Congratulations on your purchase of a Saturn RELAY. Please read this information and your Owner Manual

to ensure an outstanding ownership experience. Note that your vehicle may not include all the features

described in this booklet. Keep this booklet with your Owner Manual for easy reference.

DRIVER INFORMATION

Instrument Panel . . . . . . . . . . . . . . . . . . . . . . . . .2

Instrument Panel Cluster . . . . . . . . . . . . . . . . . . .3

Driver Information Center (DIC) . . . . . . . . . . . . . .4

REMOTE KEYLESS ENTRY

Remote Keyless Entry (RKE) . . . . . . . . . . . . . . . .6

Remote Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

ENTERTAINMENT

Audio Systems . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Multiple-Disc CD Changer . . . . . . . . . . . . . . . . . .9

Rear Seat Entertainment (RSE) System

(DVD Player) . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Steering Wheel Audio Controls . . . . . . . . . . . . .11

CONVENIENCE

Daytime Running Lamps (DRL) . . . . . . . . . . . . .11

Interior Lamps . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Cruise Control . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Window Washer Fluid . . . . . . . . . . . . . . . . . . . . .13

Passenger Air Bag Status Indicator . . . . . . . . .13

Universal Home Remote . . . . . . . . . . . . . . . . . . .13

OnStar

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Power Sliding Doors . . . . . . . . . . . . . . . . . . . . . .14

Rear Seat Climate Control with RSE . . . . . . . . .15

Folding Rear Seats . . . . . . . . . . . . . . . . . . . . . . .15

Foldaway Tray . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Rear Hideaway Storage Bins . . . . . . . . . . . . . . .16

Child Restraints (LATCH) . . . . . . . . . . . . . . . . .16

Overhead Rail Bins . . . . . . . . . . . . . . . . . . . . . . .17

115-Volt Power Outlet . . . . . . . . . . . . . . . . . . . . .17

Air Inflator Tools . . . . . . . . . . . . . . . . . . . . . . . . .17

Rear Parking Assist (RPA) . . . . . . . . . . . . . . . . .17

PERFORMANCE & MAINTENANCE

Automatic Level Control . . . . . . . . . . . . . . . . . . .18

Traction Control . . . . . . . . . . . . . . . . . . . . . . . . . .18

StabiliTrak

– Stability Control System . . . . . . .18

Proper Tire Pressure . . . . . . . . . . . . . . . . . . . . . .19

Service Intervals . . . . . . . . . . . . . . . . . . . . . . . . .19

FlexFuel (E85) – Yellow Gas Cap . . . . . . . . . . . .19

OWNER INFORMATION

Roadside

Assistance

. . . . . . . . . . . . . . . . . . . . .

My Saturn . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

RELAY 2007 A 7/19/06 3:43 PM Page 1

Summary of content (20 pages)

