Multimedia Projector MODEL PLC-XP21N PLC-XP18N Owner's Manual
INFORMATION TO THE USER NOTE : This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
IMPORTANT SAFETY INSTRUCTIONS All the safety and operating instructions should be read before the product is operated. Unplug this projector from wall outlet and refer servicing to qualified service personnel under the following conditions: Read all of the instructions given here and retain them for later use. Unplug this projector from AC power supply before cleaning. Do not use liquid or aerosol cleaners. Use a damp cloth for cleaning. a. b. c. d.
TABLE OF CONTENTS PAGE PAGE FEATURES AND DESIGN 5 COMPATIBILITY IMAGE RESOLUTION 5 5 AUTOMATIC MULTISCANNING SYSTEM MULTILANGUAGE MENU DISPLAY LASER POINTER FUNCTION OTHER FEATURES UNPACKING THE PROJECTOR TRADEMARKS 5 5 5 5 5 5 INSTALLATION NAME OF EACH PART OF THE PROJECTOR SETTING-UP THE PROJECTOR MOVING THE PROJECTOR POWER REQUIREMENTS CONNECTING THE PROJECTOR TERMINAL OF THE PROJECTOR CONNECTING THE COMPUTER CONNECTING THE VIDEO EQUIPMENT BEFORE OPERATION CONTROLS AND INDICATORS OPERATION OF T
FEATURES AND DESIGN The projector is a multimedia projector that combines powerful and sophisticated features with easy-to-use, intuitive controls. Built-in multimedia features include audio, a palette of 16.77 million colors and active matrix liquid crystal display (LCD) technology. The projector is ideal for high-performance business, training and imaging applications that demand exceptional color quality.
INSTALLATION NAME OF EACH PART OF THE PROJECTOR FRONT OF THE PROJECTOR PROJECTION LENS INFRARED REMOTE RECEIVER FEET LOCK LATCH AIR INTAKE VENT REMOVABLE LENS COVER FEET LOCK LATCH SPEAKERS REAR OF THE PROJECTOR EXHAUST VENT INFRARED REMOTE RECEIVER CAUTION HOT AIR! Air blown from the exhaust vent is hot. Observe the following when handling your projector or choosing a location to install it. ● Keep heat-sensitive objects away from the exhaust port.
INSTALLATION SETTING-UP THE PROJECTOR ● This projector is basically designed to project on a flat projection surface. ● This projector can be focused from 4.6' (1.4 m) ~ 47.3' (14.4 m). ● Refer to the figure below as an example when positioning the projector to the screen. POSITIONING: 400" Maximum Zoom ROOM LIGHT Minimum Zoom The level of brightness in a room has a great influence on picture quality. It is recommended to limit ambient lighting in order to provide the best image.
INSTALLATION ADJUSTABLE FEET FEET LOCK LATCHES Picture tilt and projection angle can be adjusted by rotating the ADJUSTABLE FEET. Projection angle can be adjusted 0 to 6°. 1. Lift the front of the projector and press the FEET LOCK LATCHES on both sides of the projector. 2. Release the FEET LOCK LATCHES to lock the ADJUSTABLE FEET and rotate the ADJUSTABLE FEET to fine tune the position and the tilt. 3.
INSTALLATION POWER REQUIREMENTS Your projector uses nominal input voltages of 100-120 VAC. The projector automatically selects the correct input voltage. The projector is designed to work with single-phase power systems having a grounded neutral conductor. To reduce the risk of electrical shock, do not plug into any other type of power system. Consult your authorized dealer or service station if you are not sure what type of power is supplied to your building.
CONNECTING THE PROJECTOR TERMINAL OF THE PROJECTOR 5 1 2 3 COMPUTER IN 1 COMPUTER IN 2 MONITOR OUT AUDIO 1 CONTROL PORT 1 (STEREO) AUDIO 2 CONTROL PORT 2 EXT. SP (8Ω) (STEREO) (STEREO) 6 7 12 AV IN 4 COMPUTER REAR OF THE PROJECTOR R AUDIO L (MONO) VIDEO S-VIDEO Y Cb/Pb Cr/Pr 8 9 10 11 1 COMPUTER INPUT-1 TERMINAL Used to connect a computer to the projector. 8 AUDIO INPUT JACKS Used to connect an audio input to the projector.
