General View of the Weighing Platform No.
With this Sartorius IS weighing platform, you have acquired a high-quality weighing instrument that features advanced technology. As a rule, you will be using this weighing platform as part of a modular weighing System. Please read through these installation and operating instructions carefully before operating your new weighing platform. Warranty Do not miss out on the benefits of our full warranty.
Safety Instructions Only authorized service technicians trained by Sartorius are allowed to open the weighing cell and A/D Converter enclosures, which are located inside the weighing platform, for repair work according to Sartorius Standard operating procedure. Before opening the weighing cell or A/D Converter enclosure, make sure to unplug the weighing platform from the power supply! You are allowed to operate the weighing platform in a Zone 2 hazardous area (in Europe).
Installation Instructions Sartorius dealers or service technicians, who have received special training, will help you set up the weighing platform and show you how to operate it. Ambient Conditions Choose a suitable place to set up the weighing platform.
IP67 Protection The IP67 protection of the weighing platform is guaranteed only if the platform is in original factory condition. In conformance with the IP67 protection rating, the weighing platform will remain leaktight for 30 minutes if immersed at a depth of 1 meter (approx. 3 ft.).
Getting Stared Unpacking the Weighing Platform — — Remove the weighing platform and separate load plate from the packaging Remove the plastic bags, packaging strips and foam material Transport Locking Devices Set up the weighing platform in the vicinity of your work area, remove the load plate (1), and remove the red plastic caps. Loosen the fastening screws on the retainer plates using the Allen wrench (key) that is supplied with the weighing platform.
Leveling the Weighing Platform Using the Level Indicator At the place of Installation, you will need to loosen the locknuts or knurled nuts on the leveling feet using the open-end wrench (Spanner) that is supplied with the scale. Then level the weighing platform using the leveling feet (3) so that the air bubble is centered within the circle of the level indicator (4): To lift the weighing platform, extend the leveling feet (turn clockwise).
Connecting the Weighing Platform Please note that the person or Company who connects any non-Sartoriusapproved indicating and control devices (e.g., a Computer) or power supplies to the weighing platform shall assume all risks and responsibilities associated with this equipment. Plug the connecting cable into the connector of a Sartorius isi industrial terminal. Afterwards, hand-tighten the locking ring. The connecting cable is 3 meters long (approx. 10 feet).
Cables for connecting the industrial-grade AC adapter, ING2, to the isi industrial terminal without an extension cord (using the YD0501S (3 m) or YD0531S (6 m) data output port): The industrial-grade AC adapter, ING2, can be connected only to the isi industrial terminal with an extension cord at a maximum length of 12 m (~ 40 ft): lf both the isi terminal and the IS weighing platform are powered by separate industrial-grade ING2 AC adapters, the interface cable for data transmission via the RS 485 port ca
For detailed Information on further options for powering the weighing platform (e.g., using local low voltage), contact Sartorius AG headquarters in Germany or one of the main offices based in your country. Hook up the weighing platform to the power supply in conformance with the Installation requirements of your country. Safety Precautions The Sartorius power supply rated to Industrial Class 2 can be plugged into any electrical outlet without requiring any additional safety precautions.
Warm-up Time The weighing platform will need to warm up for at least 30 minutes after initial connection to the power supply (or after a relatively long period without power connection). Preparing the Weighing Platform for Verification as a Legal Measuring Instrument in the EU*: After initially connecting the weighing platform to the power supply (or after a relatively long power outage), allow the platform to warm up for at least 24 hours.
Operating Limits Maximum Overload Capacity Sartorius weighing platforms are built so that occasionally loading them beyond their maximum weighing capacity will not damage them in any way. The maximum overload capacity of this IS model is 130 kg. Shock Resistance Even though Sartorius weighing platforms feature a highly rugged construction, there are some limits. Avoid dropping heavy objects from a considerable height on the weighing platform and do not expose it to strong side impact.
General Instructions for Integration into Conveyor Systems The IS weighing platform is suitable for installation in conveyor Systems. Follow the general instructions given below and refer to the "Dimensions (Scale Drawings)" to meet the requirements for such installation. Any moving or rotating parts intended to be permanently attached to the load plate must be designed so that they cannot affect the weighing results. For example, rotating mechanisms must be properly balanced.
Configuring the Weighing Platform You can adapt the weighing platform to meet your specific requirements e.g., metrological specifications, for weighing in international weight unite and to perform optimally under various ambient conditions as well as process weighing data. For this reason, final configuration of your Sartorius Modular Technology equipment is possible only at your dealers or your particular facilities.
Specifications Chart Access the configuration menu of the connected suited Sartorius terminal to set the code for the group of specifications of your choice. You must set one of the appropriate codes before verification of the platform as a legal measuring instrument. Please note that when you change the configuration, this may also change the accuracy class and the preload range besides the weighing capacity and the readability. Then select the appropriate ID label and affix it to the weighing platform.
General Technical Specifications (for use Standard Applications Not Subject to Legal Metrology) Model Readability Reproducibility (standard deviation) Linearity Response time (average) Fastest response time (IQ) Adaption to ambient conditions and application requirements Data output speed (depends on the filter level selected) Dust and water protection rating acc. to DIN 40050/IEC 529 Net weight, approx.