PAGE 1
RELAY 2007 A 7/19/06 3:43 PM Page 1 DRIVER INFORMATION Instrument Panel . . . . . . . . . . . . . . . . . . . . . . . . .2 Instrument Panel Cluster . . . . . . . . . . . . . . . . . . .3 Driver Information Center (DIC) . . . . . . . . . . . . . .4 REMOTE KEYLESS ENTRY Remote Keyless Entry (RKE) . . . . . . . . . . . . . . . .6 Remote Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 ENTERTAINMENT Audio Systems . . . . . . . . . . . . . . . . . . . . . . . . . . .
PAGE 2
Page 2 See Section 3 of your Owner Manual. M. Parking Brake N. Horn O. Cruise Controls P. Climate Controls Q. Heated Seat Controls R. Glove Box 3:43 PM H. Passenger Air Bag Status Indicator I. Audio System J. Exterior Lamps Control K. Interior Lamps Control L. Hood Release 7/19/06 Air Outlets Turn Signal/Multifunction Lever Steering Wheel Audio Controls Instrument Panel Cluster DIC Controls Traction Control Button Hazard Warning Flashers Button Getting to Know Your RELAY A. B. C. D. E. F. G.
PAGE 3
A B C D RELAY 2007 A Instrument Panel Cluster E 7/19/06 3:43 PM Page 3 Your vehicle’s instrument panel is equipped with this cluster or one very similar to it. The instrument panel cluster includes these key features: A. Fuel Gauge B. Speedometer C. Tachometer D. Driver Information Center Display/Odometer E. Engine Coolant Temperature Gauge Note: The instrument panel cluster is designed to let you know about many important aspects of your 3 See Section 3 of your Owner Manual.
PAGE 4
RELAY 2007 A 4 7/19/06 3:43 PM Page 4 Getting to Know Your RELAY Driver Information Center (DIC) Your vehicle’s Driver Information Center, located below the tachometer in the instrument panel cluster, can display trip information, fuel economy information, personalization features and other vehicle messages and warnings. The DIC controls are located on the instrument panel to the right of the steering wheel.
PAGE 5
RELAY 2007 A 7/19/06 3:43 PM Page 5 5 Personal Program and Compass (if equipped) Press the (Menu) button to scroll through the following features: • Personal Program — Certain features that may be programmed to your personal preference • Compass Zone — The compass can be set for one of 15 geographic zones • Compass Calibration — Adjusts for compass variance and zone To display the odometer, press the (Information) button.
PAGE 6
RELAY 2007 A 6 7/19/06 3:43 PM Page 6 Getting to Know Your RELAY Compass Your vehicle’s compass is self-calibrating. However, it may be necessary under certain circumstances, such as during a long-distance cross-country trip, to compensate for compass variance and reset the compass zone through the DIC. Refer to the calibration procedure in your Owner Manual for more details. See Section 3 of your Owner Manual.
PAGE 7
RELAY 2007 A 7/19/06 3:48 PM Page 7 7 The remote start system will not operate if the hood, the liftgate or a door is open, or if the key is in the ignition. Starting the Vehicle 1. Aim the RKE transmitter at the vehicle. 2. Press and release the (Lock) button on the RKE transmitter. 3. Immediately press and hold the (Remote Start) button for about two seconds. 4. When the vehicle starts, the parking lamps will light and stay on while the engine is running. 5.
PAGE 8
RELAY 2007 A 8 7/19/06 3:43 PM Page 8 Getting to Know Your RELAY Radio Controls Top Knob (Power/Volume): Press this knob to turn your audio system on or off. Turn this knob to increase or decrease the volume. (Tune): Turn this knob to select radio stations. : Press the right or left arrow to go to the next or previous station and stay there. To scan radio stations, press and hold either arrow for two seconds until a single beep sounds and FREQUENCY SCAN appears on the display.
PAGE 9
RELAY 2007 A 7/19/06 3:43 PM Page 9 9 RPT (Repeat): Press this button to hear a track again. Press the button again to turn off repeat play. (Song List): Press and hold this button to save and play up to 20 track selections in the song list. MUTE (if equipped): Press this button to silence the audio system. Press this button again to turn the sound on. (Load) (if equipped): Press this button to load CDs into the six-disc CD player. (Eject): Press this button to eject a CD.
PAGE 10
RELAY 2007 A 10 7/19/06 3:43 PM Page 10 Getting to Know Your RELAY Rear Seat Entertainment (RSE) System (DVD Player) (if equipped) The Rear Seat Entertainment (RSE) System can play a DVD, CD or MP3 disc. All passengers can listen to the system using the vehicle speakers. Passengers in the 2nd- and 3rd-row seats also can listen using the wireless headphones (if equipped) or by plugging owner-provided wired headphones into the two headphone jacks. Using the DVD Player 1.