CONNECTING THE PROJECTOR CONNECTING THE COMPUTER CONNECTING TO THE COMPUTER INPUT TERMINALS (1 and 2) Personal computers can be connected to the HDB15-pin (VGA) terminal on the projector. ● Connect the computer to these terminals using the VGA cable and VGA/Macintosh adapter (provided). CAUTION: For projectors, the VGA cable provided is designed to reduce RFI (Radio Frequency Interference) emissions. For regulatory compliance reasons, this cable must be used and must not be replaced by any other cable.
CONNECTING THE PROJECTOR CONNECTING AN IBM-COMPATIBLE DESKTOP COMPUTER COMPUTER MONITOR CABLE (NOT PROVIDED) COMPUTER OUTPUT VGA CABLE (PROVIDED) AUDIO OUTPUT SERIAL PORT INPUT PS/2 PORT INPUT COMPUTER INPUT 1 or 2 MONITOR OUTPUT MOUSE CABLE FOR PS/2 PORT (PROVIDED) MOUSE CABLE FOR SERIAL PORT (PROVIDED) COMPUTER AUDIO INPUT 1 or 2 COMPUTER AUDIO 1 CONTROL PORT 1 (STEREO) AUDIO 2 CONTROL PORT 2 EXT.
CONNECTING THE PROJECTOR CONNECTING AN IBM-COMPATIBLE LAPTOP COMPUTER COMPUTER COMPUTER OUTPUT AUDIO OUTPUT SERIAL PORT INPUT VGA CABLE (PROVIDED) PS/2 PORT INPUT COMPUTER INPUT 1 or 2 MOUSE CABLE FOR PS/2 PORT (PROVIDED) CONTROL PORT OUTPUT 1 or 2 COMPUTER AUDIO CABLE (NOT PROVIDED) CONTROL PORT 1 (STEREO) AUDIO 2 CONTROL PORT 2 EXT.
CONNECTING THE PROJECTOR CONNECTING A MACINTOSH DESKTOP COMPUTER COMPUTER MONITOR CABLE (NOT PROVIDED) VGA CABLE (PROVIDED) 123456 ON COMPUTER OUTPUT VGA/MAC ADAPTER (PROVIDED) ADB PORT INPUT AUDIO OUTPUT MONITOR OUTPUT COMPUTER INPUT 1 or 2 MOUSE CABLE FOR ADB PORT (PROVIDED) COMPUTER AUDIO 1 MONITOR OUT COMPUTER IN 2 COMPUTER IN 1 CONTROL PORT 1 (STEREO) AUDIO 2 CONTROL PORT 2 EXT.
CONNECTING THE PROJECTOR CONNECTING A MACINTOSH POWERBOOK COMPUTER NOTE: The Macintosh PowerBook requires the use of the PowerBook Video Adapter shipped with the PowerBook. COMPUTER VGA CABLE (PROVIDED) 123456 ON TO POWERBOOK VIDEO ADAPTER VGA/MAC ADAPTER (PROVIDED) AUDIO OUTPUT COMPUTER INPUT 1 or 2 ADB PORT INPUT MOUSE CABLE FOR ADB PORT (PROVIDED) COMPUTER AUDIO 1 MONITOR OUT COMPUTER IN 2 COMPUTER IN 1 CONTROL PORT 1 (STEREO) AUDIO 2 CONTROL PORT 2 EXT.
CONNECTING THE PROJECTOR CONNECTING THE VIDEO EQUIPMENT Connect to the video and audio outputs of a VCR, video disc player, DVD player, video camera, satellite TV tuner or other AV equipment. CONNECTING TO THE VIDEO INPUT JACK Connect the video output from the video equipment to this jack using the video cable. CONNECTING S-VHS VIDEO INPUT JACK Connect the S-VIDEO output from the video equipment to this jack using the S-video cable. The S-VIDEO jack has priority over the VIDEO (composite) jack.