Dimensions (Scale Drawings) IS 64 FEG-S0CE Area for attaching conveyor components; fasteners may protrude below by 10 mm max.
Pin Assignment RS-485,3-m Cable Male Connector: Type C091 D, 1 2-pin round connector with threaded locking ring, Amphenol (IP67) Pin Assignment A B C D E F G H J K L M RxD-TxD-N Not Connected Not Connected Not Connected Signal GND Menu Access Switch for Calibration/ Adjustment (routed externally) VCC (24-V Power Supply) Not Connected GND (24-V Power Supply: GND (24-V Power Supply: RxD-TxD-P VCC (24-V Power Supply) Interface Connector (Recommended): TvpeC091D, 12-pin Amphenol(IP67) Type of cable: AWG 24
Troubleshooting Guide (For Problems That You Can Fix Yourself Problem Possible Causes Solution No segments appear on the display - No line current is available - The AC adapter is not plugged in - Check the power supply - Plug the AC adapter into the platform and into an electrical outlet - Turn on the isi industrial standby mode for more than - The weighing platform has been in terminal using the 5 minutes the on/off switch The weight display shows "H" - The load exceeds the capacity of the wei
Problem Possible Causes Solution The error code "Err 10" is displayed - No values are stored in the tare memories for your application, and you tried to clear the lowerlevel tare memory - Clear the tare memories for your application first, then clear the clear the lower-level tare memory The error code "Err 12" is displayed - You tried to store a value in the tare memory for applications, although this memory has been blocked by menu code 2 2 x - Check the configuration - You entered a numeric tare
Care and Maintenance Servicing Regular servicing by a Sartorius technician will extend the service life of your weighing platform and ensure its continued weighing accuracy. Sartorius can offer you service contracts, with your choice of regular maintenance intervals ranging from 1 month to 2 years. Cleaning Before cleaning the weighing platform, unplug it from the power supply (disconnect the AC adapter).
Safely Inspection lf there is any indication that safe Operation of the weighing platform is no longer warranted, turn off the power and disconnect it from the power supply immediately. Lock the equipment in a secure place to ensure that it cannot be used for the time being.
Use of the Weighing Platform as a Legal Measuring Instrument in the EU* Components of a Legal Weighing Instrument Your weighing platform is considered a modular device. Only when this device is connected to a suitable Sartorius indicating and operator terminal and has been verified in this configuration (a different configuration can be specified for initial verification) does it constitute an approved legal weighing instrument.
Effect of the Preload on the Acceptability for Verification in the EU* Only internal adjustment (calibration) is allowed for weighing instruments verified as legal measuring instruments (refer to the operating instructions for the particular 15) industrial terminal you are using). Therefore, if you use your weighing platform in a configuration for which you cannot use the ISO test on account of the relatively high preload, the platform is not acceptable for verification.
Approved Auxiliary Measuring Devices When using the weighing platform as a legal measuring Instrument in the EU, you may connect to it only auxiliary measuring devices that have been approved for legal metrology. Approved auxiliary measuring devices are identified by the verification ID marks and metrology stickers affixed to them by a representative authorized to perform verification.
Declarations of Conformity The Mark on Sartorius Equipment In 1985, the Council of the European Community approved a resolution concerning a new approach to the technical harmonization and standardization of national regulations. The organization for monitoring marking is compliance with the directives and Standards concerning governed in the individual EU Member States through the implementation of the EC Directives adopted by the respective national laws.
Council Directive 73/23/EEC "Electrical Equipment Designed for Use within Certain Voltage Limits" Applicable European Standards: EN 60950 Safety on information technology equipment including electrical Business equipment EN61010 Safety requirements for electrical equipment for measurement, control and laboratory use Part 1 : General Requirements lf you use electrical equipment in installations and under ambient conditions requiring higher safety Standards, you must comply with the provisions as specified in
“EC Verification – A Service Offered by Sartorius Our service technicians authorized to perform the verification* of your weighing Instruments which are acceptable for legal metrological verification can inspect and verify the metrological specifications at the place of installation within the Member States of the European Union and the Signatories of the European Economic Area. "New Installation" Service Initial verification is covered in our "New Installation" service package.
Accessories (Options) Order No.
Special menu access locking device, IP65 (for legal metrology); for external positioning of the menu access lock on weighing platforms built into Systems. lf this device is used, a tag plate for ID labels is not required. YAS 02 IS Upgrade kit for DC power supply to the weighing platform (without using an external AC adapter or power supply) IP67 cable gland (to be installed by an authorized service technician only) YAS 03 IS External rechargeable battery pack; hours of Operation approx.
Selecting and Attaching ID Plates The ID plate is to be selected and attached according to the specification block (configuration of scales) and the display and control unit (terminal). For details of how to position the ID plate on the scales or tag holder, refer to the instructions in "Plates and Markings". If display and control units (terminals) of type TA, models CAIS1, CAISL1, CAIS2, CAISL2, CAIS3, CAISL3 are being used, EC Type Approval Certificate No. T7899, type SARTOCOWAT is applicable.
