Congratulations on your purchase of a Saturn OUTLOOK. Please read this information and your Owner

Manual to ensure an outstanding ownership experience. Note that your vehicle may not include all the

features described in this booklet. Keep this booklet with your Owner Manual for easy reference.

DRIVER INFORMATION

Instrument Panel . . . . . . . . . . . . .2

Instrument Panel Cluster . . . . . . .3

Driver Information Center . . . . . . .4

SAFETY & SECURITY

Remote Keyless Entry . . . . . . . . .5

OnStar

. . . . . . . . . . . . . . . . . . . . . .6

Child Restraints (LATCH) . . . . . . .6

COMFORT

Seat Adjustments . . . . . . . . . . . . .6

2nd-Row Seats . . . . . . . . . . . . . . .7

3rd-Row Seats . . . . . . . . . . . . . . . .8

Heated Seat Controls . . . . . . . . . .8

Memory Seat and Mirrors . . . . . . .9

Steering Wheel Adjustment . . . . .9

Dual Automatic Climate

Controls . . . . . . . . . . . . . . . . . . . . .9

Manual Climate Controls . . . . . .10

Rear Seat Climate Controls . . . .11

ENTERTAINMENT

Audio System Features . . . . . . .12

Navigation Entertainment

System . . . . . . . . . . . . . . . . . . . . .14

Audio Steering Wheel Controls .14

Bluetooth

System . . . . . . . . . . .14

Rear Seat Audio and DVD

Rear Seat Entertainment

Systems . . . . . . . . . . . . . . . . . . . .15

Radio . . . . . . . . . . . . . . . . . .16

CONVENIENCE

Automatic Headlamp System . . .16

Interior Lighting Features . . . . . .16

Windshield Wipers and Washer .17

Heated Washer Fluid . . . . . . . . . .17

Outside Power Foldaway

Mirrors . . . . . . . . . . . . . . . . . . . . .18

Power Windows . . . . . . . . . . . . . .18

Sunroof . . . . . . . . . . . . . . . . . . . . .18

Cruise Control . . . . . . . . . . . . . . .19

Rear Convenience Center . . . . .19

Center Console Features . . . . . .19

2nd-Row Console Features . . . .20

115-Volt Outlet . . . . . . . . . . . . . . .20

Ultrasonic Rear Park Assist . . . .20

Power Liftgate . . . . . . . . . . . . . . .20

Remote Vehicle Start . . . . . . . . .21

PERFORMANCE & MAINTENANCE

Refueling the Vehicle . . . . . . . . .22

Automatic Transmission

Operation . . . . . . . . . . . . . . . . . . .22

StabiliTrak

– Stability Control

System . . . . . . . . . . . . . . . . . . . . .22

Trailer Towing . . . . . . . . . . . . . . .22

Tire Pressure Monitor . . . . . . . . .23

Resetting the Oil Life System . .23

OWNER INFORMATION

Roadside Assistance . . . . . . . . .24

My Saturn . . . . . . . . . . . . . . . . . . .24

Summary of content (24 pages)