CONNECTING THE PROJECTOR CONNECTING THE VIDEO EQUIPMENT VIDEO EQUIPMENT Video Cassette Recorder L R AUDIO OUTPUT Satellite TV Tuner DVD Player Video Disc Player Video Camera VIDEO OUTPUT VIDEO INPUT COMPUTER CONTROL PORT 1 (STEREO) AUDIO 2 CONTROL PORT 2 EXT.
CONNECTING THE PROJECTOR CONNECTING TO THE EXT. SP. JACK (3.5 mm mini stereo type) This jack outputs stereo speaker sound which viewing on screen. If you use external speaker system, connect stereo type external speaker jack. Internal speaker sound is disconnected when speaker jack is connected. CONTROL PORT 1 (STEREO) AUDIO 2 CONTROL PORT 2 EXT.
BEFORE OPERATION BEFORE OPERATION CONTROLS AND INDICATORS FRONT INDICATORS TOP CONTROLS FRONT INDICATORS LAMP WARNING REPLACE TEMP.
BEFORE OPERATION 1 LAMP REPLACEMENT INDICATOR Light is orange when the Lamp life draws to an end. 2 TEMPERATURE WARNING INDICATOR Flashes red when internal projector temperature is too high. 3 READY INDICATOR Light is green when projector lamp is ready to be turned on. 4 LAMP POWER INDICATOR Light is dim when the projector is on. Light is brightened when the projector is in stand-by mode. 5 POWER ON/OFF BUTTON Used to turn the projector on or off. 6 VOLUME BUTTONS Used to adjust volume.
BEFORE OPERATION OPERATION OF THE REMOTE CONTROL This remote control unit is not only able to operate the projector but also usable as a wireless mouse for a PC. One pointing pad and two click buttons are used for wireless mouse operation. Wireless mouse is usable when PC mouse pointer is displayed on the screen. When the menu or indicator of the projector is displayed on the screen instead of the PC mouse pointer, the wireless mouse cannot be used.
BEFORE OPERATION 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 22 COMPUTER SELECT BUTTON Used to select computer mode. (Computer 1 or Computer 2 Input) VIDEO SELECT BUTTON Used to select video mode. POWER ON/OFF BUTTON Used to turn the projector on or off. ZOOM BUTTONS Used to operate power zoom lens. FOCUS BUTTONS Used to operate power focus system. VOLUME BUTTONS Used to adjust volume. SOUND MUTE BUTTON Used to mute sound. DIGITAL ZOOM BUTTONS Used to operate digital zoom function.
BEFORE OPERATION Remote Control Battery Installation 1 2 Remove the battery compartment lid. Slide the batteries into the compartment. 3 Replace the compartment lid. Note : For correct polarity (+ and terminal), be sure the battery terminals are in contact with the pins in the compartment. Using the Remote Control Unit Point the remote control toward the projector (Receiver window) when pressing the buttons. Maximum operating range for the remote control is about 16.
BEFORE OPERATION CONTROL THE PROJECTOR The projector has two types of operation: DIRECT OPERATION and MENU OPERATION. DIRECT OPERATION allows you to operate the projector by using one button without showing the MENU. In MENU OPERATION mode, you display menus where you can adjust the projector's settings. Follow the instruction for each control.
BEFORE OPERATION MENU OPERATION ADJUST ITEM MODE SELECT TOP CONTROL OF THE PROJECTOR REMOTE CONTROL MENU POINT LEFT/RIGHT SELECT POINT UP/DOWN SELECT MENU POINT LEFT/RIGHT SELECT POINT UP/DOWN SELECT 1.
BEFORE OPERATION 3.
BASIC OPERATION TURNING ON/OFF THE PROJECTOR TO TURN ON THE PROJECTOR Connect the projector to a source (Computer, VCR, Video Camera, Video Disc Player, etc.) using the appropriate terminals on the rear of the projector. (See "CONNECTING THE PROJECTOR" section on pages 11-18). Connect the projector's AC power cord into a wall outlet and turn the MAIN ON/OFF switch (located on the rear of the projector) to the ON position. The LAMP POWER indicator will light RED, the READY indicator will light GREEN.
