Multimedia Projector MODEL PLC-WXL46 Owner’s Manual Network Supported □ Wired LAN 100-Base-TX/10-Base-T * Refer to the owner’s manual below for details about network function.
Features and Design This Multimedia Projector is designed with the most advanced technology for portability, durability, and ease of use. This projector utilizes built-in multimedia features, a palette of 16.77 million colors, and matrix liquid crystal display (LCD) technology. ����������������������������� Large Screen in Limited Space Digital Zoom (for Computer) The digital zoom function allows you to focus on crucial information during a presentation. You can expand the images approx.
Table of Contents Features and Design . . . . . . . . . . . . . . . . Table of Contents . . . . . . . . . . . . . . . . . . To the Owner . . . . . . . . . . . . . . . . . . . . . . Safety Instructions . . . . . . . . . . . . . . . . . 2 3 4 5 Air Circulation 6 Installing the Projector in Proper Position 6 Moving the Projector 6 Compliance . . . . . . . . . . . . . . . . . . . . . . .
To the Owner Before installing and operating the projector, read this manual thoroughly. The projector provides many convenient features and functions. Operating the projector properly enables you to manage those features and maintain it in good condition for many years to come. Improper operation may result in not only shortening the product life, but also malfunctions, fire hazard, or other accidents.
Safety Instructions All the safety and operating instructions should be read before the product is operated. Read all of the instructions given here and retain them for later use. Unplug this projector from AC power supply before cleaning. Do not use liquid or aerosol cleaners. Use a damp cloth for cleaning. This projector should be operated only from the type of power source indicated on the marking label.
Safety Instructions Air Circulation Openings in the cabinet are provided for ventilation. To ensure reliable operation of the product and to protect it from overheating, these openings must not be blocked or covered. Installing the Projector in Proper Position Install the projector properly. Improper Installation may reduce the lamp life and cause fire hazard. Do not roll the projector more than 20 degrees from side to side. CAUTION Do not point the projector up to project an image.
Compliance Federal Communications Commission Notice This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy. If it is not installed and used in accordance with the instructions, it may cause harmful interference to radio communications.
Part Names and Functions Front ① Focus Lever ② Projection Lens ③ Lens Cover (See p. 53 for attaching) CAUTION ① ② ① ③ ④ Do not turn on the projector with putting the lens cover on. The light beam may damage lens cover and result in fire hazard. Attach the lens cover while the projector is not in use to avoid scratching the lens surface. ⑤ ④ Exhaust Vents Back ④ ⑥ ⑨ ⑦ CAUTION ⑩ Hot air is exhausted from the exhaust vent. Do not put heat-sensitive objects near this side.
Part Names and Functions Rear Terminal ① ② ③ ④ ⑤ ⑥ ⑦ (VARIABLE) COMPUTER IN 2 / R AUDIO OUT L COMPUTER / COMPONENT MONITOR OUT VIDEO IN S-VIDEO IN ⑨ ① COMPUTER IN 1/COMPONENT IN Connect output signal from a computer, RGB scart 21-pin video output, or component video output to this terminal (pp.14, 16). When the cable is of the longer variety, it is advisable to use this terminal and not COMPUTER IN 2/MONITOR OUT.
Part Names and Functions Top Control ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ① SELECT button –Execute the selected item (p.20). –Expand or compress the image in Digital zoom mode (p.33). ② ON–OFF button Turn the projector on or off (pp.18-19). ③ MENU button Open or close the On-Screen Menu (p.20). ④ POWER indicator –Lights red when the projector is in stand-by mode. –Lights green during operations. –Blinks green in the Power management mode (pp.45, 61).
Part Names and Functions Remote Control ① POWER ON/STAND-BY button ③ ② Turn the projector on or off (pp.18, 19). ① ② VIDEO button Select VIDEO input port (pp.23, 34). ③ COMPUTER button Select COMPUTER input port (pp.23, 25, 35). ④ MENU button Open or close the On-Screen Menu (p.20). ⑤ Point ▲▼◄► (VOLUME + / –) buttons ④ ⑮ – Select an item or adjust the value in the On-Screen Menu. (p.20) – Pan the image in Digital zoom + mode (p.33). – Adjust the volume level (Point ◄► buttons) (p.23).