PAGE 1
DRIVER INFORMATION Instrument Panel . . . . . . . . . . . . .2 Instrument Panel Cluster . . . . . . .3 Driver Information Center . . . . . . .4 SAFETY & SECURITY Remote Keyless Entry . . . . . . . . .5 OnStar® . . . . . . . . . . . . . . . . . . . . . .6 Child Restraints (LATCH) . . . . . . .6 COMFORT Seat Adjustments . . . . . . . . . . . . .6 2nd-Row Seats . . . . . . . . . . . . . . .7 3rd-Row Seats . . . . . . . . . . . . . . . .8 Heated Seat Controls . . . . . . . . . .8 Memory Seat and Mirrors . . . .
PAGE 2
Getting to Know Your OUTLOOK 2 DRIVER INFORMATION Instrument Panel A H I B J K C L M D E A F N O P Q R S T The main features of the instrument panel include: A. Air Outlets B. Turn Signal/Windshield Wipers/Multifunction Lever C. Instrument Panel Cluster D. Driver Information Center Buttons (if equipped) E. Hazard Warning Flashers Button F. Audio System/Navigation System (if equipped) G. Passenger Airbag Status Indicator H. Exterior Lamps Control I. Instrument Panel Brightness Control J.
PAGE 3
Instrument Panel Cluster A B C D E Your vehicle’s instrument panel is equipped with this cluster or one very similar to it. The instrument panel cluster includes these key features: A. Engine Coolant Temperature Gauge B. Tachometer C. Malfunction Indicator Lamp (Check Engine Light) D. Tire Pressure Warning Light E. Driver Information Center F. Fuel Gauge G. Speedometer H. Security Light I. Cruise Control Set Light F G H I J K L J. Antilock Brake System Warning Light K.
PAGE 4
Getting to Know Your OUTLOOK Driver Information Center Your vehicle’s Driver Information Center (DIC) provides vehicle information, vehicle feature customization, and vehicle warning messages. The DIC messages will be shown on the instrument panel cluster display.
PAGE 5
Customization Settings with DIC Buttons To customize features: 1. With the vehicle in Park, turn on the ignition. 2. Press the (Customization) button to enter the Feature Settings menu. 3. Press the button to scroll through the available customization features. 4. With the desired feature displayed, press the (Set/Reset) button to access the settings. 5. Press the button to scroll through the available settings. 6. With the desired setting displayed, press the button to select it. 7.
PAGE 6
Getting to Know Your OUTLOOK (Power Liftgate) (if equipped): Press and hold this button until the liftgate starts moving to open and close the liftgate. The taillamps will flash and a chime will sound when the liftgate is moving. (Vehicle Locator/Panic Alarm): Press and release this button to locate your vehicle. The turn signal lamps will flash and the horn will sound three times. Press and hold the button to activate the panic alarm.
PAGE 7
Manual Lumbar Support Adjustment (if equipped) 2nd-Row Seats Entering or Exiting the 3rd-Row Seats To increase the amount of lumbar support, pull up the lever located on the inboard side of the seatback. To decrease support, push down on the lever.
PAGE 8
Getting to Know Your OUTLOOK Sliding the Seats To slide the 2nd-row seats for more leg room in the 2nd or 3rd row: 1. Make sure nothing is on the floor in front or behind the 2nd-row seat. 2. Pull outward on the handle located on the outboard side of the seat cushion and slide the seat forward or rearward. 3. Release the handle. 4. Pull on the seat to make sure it is locked in place. Folding the Seatbacks To fold the seatbacks forward to create a flat load floor: 1.
PAGE 9
Continue to press the desired button to cycle through the temperature settings of High (three indicator lights), Medium (two indicator lights), Low (one indicator light), and Off (no indicator lights). See Section 1 of your Owner Manual. Memory Seat and Mirrors (if equipped) Memory settings can be programmed for the position of the driver’s seat and outside mirrors. The memory buttons are located on the driver’s door. To save memory settings: 1.
PAGE 10
Getting to Know Your OUTLOOK Automatic Operation 1. Press the AUTO button. 2. Set the desired driver’s and front passenger’s temperature using the + or – temperature buttons. Allow time for the system to reach the desired temperature. Manual Operation To operate the system manually, use the following controls: (On/Off): Press this button to turn the system on or off. Temperature Control: Press the + or – temperature button(s) to raise or lower the temperature setting(s).
PAGE 11
(Recirculation): Press this button to recirculate air inside the vehicle. This mode keeps outside air from entering the vehicle. The recirculation feature will operate only when the vent or bi-level airflow setting is selected. Airflow Modes Turn the airflow mode knob (C) to change the direction of the airflow to the floor, vent or defog outlets. The knob can be positioned between two modes for a wide range of airflow adjustments. (Vent): Directs air to the vent outlets.
PAGE 12
Getting to Know Your OUTLOOK ENTERTAINMENT Audio System Features While most of the features on your radio will look familiar, some of the following may be new: (Power/Volume): Press this knob to turn the system on or off. Turn the knob to adjust the volume. (Tune): Turn this knob to select radio stations or, when a CD is playing, to select a track or MP3 file. Tone and Speaker Control: Press the (Tune) knob to adjust the tone control (bass/treble) or speaker control (balance/fade) setting.
PAGE 13
