NF4Q/NA (SRC-850A GB) Tue. Sept., 10/2002 I index INSTRUCTION MANUAL SRC-850A Video Cassette Recorder English Magnétoscope à Cassette Français Videograbador Español Please read this manual and accompanying “IMPORTANT SAFETY INSTRUCTIONS” sheet carefully before connecting your VCR and operating it for the first time. Be sure to read carefully and follow all the PRECAUTIONS on page 1 and 2. Keep the manual in a safe place for future reference.
NF4Q/NA (SRC-850A GB) Tue. Sept., 10/2002 PRECAUTIONS The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
NF4Q/NA (SRC-850A GB) Tue. Sept., 10/2002 PRECAUTIONS Location Moisture Condensation Problems For safe operation and satisfactory performance of your VCR, keep the following in mind when selecting a place for its installation: Cause: When the VCR is first installed, moved from a cold area to a warm area or placed in a location with high humidity, dew (moisture) may form in the unit. The Dew indicator (À) blinks. If you operate the VCR with dew inside, damage may result.
NF4Q/NA (SRC-850A GB) Tue. Sept., 10/2002 CONTENTS FEATURES œ œ œ œ œ œ œ œ œ œ œ œ œ œ œ œ œ œ PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 FEATURES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 ACCESSORY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 LOCATIONS OF CONTROLS AND INDICATORS . . . . 4 CONNECTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 ON-SCREEN MENU. . . . . . . . . . . . . . . . . . . . .
NF4Q/NA (SRC-850A GB) Tue. Sept.
NF4Q/NA (SRC-850A GB) Tue. Sept., 10/2002 LOCATIONS OF CONTROLS AND INDICATORS œ Time display (No tape) Digital Display 1 2 AL T/D P 3 œ Linear time counter display (Tape inserted) M œ Dew display OFF 6 œ Tracking control display 4 5 1 Mode display œ Data transfer speed setting display AL œ Warning display œ Address setting display N flashes: Mode changed to non-recording mode while recording was in progress. M flashes: Problem with mechanism.
NF4Q/NA (SRC-850A GB) Tue. Sept., 10/2002 LOCATIONS OF CONTROLS AND INDICATORS 4 Operation Indicators œ They display the actual operation mode. Operation Mode Record (REC) Indicator Record pause (REC PAUSE) Playback (PLAY) Still image (STILL) Fast forward (FF) Rewind (REW) Forward picture search Reverse picture search Forward field advance Reverse field advance 5 OFF indicator Lights when the tape end has been reached after recording. 6 Cassette indicator Lights when a cassette is loaded.
NF4Q/NA (SRC-850A GB) Tue. Sept., 10/2002 LOCATIONS OF CONTROLS AND INDICATORS Back Panel 1 SHORT FOR TERMINATION. RS485 A COM OPEN COLLECTOR COM RS485 B 3 5 7 9 G 2 4 6 8 F RS485 B RS485 A 1=500mA(Max.) 2= 50mA(Max.) CLOCK IN ALARM IN EJECT IN SERIES IN SHORT FOR TERMINATION.
NF4Q/NA (SRC-850A GB) Tue. Sept., 10/2002 CONNECTIONS Connect the video camera and TV monitor as shown in the figure below. NOTE: Before making the connections, make sure the devices are disconnected from the power outlet. TV Monitor (sold separately) Video camera (sold separately) To VIDEO IN jack From an external audio source SHORT FOR TERMINATION. RS485 A COM OPEN COLLECTOR COM RS485 B RS485 B RS485 A 1=500mA(Max.) 2= 50mA(Max.
NF4Q/NA (SRC-850A GB) Tue. Sept., 10/2002 ON-SCREEN MENU Main Menu Sub-menus To access on-screen menu To enter or modify settings within a sub-menu 1 When no menu is displayed on-screen, press the 1 When a MAIN MENU is being displayed, press the l (or j) button to select one of the sub-menus, then press the ENTER button. MENU button. ø The MAIN MENU appears. ø The selected sub-menu appears. MAIN MENU 2 Press the l (or j) button to move the selection to 1.LANGUAGE/CLOCK@SET 2.