BASIC OPERATION SOUND VOLUME ADJUSTMENT Press the VOLUME buttons on the remote control unit or on the projector to adjust the volume. The volume display will be displayed on the screen for a few seconds. Pressing volume (+) will increase volume and increase the number on the screen. Pressing volume (-) will decrease volume and decrease the number on the screen. SOUND MUTE FUNCTION Pressing the MUTE button on the remote control unit will mute audio.
BASIC OPERATION NO SHOW FUNCTION Press the NO SHOW button on the remote control unit. The screen will change into black image and the "NO SHOW" is displayed on the screen for a few seconds. This function is cancelled when the NO SHOW button is pressed again or any other function button is pressed. FREEZE PICTURE FUNCTION Press the FREEZE button on the remote control unit to freeze the picture on screen. This function is cancelled when the FREEZE button is pressed again or any other button is pressed.
BASIC OPERATION MENU OPERATION In MENU OPERATION mode, you display menus where you can adjust the projector's settings. You can use the TOP CONTROL OF THE PROJECTOR or the REMOTE CONTROL UNIT. REMOTE CONTROL UNIT TOP CONTROL OF THE PROJECTOR POINT UP BUTTON MENU BUTTON ZOOM FOCUS VOLUME LOCK MENU MODE ON-OFF COMPUTER VIDEO MUTE D.
BASIC OPERATION SOUND ADJUSTMENT You can adjust the sound volume and sound mute ON/OFF switch in the MENU display. 1. Press the MENU BUTTON and the MAIN MENU DISPLAY dialog box will appear. 2. Press the POINT LEFT/RIGHT BUTTON(s) to select SOUND and press the SELECT BUTTON. Another dialog box SOUND ADJUST DISPLAY will appear. 3. Press the POINT DOWN BUTTON and a red arrow will appear. 4. Move the arrow to an item that you want to adjust by pressing the POINT UP/DOWN BUTTON(s). 5.
VIDEO MODE COLOR SYSTEM SELECT This projector is compatible with the six major broadcast video standards: PAL, SECAM, NTSC, NTSC 4.43, PAL-M and PAL-N (COLOR SYSTEMs). When the color system is set to "Auto position", this projector can detect one of 4 systems (PAL, SECAM, NTSC or NTSC 4.43) automatically. However, if the video signal is not strong enough to detect the video format, the projector may not reproduce the proper video image.
VIDEO MODE VIDEO SOURCE SELECT This projector is compatible with 4 types video source input: Composite Video, S-Video, Component Video (Y, Cb, Cr) and Component Video (Y, Pb, Pr). When the video source is set to "Auto" position this projector can detect one of 3 types Composite Video, S-Video and Component Video (Y, Cb,Cr) automatically. However, if the input video source is Component Video (Y, Pb, Pr), the projector may not detect the video source. 1. 2. 3. 4.
VIDEO MODE PICTURE IMAGE ADJUSTMENT Picture adjustments have been preset at the factory. If you want to change the setting, operate the projector as follows. 1. Press MENU BUTTON and the MAIN MENU DISPLAY dialog box will appear. 2. Press the POINT LEFT/RIGHT BUTTON(s) to select IMAGE and press the SELECT BUTTON. Another dialog box IMAGE ADJUST DISPLAY will appear. This shows the current picture settings. 3.
VIDEO MODE PICTURE SCREEN ADJUSTMENT This projector has a picture screen resize function, which enables you to display the image in desirable size. WIDE function This projector is able to project not only a normal video image (with 4 x 3 aspect ratio), but also a wider video image by compressing 4 x 3 image. This feature enable you to enjoy watching pictures like cinema images. You can switch either to WIDE or to REGULAR screen mode. 1.
COMPUTER MODE COMPUTER SYSTEM SELECT This projector is adjustable to different types of computer display signals based on VGA, SVGA, XGA or SXGA (See "COMPATIBLE COMPUTER SPECIFICATIONS" on the next page). If you set MODE SELECT to "COMPUTER", the projector will automatically process the incoming signal and projects the proper image without any special setting. Although this will work in most cases, you may be required to manually set the projector for some computer signals.
