and remove the battery before continuing. Only use the same type of memory as specified in the Product Specification. Pull the memory module latches 2 outward.
Insert a new memory module into 3 the memory slot at an angle of module down 4 soPushthattheit ismemory completely fixed. If the memory does not fit easily, push the memory module down while pulling the memory module latches outward. approximately 30 degrees aligning it to the angle of the memory slot. Close the memory compartment 5 cover and fasten the screw.
Battery Please refer to the following instructions when running the computer on battery power without connecting the AC power. A Lithium-Ion smart battery is supplied with this computer. Carefully read and follow the precautions printed on the battery before using the battery. Precautions Use only chargers specified in the User Manual. Never heat the battery pack, put it near or in a fire or use at a temperature higher than 60°C, as this may cause fire.
Slide the right battery latch to the 2 OPEN position and remove the To install the battery again, slide the 3 battery into the system. battery while holding the left battery latch to the OPEN position. x c Slide and fix the right battery latch to the CLOSE (inside) position so that the battery is fixed. z z x If the right battery latch is not in the CLOSE (inside) position, there is a danger of data loss because the battery may become separated.
Charging the Battery Attach the battery and connect the 1 AC adapter to the DC-in jack of the computer. The battery will then start charging. When charging is complete, the 2 Charge LED turns green.
Measuring the Remaining Battery Charge You can view the battery charge status by completing the following procedures. To use the shortcut key to view Confirming the battery charge in the Taskbar Press the Fn + keys on the keyboard. The remaining battery charge (%) will displayed for a moment. You can only view the charge status in this way when Easy Display Manager is installed on your computer.
Extending the Battery Usage Time Decreasing the LCD Brightness Using the Battery Calibration Function Press the Fn + keys on the keyboard to decrease the LCD brightness to extend the battery usage time. If you turn off unused devices, battery usage time will improve. When charging/discharging the battery repeatedly for a short time only, the battery usage time may be reduced by the difference between the actual battery charge and the remaining charge display.
to the Boot > Smart Battery 3 Move Calibration item using the direction keys and press . XXXXXXXX Highlight Yes in the Battery 4 Calibration Confirmation window and press . The Battery Calibration function is activated and the battery is forcefully discharged. To stop the operation, press the button. This operation requires 3~5 hours depending on the battery capacity and the remaining battery charge.
Using the Security Lock Port You can connect a Kensington lock to the Security Lock port to prevent your computer from being stolen when you need to use the computer in a public place. To use this feature, you must purchase a Kensington lock additionally. To use the Kensington lock, refer to the product manual. Tie the Kensington lock cable to a fixed object and install the other end of the cable to the Security Lock port.
Chapter 4. Troubleshooting Using Samsung Recovery Solution (Optional) 109 Reinstalling Windows 7 (For Windows 7.
Using Samsung Recovery Solution (Optional) Samsung Recovery Solution is a program that can backup your hard disk and restores it later when a problem occurs with your computer. It also provides a System Software function that enables you to install or backup device drivers and system software programs needed for your system to function properly. Samsung Recovery Solution may not be provided or the version may differ depending on the model.
Samsung Recovery Solution Functions Restore: A function that restores the computer to a previous state after a problem occurs Backup : A function that backs up the data on the computer System Software: A function that reinstalls or backs up device drivers and application programs needed for the system The system software function is supported by Samsung Recovery Solution version 4 or later. Therefore, the function may not be supported depending on the version.
Restore Function Using this function, you can easily restore your computer to a previous, stable state when your computer no longer works properly or you are unable to boot up your computer due to some problem. If you have backed up data, you can restore the backup data. Restore Functions Basic Restore This function quickly restores major Windows files (C:\ Windows) without touching the user configuration and data on the C drive.
Backup Functions Initial Status Backup This function backs up the initial status of the computer. Complete Backup This function backs up the entire drive C. Data Backup This function backs up specific folders or files. System Software function You can back up the System Software saved on the hard disk to another hard disk drive or DVD, and reinstall part or all software programs to your computer.
