Multimedia Projector MODEL PLC-XU75 PLC-XU78 Owner's Manual
Features and Design This Multimedia Projector is designed with the most advanced technology for portability, durability, and ease of use. This projector utilizes built-in multimedia features, a palette of 16.77 million colors, and matrix liquid crystal display (LCD) technology. ◆ Compact Design This projector is designed compact in size and weight. It is easy to carry and work anywhere you wish to use.
Table of Contents Features and Design . . . . . . . . . . . . . 2 Table of Contents . . . . . . . . . . . . . . . 3 To the Owner . . . . . . . . . . . . . . . . . . . 4 Safety Instructions . . . . . . . . . . . . . . 5 Air Circulation 6 Installing the Projector in Proper Position 6 Moving the Projector 6 Compliance . . . . . . . . . . . . . . . . . . . . 7 Part Names and Functions . . . . . . . .
To the Owner Before operating this projector, read this manual thoroughly and operate the projector properly. This projector provides many convenient features and functions. Operating the projector properly enables you to manage those features and maintains it in better condition for a considerable time. Improper operation may result in not only shortening the product-life, but also malfunctions, fire hazard, or other accidents.
Safety Instructions All the safety and operating instructions should be read before the product is operated. Read all of the instructions given here and retain them for later use. Unplug this projector from AC power supply before cleaning. Do not use liquid or aerosol cleaners. Use a damp cloth for cleaning. Follow all warnings and instructions marked on the projector.
Safety Instructions Air Circulation Openings in the cabinet are provided for ventilation and to ensure reliable operation of the product and to protect it from overheating, and these openings must not be blocked or covered. CAUTION Installing the Projector in Proper Position Install the projector properly. Improper Installation may reduce the lamp life and cause a fire hazard. 20˚ Hot air is exhausted from the exhaust vent.
Compliance Federal Communications Commission Notice Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
Part Names and Functions Front q Infrared Remote Receiver w Zoom Ring e Projection Lens r Focus Ring t Lens Cover (See page 53 for attaching.) y Air Intake Vent q w e r t Back y u Power Cord Connector !1 y u i o !0 y i Speaker o Terminals and Connectors !0 Top Controls and Indicators !1 Exhaust Vents CAUTION Hot air is exhausted from the exhaust vent. Do not put heat-sensitive objects near this side.
Part Names and Functions Rear Terminal q w e r i q SERVICE PORT This jack is used to service the projector. w COMPUTER IN 1/COMPONENT IN Connect output signal from a computer, RGB scart 21-pin video output, or component video output to this terminal. (p15, 17) When the cable is of the longer variety, it is advisable to use this terminal and not COMPUTER IN 2/MONITOR OUT.
Part Names and Functions Top Control y t u r i e w o q SELECT button – Execute the selected item. (p.20) – Expand or compress the image in Digital zoom mode. (p.34) w POINT (ed7 8) buttons – Select an item or adjust the value in the On-Screen Menu. (p.20) – Pan the image in Digital zoom + mode. (p.34) – Adjust the volume level. (Point 7 8 buttons) (p.23) e KEYSTONE button Correct the keystone distortion. (p.
Part Names and Functions Remote Control q POWER ON/STAND-BY button Turn the projector on or off. (p.18, 19) e w w VIDEO button q Select VIDEO input source. (p.23, 35) e COMPUTER button Select COMPUTER input source. (p.23, 25, 36) r MENU button Open or close the On-Screen Menu. (p20) t Point ed 7 8 (VOLUME + / –) buttons !5 r t !4 y – Select an item or adjust the value in the OnScreen Menu. (p.20) – Pan the image in Digital zoom + mode. (p.34) – Adjust the volume level.
Part Names and Functions Remote Control Battery Installation 1 Open the battery compartment lid. 2 3 Install new batteries into the compartment. Replace the compartment lid. Two AA size batteries For correct polarity (+ and –), be sure battery terminals are in contact with pins in the compartment. To insure safe operation, please observe the following precautions: ● Use two (2) AA or LR6 type alkaline batteries. ● Always replace batteries in sets. ● Do not use a new battery with a used battery.