NF4Q/NA (SRC-850A GB) Tue. Sept., 10/2002 ON-SCREEN MENU WARNING OUT/EJECT SET menu NOTES: œ Setting items are highlighted (appear in blue characters) when they are selected. SET@UP ALARM@@@@@@@@@@@@Y NON@REC@@@@@@@@@@N MECHA.PROBLEM@@@@Y VIDEO@LOSS@@@@@@@Y œ Settings flash while they are being changed. œ When a menu is displayed, recording will not be possible. EJECT@MODE@@@@@@@EJECT1 OPERATION@@@@@@@@SLAVE œ During recording or playback the menus cannot be displayed.
NF4Q/NA (SRC-850A GB) Tue. Sept., 10/2002 SETTING THE LANGUAGE AND CLOCK Language Setting Clock setting English, French, Spanish or Portuguese can be selected by the user. Example: To set the clock to October 15, 2002 at 3:20 PM (15:20). 1 Turn the power on to all devices used. 2 Press the MENU button to display the MAIN MENU. 1 Follow steps 1 to 3 under “Language Setting”. 2 Press the l (or j) button until the “CLOCK SET” setting is highlighted (appears in blue characters). ø The “1.
NF4Q/NA (SRC-850A GB) Tue. Sept., 10/2002 SETTING THE LANGUAGE AND CLOCK 6 Press the l (or j) button to select the “OFF” line Automatic Daylight Saving Time Adjustment setting, then press the ENTER button. ø The “LST” of the “OFF” line flashes. 1 Follow steps 1 to 3 under “Language Setting” on 7 Following the same procedure as above (step 5), page 11. set when the time is changed back from daylight saving time to standard time.
NF4Q/NA (SRC-850A GB) Tue. Sept., 10/2002 SUPERIMPOSE DISPLAY Selecting the Superimpose Display Changing the Superimpose Display Position You can select to display or not the date, time and number of alarm recordings. 1 Turn the power on to all input devices to the VCR. 2 Set the ON SCREEN switch to the “ON” position. 1 Turn the power on to all devices used. 2 Press the MENU button to display the MAIN MENU. 3 Press the l (or j) button to select the ø The superimpose display appears.
NF4Q/NA (SRC-850A GB) Tue. Sept., 10/2002 VIDEO CASSETTE TAPES Use only video cassette tapes bearing the VHS logo. This VCR was primarily designed for use with T-160 cassette tapes. It is recommended that you use T-160 standard grade VHS video cassette tapes for optimal performance. Loading 1 Place the cassette, label side up, in the loading slot. Gently push the center of the cassette until it is loaded automatically. NOTE: œ If using longer tapes (i.e.
NF4Q/NA (SRC-850A GB) Tue. Sept., 10/2002 VIDEO CASSETTE TAPES Correct tape thread check function Setting the Action to Take When a Cassette is Loaded This function checks to make sure that the cassette has been correctly loaded so that recording can be carried out. You can set the mode the VCR will go into when a cassette is loaded. 1 Press the MENU button to display the MAIN MENU. 2 Press the l (or j) button to select the “4.
NF4Q/NA (SRC-850A GB) Tue. Sept., 10/2002 TAPE MANAGEMENT This VCR is equipped with a tape management function. Using this function you can protect previous recordings and prevent overuse of the tape by controlling the tape protection term (number of days), the maximum number of re-recordings of the tape and the recording group. For details on how to set this function, refer to “Setting the Tape Management Function”.
NF4Q/NA (SRC-850A GB) Tue. Sept., 10/2002 TAPE MANAGEMENT 8 Press the l (or j) button to select the desired Setting the Tape Management Function number of re-recording times, then press the ENTER button. 1 Press the MENU button to display the MAIN MENU. 2 Press the l (or j) button to select the “7.TAPE OFF . . . . The number of re-recording times will not be checked. MANAGEMENT” line, then press the ENTER button. ø The (TAPE MANAGEMENT) menu appears. 1-100 . . . Maximum number of re-recording times.