Part Names and Functions Remote Control Battery Installation 1 Open the battery compartment lid. 2 3 Install new batteries into the compartment. Replace the compartment lid. Two AA size batteries For correct polarity (+ and –), be sure battery terminals are in contact with pins in the compartment. To ensure safe operation, please observe the following precautions: ● Use two (2) AA or LR6 type alkaline batteries. ● Always replace batteries in sets. ● Do not use a new battery with a used battery.
Installation Positioning the Projector For the projector positioning, see the figures below. The projector should be set perpendicularly to the plane of the screen. Note: •This projector is not equipped with an optical zoom. To adjust the screen size, change the throw distance. • The brightness in the room has a great influence on picture quality. It is recommended to limit the ambient lighting in order to get the best image. •All measurements are approximate and may vary from the actual sizes. 3.
Installation Connecting to a Computer Cables used for connection • VGA Cables (Mini D-sub 15 pin)* • Audio Cables (Mini Plug: stereo) (*One cable is supplied; other cables are not supplied with the projector.) Audio Output Monitor Output VGA cable Audio cable (stereo) COMPUTER IN 1/ COMPONENT IN Monitor Output or Monitor Input External Audio Equipment Audio Input VGA cable Audio cable (stereo) COMPUTER IN 2/ MONITOR OUT This terminal is switchable.
Installation Connecting to Video Equipment Cables used for connection • Video and Audio Cable (RCA x 3) • S-VIDEO Cable • Audio Cable (Mini Plug: stereo) (Cables are not supplied with the projector.
Installation Connecting to Component Video Equipment Cables used for connection • Audio Cables (Mini Plug: stereo) • Scart-VGA Cable • Component Cable • Component-VGA Cable (Cables are not supplied with the projector.
Installation Connecting the AC Power Cord This projector uses nominal input voltages of 100–120 V or 200–240 V AC and it automatically selects the correct input voltage. It is designed to work with single-phase power systems having a grounded neutral conductor. To reduce the risk of electrical shock, do not plug into any other type of power system. If you are not sure of the type of power being supplied, consult your authorized dealer or service station.
Basic Operation Turning On the Projector 1 Complete peripheral connections (with a computer, VCR, etc.) before turning on the projector. 2 Connect the projector’s AC power cord into an AC outlet. The POWER indicator turns red. Open the lens cover. 3 Press the POWER ON/STAND-BY button on the remote control. The POWER indicator becomes green and the cooling fans start to operate. The preparation display appears on the screen and the count down starts.
Basic Operation Turning Off the Projector 1 Press the POWER ON/STAND-BY button on the remote control, and “Power off?” appears on the screen. 2 Press the POWER ON/STAND-BY button again to turn off the projector. The POWER indicator starts to blink red, and the cooling fans keep running. (You can select the level of the fans’ quietness and running speed. See page 49.) At this time you can unplug the AC power cord even if the fans are still running.
Basic Operation How to Operate the On-Screen Menu The projector can be adjusted or set via the On-Screen Menu. For each adjustment and setting procedure, refer to the respective sections in this manual. Top Control 1 Press the MENU button on the top control or on the remote control to display the On-Screen Menu. MENU button 2 Use the Point ◄► buttons to select a Menu icon; use the Point ▲▼ buttons to select an item. POINT buttons 3 Press the SELECT button to show the item data.
Basic Operation Menu Bar For detailed functions, see Menu Tree on pages 59-60. For computer source ① ① ② ③ ④ Guide Window ⑦ Shows the selected Menu of the On-Screen Menu. ② ⑧ PC System Menu PC Adjust Menu ⑨ Used to adjust parameters to match with input signal format (pp.27–29). ⑤ Image Select Menu Image Adjust Menu Used to adjust the computer image from Contrast, Brightness, Color temp., White balance (R/G/B), Sharpness, and Gamma (pp.31–32).
Basic Operation Focus Adjustment Adjust the lens focus with the focus lever. Focus Lever Keystone Correction If a projected picture has keystone distortion, correct the image with the Keystone function. Press the KEYSTONE button on the top control or on the remote control. The keystone dialog box appears. Correct keystone distortion with the Point ▲▼ buttons. Keystone adjustment can be stored (p.41). Reduce the upper width with the Point ▲ button. Reduce the lower width with the Point ▼ button.
Basic Operation Sound Adjustment Direct Operation Top Control Volume VOLUME+/- button Press the VOLUME+/– buttons on the top control or on the remote control to adjust the volume. The volume dialog box appears on the screen for a few seconds. Mute Remote Control Press the MUTE button on the remote control to turn off the sound. To restore the sound to its previous level, press the MUTE button again or press the VOLUME+/– buttons. Mute function is also effective for AUDIO OUT jack.