Installation Positioning the Projector For projector positioning, see the figures below. The projector should be set horizontally to the flat screen. ✔ Note: • The brightness in the room has a great influence on picture quality. It is recommended to limit ambient lighting in order to obtain the best image. • The values shown below are approximate and may vary from the actual sizes. 34.4' (10.5 m) A:B = 9:1 (Inch Diagonal) 300" 23.0' (7.0 m) 17.0' (5.2 m) 200" 11.5' (3.5 m) 4.6' (1.
Installation Connecting the AC Power Cord This projector uses nominal input voltages of 100-120 V or 200-240 V AC. This projector automatically selects the correct input voltage. It is designed to work with single-phase power systems having a grounded neutral conductor. To reduce the risk of electrical shock, do not plug into any other type of power system. Consult your authorized dealer or service station if you are not sure of the type of power being supplied.
Installation Connecting to a Computer Cables used for connection • VGA Cables (Mini D-sub 15 pin) (Only one cable is supplied.) • Audio Cables (Mini Plug: stereo) (*One cable is supplied; other cables are not supplied with the projector.) Audio Output Monitor Output Monitor Output or Monitor Input VGA cable External Audio Equipment Audio Input VGA cable Audio cable (stereo) COMPUTER IN 1/ COMPUTER IN 2/ COMPONENT IN MONITOR OUT This terminal is switchable.
Installation Connecting to Video Equipment Cables used for connection • Video and Audio Cable (RCA x 3) • S-VIDEO Cable • Audio Cable (Mini Plug: stereo) ( Cables are not supplied with the projector.
Installation Connecting to Component Video Equipment Cables used for connection • Audio Cables (Mini Plug :stereo) • Scart-VGA Cable • Component Cable • Component-VGA Cable ( Cables are not supplied with the projector.
Basic Operation Turning On the Projector 1 2 3 4 Complete peripheral connections (with a computer, VCR, etc.) before turning on the projector. Connect the projector’s AC power cord into an AC outlet. The POWER indicator becomes red. Press the POWER ON/STAND-BY button on the top control or on the remote control. The POWER indicator becomes green and the cooling fans start to operate. The preparation display appears on the screen and the count down starts.
Basic Operation Turning Off the Projector 1 Press the POWER ON/STAND-BY button on the top control or on the remote control, and a message "Power off?" appears on the screen. 2 Press the POWER ON/STAND-BY button again to turn off the projector.The POWER indicator starts to blink red, and it continues while the cooling fans are operating for about 90 seconds. (You can select the level of fan quietness and rotation speed. See page 51.
Basic Operation How to Operate the On-Screen Menu The projector can be adjusted or set via the On-Screen Menu. Refer to the following pages regarding each adjustment and setting procedures. 1 2 3 Top Control Press the MENU button to display the On-Screen Menu. POINT buttons (outer ring) Press the Point 7 8 buttons to select a Menu icon to adjust and press the Point ed buttons to select an item to adjust. Press the SELECT button to show the item data. To adjust the data, press the Point 7 8 buttons.
Basic Operation Menu Bar For detailed functions, see Menu Tree on p.59,60. For computer source Guide Window Show the selected Menu of the On-Screen Menu. PC System Menu Image Select Menu Screen Menu Used to select computer Used to select an image level among system. (p.26) Dynamic, Standard, Real, Blackboard (Green), and Image 1 ~ 4. (p.30) Input Menu Used to select input source either Computer or Video. (p.25) PC Adjust Menu Used to adjust parameters to match with input signal format. (p.
Basic Operation Zoom and Focus Adjustment Rotate the Zoom Ring to zoom in and out. Rotate the Focus Ring to adjust the projected picture focus. Focus Ring (Front) Zoom Ring (Rear) Keystone Correction If a projected picture has keystone distortion, correct the image with Keystone adjustment. Press the KEYSTONE button on the top control or on the remote control. The keystone dialog box appears. Correct keystone distortion by pressing the Point ed buttons. Keystone adjustment can be memorized. (p.
Basic Operation Sound Adjustment Direct Operation Top Control Volume VOLUME+/buttons Press the VOLUME+/– buttons on the top control or on the remote control to adjust the volume. The volume dialog box appears on the screen for a few seconds. Mute Press the MUTE button on the remote control to cut off the sound. To restore the sound to its previous level, press the MUTE button again or press the VOLUME +/– buttons. Mute function is also effective for AUDIO OUT jack.