COMPUTER MODE COMPATIBLE COMPUTER SPECIFICATIONS ON-SCREEN RESOLUTION DISPLAY VGA1 640 x 480 H-Freq. (kHz) 31.47 V-Freq. (Hz) 59.88 ON-SCREEN RESOLUTION DISPLAY XGA12 1024 x 768 H-Freq. (kHz) 35.522 V-Freq. (Hz) 86.96 (Interlace) VGA2 720 x 400 31.47 70.09 VGA3 640 x 400 31.47 70.09 XGA13 1024 x 768 46.90 58.20 VGA4 640 x 480 37.86 74.38 XGA14 1024 x 768 47.00 58.30 VGA5 640 x 480 37.86 72.81 XGA15 1024 x 768 58.03 72.00 VGA6 640 x 480 37.50 75.
COMPUTER MODE AUTO IMAGE FUNCTION The Auto image function is provided to automatically adjust Fine sync., Total dots and Screen position for most computers. NOTE: This AUTO IMAGE function cannot be operated when "RGB", "HDTV720p", "HDTV1035i" or "HDTV1080i" is selected on the COMPUTER SYSTEM SELECT menu. (See pages 36 ~ 37). 1. Press the MENU BUTTON and the MAIN MENU DISPLAY dialog box will appear. 2. Press the POINT LEFT/RIGHT BUTTON(s) to select AUTO IMAGE and press the SELECT BUTTON.
COMPUTER MODE PICTURE IMAGE ADJUSTMENT Picture adjustments have been preset at the factory. If you want to change the setting, operate the projector as follows. 1. Press the MENU BUTTON and the MAIN MENU DISPLAY dialog box will appear. 2. Press the POINT LEFT/RIGHT BUTTON(s) to select IMAGE and press the SELECT BUTTON. Another dialog box IMAGE ADJUST DISPLAY will appear. This shows the current picture settings. 3.
COMPUTER MODE PICTURE POSITION ADJUSTMENT 1. Press the MENU BUTTON and the MAIN MENU DISPLAY dialog box will appear. 2. Press the POINT LEFT/RIGHT BUTTON(s) to select POSITION and press the SELECT BUTTON. Another dialog box POSITION SETTING DISPLAY will appear. 3. Press the POINT DOWN BUTTON and a red arrow will appear. 4. Move the arrow to a desirable direction ( , , or ) by pressing the POINT LEFT/RIGHT/UP/DOWN BUTTON(s) and press the SELECT BUTTON to a desirable picture position. 5.
COMPUTER MODE PC ADJUSTMENT This projector can automatically detect display signals from most personal computers currently distributed. However, some computers employ a special signal format which is different from the standard one and the projector cannot detect it. If this happens, the projector cannot reproduce a proper image. And a flickering picture, a non-synchronized picture, a non-centered picture or a skewed picture may be projected instead.
COMPUTER MODE 6. Another dialog box "PC ADJUSTMENT DISPLAY 1" will appear and the parameter data for the Mode you have selected is shown in this dialog box. 7. The parameters will be filled with the data determined by the projector according to the present signal input. 8. The function of the parameters and their values are summarized in the table as below. 9. Move the arrow to an item that you want to adjust by pressing the POINT UP/DOWN BUTTON(s). 10.
COMPUTER MODE 17. Another dialog box "PC ADJUSTMENT DISPLAY 2" will appear and the parameter data for the Mode you have selected is shown in this dialog box. 18. Move the arrow to an item that you want to adjust by pressing the POINT UP/DOWN BUTTON(s). 19. To increase the level, point the arrow to ▲ and then press the SELECT BUTTON. To decrease the level, point the arrow to ▼ and then press the SELECT BUTTON. 20.
COMPUTER MODE MODE FREE The Mode free function is provided to confirm or clear the parameter data produced by PC ADJUST. 1. Press the MENU BUTTON and the MAIN MENU DISPLAY dialog box will appear. 2. Press the POINT LEFT/RIGHT BUTTON(s) to select PC ADJUST and press the SELECT BUTTON. Another dialog box "Where to reserve" will appear. 3. Press the POINT DOWN BUTTON and a red arrow will appear. 4.
