Installation
Instructions SCR
03 65044 0 __
Page: 6 of 8
4 Antenna Setup
For SCR system, the following antenna setups can be used
Antenna Connector BU500 Antenna Connector BU550
03 57570 none
03 64127 none
none 03 57570
none 03 64127
03 57570 03 57570
03 57570 03 64127
03 64127 03 57570