Basic Operation AUTO PC button Press the AUTO PC button on the remote control to operate the Auto PC function. For more detail, see page 27. Remote Control VOLUME +/- buttons (See p.23.) KEYSTONE button (See p.22) D.ZOOM buttons POINT ed buttons Press the D.ZOOM buttons on the remote control to zoom in and zoom out the images. For more detail, see page 34. AUTO PC button IMAGE button NO SHOW button P-TIMER button Press the NO SHOW button on the remote control to black out the image.
Computer Input Input Source Selection Direct Operation Top Control INPUT button Choose either Computer 1 or Computer 2 by pressing the INPUT button on the top control or press the COMPUTER button on the remote control. Before using these buttons, correct input source should be selected through Menu operation as described below. INPUT button Computer 1 Computer 2 ✳ Video Remote Control COMPUTER button COMPUTER button Computer 1 Computer 2 ✳ ✳ See Note at the bottom of this page.
Computer Input Computer System Selection This projector automatically tunes to various types of computers based on VGA, SVGA, XGA, SXGA, WXGA, or UXGA with its Multi-scan system and Auto PC Adjustment. If Computer is selected as a signal source, this projector automatically detects the signal format and tunes to project a proper image without any additional setting.
Computer Input Auto PC Adjustment Auto PC Adjustment function is provided to automatically adjust Fine sync, Total dots, Horizontal, and Vertical to conform to your computer. Auto PC Adjustment function can be operated as follows. Direct Operation Remote Control The Auto PC adjustment function can be operated directly by pressing the AUTO PC button on the remote control unit. Menu Operation AUTO PC button PC Adjust Menu Auto PC Adj. 1 Press the MENU button to display the On-Screen Menu.
Computer Input Manual PC Adjustment Some computers employ special signal formats which may not be tuned by Multi-scan system of this projector. Manual PC Adjustment enables you to precisely adjust several parameters to match those signal formats. The projector has 5 independent memory areas to memorize those parameters manually adjusted. It allows you to recall the setting for a specific computer. 1 Press the MENU button to display the On-Screen Menu.
Computer Input Display area H Adjust the horizontal area displayed by this projector. Press the Point 7 8 buttons to decrease/increase the value. Display area V Adjust the vertical area displayed by this projector. Press the Point 7 8 buttons to decrease/increase the value. Reset To reset the adjusted data, select Reset and press the SELECT button. The confirmation box appears and then select [Yes]. All adjustments return to their previous figures.
Computer Input Image Level Selection Direct Operation Select an image level among Dynamic, Standard, Real, Blackboard (Green), Image 1, Image 2, Image 3, and Image 4 by pressing the IMAGE button on the remote control. Dynamic Picture level suitable for viewing picture in a bright room. Standard Normal picture level preset on this projector. Real Picture level with improved halftone for graphics. Blackboard (Green) Picture level suitable for the image projected on a blackboard.
Computer Input Image Level Adjustment 1 2 Press the MENU button to display the On-Screen Menu. Press the Point 7 8 buttons to move the red framed pointer to the Image Adjust Menu icon. Image Adjust Menu Press the Point ed buttons to move the red framed pointer to the item that you want to adjust, and then press the SELECT button. The level of each item is displayed. Adjust each level by pressing the Point 7 8 buttons.
Computer Input Store To store the adjusted data, select Store and press the SELECT button. Select a level from Image 1 to 4 with the Point ed buttons and press the SELECT button. A confirmation box appears and then select [Yes]. Stored data can be called up by selecting "Image" in the Image Level Selection on page 30. Move the red framed pointer to any of Image 1 to 4 where you want to set and then press the SELECT button. Quit Exit the Image Adjust Menu.
Computer Input Custom Adjust the screen scale and position manually with this function. Press the SELECT button at Custom and the "Custom" is displayed on the screen for a few seconds and then the Aspect dialog box appears. Scale H/V................... Adjust the Horizontal/Vertical screen scale. H&V............................ When set to "On", the aspect ratio is fixed. The "Scale V" appears dimmed and becomes unavailable.
Computer Input For zooming in and out the images Digital zoom + Remote Control When the Digital zoom + is selected, the On-Screen Menu disappears and the message "D. zoom +" is displayed. Press the SELECT button to expand the image size. And press the Point ed 7 8 buttons to pan the image. The Panning function can work only when the image is larger than the screen size. POINT buttons A projected image can be also expanded by pressing the D.ZOOM e button on the remote control. D.