Basic Operation AUTO PC button Press the AUTO PC button to operate the Auto PC function. See page 27 for more details. D.ZOOM buttons Press the D.ZOOM buttons to zoom in and zoom out the images. See page 33 for more details. NO SHOW button Press the NO SHOW button to black out the image. To restore to normal, press the NO SHOW button again or press any other button. When the projected image is captured and is set as “User” in the Logo selection (p.
Computer Input Input Source Selection Direct Operation Top Control Select either Computer 1 or Computer 2 by pressing the INPUT button on the top control or the COMPUTER button on the remote control. Before using INPUT or COMPUTER button, select the correct input source through Menu operation as described below. INPUT button INPUT button Computer 1 Computer 2 * Video Remote Control COMPUTER button COMPUTER button Computer 1 Computer 2 * *See Notes at the bottom of this page.
Computer Input Computer System Selection The projector automatically tunes to various types of computers based on VGA, SVGA, XGA, SXGA, WXGA, or UXGA with its Multi-scan system and Auto PC Adjustment. If computer is selected as a signal source, the projector automatically detects the signal format and tunes to project proper images without any additional setting. (Signal formats provided in this projector is shown on page 62.
Computer Input Auto PC Adjustment Auto PC Adjustment function is provided to automatically adjust Fine sync, Total dots, Horizontal, and Vertical positions to conform to your computer. Direct Operation Remote Control The Auto PC adjustment function can be operated directly with the AUTO PC button on the remote control. AUTO PC button Menu Operation 1 2 Auto PC adj. Press the MENU button to display the On-Screen Menu. Use the Point ◄► buttons to move the red frame pointer to PC Adjust Menu.
Computer Input Manual PC Adjustment Some computers employ special signal formats which may not be tuned by Multi-scan system of this projector. Manual PC Adjustment enables you to precisely adjust several parameters to match those signal formats. The projector has five independent memory areas (Mode 1–5) to store those parameters manually adjusted, which allows you to recall the setting for a specific computer. 1 Press the MENU button to display the On-Screen Menu.
Computer Input Display area H Use the Point ◄► buttons to adjust the horizontal area displayed by this projector. Display area V Use the Point ◄► buttons to adjust the vertical area displayed by this projector. Reset To reset the adjusted data, select “Reset” and press the SELECT button. A confirmation box appears and then select “Yes.” All adjustments return to their previous figures. Move the red frame pointer to an item and press the SELECT button.
Computer Input Image Level Selection Direct Operation Select an image level from among Dynamic, Standard, Real, Blackboard (Green), Colorboard, Image 1, Image 2, Image 3, and Image 4 with the IMAGE button on the remote control. Dynamic For viewing pictures in a bright room. Standard Normal picture level preset on the projector. Remote Control IMAGE button Dynamic Standard IMAGE button Real Blackboard(Green) Real Picture level with improved halftone for graphics.
Computer Input Image Level Adjustment 1 Press the MENU button to display the On-Screen Menu. Use the Point ◄► buttons to move the red frame pointer to the Image Adjust Menu icon. 2 Use the Point ▲▼ buttons to move the red frame pointer to the desired item, and then press the SELECT button. The level of each item is displayed. Use the Point ◄►buttons to adjust each level. Image Adjust Menu Image Adjust Menu icon Move the red frame pointer to the desired item and then press the SELECT button.
Computer Input Store To store the adjusted data, select “Store” and press the SELECT button. The Image Level Menu appears. Use the Point ▲▼ buttons to choose one of the four image level and press the SELECT button. A confirmation box appears and then select “Yes.” The stored data can be called up by selecting “Image” in the Image Level Selection on page 30. Move the red frame pointer to the desired image level (from Image 1 to 4) and then press the SELECT button. Quit Exit the Image Adjust Menu.
Computer Input Custom Adjust the screen scale and position manually with this function. Press the SELECT button at Custom and the “Custom” is displayed on the screen for a few seconds and then the Aspect dialog box appears. Scale H/V……… Adjust the Horizontal/Vertical screen scale. H&V …………… When set to “On,” the aspect ratio is fixed. “Scale V” appears dimmed and becomes unavailable. Adjust “Scale H,” then the screen scale is automatically modified based on the aspect ratio.
