Multimedia Projector MODEL PLC-XL50A Owner’s Manual
Features and Design This Multimedia Projector is designed with the most advanced technology for portability, durability, and ease of use. This projector utilizes built-in multimedia features, a palette of 16.77 million colors, and matrix liquid crystal display (LCD) technology. ◆ Large Screen in Limited Space Short focus lens allows you to project large images from short distance (p.14). Images can be projected on the floor.
Table of Contents Features and Design . . . . . . . . . . . . . . . . . . . . . . . . 2 Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 To the Owner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . .
To the Owner Before installing and operating this projector, read this manual thoroughly and operate the projector properly. This projector provides many convenient features and functions. Operating the projector properly enables you to manage those features and maintain it in good condition for many years to come. Improper operation may result in not only shortening the product life, but also malfunctions, fire hazard, or other accidents.
Safety Instructions All the safety and operating instructions should be read before the product is operated. Read all of the instructions given here and retain them for later use. Unplug this projector from AC power supply before cleaning. Do not use liquid or aerosol cleaners. Use a damp cloth for cleaning. Follow all warnings and instructions marked on the projector.
Safety Instructions Air Circulation Moving the Projector Openings in the cabinet are provided for ventilation. To ensure reliable operation of the product and to protect it from overheating, these openings must not be blocked or covered. When the projector is not in use for an extended period, put it into a suitable case. Handle the projector carefully; do not drop, bump, subject it to strong forces, or put other things on the cabinet. CAUTION Hot air is exhausted from the exhaust vent.
Safety Instructions Installing the Projector in Proper Position PLC-XL50 スタンド取り付け穴と 天吊り用穴４カ所共通 Install the projector properly. Improper Installation may reduce the lamp life and cause fire hazard. Side B Side A CAUTION – Do not put anything or sit on the projector, otherwise, it may fall down or cause failure of the projector or injury. Side C Side D Side E Side F 10˚ 10˚ Do not roll the projector more than 10 degrees from side to side. This side is Side A or B.
Compliance Federal Communications Commission Notice This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy. If it is not installed and used in accordance with the instructions, it may cause harmful interference to radio communications.
Part Names and Functions q Infrared Remote Receiver Front CAUTION The Infrared Remote Receiver sticks out beyond the cabinet surface. If the Infrared Remote Receiver is put on the wall or floor directly, the Infrared Remote Receiver may damage.
Part Names and Functions Rear Terminal q w e y y r u q AUDIO IN Connect the audio output from video equipment connected to w, t or y to this jack. [When the audio output is monaural, connect it to L (MONO) jack (p.17-18). w VIDEO IN Connect the composite video output from video equipment to VIDEO jack (p.17). e AUDIO IN COMPUTER Connect the audio output (stereo) from a computer connected to u or i to this jack (pp.16, 18). r AUDIO OUT(VARIABLE) Connect an external audio amplifier to this jack (pp.
Part Names and Functions Top q w e r t o y !0 u i q POWER indicator – Lights red when the projector is in stand-by mode. – Lights green during operations. – Blinks green in the Power management mode (pp.50, 66). w WARNING TEMP. indicator – Lights red when the projector detects an abnormal condition. – Blinks red when the internal temperature of the projector exceeds the operating range (pp.55, 66).
Part Names and Functions Remote Control e w q ON/STAND-BY button Turn the projector on or off (pp.20, 21). q w VIDEO button Select VIDEO input source (pp.25, 37). / e COMPUTER button Select COMPUTER input source (pp.25, 27, 38). r MENU button Open or close the On-Screen Menu (p.22). r !6 t Point ed 7 8 (VOLUME + / –) buttons – Select an item or adjust the value in the On-Screen Menu. (p.22) – Pan the image in Digital zoom + mode (p.36). – Adjust the volume level (Point 7 8 buttons) (p.25).
Part Names and Functions Remote Control Battery Installation 1 Open the battery compartment lid. 2 Install new batteries into the compartment. 3 Replace the compartment lid. Two AA size batteries For correct polarity (+ and –), be sure battery terminals are in contact with pins in the compartment. To ensure safe operation, please observe the following precautions: ● Use two (2) AA or LR6 type alkaline batteries. ● Always replace batteries in sets. ● Do not use a new battery with a used battery.