COMPUTER MODE PICTURE SCREEN ADJUSTMENT This projector has a picture screen resize function, which enables you to display the image in desirable size. 1. Press MENU BUTTON and MAIN MENU DISPLAY dialog box will appear. 2. Press POINT LEFT/RIGHT BUTTON(s) to select SCREEN and press the SELECT BUTTON. Another dialog box SCREEN ADJUST DISPLAY will appear. 3. Press POINT DOWN BUTTON and a red arrow will appear. 4. Move the arrow to the function that you want to adjust.
OTHER FUNCTION SETTING This projector has other functions settings: Blue back, Display, Ceiling, Rear, Split wipe, Power management, Remote control and Lamp age. See the next page menus figure and settings. BLUE BACK (On or Off) When this function is in the "On" position, the projector will project a blue image without video noise on the screen when the video source is unplugged or turned off.
OTHER FUNCTION SETTING REMOTE CONTROL CODE CHANGE (Mode 1 or Mode 2) This projector can be operated with two different code, one is factory-set normal code (MODE 1) and the other one is extended code (MODE 2). This is used to prevent the remote control operation mixture (jam) when two projector and several remote control video equipments are system-up and used together. When you change the code MODE 2, you must change both projector and Remote Control Unit.
OTHER FUNCTION SETTING LAMP AGE The Lamp age function is designed to reset the lamp replacement monitor timer. When replacing the lamp, reset the lamp replacement monitor timer by using this function. NOTE: Do not reset the LAMP REPLACEMENT MONITOR TIMER, except after the lamp is replaced. 1. Press the MENU BUTTON and the MAIN MENU DISPLAY dialog box will appear. 2. Press the POINT LEFT/RIGHT BUTTON(s) to select SETTING and press the SELECT BUTTON. Another dialog box SETTING DISPLAY will appear. 3.
APPENDIX MAINTENANCE TEMPERATURE WARNING INDICATOR The TEMPERATURE WARNING INDICATOR flashes red when the internal temperature of the projector exceeds the normal temperature. Possible causes for the temperature warning may be: 1. Ventilation slots of the projector are blocked. In such an event, reposition the projector so that ventilation slots are not obstructed. 2. Air filter is clogged with dust particles.
APPENDIX LAMP REPLACEMENT If the lamp fails to come on and the lamp monitor on the projector light is orange, you must replace the lamp. ● For continued safety, replace with a lamp assembly of the same type. ● Allow the projector to cool for at least 45 minutes before you open the lamp cover. The inside of the projector can become very hot. ● Do not drop the lamp module or touch the glass bulb ! The glass can shatter and cause injury. Follow these steps to replace the lamp assembly. 1.
APPENDIX CLEANING THE LENS Follow these steps to clean the projection lens: 1. Apply a non-abrasive camera lens cleaner to a soft, dry cleaning cloth. Avoid using an excessive amount of cleaner. Abrasive cleaners, solvents or other harsh chemicals might scratch the lens. 2. Lightly wipe the cleaning cloth over the lens. 3. When you are not using the projector, replace the lens cover. TROUBLESHOOTING Before calling your dealer or service station for assistance, check the items below once again. 1.
APPENDIX Problem: Try these Solutions: Picture is L/R Reversed. Check Ceiling/Rear feature. (See "OTHER FUNCTION SETTING" section on pages 46 ~ 47). Picture is T/B inverted. Check Ceiling feature. (See "OTHER FUNCTION SETTING" section on pages 46 ~ 47). Some displays are not seen during the operation. Check Display feature. (See "OTHER FUNCTION SETTING" section on pages 46 ~ 47). No sound. Remote control unit does not work. Wireless mouse function does not work.
APPENDIX TECHNICAL SPECIFICATIONS Projector Type Multi-media Projector Dimensions (W x H x D) 10.7" (272 mm) x 5.7" (145.5 mm) x 16.2" (412.5 mm) Net Weight 15.2 Ibs (6.9 kg) LCD Panel System 1.3" TFT Active Matrix type x 3 panels Number of Pixels 2,359,296 {786,432 (1,024 x 768) x 3} Color System 6 color system (PAL, SECAM, NTSC, NTSC4.43, PAL-M and PAL-N) Scanning Frequency H-sync. 15 ~ 100 KHz, V-sync.