Video Input Input Source Selection (Video, S-video) Direct Operation Top Control Select Video by pressing the INPUT button on the top control or the VIDEO button on the remote control. Before using INPUT or VIDEO button, select the correct input source through menu operation as described below. INPUT button INPUT button Video Computer 1 Computer 2 * *See Notes at the bottom of this page. Remote Control VIDEO button Video Menu Operation 1 Use the MENU button to display the On-Screen Menu.
Video Input Input Source Selection (Component, RGB Scart 21-pin) Direct Operation Top Control Select Computer 1 by pressing the INPUT button on the top control or COMPUTER button on the remote control. Before using INPUT or COMPUTER button, select the correct input source through Menu operation as described below. INPUT button INPUT button Computer 1 * Computer 2 Video Remote Control COMPUTER button COMPUTER button Computer 1 Computer 2 * *See Note at the bottom of this page.
Video Input Video System Selection 1 Press the MENU button to display the On-Screen Menu. Use the Point ◄► buttons to move the red frame pointer to the AV System Menu icon. 2 Use the Point ▲▼ buttons to move the red arrow pointer to the desired system and then press the SELECT button. Video or S-video Auto The projector automatically detects an incoming video system, and adjusts itself to optimize its performance. When Video System is PAL-M or PAL-N, select the system manually. PAL/SECAM/NTSC/NTSC4.
Video Input Image Level Selection Direct Operation Select an image level from among Dynamic, Standard, Cinema, Blackboard (Green), Colorboard, Image 1, Image 2, Image 3, and Image 4 with the IMAGE button on the remote control. Dynamic For viewing pictures in a bright room. Standard Normal picture level preset on this projector. Remote Control IMAGE button Dynamic Standard IMAGE button Cinema Picture level adjusted for the picture with fine tone.
Video Input Image Level Adjustment 1 Press the MENU button to display the On-Screen Menu. Use the Point ◄► buttons to move the red frame pointer to the Image Adjust Menu icon. 2 Use the Point ▲▼ buttons to move the red frame pointer to the desired item and then press the SELECT button. The level of each item is displayed. Adjust each level by pressing the Point ◄► buttons. Image Adjust Menu Image Adjust Menu icon Move the red frame pointer to the desired item and then press the SELECT button.
Video Input Sharpness Press the Point ◄ button to decrease the sharpness of the image; press the Point ► button to increase the sharpness of the image (from 0 to 15). Gamma Use the Point ◄► buttons to adjust the gamma value to get better balance of contrast (from 0 to 15). Noise reduction Noise interference on the screen can be reduced. Select one of the following options to get smoother images. Off……… Disabled.
Video Input Screen Size Adjustment This projector has the picture screen resize function, which enables you to customize the image size. 1 Press the MENU button to display the On-Screen Menu. Use the Point ◄► buttons to move the red frame pointer to the Screen Menu icon. 2 Use the Point ▲▼ buttons and move the red frame pointer to the desired function and then press the SELECT button. Normal Screen Menu Screen Menu icon Move the red frame pointer to the desired function and press the SELECT button.
Setting Setting This projector has Setting menu that allows you to set up the other various functions described as follows: 1 Press the MENU button to display the On-Screen Menu. Use the Point ◄► buttons to move the red frame pointer to the Setting Menu icon. 2 Use the Point ▲▼ buttons to move the red frame pointer to the item that you want to set and then press the SELECT button. The Setting dialog box appears.
Settin� Lo�o (Lo�o and Lo�o PIN code lock settin�s) Lo�o select This function allows you to customize the screen logo with Logo select, Capture, and Logo PIN code lock functions. Note: When “On” is selected in Logo PIN code lock function, Logo select and Capture functions cannot be selected.
Settin� Lo�o PIN code lock Lo�o PIN code lock This function prevents an unauthorized person from changing the screen logo. Off…… the screen logo can be changed freely from the Logo select menu (p.42). On…… the screen logo cannot be changed without the Logo PIN code. If you want to change the Logo PIN code lock setting, enter a Logo PIN code along the following steps. The initial Logo PIN code is set “4321” at the factory.
Setting Ceiling Ceiling When this function is set to “On”, the picture is top/bottom and left/right reversed. This function is used to project the image from a ceiling-mounted projector. Rear When this function is set to “On”, the picture is left/right reversed. This function is used to project the image to a rear projection screen. Rear Screen aspect This function is used to project the image to a 4:3 or 16:9 projection screen. 4:3 ..... Set to a 4:3 projection screen. 16:9 .....
