PJ-NET ORGANIZER
OWNER'S MANUAL [PLV-80/75 Series]
ENGLISH
Features
Multi-control func-
tion (+p.58)
A single computer can con-
trol and set up the multiple
projectors at the same time.
PJ1
PC6
PC4
PC5
Select Input2 for
PJ1 to PJ4.
PJ2 PJ3 PJ4
Automatic On/Off using
Clock function (+p.53)
Automatically turn on or off the
projectors at specified date/day
and time by using the clock func-
tion.
Now it’s 11:30
I am ready to turn ON,
and select Input 3 (Video)
SNMP Manager function (refer to the separated booklet)
A f u nc t ion to mana g e th e
condition of projectors in the
network by using the SNMP
protocol. The managing com-
puter needs to provide an
SNMP managing software. Refer
to the owner's manual of the
"PJ Network Manager" supplied
separately for further details.
PJ1
PC6
PC4
PJ2 PJ3 PJ4
PC5
You received
a Trap.
SNMP Manager
Trap
Trap
Control port ready for external equipment (+p.63)
This product provides a serial port for con-
trolling external equipment. By connecting
the equipment to the serial port, it can be
controlled by a computer via the network.
* This product does not provide the interface
driver software to control external equipment.
DVD Player
PC3
PC5
PJ2
Playback DVD