Installation Positioning the Projector For the projector positioning, see the figures below. The projector should be set perpendicularly to the plane of the screen. A A ✔Note: • This projector is not equipped with an optical zoom. To adjust the screen size, change the throw distance. • The brightness in the room has a great influence on picture quality. It is recommended to limit the ambient lighting in order to get the best image. • All measurements are approximate and may vary from the actual sizes.
Installation Mounting the Rear Leg Rear Leg 1 Turn off the projector and unplug the AC power cord. 2 Secure the rear leg with the four (4) screws. Screw Rear leg ✔Note: • Make sure not to lose screws when installing the rear leg.
Installation Connecting to Computer Cables used for connection • VGA Cables (Mini D-sub 15 pin)* • Audio Cables (Mini Plug: stereo) (*One cable is supplied; other cables are not supplied with the projector.) External Audio Equipment Audio Output Monitor Output or Monitor Input Monitor Output Audio Input VGA cable VGA cable Audio cable (stereo) Audio cable (stereo) AUDIO IN COMPUTER COMPUTER IN 2/ MONITOR OUT COMPUTER IN 1 This terminal is switchable.
Installation Connecting to Video Equipment (Video, S-Video) Cables used for connection • Video and Audio Cable (RCA x 3) • S-VIDEO Cable • Audio Cable (Mini Plug: stereo) (Cables are not supplied with the projector.
Installation Connecting to Video Equipment (Component and RGB Scart) Cables used for connection • Audio Cables (Mini Plug: stereo, RCA x 2) • Scart-VGA Cable • Component Cable (Cables are not supplied with the projector.
Installation Connecting the AC Power Cord This projector uses nominal input voltages of 100–120 V or 200–240 V AC and it automatically selects the correct input voltage. It is designed to work with single-phase power systems having a grounded neutral conductor. To reduce the risk of electrical shock, do not plug into any other type of power system. If you are not sure of the type of power being supplied, consult your authorized dealer or service station.
Basic Operation Turning On the Projector 1 Complete peripheral connections (with a computer, VCR, etc.) before turning on the projector. 2 Connect the projector’s AC power cord into an AC outlet. The POWER indicator turns red. 3 Press the ON/STAND-BY button on the top control or on the remote control. The POWER indicator becomes green and the cooling fans start to operate. The preparation display appears on the screen and the count down starts.
Basic Operation Turning Off the Projector 1 Press the ON/STAND-BY button on the top control or on the remote control, and “Power off?” appears on the screen. 2 Press the ON/STAND-BY button again to turn off the projector. The POWER indicator starts to blink red, and the cooling fans keep running. (You can select the level of the fans’ quietness and running speed. See page 54.) At this time you can unplug the AC power cord even if the fans are still running. 3 “Power off” disappears after 4 seconds.
Basic Operation How to Operate the On-Screen Menu The projector can be adjusted or set via the On-Screen Menu. For each adjustment and setting procedure, refer to the respective sections in this manual. Top Control MENU button 1 Press the MENU button on the top control or on the remote control to display the On-Screen Menu. 2 Use the Point 7 8 buttons to select a Menu icon; use the Point ed buttons to select an item. 3 Press the SELECT button to show the item data.
Basic Operation Menu Bar For detailed functions, see Menu Tree on pages 63-64. For computer source q w e r q Guide Window Shows the selected Menu of the On-Screen Menu. w Input Menu Used to select the input source, Computer or Video (p.27). e PC System Menu Used to select the computer system (p.28). t y u i o y Image Adjust Menu Used to adjust the computer image from Contrast, Brightness, Color temp., White balance (R/G/B), Sharpness, and Gamma (pp.34-35).