Video Input Input Source Selection (Video, S-Video) Direct Operation Top Control Choose Video by pressing the INPUT button on the top control or the VIDEO button on the remote control. Before using these buttons, correct input source should be selected through menu operation as described below. INPUT button INPUT button Video Computer 1 Computer 2 ✳ ✳ See Note at the bottom of this page. Remote Control VIDEO button Menu Operation 1 Press the MENU button to display the On-Screen Menu.
Video Input Input Source Selection (Component, RGB Scart 21-pin) Direct Operation Top Control INPUT button Choose Computer 1 by pressing the INPUT button on the top control or press the COMPUTER button on the remote control. Before using these buttons, correct input source should be selected through Menu operation as described below.
Video Input Video System Selection 1 Press the MENU button to display the On-Screen Menu. Press the Point 7 8 buttons to move the red framed pointer to the AV System Menu icon. 2 Press the Point ed buttons to move the red arrow pointer to the system that you want to select and then press the SELECT button. Video or S-Video AV System Menu (Video or S-Video) Auto The projector automatically detects incoming video system, and adjusts itself to optimize its performance.
Video Input Image Level Selection Direct Operation Select an image level among Dynamic, Standard, Cinema, Blackboard (Green), Image 1, Image 2, Image 3, and Image 4 by pressing the IMAGE button on the remote control. Dynamic Picture level suitable for viewing picture in a bright room. Standard Normal picture level preset on this projector. Cinema Picture level adjusted for the picture with fine tone. Blackboard (Green) Picture level suitable for the image projected on a blackboard.
Video Input Image Level Adjustment 1 2 Press the MENU button to display the On-Screen Menu. Press the Point 7 8 buttons to move the red framed pointer to the Image Adjust Menu icon. Press the Point ed buttons to move the red framed pointer to the item that you want to adjust, and then press the SELECT button. The level of each item is displayed. Adjust each level by pressing the Point 7 8 buttons.
Video Input Sharpness Press the Point 7 button to soften the image and the Point 8 button to sharpen the image. (From 0 to 15.) Gamma Press the Point 7 8 buttons to obtain better balance of contrast. (From 0 to 15.) Noise reduction Noise interference on the screen can be reduced. Select one of the following to get smoother images. Off . . . . disabled. L1 . . . . lower reduction L2 . . . . higher reduction Progressive Interlaced video signal can be displayed in a progressive picture.
Video Input Screen Size Adjustment This projector has the picture screen resize function, which enables you to customize the image size. 1 2 Press the MENU button to display the On-Screen Menu. Press the Point 7 8 buttons to move the red framed pointer to the Screen Menu icon. Press the Point ed buttons and move the red framed pointer to the function that you want to select and then press the SELECT button. Normal Provide the image at a normal video aspect ratio of 4:3.
Setting Setting This projector has Setting menu that allows you to set up the other various functions described as follows: 1 Press the MENU button to display the On-Screen Menu. Press the Point 7 8 buttons to move the red framed pointer to the Setting Menu icon. 2 Press the Point ed buttons to move the red framed pointer to the item that you want to set and then press the SELECT button. The Setting dialog box appears.
Setting Display Press the Point 7 8 buttons to switch On/Off. This function decides to display On-Screen Displays. On . . . . . . . . . . . . . Show all the On-Screen Displays. Use this function when you want to project images after the lamp becomes bright enough. Factory default setting is this mode. Countdown off . . . . Show the input image instead of the countdown when turning on the projector.
Setting Capture This function enables you to capture the image being projected and use it for a start-up display or interval of presentations. After capturing the projected image, go to the Logo select function and set it to "User". Then the captured image is displayed when turning on the projector next time or pressing the NO SHOW button. (p.24) To capture the image, select [Yes]. To cancel the Capture function, select [No].
Setting To Enter the Logo PIN code Select a number by pressing the Point ed buttons. And then press the Point 8 button to fix the number and move the pointer. The number changes to "✳". If you fixed an incorrect number, move the pointer to the number you want to correct by pressing the Point 7 button, and then select the correct number by pressing the Point ed buttons. Repeat this step to complete entering a four-digit number.
Setting Ceiling Ceiling When this function is "On", the picture is top/bottom and left/right reversed. This function is used to project the image from a ceiling mounting the projector. Rear When this function is "On", the picture is left/right reversed. This function is used to project the image to a rear projection screen. Rear Input search This function detects the input signal automatically. When finding a signal, the search will stop. Use the Point 7 8 buttons to select one of the following. Off .