Setting Standby mode This function is available when operating the projector via network. Normal........ Supply the power to the network function even after turning off the projector You can turn on/ off the projector via network, modify network environment, and receive an e-mail about projector status while the projector is powered off. Eco.............
Setting On start On start When this function is set to “On,” the projector is automatically turned on just by connecting the AC power cord to an outlet. Note: Be sure to turn the projector off properly (see “Turning Off the Projector” on page 19). If the projector is turned off in the incorrect sequence, the On start function does not operate properly. Lamp control You can change the brightness of the screen.
Setting Security (Key lock and PIN code lock settings) This function allows you to use Key lock and PIN code lock function to set the security for the projector operation. Key lock This function locks operation of the top control or the remote control. It is useful to prevent operation by an unauthorized person. ……not locked. Key lock ……lock the operation of the top control. To unlock, use the remote control. ……lock the operation of the remote control.
Setting Enter a PIN code Enter a PIN code Select a number by pressing the Point ▲▼ buttons. And then press the Point ◄► button to fix the number and move the pointer. The number changes to "". If you fixed an incorrect number, move the pointer to the number you want to correct by pressing the Point ◄► button, and then select the correct number by pressing the Point ▲▼ buttons. Repeat this step to complete entering a four-digit number.
Setting Fan This function provides the following options in the cooling fans’ operation after turning off the projector (p.19). L1 …… Normal operation L2 …… Slower and lower-sound than the normal operation (L1), but it takes longer to cool down the projector. Note: Setting “Fan control” to On1 or On2 affects L2 operation in “Fan.” Fan control Choose the running speed of cooling fans from the following options according to the ground elevation under which you use the projector. Off.............
Settin� Warnin� lo� This function records anomalous operations while the projector is in operation and use it when diagnosing faults. Up to 10 warning logs are displayed with the latest warning message at the top of the list, followed by previous warning messages in chronological order. Note: When the Factory default function is executed, all the warning log records will be deleted.
Maintenance and Cleaning Warning Indicator The WARNING indicator shows the state of the function which protects the projector. Check the state of the WARNING indicator and the POWER indicator to take proper maintenance. The projector is shut down and the WARNING indicator is blinking red. Top Control WARNING blinking red Top Control WARNING emit a red light When the temperature inside the projector reaches a certain level, the projector is automatically shut down to avoid overheating.
Maintenance and Cleaning Cleaning the Air Filters Air filters prevent dust from accumulating on the surface of the optical elements inside the projector. Should the air filters become clogged with dust particles, they will reduce cooling fans’ effectiveness and may result in a buildup of internal heat and adversely affect the life of the projector. Clean the air filters by following the steps below. 1 2 3 4 Turn off the projector, and unplug the AC power cord from the AC outlet.
Maintenance and Cleaning Attaching the Lens Cover When moving the projector or while it is not in use, replace the lens cover. 1 Thread the string through the hole on the lens cover and then tie a knot in the string to secure it in place. 2 Thread the other end of the string through the hole on the bottom of the projector. Then pass the lens cover through the resulting loop of the string and pull it to tighten the knot.
Maintenance and Cleaning Lamp Replacement When the projection lamp of the projector reaches the end of its life, the LAMP REPLACE indicator emits a yellow light. If this indicator lights yellow, replace the lamp with a new one promptly. WARNING: TURN OFF THE UV LAMP BEFORE OPENING THE LAMP COVER This indicator turns yellow when the projection lamp reaches the end of its life.
Maintenance and Cleaning Lamp Replacement Counter Be sure to reset the Lamp replacement counter after the lamp is replaced. When the Lamp replacement counter is reset, the LAMP REPLACE indicator stops lighting. Lamp counter Turn the projector on and press the MENU button Lamp counter to display the On-Screen Menu. Use the Point ◄► buttons to move the red frame pointer to the Setting To reset the lamp counter, Menu icon. move the pointer to 1 2 3 Reset and then press the SELECT button.
Appendix Troubleshooting Before calling your dealer or service center for assistance, check the items below once again. – Make sure you have properly connected the projector to peripheral equipment as described on pages 14-16. – Make sure all equipment is connected to the AC outlet and the power is turned on. – When you operate the projector with a computer and it does not project an image, restart the computer.
Appendix Picture is not bright enough. –����������������������������������������������������������������� ��������������������������������������������������������������� Check if "Contrast" or "Brightness" are adjusted properly ����� (see pages 31������ , ���� 38)�. –���������������������������������������������������������������� ��������������������������������������������������������������� Check if "Image level" is selected properly ������������������� (see pages 30������ , ���� 37)�.