Basic Operation Top Control Zoom Adjustment ZOOM +/- buttons Press the ZOOM +/- buttons on the top control to adjust the screen size. Screen size can be adjusted 84% to 100% from its maximum screen size. It is not available when On-Screen menu is displayed. Zoom adjustment can be memorized. (p.45) Screen Position Adjustment Screen position can be adjusted in the Zoom Adjustment. 1 Press the ZOOM+ or ZOOM- buttons on the top control.
Basic Operation Sound Adjustment Direct Operation Top Control Volume / Press the VOLUME+/– buttons on the top control or on the remote control to adjust the volume. The volume dialog box appears on the screen for a few seconds. Mute Press the MUTE button on the remote control to turn off the sound. To restore the sound to its previous level, press the MUTE button again or press the VOLUME+/– buttons. Mute function is also effective for AUDIO OUT jack.
Basic Operation / AUTO PC button Press the AUTO PC button to operate the Auto PC function. See page 24 for more details. D.ZOOM buttons Press the D.ZOOM buttons to zoom in and zoom out the images. See page 36 for more details. Remote Control IMAGE button D.ZOOM buttons CEILING button Press the CEILING button to reverse the top/bottom and left/right of image (p49). NO SHOW button Press the NO SHOW button to black out the image.
Computer Input Input Source Selection Direct Operation Top Control INPUT button INPUT button Press the INPUT button on the top control or the COMPUTER button on the remote control to select either Computer 1 or Computer 2. Before using the INPUT or COMPUTER buttons, select the correct input source through Menu operation as described below. Computer 1 Computer 2* Video Remote Control COMPUTER button / COMPUTER button Computer 1 Computer 2* *See Notes at the bottom of this page.
Computer Input Computer System Selection The projector automatically tunes to various types of computers with its Multi-scan system and Auto PC Adjustment. If computer is selected as a signal source, the projector automatically detects the signal format and tunes to project proper images without any additional setting. (Signal formats provided in this projector is shown on page 67.
Computer Input / Auto PC Adjustment Auto PC Adjustment function is provided to automatically adjust Fine sync, Total dots, Horizontal, and Vertical positions to conform to your computer. Direct Operation Remote Control The Auto PC adjustment function can be operated directly with the AUTO PC button on the remote control. AUTO PC button CEILING Menu Operation Auto PC Adj. 1 2 Press the MENU button to display the On-Screen Menu. Use the Point 7 8 buttons to move the red frame pointer to PC Adjust Menu.
Computer Input Manual PC Adjustment Some computers employ special signal formats which may not be tuned by Multi-scan system of this projector. Manual PC Adjustment enables you to precisely adjust several parameters to match those signal formats. The projector has five independent memory areas (Mode 1–5) to store those parameters manually adjusted, which allows you to recall the setting for a specific computer. 1 Press the MENU button to display the On-Screen Menu.
Computer Input Display area H Use the Point 7 8 buttons to adjust the horizontal area displayed by this projector. Display area V Use the Point 7 8 buttons to adjust the vertical area displayed by this projector. Reset To reset the adjusted data, select “Reset” and press the SELECT button. A confirmation box appears and then select “Yes.” All adjustments return to their previous figures. Move the red frame pointer to an item and press the SELECT button.
/ Computer Input Image Level Selection Direct Operation Remote Control Select an image level from among Dynamic, Standard, Real, Blackboard (Green), Colorboard, Image 1, Image 2, Image 3, or Image 4 with the IMAGE button on the remote control. Dynamic Standard CEILING Dynamic For viewing pictures in a bright room. Standard Normal picture level preset on the projector. IMAGE button Real Blackboard(Green) Real Picture level with improved halftone for graphics.
Computer Input Menu Operation 1 Press the MENU button to display the On-Screen Menu. Use the Point 7 8 buttons to move the red frame pointer to the Image Select Menu icon. 2 Use the Point ed buttons to move the red frame pointer to the desired level and then press the SELECT button. Image Select Menu icon Image Select Menu Move the red frame pointer to the desired level and press the SELECT button. Dynamic For viewing pictures in a bright room.