Setting Terminal The COMPUTER IN 2/MONITOR OUT terminal on the back of the projector is switchable for computer input or monitor output. (See page 9) Select Computer 2 or Monitor Out with the Point 7 8 buttons. Computer 2 . . . . . . computer input Monitor Out . . . . . . monitor out Terminal function is not available when selecting Computer 2 to the input source. Change the input source to the others (Computer1 or Video) so that the Terminal function will be available. (p.
Setting On start On start When this function is "On", the projector is automatically turned on just by connecting the AC power cord to a wall outlet. ✔ Note: • Be sure to turn the projector off properly (see "Turning Off the Projector" on page 19). If the projector is turned off in the incorrect sequence, the On start function does not operate properly. Lamp control This function allows you to change brightness of the screen. Normal . . . . . normal brightness Auto . . . . . . .
Setting Security (Key lock and PIN code lock settings) Key lock This function allows you to use Key lock and PIN code lock function to set the security for the projector operation. Key lock This function locks operation of the top control or the remote control. It is useful to prevent operation by an unauthorized person. Select Key lock. Choose one of the alternatives with the Point ed buttons and select [Yes] to activate it. ���������� not locked. ���������� lock the operation of the top control.
Setting To Enter the PIN code Select a number by pressing the Point ed buttons. And then press the Point 8 button to fix the number and move the pointer. The number changes to "✳". If you fixed an incorrect number, move the pointer to the number you want to correct by pressing the Point 7 button, and then select the correct number by pressing the Point ed buttons. Enter a PIN code Repeat this step to complete entering a four-digit number.
Setting Fan This function provides the following alternatives in the cooling fans' operation after turning off the projector. (p.19) L1 . . . . . . normal operation L2 . . . . . . slower and lower-sound than the normal operation (L1), but it takes longer to cool the projector down. Lamp counter This function is used to reset the lamp replacement counter. When replacing the projection lamp, reset the lamp replacement counter by using this function. See page 56 for operation.
Maintenance and Cleaning Warning Temp. Indicator The WARNING Temp. indicator shows the state of the function which protects the projector.Check the state of the WARNING Temp. indicator and the POWER indicator to take proper maintenance. The projector is shut down and the WARNING TEMP. indicator is blinking red. Top Control WARNING Temp. blinking red When the temperature inside the projector reaches a certain level, the projector is automatically shut down to protect the inside of the projector.
Maintenance and Cleaning Cleaning the Air Filters Air filters prevent dust from accumulating on the optical elements inside the projector. Should the air filters become clogged with dust particles, it will reduce cooling fans' effectiveness and may result in internal heat build up and adversely affect the life of the projector. Clean the air filters following the steps below. 1 2 3 4 Turn off the projector, and disconnect the AC power cord from the AC outlet.
Maintenance and Cleaning Cleaning the Projection Lens Follow these steps to clean the projection lens. 1 Disconnect the AC power cord before cleaning. 2 Softly wipe the projection lens with a cleaning cloth that contains a small amount of non-abrasive camera lens cleaner, or use lens cleaning paper or a commercially available air blower to clean the lens. Avoid using an excessive amount of cleaner. Abrasive cleaners, solvents, or other harsh chemicals might scratch the surface.
Maintenance and Cleaning Lamp Replacement When the life of the projection lamp of this projector draws to an end, the LAMP REPLACE indicator emits a yellow light. If this indicator lights yellow, replace the lamp with a new one promptly. Top Control This indicator is yellow when the life of the projection lamp draws to an end. WARNING: TURN OFF THE UV LAMP BEFORE OPENING THE LAMP COVER CAUTION CAUTION Allow a projector to cool, for at least 45 minutes before you open the Lamp cover.
Maintenance and Cleaning Lamp Replacement Counter Be sure to reset the Lamp replacement counter after the lamp is replaced. When the Lamp replacement counter is reset, the LAMP REPLACE indicator stops lighting. 1 Turn the projector on, press the MENU button to display the On-Screen Menu. Press the Point 7 8 buttons to move the red framed pointer to the Setting Menu icon. 2 Press the Point ed buttons to move the red framed pointer to the Lamp counter function and then press the SELECT button.