PAGE 11
RELAY 2007 A 7/19/06 3:44 PM Page 11 11 Parental Controls While a disc is playing in the DVD player or while using Rear Seat Audio (RSA), press the Parental Control button, located behind the video screen next to the auxiliary jacks, to stop the video and mute the audio. The DVD and RSA lights will flash. It will also disable all other button operations except the Eject button. Press the button again to restore normal operation. (Seek): Seeks radio stations or the next track on a CD.
PAGE 12
RELAY 2007 A 12 7/19/06 3:44 PM Page 12 Getting to Know Your RELAY Interior Lamps The interior lamps control knob is located on the instrument panel to the left of the steering wheel. (On): Turns on the interior lamps. (Door): Enables the interior lamps to illuminate when a door is opened and the key is removed from the ignition. (Override): Disables the interior lamps. (Instrument Panel Brightness Control): Turn the knob clockwise to brighten the lights and counterclockwise to dim them.
PAGE 13
RELAY 2007 A 7/19/06 3:44 PM Page 13 13 Window Washer Fluid Your vehicle’s windshield washer fluid reservoir, located under the hood, sends washer fluid to both the windshield and the rear window. When the reservoir is almost empty, the rear washer will no longer receive fluid, thereby conserving fluid for the windshield. It’s recommended to refill the reservoir when you notice the rear washer is not receiving any fluid. See Section 3 of your Owner Manual.
PAGE 14
RELAY 2007 A 14 7/19/06 3:44 PM Page 14 Getting to Know Your RELAY Power Sliding Doors (if equipped) On equipped vehicles, driver-side and/or passenger-side Power Sliding Doors provide added operating convenience. The Power Sliding Doors may be controlled by: Switches on the Overhead Console • (Driver-side door): Press the top of the switch (closer to you) to open the door; press it again to close.
PAGE 15
RELAY 2007 A 7/19/06 3:44 PM Page 15 15 Rear Seat Climate Control with the RSE System (if equipped) The driver or the rear seat passengers can operate the rear seat climate control. The driver can operate the rear seat climate control by using the rear fan switch located at the bottom center of the front climate control panel.
PAGE 16
RELAY 2007 A 16 7/19/06 3:44 PM Page 16 Getting to Know Your RELAY 3rd-Row 50/50 Split Bench Seat To fold the seats for more cargo room: 1. Pull the seatback latch located on the back of the seat. 2. Fold the seatback forward. The headrest will flip rearward if it contacts an object when the seat is folded forward. 3.
PAGE 17
RELAY 2007 A 7/19/06 3:44 PM Page 17 17 Overhead Rail Bins (if equipped) Overhead rail system storage modules featuring a variety of accessories are available from your dealer. The storage modules do not slide on the rails, but can be removed and repositioned. Installing a Storage Module 1. Place the storage module on the rails in the desired location. 2. Push firmly upward on the module while supporting it with one hand. 3. The module will snap into place. Removing a Storage Module 1.
PAGE 18
RELAY 2007 A 18 7/19/06 3:44 PM Page 18 Getting to Know Your RELAY The RPA system features a different sequence of warning lights and chimes than on previous systems. • When in reverse, a chime will sound the first time an object is detected if the object is between 20 inches and five feet away. • At five feet, the RPA indicator (located near the rear dome light) will display one amber light. • As you move closer, an additional amber light will appear.
PAGE 19
RELAY 2007 A 7/19/06 3:44 PM Page 19 19 Proper Tire Pressure Check all tires frequently to maintain the recommended pressure. A Tire and Loading Information label, located near the driver’s door latch, shows the correct inflation pressures for your tires when they’re cold. “Cold” means your vehicle has been sitting for at least three hours or driven no more than one mile. See Section 5 of your Owner Manual.
PAGE 20
RELAY 2007 A 20 7/19/06 3:44 PM Page 20 Getting to Know Your RELAY OWNER INFORMATION Roadside Assistance 1-800-553-6000 TTY Users: 1-888-889-2438 As the proud owner of a new Saturn vehicle, you are automatically enrolled in the Saturn Roadside Assistance program. This value-added service is intended to provide you with peace of mind as you drive in the city or travel the open road.
