Service Manual Printers CL608e/CL612e

Page 6-18
Section 6. Replacement Procedures
SATO CL608e/CL612e Service Manual
PN 9001079
Rev. B
Fig. 6-28
RECONNECT
CABLES
PRINT HEAD
ALIGNMENT
PINS
Fig. 6-29
FOR THIS MODEL
PRINTER SET SWITCH
TO THE RIGHT
Replacing the Print Head
