Appendix

ASSY, PWB, COVER SW disassemble (A1801)

Refer to mechanical disassemblies.

Step 1 Mechanical disassembly 1 P15 (Remove the Cabinet bottom cover.)

2. Mechanical disassembly 2 P16 (Remove the Holder bracket back.)

3 Mechanical disassembly 5-1 P20 (Remove the Digital tuner unit.)

4. Mechanical disassembly 6 P22 (Remove the Optical / chassis unit.)

5 Mechanical disassembly 8 P24

1 2

4 5

Cover switch board

ASSY,PWB,COVER SW (A1801)