Appendix Indicator blinks or lights. – �������������������������������������������������������������������� Check the status of the projector with referring to "indicators and Projector Condition" (see page 61). Computer 2 cannot be selected. – ��������������������������������������������������������� Select Computer 2 in the Terminal function (see page 44). The terminal function cannot be selected.
Appendix Menu Tree Computer Input/Video Input Input Computer 1 RGB Go to System (1) Component Go to System (2) RGB( Scart ) Quit Computer 2 Go to System (1) Video Auto Go to System (3) Video Go to System (3) S-video Go to System (3) Quit Sound Sound Volume 0 - 63 Mute On / Off Quit Computer Input System (1) Mode 1 Mode 2 SVGA 1 ---Systems displayed in the System Menu vary depending on an input signal. PC Adjust Auto PC adj.
Appendix Setting Video Input System (2) System (3) Image Select Image Adjust Setting Auto 1080i 1035i 720p 575p 480p 575i 480i Keystone Blue back Display Logo Dynamic Standard Cinema Blackboard (Green) Colorboard Image 1 Image 2 Image 3 Image 4 Contrast Brightness Color Tint Color temp.
Appendix Indicators and Projector Condition Check the indicators for projector condition. Indicators POWER red/green WARNING red Projector Condition LAMP REPLACE yellow The projector is off. (The AC power cord is unplugged.) The projector is preparing for stand-by or the projection lamp is being cooled down. The projector cannot be turned on until cooling is completed. The projector is ready to be turned on with the POWER ON/STAND-BY button. The projector is operating normally.
Appendix Compatible Computer Specifications Basically this projector can accept the signal from all computers with the V-, H-Frequency mentioned below and less than 140 MHz of Dot Clock. When selecting these modes, Screen, Auto PC adjustment and PC adjustment can be limited. 62 ON-SCREEN DISPLAY RESOLUTION H-Freq. (kHz) V-Freq. (Hz) VGA1 VGA2 VGA3 VGA4 VGA5 VGA6 VGA7 MAC LC13 MAC 13 480p 575p 640x480 720x400 640x400 640x480 640x480 640x480 640x480 640x480 640x480 640x480 768x575 31.47 31.47 31.
Appendix Technical Specifications Mechanical Information Projector Type Dimensions (W x H x D) Net Weight Feet Adjustment Multi-media Projector 12.59" x 5.73" x 11.85" (319.9 mm x 145.5 x 300.9 mm) (Not including protrusions) 7.5 lbs (3.4 kg) 0˚ to 10.0˚ Panel Resolution LCD Panel System Panel Resolution Number of Pixels 0.
Appendix Accessories Owner’s Manual(CD-ROM) Network Application (CD-ROM) Quick Reference Guide AC Power Cord Remote Control and Batteries VGA Cable Lens Cover with String PIN Code Label ● The specifications are subject to change without notice. ● LCD panels are manufactured to the highest possible standards. Even though 99.99% of the pixels are effective, a tiny fraction of the pixels (0.01% or less) may be ineffective by the characteristics of the LCD panels.
Appendix PJ Link Notice This projector is compliant with PJLink Standard Class 1 of JBMIA (Japan Business Machine and Information System Industries Association). This projector supports all commands defined by PJLink Class 1 and is verified conformance with PJLink Standard Class 1. For PJ Link password, see page 21 on the owner’s manual “Network Set-up and Operation.
Appendix Configurations of Terminals COMPUTER INPUT/COMPONENT INPUT/MONITOR OUTPUT TERMINAL (ANALOG) Terminal : Analog RGB (Mini D-sub 15 pin) 4 5 10 15 3 9 14 2 8 13 12 1 2 3 4 5 6 7 8 1 7 6 11 Red (R/Cr) Input / Output Green (G/Y) Input / Output Blue (B/Cb) Input / Output ----Ground (Horiz.sync.
Appendix PIN Code Number Memo Write down the PIN code number in the column below and keep it with this manual securely. If you forgot or lost the number and unable to operate the projector, contact the service station. PIN Code Lock No. Factory default set No: 1 2 3 4* Logo PIN Code Lock No. Factory default set No: 4 3 2 1* While the projector is locked with the PIN code... Put the label below (supplied) to a prominent place of the projector’s body while it is locked with a PIN code.
KM5AZ SANYO Electric Co., Ltd.