Computer Input Image Level Adjustment 1 Press the MENU button to display the On-Screen Menu. Use the Point 7 8 buttons to move the red frame pointer to the Image Adjust Menu icon. 2 Use the Point ed buttons to move the red frame pointer to the desired item, and then press the SELECT button. The level of each item is displayed. Use the Point 7 8 buttons to adjust each level. Image Adjust Menu Image Adjust Menu icon Move the red frame pointer to the desired item and then press the SELECT button.
Computer Input Store To store the adjusted data, select “Store” and press the SELECT button. The Image Level Menu appears. Use the Point ed buttons to choose one of the four image level and press the SELECT button. A confirmation box appears and then select “Yes.” The stored data can be called up by selecting “Image” in the Image Level Selection on pages 32-33. Move the red frame pointer to the desired image level (from Image 1 to 4) and then press the SELECT button. Quit Exit the Image Adjust Menu.
Computer Input / For zooming in and out the images Remote Control Digital zoom + POINT buttons When Digital zoom + is selected, the On-Screen Menu disappears and “D. zoom +” is displayed. Press the SELECT button to expand the image size. Use the Point ed7 8 buttons to pan the image. The Panning function can work only when the image is larger than the screen size. A projected image can be also expanded by pressing the D.ZOOM e button on the remote control. SELECT button D.ZOOM + button CEILING D.
Video Input Input Source Selection (Video, S-Video, Component) Direct Operation Top Control INPUT button Press the INPUT button on the top control or VIDEO button on the remote control to select “Video.” Before using the INPUT or VIDEO buttons, select the correct input source through menu operation as described below. INPUT button Video Computer 1 Computer 2* Menu Operation 1 Use the MENU button to display the On-Screen Menu.
Video Input Input Source Selection (RGB Scart 21-pin) Direct Operation Top Control INPUT button Press the INPUT button on the top control or COMPUTER button on the remote control to select Computer 1. Before using INPUT or COMPUTER buttons, select the correct input source through Menu operation as described below. INPUT button Video Computer 1 Computer 2* Remote Control COMPUTER button Menu Operation 1 2 3 / Use the MENU button to display the On-Screen Menu.
Video Input Video System Selection 1 Press the MENU button to display the On-Screen Menu. Use the Point 7 8 buttons to move the red frame pointer to the AV System Menu icon. 2 Use the Point ed buttons to move the red arrow pointer to the desired system and then press the SELECT button. Video or S-Video Auto The projector automatically detects an incoming video system, and adjusts itself to optimize its performance. When Video System is PAL-M or PAL-N, select the system manually. PAL/SECAM/NTSC/NTSC4.
/ Video Input Image Level Selection Direct Operation Select an image level from among Dynamic, Standard, Cinema, Blackboard (Green), Colorboard, Image 1, Image 2, Image 3, and Image 4 with the IMAGE button on the remote control. Dynamic For viewing pictures in a bright room. Standard Normal picture level preset on this projector. IMAGE button Dynamic Standard CEILING IMAGE button Cinema Blackboard (Green) Colorboard Cinema Picture level adjusted for the picture with fine tone.
Video Input Menu Operation 1 Use the MENU button to display the On-Screen Menu. Press the Point 7 8 buttons to move the red frame pointer to the Image Select Menu icon. 2 Use the Point ed buttons to move the red frame pointer to the desired level and then press the SELECT button. Image Select Menu Image Select Menu icon Move the red frame pointer to the desired image level and press the SELECT button. Dynamic For viewing picture in a bright room.
Video Input Image Level Adjustment 1 Press the MENU button to display the On-Screen Menu. Use the Point 7 8 buttons to move the red frame pointer to the Image Adjust Menu icon. 2 Use the Point ed buttons to move the red frame pointer to the desired item and then press the SELECT button. The level of each item is displayed. Adjust each level by pressing the Point 7 8 buttons.
Video Input Sharpness Press the Point 7 button to decrease the sharpness of the image; press the Point 8 button to increase the sharpness of the image (from 0 to 15). Gamma Use the Point 7 8 buttons to adjust the gamma value to get better balance of contrast (from 0 to 15). Noise reduction Noise interference on the screen can be reduced. Select one of the following options to get smoother images. Off……… Disabled.