Restore Function Not only can you use Samsung Recovery Solution when Windows is running, but also when you are unable to boot up into Windows. Let’s learn how to use Samsung Recovery Solution. Some models provide a backup image of the initial state and do not provide partitioning. Partition Setup & Initial Status Backup The Partition Setup function is only available when the computer is turned on for the first time and will not be available afterwards.
Restoring the computer Restore is a function that enables restoring the computer to a saved point when the computer was purchased or a user-saved point. The Restore function provides the Basic Restore and Complete Restore options. Windows is running: 1 – C When lick Start > All Programs > Samsung > Samsung Recovery Solution > Samsung Recovery Solution. If you click Select by Symptom, the Select by Symptom menu appears. If you select a symptom, a recommended restoration option will blink.
If the Samsung Recovery Solution 4 program is launched for the first time 3-1 If you have selected Basic Restore: In the Basic Restore screen, click the Next button. The system will be restarted. after purchasing the computer, the license agreement screen appears before the restoration is started. Read the agreement and click Agree to continue.
Backup Function Enter a description for the backup 4 regarding the current computer status Complete Backup/Restore in the Description field so that you can easily recognize it later, and specify the Save Path. If your computer has a DVD-Writer, you can specify the DVD drive as the Save Path. A Complete Backup saves the complete image of the C drive onto another drive or DVD. A Complete Restore restores the image file saved by the Complete Backup onto the C drive.
If you click the Next button, the 5 system restarts in restoration mode Complete Backup begins. 6 IfThemultiple DVDs are required, and the Complete Backup begins. If you have selected the DVD drive as the Save Path, the “Insert a blank DVD” message appears. Insert a blank DVD and click the OK button. the expected number of DVDs is displayed in the progress screen. Whenever burning a DVD is completed, the “Insert the next DVD” message will appear. Continue the backup according to the instructions.
Complete Restore – When backing up onto DVD 1 Turn the computer on and insert the backup DVD into the DVD drive. I f there are multiple backup DVDs, insert the first DVD. – When backing up to another drive Proceed to Step 2. The restoration progress message 5 appears after the computer boots up Click Start > All Programs > 2 Samsung > Samsung Recovery in restoration mode. If you click OK, the restoration begins. Solution > Samsung Recovery Solution.
Enter a description for the backup in 4 the Description field so that you can Data Backup/Restore Data Backup enables you to save specific files or folders onto another drive or DVD. Data Restore enables you to restore data using the data saved by a Data Backup when data is lost. This guide describes the Backup and Restore procedures on the basis of backing up and restoring by using DVD. easily recognize it later and specify the Save Path.
If you click the Next button, the Data 5 Backup begins. If you have selected When the initial menu screen 3 appears, click Restore and then click Data Restore. the DVD drive as the Save Path, the “Insert a blank DVD” message appears. Insert a blank DVD and click the OK button. a backup item to be restored 4 inSelect the backup list and click the Next button. The “Backup is completed” message 6 appears.
System Software Function When the initial menu screen 2 appears, click System Software > Using System Software System Software Installation. The System Software function is a function that enables you to reinstall device drivers and System Software Programs or back up those programs. The system software function is supported by Samsung Recovery Solution version 4 or later. Therefore, the function may not be supported depending on the version.
System Software Backup If you have specified a hard disk drive or a removable disk as the Save Path, the SamsungSoftware folder is created on the corresponding drive (e.g. D:\) and the system software programs are saved to that folder. Take care to not delete the folder. Click Start > All Programs > 1 Samsung > Samsung Recovery Solution > Samsung Recovery Solution. When the initial menu screen 2 appears, click System Software > If you click the Next button, the 4 Software Backup begins.
Reinstalling Windows 7 (For Windows 7. For supported models only) You can reinstall Windows using the SYSTEM RECOVERY MEDIA for Windows when Windows is no longer working properly. (For models supplied with a SYSTEM RECOVERY MEDIA.) For models supplied with the Samsung Recovery Solution, you can reinstall Windows using the Samsung Recovery Solution. These descriptions are for Windows 7 and for supported models only. A SYSTEM RECOVERY MEDIA may not be supplied depending on your computer model.