NF4Q/NA (SRC-850A GB) Tue. Sept., 10/2002 TAPE MANAGEMENT PROTECT DAY CONFLICT Tape Management Conflict Display The tape is protected, and the tape protection term (ex. 30 days) is not yet over. If a conflict that prevents recording is found when the tape management function checks the tape data, the (TAPE MANAGEMENT) menu appears with the conflicting setting flashing and the VCR go into the stop mode. If “WARNING” in the (BUZZER SET) menu is set to “Y”, the buzzer is heard.
NF4Q/NA (SRC-850A GB) Tue. Sept., 10/2002 NORMAL RECORDING Normal Recording Record Pause Recording can be interrupted temporarily. Before starting 1 Press the STILL/PAUSE button during recording. ø The pause/still indicator “:” flashes. œ Turn the power on to all devices used. œ Load a cassette tape with its erasure-prevention tab intact. œ Set the ON SCREEN switch to the “ON” position. NOTES: œ The image appears on-screen but it is not recorded.
NF4Q/NA (SRC-850A GB) Tue. Sept., 10/2002 NORMAL RECORDING Tape Counter Notes: Action to Take when the Video Signal Deteriorates œ There is no tape counter indication for the blank portions of the tape. If there is no video signal during recording or when a menu is not displayed (in stop, fast forward or rewind modes, etc.), “VIDEO LOSS” can be displayed on-screen.
NF4Q/NA (SRC-850A GB) Tue. Sept., 10/2002 NORMAL RECORDING Setting the Mode at the End of the Tape Setting the video input signal You can select the mode on the VCR when the tape reaches the end during recording. The video input signal during recording can be set to either color or black & white. 1 Press the MENU button to display the MAIN MENU. 2 Press the l (or j) button to select the “4.GENERAL 1 Press the MENU button to display the MAIN MENU. 2 Press the l (or j) button to select the “4.
NF4Q/NA (SRC-850A GB) Tue. Sept., 10/2002 AUTOREPEAT RECORDING NOTES: Autorepeat Recording œ If there is an alarm trigger during autorepeat recording, “AL” and “A” flash on the digital display and alarm recording starts. (Refer to “ALARM RECORDING” on page 23.) The same tape can be recorded over many times. œ Follow the Before starting steps, under “NORMAL RECORDING”. 1 Press the MENU button to display the MAIN MENU. 2 Press the l (or j) button to select the “4.
NF4Q/NA (SRC-850A GB) Tue. Sept., 10/2002 ALARM RECORDING By connecting the ALARM IN terminal to a normally open door switch, an interphone, etc., a recording can be done only when necessary. NOTES: œ During alarm recording all buttons are disabled. œ If “OFF” appears on the digital display, alarm recording is not possible in order to prevent the recorded tape to be recorded over. To cancel the “OFF” display, press the STOP, EJECT, FF, REW or PLAY button.
NF4Q/NA (SRC-850A GB) Tue. Sept., 10/2002 ALARM RECORDING Alarm Recording Counter Display Checking the Alarm Recordings Time œ During alarm recording, “AL” and “A” will be flashing on the digital display. 1 Press the MENU button to display the MAIN MENU. 2 Press the l (or j) button to select the “8.OTHERS” œ If a superimpose display is being displayed and “ALARM COUNT” has been set to “Y” in the (DISPLAY/SW OUT SET) menu, the number of alarm recordings will flash on the monitor screen.
NF4Q/NA (SRC-850A GB) Tue. Sept., 10/2002 ALARM RECORDING Alarm Search Alarm Scan To go to the beginning of a desired alarm recording. To look for an alarm recording by viewing the first 5 seconds of each alarm recording. 1 Press the SEARCH button during stop mode. 1 Press the SEARCH button twice during stop mode. ø “AL SEARCH 01” appears on screen. ø “AL SCAN” will be displayed on screen. 2 Press the l (or j) button to set the desired alarm 2 Press the FF (or REW) button.