Video Input Screen Size Adjustment This projector has the picture screen resize function, which enables you to customize the image size. 1 Press the MENU button to display the On-Screen Menu. Use the Point 7 8 buttons to move the red frame pointer to the Screen Menu icon. 2 Use the Point ed buttons and move the red frame pointer to the desired function and then press the SELECT button. Normal Provide the image at a normal video aspect ratio of 4:3. Wide Provide the image at a wide screen ratio of 16:9.
Setting Setting This projector has Setting menu that allows you to set up the other various functions described as follows: 1 Press the MENU button to display the On-Screen Menu. Use the Point 7 8 buttons to move the red frame pointer to the Setting Menu icon. 2 Use the Point ed buttons to move the red frame pointer to the item that you want to set and then press the SELECT button. The Setting dialog box appears.
Setting Uniformity adj. This function adjusts the brightness uniformity on a screen. Select either Store 1, Store 2 or Reset with the Point 7 8 buttons, and then press the SELECT button. Press the Point 7 8 buttons to adjust the brightness uniformity (from 0 to 7). Store 1…… Store the uniformity adjustment even when the projector is turned off. Reset the uniformity adjustment when the AC power cord is unplugged.
Setting Logo (Logo and Logo PIN code lock settings) Logo select This function allows you to customize the screen logo with Logo select, Capture, and Logo PIN code lock functions. ✔Note: • When “On” is selected in Logo PIN code lock function, Logo select and Capture functions cannot be selected.
Setting Logo PIN code lock Logo PIN code lock This function prevents an unauthorized person from changing the screen logo. Off…… the screen logo can be changed freely from the Logo select menu (p.47). On…… the screen logo cannot be changed without the Logo PIN code. If you want to change the Logo PIN code lock setting, enter a Logo PIN code along the following steps. The initial Logo PIN code is set “4321” at the factory. Enter a Logo PIN code Select a number by pressing the Point ed buttons.
Setting Ceiling Ceiling When this function is set to “On,” the picture is top/bottom and left/right reversed. This function is used to project the image from a ceiling-mounted projector. Rear When this function is set to “On,” the picture is left/right reversed. This function is used to project the image to a rear projection screen. Rear Terminal The COMPUTER IN 2/MONITOR OUT terminal on the back of the projector is switchable for computer input or monitor output (p.10).
Setting Power management Power management For reducing power consumption as well as maintaining the lamp life, the Power management function turns off the projection lamp when the input signal is interrupted and no button is pressed for a certain period. When the input signal is interrupted and no button is pressed for more than 30 seconds, the timer display with “No signal” appears. The countdown starts to turn off the lamp. Time left before Lamp is off. Select one of the operations.
Setting / Remote control This projector provides two different remote control codes; the factory-set, initial code (Code 1) and the secondary code (Code 2). This switching function prevents remote control interference when several projectors or video equipment are operated at the same time. When the projector is operated in “Code 2,” both the projector and the remote control must be switched to “Code 2.” Remote control Press and hold MENU and IMAGE buttons for more than 5 seconds.
Setting PIN code lock PIN code lock This function prevents the projector from being operated by unauthorized persons and provides the following setting options for security. Off…… The projector is not locked with the PIN code. On1…… Requires to enter a PIN code every time turning on the projector. On2…… Requires to enter a PIN code to operate the projector once the power cord is unplugged; as long as the AC power cord is connected, the projector can be operated without a PIN code.
Setting Change the PIN code lock setting Select Off, On1, or On2 with the Point 7 8 buttons and then move the red frame pointer to “Quit” with the Point d button. Press the SELECT button to close the dialog box. Change the PIN code lock setting Select a desired setting with the Point 7 8 buttons. Change the PIN code The PIN code can be changed to your desired four-digit number. Select "PIN code change" with the Point d button, and press the SELECT button to display the New PIN code input dialog box.