If the Select Windows Installation 3 window appears, click Install Now. If the User Agreement screen 4 appears, select I accept the license terms and then click Next. When the Select Update window appears, click on the relevant item. For Windows 7, this screen may not appear depending on the version. The following window appears, select 5 an installation option.
When previous Windows installation files are in the selected partition, a message appears informing you that the files and folders will be moved to the Windows.old folder. Click the OK button. Custom Select this option to Reinstall Windows. You have to reinstall all necessary device drivers and programs after the Custom installation. In addition, unnecessary folders and files may remain on the hard disk drives after the installation (e.g. C:\ Windows.old, etc.). The Windows installation continues.
Reinstalling when Windows does not start When Windows does not start, boot up with the SYSTEM RECOVERY MEDIA and from there you can reinstall Windows. 1 For Windows 7, the screen asking for the operating system to be installed may appear depending on the version. If you click the Next button, the screen of Step 5 appears. If the User Agreement screen 5 appears, select I accept the license Insert the SYSTEM RECOVERY MEDIA into the DVD drive and restart the computer. terms and then click Next.
A If you click Drive Options (Advanced), you can delete, format, create or expand a partition. Click on a function and proceed according to the instructions on the screen. When previous Windows installation files are in the selected partition, a message appears informing you that the files and folders will be moved to the Windows.old folder. Click the OK button. subsequent steps are the same 8 asThethose from Step 7 of Installing in Windows.
Reinstalling Windows XP (For Windows XP, For supported models only) You can reinstall Windows using the SYSTEM RECOVERY MEDIA when Windows does not work properly. (For models supplied with a SYSTEM RECOVERY MEDIA.) For models supplied with the Samsung Recovery Solution, you can reinstall Windows using the Samsung Recovery Solution. These descriptions are for Windows XP and for supported models only. A SYSTEM RECOVERY MEDIA may not be supplied depending on your computer model.
Standard Installation Standard Installation You can change the settings for partitioning, the installation folder, etc. during the Windows installation. However, reinstalling Windows may delete the data on the hard disk drive such as files, programs, etc. In order to minimize damage from data loss, please remember to always back up data. Explain Standard Installation option as a standard. In the initial screen, click Standard 1 Installation.
After the system has restarted, the 3 message ’Press any key to boot from After the installation process copies 5 the necessary folders for the CD’ appears. Do not press any key at this time. After a while the partition configuration screen appears. To not change the partition, press Enter. Windows installation, restart the system, and the message “Press any key to boot from CD” is displayed. You do not need to enter anything.
Reinstalling when Windows does not start When Windows does not start, boot up with the SYSTEM RECOVERY MEDIA and from there you can reinstall Windows. Insert the SYSTEM RECOVERY 1 MEDIA into the CD-ROM drive and After the installation process copies 6 the necessary folders for the start the computer. Windows installation, restart the system, and the message “Press any key to boot from CD” is displayed. You do not need to enter anything.
Questions and Answers This section provides information on possible problems, solutions and other references for system use. These descriptions are written based on Windows 7, the latest operating system. Therefore, some descriptions and figures may differ from your operating system. But as the usage is similar to other Windows operating systems, you can use these descriptions for reference. The path may differ depending on the operating system.
Q The Windows Firewall setting according to the network location (for the Windows 7 operating system only) Q What Is Virtual XP? (For Windows 7 only, For supported models only) A Virtual XP refers to a virtual operating system that allows you to run Windows XP virtually in the Windows 7 environment. By using Virtual XP, you can use applications that do not run on Windows 7. A Windows 7 allows different Windows firewall settings for each network location.
Q What are the restrictions of Windows 7 Starter? A z The DualView function is not supported when an external display device is connected. x The Aero function of Windows 7 is not supported. c The Set as Background function to change the wallpaper of the Desktop is not supported. v Functions that are not supported by the operating system, may also not be supported by related programs such as Easy Display Manager, the graphics driver and so on.