NF4Q/NA (SRC-850A GB) Tue. Sept., 10/2002 SERIES RECORDING Using 2 VCRs or more, the series recording function lets you switch recording from one unit to the next (only with VCRs of the same model as this one). Operation The output signal at the SERIES OUT terminal will be present either at the point when the counter reading is 8:00:00 or when VCR No. 1 reaches the end of the tape, whichever is first. Series Recording Setup œ Connect 2 VCRs or more as illustrated below.
NF4Q/NA (SRC-850A GB) Tue. Sept., 10/2002 PLAYBACK Normal Playback Picture Search (Forward and Reverse) 1 Turn on the power to the VCR and TV monitor. 2 Load the video cassette tape. 3 Press the PLAY button. 1 Press the FF (or REW) button, during normal playback. ø The image can be seen while the tape is advanced (or rewound) at high speed. ø Playback starts. 2 To return to normal playback, press the PLAY button. ø If necessary, adjust the tracking to eliminate the noise from the picture.
NF4Q/NA (SRC-850A GB) Tue. Sept., 10/2002 DAY/TIME SEARCH Day/Time Search NOTES: This searches for a specified day/time for still images to be played back. œ If the end of the tape is reached during a search, the tape will rewind and stop. If the beginning of the tape is reached, it will stop. 1 Press the SEARCH button three times during stop œ The alarm and day/time data are recorded on the tape in a similar format. If they overlap, the alarm data will have the priority.
NF4Q/NA (SRC-850A GB) Tue. Sept., 10/2002 SETTING THE BUZZER WARNING . . The buzzer will be heard if the tape stops or is ejected due to a problem with the internal mechanism. The buzzer may also be heard depending on the settings for “THREAD CHECK” and “VIDEO LOSS” in the (GENERAL SET) menu, and “VIDEO LOSS” in the (WARNING OUT/EJECT SET) menu. To stop the buzzer, press the STOP button twice.
NF4Q/NA (SRC-850A GB) Tue. Sept., 10/2002 CLOCK ADJUSTMENT The time for the second and subsequent VCRs can be set to the same time as the first VCR. Example TAPE@IN@MODE@@@@@STOP TAPE@END@MODE@@@@REW CLOCK@ADJUST@@@@@03:00 THREAD@CHECK@@@@@N VIDEO@LOSS@@@@@@@N REMOTE@@@@@@@@@@@MENU VIDEO@@@@@@@@@@@@COLOR A signal from a separate device can also be used to set the time for the second and subsequent VCRs to the same time as the first VCR.
NF4Q/NA (SRC-850A GB) Tue. Sept., 10/2002 SETTING THE CASSETTE EJECT MODE Cassette Eject Setup Connection When using two or more VCRs, the cassette tapes of all the VCRs or some of the VCRs can be ejected at the same time. VCR No. 1 EJECT IN VCR No. 2 COM EJECT OUT 1 Press the MENU button to display the MAIN MENU. 2 Press the l (or j) button to select the “5.WARNING EJECT IN COM EJECT OUT To EJECT IN terminal To COM terminal OUT/EJECT SET” line, then press the ENTER button.
NF4Q/NA (SRC-850A GB) Tue. Sept., 10/2002 SETTING FOR RS-485 USE The RS-485 interface can be used to operate the VCR using a SANYO brand system controller. Settings when using RS-485 1 Press the MENU button to display the MAIN MENU. 2 Press the l (or j) button to select the “8.OTHERS” NOTE: œ Refer to the instruction manual for the system controller. line, then press the ENTER button. ø The (OTHERS) menu appears. *ALARM@LOG *POWER@FAILURE/DEW *RS-485@SET @@STATUS@INFO.@@@Y @@ALARM@INFO.
NF4Q/NA (SRC-850A GB) Tue. Sept., 10/2002 CHECKING POWER FAILURE, FAILURE DUE TO CONDENSATION AND USAGE DURATION 1 Press the MENU button to display the MAIN MENU. 2 Press the l (or j) button to select the “8.OTHERS” NOTE: œ If the MENU RESET button is pressed while the “POWER FAILURE” and “DEW” data is displayed, the data is erased. The “USED TIME” data cannot be reset. “P” will be erased from the digital display. line, then press the ENTER button. ø The (OTHERS) menu appears.