Setting Lamp Replacement icon Lamp counter This function is used to reset the lamp counter. When the lamp life is left less than 100 hours, the Lamp replacement icon appears on the screen, indicating that the end of lamp life is approaching. When the lamp life is counted down to 0 hour, the Lamp replacement icon (Fig.2) will appear on the screen, indicating that the end of lamp life is reached. When replacing the projection lamp, reset the lamp counter. See “Lamp Replacement Counter” on page 59.
Maintenance and Cleaning Warning Indicator The WARNING indicator shows the state of the function which protects the projector. Check the state of the WARNING indicator and the POWER indicator to take proper maintenance. The projector is shut down and the WARNING TEMP. indicator is blinking red. When the temperature inside the projector reaches a certain level, the projector is automatically shut down to avoid overheating. The POWER indicator is blinking while the projector is being cooled down.
Maintenance and Cleaning Cleaning the Air Filter The air filter prevents dust from accumulating on the surface of the optical elements inside the projector. Should the air filter become clogged with dust particles, it will reduce cooling fans’ effectiveness and may result in a buildup of internal heat and adversely affects the life of the projector. Clean the air filter by following the steps below. 1 Turn off the projector, and unplug the AC power cord from the AC outlet.
Maintenance and Cleaning Cleaning the Projection Window CAUTION This projector is equipped with a projection window. Do not rub the projection window with a hard fiber cloth or hit it with a something hard to prevent the projection window from scratching. Do not use a chemical cleaner (liquid and solid) to avoid deteriorating the projection window. Unplug the AC power cord before cleaning. First, remove the dust with a blower. Then gently wipe the projection window surface.
Maintenance and Cleaning Lamp Replacement When the projection lamp of the projector reaches its end of life, the Lamp replacement icon appears on the screen and LAMP REPLACE indicator lights yellow. Replace the lamp with a new one promptly. The timing when the LAMP REPLACE indicator should light is depending on the lamp mode.
Maintenance and Cleaning Lamp Replacement Counter Be sure to reset the Lamp replacement counter after the lamp is replaced. When the Lamp replacement counter is reset, the LAMP REPLACE indicator stops lighting. 1 Turn the projector on and press the MENU button to display the On-Screen Menu. Use the Point 7 8 buttons to move the red frame pointer to the Setting Menu icon. 2 Use the Point ed buttons to move the red frame pointer to Lamp counter and then press the SELECT button.
Appendix Troubleshooting Before calling your dealer or service center for assistance, check the items below once again. – Make sure you have properly connected the projector to peripheral equipment as described on pages 16-18. – Make sure all equipment is connected to the AC outlet and the power is turned on. – When you operate the projector with a computer and it does not project an image, restart the computer. Problem: – Solutions No power – Plug the power cord of the projector into the AC outlet.
Appendix Image is out of focus. – Adjust focus of the projector (see page 24). – Provide proper distance between the projector and the projection screen (see page 14). – Check the projection window to see if it needs cleaning (see page 57). – Moving the projector from a cool to warm place may result in moisture condensation on the projection lens. If this occurs, leave the projector off and wait until condensation evaporates.
Appendix The Remote Control does not work. – Check the batteries. – Make sure no obstruction is between the projector and the remote control. – Make sure you are not too far from the projector when using the remote control. Maximum operating range is 11.5’ (3.5 m). – Make sure the code of the remote control is conformed to that of the projector (see page 51). – Unlock the Key lock function for the remote control. See page 51. Indicators blinks or lights.
Appendix Menu Tree Computer Input/Video Input Input Computer 1 RGB Go to System (1) RGB( Scart ) N/A Quit Computer 2 Go to System (1) Video Auto Go to System (2) or (3) Video Go to System (3) S-Video Go to System (3) Component Go to System (2) Quit ✽N/A - - - not applicable Sound Sound Volume 0 - 63 Mute On / Off Quit Computer Input System (1) Mode 1 Mode 2 SVGA 1 ---✽Systems displayed in the System Menu vary depending on an input signal. PC Adjust Auto PC Adj. Fine sync.