Display Related Q The LCD screen is too dark or too bright. Q A Turn on the LCD backlight or adjust the screen brightness. Press Fn + to turn on the LCD backlight or press Fn + , Fn + to adjust the screen brightness. Q In the following cases, the screen blinks or there is noise for a short time. Click the Graphics Related tab, Change Resolution, Change Display Device, Remove the AC Adapter, Restart the System, Change Power Scheme.
Please press the + keys more quickly, or press the + keys using the system keyboard. Right-click over the Desktop, select Properties, select the Settings tab and change the resolution to 800 x 600. Q The Taskbar on the bottom of the screen does not appear when a projector is used as the display device. Q A This may happen, if the projector does not support LCD resolution. In this case change the resolution to 800 x 600 (recommended) on your computer.
Sound Related Q How can I configure the sound for video or audio chatting? c Select the Microphone item in the Record Control window and close the window. A1 Configuring the Realtek HD Audio Manager z Select Control Panel > Realtek HD Audio Manager. x Select the Mic tab. c Select the Suppress noise and the Remove sound echo items and click the OK button. Q I cannot hear my voice with the internal microphone.
Q Sound is recorded abnormally when I select the Remove sound echo option, connect an external microphone, select the Play Device > Speaker > Level tab and then deselect Mute for the Microphone. Q How can I configure the Recording Mixer while broadcasting music in WinAMP? (for the Windows XP operating system only) A1 Playback Mixer Settings z Double-click the Volume icon in the Taskbar and select Options > Properties from the menu.
Wired LAN Related - If the system wake up from Sleep mode even though there is no received signal, use the system after disabling the function. Q The function A is a function that activates the system from Sleep mode when a signal (such as a ping or magic packet command) arrives over the network (wired LAN).
Q The Home Group function (for the Windows 7 operating system only) A Home Group is a function that enables connecting all the computers at home allowing users to access the data on all computers as if accessing the data on the local computer. If you set the first computer to use a Home Group as a Home Network, you can create a Home Group. A second (and more) computer can participate in the created Home Group. A password is required for participation and you can confirm the password on the first computer.
Wireless LAN Related A3 Check that the device driver is installed properly. If the driver is not properly installed, you will find a yellow exclamation mark on the network icon by clicking Device Manager > Network Adapter. Q I cannot find an AP. A Verify whether the Wireless LAN LED is on. If it is turned off, turn it on by pressing the Wireless LAN On/Off button ).
For Windows XP, double-click the icon and check if the IP address is properly allocated on the Support tab. If the IP is not allocated properly, the IP address will be displayed as follows (e.g. 169.254.xxx.xxx). If the network does not provide DHCP, you have to specify the correct IP address by asking your network administrator. Even if the network provides DHCP, the server may not allocate an IP address to the client properly, and the client station cannot connect to the network.
A6 Check the AP settings as follows. (The following is recommended for a standard environment and thus may differ according to the specific wireless network environment.) When several APs are present simultaneously, check the channel settings for each AP. When different APs are using nearby channels, interference may occur between the electronic waves. Set the AP channels further apart from each other.
Q The wireless LAN does not work properly when there is a device operating on an adjacent frequency in the vicinity of the product. A1 Channel interference may occur when a wireless video transceiver or a microwave oven is being used. If you experience channel interference from other equipment, we recommended changing the channel for connecting to the AP. For more information about AP settings, refer to the User Manual supplied by the AP manufacturer. A2 Since IEEE802.
Games and Programs Related Windows may not provide some functions properly when performing some applications especially games, or may cause a problem due to a device driver compatibility issue. For the latest device drivers and bug fixes, please refer to the respective company’s website. Q 3D game is not executed, or some functions are not working. Q A Change the graphic setting of the game to “2D” or “Software Renderer,” then execute the program again.
Q Fn + work. Key combination does not Q A While displaying video of VCD or MPEG, or the display setting is Dual View, you cannot toggle display devices. Also the installation of NetWare Client 32 program disables the function of Fn + . Running speed of a game is too slow or fast. (for the Windows XP operating system only) A Change the setting of Power Schemes to “Always On.