Appendix Troubleshooting Before calling your dealer or service center for assistance, check the items below once again. – Make sure you have properly connected the projector to peripheral equipment as described on pages15-17. – Make sure all equipment is connected to AC outlet and the power is turned on. – When you operate the projector with a computer and it does not project an image, restart the computer. Problem – Solutions No power – Plug the power cord of the projector into the AC outlet.
Appendix Some displays are not seen – Check the Display item. (See page 43.) the start-up PIN code dialog box appears at – PIN code lock is being set. Input a PIN code (1234 or numbers you have set). (See pages 18, 49 and 50.) Computer 2 cannot be selected – Select Computer 2 at the Terminal function. (See page 47.) The Terminal function cannot be – The Terminal function cannot be selected after Computer 2 is selected.
Appendix Menu Tree Computer Input/Video Input Input Computer 1 RGB Go to System (1) Component Go to System (2) RGB (Scart) N/A Quit ✽ N/A - - - not applicable Auto Go to System (3) Video Go to System (3) S-Video Go to System (3) Computer 2 Go to System (1) Video Sound Quit Sound Volume 0 - 63 Mute On/Off Quit Computer Input System (1) Mode 1 Mode 2 Image Select ---- Blackboard (Green) Image 1 ✽ Systems displayed in the System Menu vary depending the input signal.
Appendix Video Input Setting System (2) System (3) Image Select Setting Auto 1080i 1035i 720p 575p 480p 575i 480i Language Auto PAL SECAM NTSC NTSC 4.43 PAL-M PAL-N Dynamic Standard Cinema Blackboard (Green) Image 1 Keystone Blue back Display Logo Image 4 Contrast Brightness 0 - 63 0 - 63 Color 0 - 63 Tint 0 - 63 Color temp. High Mid Low XLow Adj.
Appendix Indicators and Projector Condition Check the indicators for projector condition. Indicators POWER red/green Projector Condition WARNING LAMP TEMP. REPLACE red yellow The projector is off. (The AC power cord is unplugged.) ✽ The projector is preparing for stand-by or the projection lamp is being cooled down. The projector cannot be turned on until cooling is completed. ✽ The projector is ready to be turned on with the POWER ON/STAND-BY button. ✽ The projector is operating normally.
Appendix Compatible Computer Specifications Basically this projector can accept the signal from all computers with the V, H-Frequency below mentioned and less than 140 MHz of Dot Clock. When selecting these modes, PC adjustment can be limited.
Appendix Technical Specifications Mechanical Information Projector Type Dimensions (W x H x D) Net Weight Feet Adjustment Multi-media Projector 335 mm x 83 mm x 238.4 mm (Not including adjustable feet) 6.63lbs (3.0 kgs) 0˚ to 10.0˚ Panel Resolution LCD Panel System 0.
Appendix Accessories Owner's Manual (CD-ROM) Quick Reference Guide AC Power Cord Remote Control and Batteries VGA Cable Lens Cover with String PIN Code Label Lamp Replacement Label ● The specifications are subject to change without notice. ● LCD panels are manufactured to the highest possible standards. Even though 99.99% of the pixels are effective, a tiny fraction of the pixels (0.01% or less) may be ineffective by the characteristics of the LCD panels.
Appendix Configurations of Terminals COMPUTER INPUT/COMPONENT INPUT/MONITOR OUTPUT TERMINAL (ANALOG) Terminal : Analog RGB (Mini D-sub 15 pin) 4 5 10 15 3 9 14 2 8 13 12 1 Red (R/Cr) Input/Output 3 Blue (B/Cb) Input/Output 2 1 7 6 11 4 11 Ground/----- ----- 12 Ground (Horiz.sync.) 7 Ground (Green) 8 5V 10 5 6 9 Green (G/Y) Input/Output Ground (Red) Ground (Blue) 13 14 15 Ground (Vert.sync.) DDC data Horiz. sync. Input/Output (Composite H/V sync.) Vert. sync.
Appendix PIN Code Number Memo Write down the PIN code number in the column below and keep it with this manual securely. If you forgot or lost the number and unable to operate the projector, contact the service station. PIN Code Lock No. Factory default set No: 1 2 3 4* Logo PIN Code Lock No. Factory default set No: 4 3 2 1* * Should the four-digit number be changed, the factory set number will be invalid. While the projector is locked with the PIN code....
KH3AC SANYO Electric Co., Ltd.
