Installation Guide Savi SensorTag ST-676-I ISO Container Door Tag with Sensors Version 1.
Published September 2005 Part number 805-05125-001 Rev A Documentation for Savi SensorTag ST-676-I ISO Container Door Tag with Sensors, version 1.0 Copyright © 2005 Savi Technology, Inc. All rights reserved. Information in this manual is subject to change without notice and does not represent a commitment from the vendor. The software and/or databases described in this document are furnished under a license agreement or nondisclosure agreement.
Contents 1 About Savi SensorTag ST-676-I ISO Container Door Tag with Sensors Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 For More Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Guides to Read . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Contacting Savi Support . . . . . . . . . . . . .
Savi SensorTag ST-676-I ISO Container Door Tag with Sensors Installation Guide
CHAPTER 1 About Savi SensorTag ST-676-I ISO Container Door Tag with Sensors 1 Savi® SensorTag ST-676-I ISO Container Door Tag with Sensors is a high performance active RFID tag that works with Savi software to track and monitor the security status of containers as they move through the global supply chain. This device is fully compatible with fixed and portable Savi readers and features up to 300 feet (91.44 meters) of omni-directional line-of-sight range. Lithium battery life is typically four years.
CHAPTER 1 About Savi SensorTag ST-676-I ISO Container Door Tag with Sensors Description Figure 1-1 Savi SensorTag ST-676-I ISO Container Door Tag with Sensors Front view External patch antenna Back view Light sensor Tag Top view of tag Door sensor Easy to install door clamp; clips onto front door of container.
Description Intrusion Detection Sensors The ST-676-I tags include door and light sensors. The door sensor monitors the amount of pressure between the door and the device. If the door is open and the device has not been electronically unsealed, the device sends a message to the monitoring software indicating that the device has been tampered. It also writes the time and date of the tamper to an event log.
CHAPTER 1 About Savi SensorTag ST-676-I ISO Container Door Tag with Sensors For More Information Guides to Read For information about using: ◆ Signposts, see the Savi Signpost SP-65X Series Installation Guide ◆ Fixed readers, see the Savi Fixed Reader SR-650-101 Installation Guide ◆ Mobile readers, see the Savi Mobile Reader SMR-650 for the Intermec 751G/A Mobile Computer and PC User Guide Contacting Savi Support If you cannot find the information you need, contact Savi Support. ◆ Check www.savi.
CHAPTER 2 Installing Savi SensorTag ST-676-I ISO Container Door Tag with Sensors 2 Required Tools and Materials Before you begin installation, make sure the following materials are available: Savi SensorTag ST-676-I ISO Container Door Tag with Sensors ◆ SaviTag Write Cable STA-1030 ◆ One 3.
Installing Savi SensorTag ST-676-I ISO Container Door Tag with Sensors 1. Connect SaviTag Write Cable STA-1030 to an available serial port on the host computer. 2. Locate the tag commissioning port on the Savi SensorTag ST-676-I ISO Container Door Tag with Sensors. Port 3. Unplug the rubber cap covering the port. 4. Insert SaviTag Write Cable STA-1030, with the LED up, into the Savi SensorTag ST-676-I ISO Container Door Tag with Sensors commissioning port. Start the tag commissioning application.
Replacing the Battery Replacing the Battery Savi SensorTag ST-676-I ISO Container Door Tag with Sensors is equipped with non-volatile memory, which means stored data is not lost when you replace the battery. 1. Using a coin or flat-head screwdriver, turn the battery cover counterclockwise. When removing the battery cover, hold on to it to avoid dropping it. 2. Remove the discharged battery from its compartment. Warning: The lithium battery can be harmful to the environment.
Installing Savi SensorTag ST-676-I ISO Container Door Tag with Sensors The tag beeps twice if you install a fully charged battery. The tag beeps three times if you install a battery with low charge; replace it with a charged battery. When removing and replacing a charged battery, you may need to wait a few seconds after replacing the battery to hear the confirmation beep. 4. Replace the battery cover using a coin or screwdriver. With the coin placed in the battery cover groove, push the cover in.
Tag Placement Tag Placement Savi Technology recommends that you fit the Savi SensorTag ST-676-I ISO Container Door Tag with Sensors above the door bracket and on the left-hand door of the container. The recommended mounting location for the tag is shown in the following photos.
Installing Savi SensorTag ST-676-I ISO Container Door Tag with Sensors 1. Open the right door of the container. 2. Align the device with the bracket on the right door, if possible. Door bracket 3. Using both hands, secure the device on the left door until it is flush. This is a view from inside the container. 4. Move the door sensor to the left and ensure that the lever is fully extended before closing the container door. Door sensor This is a side view of the device mounted on the left door.
Tag Placement This is a view of the outside of the container 5. Close the right door. This is a view of the tag on the container with both doors closed. 6. Seal the tag using the software on your mobile device. The door sensor recognizes when the right door is closed and when the container is dark. 7. After successfully sealing the tag, insert the container’s bolt into the hasp.
Installing Savi SensorTag ST-676-I ISO Container Door Tag with Sensors 16 Savi SensorTag ST-676-I ISO Container Door Tag with Sensors Installation Guide
APPENDIX A Savi SensorTag ST-676-I ISO Container Door Tag with Sensors A Specifications Specification Description Physical characteristics Tag Height: 4.75 inches (12.07 cm) Width: 4.5 inches (11.43 cm) Depth: 1.5 inches (3.81 cm) Patch antenna Height: 4.6 inches (11.68 cm) Width: 3.2 inches (8.13 cm) Depth: 0.5 inches (1.27 cm) Door clamp Height: 4.75 inches (12.07 cm) Width: 5.25 inches (13.34 cm) Depth: 2 inches (5.08 cm) Total weight of tag 16 ounces (453.59 g) without battery 16.8 ounces (476.
Savi SensorTag ST-676-I ISO Container Door Tag with Sensors Specifications Specification RF receiver/transmitter Description Ultra High Frequency transceiver: Frequency: 433.92 MHz Modulation: FSK, deviation +/- 50 KHz Data rate: 27.8 Kbps Data coding: Manchester Communication range (unobstructed): Typical range is up to 300 feet (91.44 meters) line-of-sight when mounted on a container and communicating with a Savi Fixed Reader SR-650-101 or SaviReader 410R.
Specification Description Hardware compatibility ✦ Savi Mobile Reader SMR650P (model SMR-650P-xxx) ✦ Savi Mobile Reader SMR-650 (models SMR-650-xxx) ✦ Savi Fixed Reader SR-650 ✦ Savi Signpost SP 65x series Antenna External patch antenna Shock and vibration Shock: MIL-STD-810E Mechanical Shock, Transit Drop Methods 516.4 Vibration: MIL-STD-810E Method 514.4, Category 10 Loose cargo test: MIL-STD-810F Method 514.
Savi SensorTag ST-676-I ISO Container Door Tag with Sensors Specifications 20 Specification Description Sensors Door sensor: Senses the right side of the container door in the closed or open position Light sensor: Senses light coming through the door Temperature sensor: Integrated temperature takes readings every five minutes (default; use Savi software to adjust settings).