Q The picture is not displayed properly for some games. A Some games may not display the picture properly when the screen resolution is set to 1024 × 600 and the color quality is set to 32 bit. For these games, set the screen resolution to 1024 x 600 or 800 x 600, and the color quality to 16bit.
Bluetooth Q How to view the Bluetooth help information. A2 For some headset models, if the headset is connected to the power adapter, the headset cannot be connected through the Bluetooth wireless connection. Disconnect the headset from the power adapter and try again. A ► For Windows 7 Press the Windows + F1 key combination to launch Windows Help and search for Bluetooth related items in the Help section. A3 A Bluetooth headset generally provides On/Off and Pairing modes.
Usage Instructions The Bluetooth function of a Bluetooth PDA, mobile phone, mouse or keyboard may be turned off. To use them in connection with a Samsung computer supporting Bluetooth, you must check if the Bluetooth function of the device to connect to is turned on. For the procedures on turning on the Bluetooth function of a device, refer to the relevant device manual. Generally, Bluetooth devices deliever stable performance while connected within a 3m(10 ft.) distance.
Chapter 5.
Product Specifications The system specifications may differ depending on the derived models. For detailed system specifications, refer to the product catalog. CPU Intel ATOM™ Processor Main Memory Memory type: DDR2 SODIMM Main Chipset Intel 945GSE + ICH7M Hard Disk Drive (Optional) 9.
Registered Trademarks is a trademark of SRS Labs, Inc. WOW XT technology is incorporated under license from SRS Labs, Inc. SRS WOW XT™ significantly improves the playback quality of audio, delivering a dynamic 3D entertainment experience with deep bass from even the smallest and most closely spaced speakers. Samsung is a registered trademark of Samsung Co., Ltd. Intel, ATOM/ Pentium/Celeron are registered trademarks of the Intel Corporation.
Glossary The Glossary lists the terminologies used in this User Guide. For terminologies other than these, look in Windows Help. Backup A way to save the current data to restore it later if necessary. A backup is a way to restore computer data when the data or computer is damaged. doubling the operating speed of the SDRAM and is widely used nowadays. This computer uses DDR SDRAM. Device Manager An administrative tool used to manage computer devices.
Driver Software that interacts between the hardware and the operating system. An operating system knows the hardware information and controls the hardware. In general, a driver is supplied with the corresponding hardware device. Hibernation Mode A power mode that saves all data in memory to the hard disk and turns the CPU and hard disk off. When canceling Hibernation Mode, all application programs that were running are restored to their last state.
LCD (Liquid Crystal Display) There are Passive Matrix and Active Matrix LCD types. This computer uses the Active Matrix type LCD called a TFT LCD. Since an LCD is implemented by transistors instead of a cathode-ray tube unlike a CRT, its size can be slim. And because it does not blink, it reduces eye strain. Power Schemes This refers to a pre-determined power management option group.
Shared Folder A folder that can be used by other users on the network. Sleep Mode A power mode that enables computers to save power consumption when they are not being used. When a computer is in Sleep Mode, the data on the computer memory is not saved to the hard disk. If the power is turned off, the data in memory will be lost. SSD (Solid State Disk) This refers to a device that saves information to semiconductors unlike a normal hard disk drive (HDD). There are two types of SSD.
Virtual XP Mode This is a virtual operating system that enables running Windows XP programs on the Windows 7 operating system. Using this mode, you can run programs that do not run on Windows 7. Windows Media Player A multimedia program included with Windows. Using this program, you can play a media file, create an audio CD, listen to a radio broadcast, search and manage media files, and copy files to a portable device, etc.
Index B Battery Battery Calibration BIOS Setup Booting Priority R 101 105 92 98 Recorder Remaining Battery Charge S Safety Precautions Security Lock Port Shortcut Keys Status Indicators C CD Drive / Recording Charge Click Connect / Output Monitor 67 103 63 72 Touchpad Volume Control 77 W 90 Wired Network Wireless Network M Memory Multi Card Slot 62 V 74 L LCD Brightness 8 107 59 51 T D Dual View 80 104 99 69 82 86 P Password Product Specifications