You can set up to six pages of any combination (AM, FM, or XM, if equipped) of favorite radio stations, with up to six stations stored on each page. To set the number of favorite station pages: 1. Press the MENU button to display the radio setup menu. 2. Press the pushbutton located below the FAV 1–6 label on the radio display. 3. Select the desired number of favorite station pages. 4. Press the FAV button. You may now begin storing your favorite stations for the chosen number of pages.
PAGE 14
Getting to Know Your OUTLOOK Navigation Entertainment System (if equipped) Your vehicle’s Navigation Entertainment System provides you with detailed maps of all major highways and roads throughout the United States. The system provides turn-by-turn driving instructions for each destination you enter. In addition, the system can help you locate a variety of points of interest, such as banks, airports and restaurants. Refer to your Navigation Entertainment System Owner Manual for operating instructions.
PAGE 15
Rear Seat Audio and DVD Rear Seat Entertainment Systems (if equipped) Rear Seat Audio The Rear Seat Audio (RSA) system allows front seat and rear seat passengers to listen to different entertainment sources at the same time using the rear seat controls and wired headphones (not supplied) or wireless headphones (if equipped). To select an entertainment source (radio, CD, or DVD, if equipped): • Press the SRCE (Source) button.
PAGE 16
Getting to Know Your OUTLOOK XM ® Radio XM Radio provides more than 170 channels of digital-quality sound that goes wherever you go — coast to coast. After a free three-month trial period, activation and service subscription fees apply. Service is based in the continental United States and Canada. For more information, visit XM online at www.XMradio.com or call 1-800-929-2100. See Section 3 of your Owner Manual. CONVENIENCE Automatic Headlamp System side of the instrument panel.
PAGE 17
Windshield Wipers and Washer The wiper controls, located on the multifunction lever on the left side of the steering column, include the following functions: (Mist): Rotate the control band to this position to turn the wipers on for one wipe. (Off): Rotate the control band to this position to turn off the wipers. (Delay): Rotate the control band to one of these positions to adjust the delay between wipes. The wipers activate more often as the band is rotated upward.
PAGE 18
Getting to Know Your OUTLOOK (Mirror Adjustment): Press the four-way control pad (B) to adjust the selected mirror. (Foldaway Mirrors) (if equipped): Press the right side of this switch (C) to fold the mirrors, and press the left side of this switch to unfold the mirrors. Express-Down Windows To operate the driver or front passenger express-down window (if equipped), press the switch completely and the window will go all the way down automatically.
PAGE 19
Vent: From the closed position, press and hold the front of the driver’s side switch (A) to vent the sunroof. Press and hold the rear of the switch to close the sunroof. Front Sunshade: Push up and slightly forward on the sunshade handle and then release it rearward to open the manual sunshade. Rear Sunshade (if equipped): Press and release the rear of the passenger’s side switch (B) to express-open the sunshade over the 2nd-row seats.
PAGE 20
Getting to Know Your OUTLOOK 2nd-Row Console Features (if equipped) To open the upper storage area, press the upper button located on the front of the console. To open the lower storage area, press the lower button located on the front of the console. To fold the top of the console forward for increased storage space, slide the front console completely forward; then lift up the handle on the rear of the 2nd-row console and pull forward. See Section 2 of your Owner Manual.
PAGE 21
• Press the (Power Liftgate) button on the center console in front of the shift lever. Press it again to reverse operation. • Press the touchpad on the liftgate handle to open. Press it again to reverse operation. • Press the button on the bottom of the liftgate, next to the liftgate latch, to close. Press it again to reverse operation. To disable all power liftgate controls, switch the button on the center console to the OFF position. The liftgate can be opened and closed manually.
PAGE 22
Getting to Know Your OUTLOOK PERFORMANCE & MAINTENANCE StabiliTrak ® – Stability Control System Refueling the Vehicle To open the fuel door, press the center of the rear edge of the door and it will pop open slightly. Pull the door to open it fully. When closing the fuel door, press the center of the rear edge of the door until it is flush with the side of the vehicle. See Section 5 of your Owner Manual.
PAGE 23
Tire Pressure Monitor The Tire Pressure Monitor alerts you when a significant reduction in pressure occurs in one or more of your vehicle’s tires by illuminating the (Low Tire Pressure) warning light on the instrument panel. The low tire pressure warning light will remain on until you correct the tire pressure. A CHECK TIRE PRESSURE message may appear on the DIC.
PAGE 24
Getting to Know Your OUTLOOK OWNER INFORMATION Roadside Assistance 1-800-553-6000 TTY Users: 1-888-889-2438 As the proud owner of a new Saturn vehicle, you are automatically enrolled in the Saturn Roadside Assistance program. This value-added service is intended to provide you with peace of mind as you drive in the city or travel the open road.