NF4Q/NA (SRC-850A GB) Tue. Sept., 10/2002 OUTPUT TERMINALS TAPE END (SERIES) OUT Terminal NOTES: œ During recording, when the end of the tape is reached or when the tape counter reading indicates 8 hours, the output becomes 0V (Low). During autorepeat recording, the output becomes 0 V (Low) for about 2 seconds only.
NF4Q/NA (SRC-850A GB) Tue. Sept., 10/2002 OUTPUT TERMINALS 8 Press the l (or j) button to select the desired SW OUT Terminal “OUTPUT” mode, then press the ENTER button. When recording, a pulse signal is output at the SW OUT terminal. Y. . . . . . . . . . When recording, a pulse signal is output. This terminal is usually connected to the switch input (SW IN) of devices like a camera switcher unit, or a quad compressor. N . . . . . . . . . When recording, a pulse signal is not output.
NF4Q/NA (SRC-850A GB) Tue. Sept., 10/2002 OUTPUT TERMINALS VIDEO LOSS . . . . . The output becomes 0 V and “V” appears on the digital display when there is no video signal WARNING OUT Terminal œ The WARNING OUT terminal output becomes 0 V (Low) in accordance with the (WARNING OUT/EJECT SET) menu. 7 Repeat steps 5 and 6 when setting other items. 8 When finished, press the MENU EXIT button. WARNING OUT Terminal Output Setting 1 Press the MENU button to display the MAIN MENU.
NF4Q/NA (SRC-850A GB) Tue. Sept., 10/2002 OUTPUT TERMINALS REMOTE Jack Remote control setting Remote control of the VCR is possible by connecting a remote controller with a circuit such as indicated below, to the REMOTE jack. The remote control switch 7 (see illustration at left) can be set to either eject the tape or access the menus. 1 Press the MENU button to display the MAIN MENU. 2 Press the l (or j) button to select the “4.GENERAL NOTES: SET” line, then press the ENTER button. œ Use a 3.
NF4Q/NA (SRC-850A GB) Tue. Sept., 10/2002 MAINTENANCE Daily Inspection Periodic Inspection The following daily inspections are recommended in order to assure long-term and trouble-free operation of the unit. Periodic inspection and maintenance should be referred to your dealer. If there is noise in the playback picture, and it cannot be corrected using the tracking control, it may indicated that the video heads need cleaning.
NF4Q/NA (SRC-850A GB) Tue. Sept., 10/2002 MAINTENANCE Maintaining and Checking The Mechanism To maintain the VCR functions and features working properly, and to avoid damages or dirt on the tape, it is recommended to follow the maintenance points and periodicity indicated below. For detailed information, please contact your dealer.
NF4Q/NA (SRC-850A GB) Tue. Sept., 10/2002 TROUBLESHOOTING GUIDE If the unit does not operate normally when you follow the instructions indicated in the manual, please refer to the table below.
NF4Q/NA (SRC-850A GB) Tue. Sept., 10/2002 SPECIFICATIONS General Specifications Video head system Audio recording Tape speed Specified video cassette tape Recording/playback time Fast forward/rewind time Television system Dual-azimuth 4-head rotating helical scanning system: Dual azimuth 2-head for record and standard playback Dual azimuth 4-head for forward picture search, reverse picture search and still mode In 8-hour mode (when using T-160 tape) 11.
NF4Q/NA (SRC-850A GB) Tue. Sept., 10/2002 SANYO INDUSTRIAL VCR WARRANTY OBLIGATIONS In order to obtain warranty service, the product must be delivered to and picked up from an Authorized Sanyo Service Center at the user’s expense, unless specifically stated otherwise in this warranty. The names and addresses of Authorized Sanyo Service Centers may be obtained by calling the toll-free number listed below.
NF4Q/NA (SRC-850A GB) Tue. Sept.