Appendix Setting Video Input System (2) Setting Auto 1080i 1035i 720p 575p 480p 575i 480i System (3) Dynamic Standard Cinema Blackboard (Green) Colorboard Image 1 Image 2 Image 3 Image 4 Image Adjust Contrast Brightness Color Tint Color temp. Red Green Blue Sharpness Gamma Noise reduction Progressive Reset Store Zoom 16 languages provided. Quit Store 1 / Store 2 / Reset Keystone Uniformity Adj. Store / Reset Store 1 / Store 2 / Reset Blue back Display Logo Auto PAL SECAM NTSC NTSC 4.
Appendix Indicators and Projector Condition Check the indicators for projector condition. The projector is operating normally. Indicators POWER red/green WARNING WARNING TEMP. FILTER orange red Projector Condition LAMP REPLACE yellow The projector is off. (The AC power cord is unplugged.) ✽ ✽ The projector is preparing for stand-by or the projection lamp is being cooled down. The projector cannot be turned on until cooling is completed.
Appendix The projector is detecting abnormal condition. Indicators POWER red/green WARNING WARNING TEMP. FILTER orange red LAMP REPLACE yellow ✽ ✽ The temperature inside the projector is abnormally high. The projector cannot be turned on. When the projector is cooled down enough and the temperature returns to normal, the POWER indicator lights red and the projector can be turned on. (The WARNING indicator keeps blinking.) Check and clean the air filters.
Appendix Compatible Computer Specifications Basically this projector can accept the signal from all computers with the V-, H-Frequency mentioned below and less than 140 MHz of Dot Clock. When selecting these modes, PC adjustment can be limited. ON-SCREEN DISPLAY RESOLUTION H-Freq. (kHz) V-Freq. (Hz) ON-SCREEN DISPLAY VGA1 640x480 31.47 59.88 VGA2 720x400 31.47 70.09 VGA3 640x400 31.47 VGA4 640x480 VGA5 RESOLUTION H-Freq. (kHz) V-Freq. (Hz) SXGA1 1152x864 64.20 70.
Appendix Technical Specifications Mechanical Information Projector Type Dimensions (W x H x D) Net Weight Feet Adjustment Multi-media Projector 14.72” x 7.75” x 19.49” (374 mm x 196.8 mm x 495 mm) (Not including Rear leg) 15.9 lbs (7.2 kg) 0˚ to 1.0˚ Panel Resolution LCD Panel System Panel Resolution Number of Pixels 0.8” P-Si TFT Active Matrix type 1,024 x 768 dots 2,359,296 (1,024 x 768 x 3 panels) Signal Compatibility Color System SD/HDTV Signal Scanning Frequency PAL, SECAM, NTSC, NTSC4.
Appendix Accessories Owner’s Manual(CD-ROM) Quick Reference Guide AC Power Cord Remote Control and Batteries VGA Cable PIN Code Label ● The specifications are subject to change without notice. ● LCD panels are manufactured to the highest possible standards. Even though 99.99% of the pixels are effective, a tiny fraction of the pixels (0.01% or less) may be ineffective by the characteristics of the LCD panels. Optional Parts The parts listed below are optionally available.
Appendix Configurations of Terminals COMPUTER INPUT / MONITOR OUTPUT TERMINAL (ANALOG) Terminal : Analog RGB (Mini D-sub 15 pin) 11 6 12 7 8 2 1 13 14 10 9 3 1 2 3 4 5 6 7 8 15 4 5 Red Input / Output Green Input / Output Blue Input / Output 9 10 11 12 13 14 15 ----Ground (Horiz.sync.) Ground (Red) Ground (Green) Ground (Blue) 5V / ----Ground (Vert.sync.) Ground / ----DDC data / ----Horiz. sync. Input/Output (Composite H/V sync.) Vert. sync.
Appendix PIN Code Number Memo Write down the PIN code number in the column below and keep it with this manual securely. If you forgot or lost the number and unable to operate the projector, contact the service station. PIN Code Lock No. Factory default set No: 1 2 3 4* Logo PIN Code Lock No. Factory default set No: 4 3 2 1* *Should the four-digit number be changed, the factory set number will be invalid. While the projector is locked with the PIN code...
