CYLINDERS, KEYS AND KEY CONTROL
CYLINDERS, KEYS AND KEY CONTROL Patented Key and High Security Cylinder System The Primus® system offers a new dimension in high security cylinders and key control. The system features a specially designed, patent protected key which operates a choice of Underwriters Laboratories Listed 20-500 series, Controlled Access 20-700 series and standard cylinders all in one integrated key system. Primus cylinders are compatible with Schlage's commercial grade locks.
CYLINDERS, KEYS AND KEY CONTROL Specifications Certifications Key Control Patents*: Everest and Primus cylinders and keys are covered by one or more of the following U.S. utility patents: 4,756,177 4,815,307 5,715,717 5,809,816 ANSI: 20-500 High Security cylinder – A156.5, Grade 1. For international Patent coverage information, please contact Schlage Commercial Customer Service. 20-700 Controlled Access cylinder – ANSI A156.5, Grade 1 Operational.
CYLINDERS, KEYS AND KEY CONTROL Primus Flexibility Unlike many other brands of high security cylinders, Schlage can easily integrate Primus UL 437 Listed cylinders, Primus Controlled Access cylinders, and Schlage conventional cylinders all into the same key system, and this happens with no adverse affects on keying capacity! Primus keys will operate conventional cylinders but conventional keys will not operate Primus cylinders.
CYLINDERS, KEYS AND KEY CONTROL Choose the Right Cylinder for Each Application Interchangeable Core (IC) Cylinders 6-pin Everest cylinders in C123 keyway with two patented keys are standard for stock. C145 is standard for new master key systems. For use where fast rekeying by non-technical personnel is desired, Schlage Primus and conventional interchangeable cores offer a great blend of security and convenience.
CYLINDERS, KEYS AND KEY CONTROL Cylinders for Schlage Locksets Cylinders for A-Series Knobs Number 21-002 21-002-122 20-724 20-724-122 20-524 20-524-122 Description Cylinders for BC100-Series (Order tailpiece and housing separately.
CYLINDERS, KEYS AND KEY CONTROL Cylinders for Schlage Locksets B600-Series - Conventional Cylinder B700-Series - Primus Cylinder B800-Series - UL437 Listed Primus Cylinder Cylinders for B600/700/800-Series Deadlocks (Housing not included) Lockset Function Cylinder Number Door Thickness B660, B663 22-644 1³⁄₈”- 2¹⁄₂” 22-642 22-643 22-645 22-646 1³⁄₈”- 2” 2”- 2¹⁄₂” 1³⁄₈” - 2” 2”- 2¹⁄₂” 20-744 1³⁄₈”- 2¹⁄₂” 20-742 20-743 20-745 20-746 1³⁄₈”- 2” 2”- 2¹⁄₂” 1³⁄₈” - 2” 2”- 2¹⁄₂” 20-544 1³⁄₈”- 2¹⁄₂”
CYLINDERS, KEYS AND KEY CONTROL Cylinders for Schlage Locksets 29-002 29-003 29-005 Cylinders for F-Series Knobs and Levers Number Cylinders for S-Series Levers Number Description Description 29-002 Bell, Georgian and Plymouth knobs 21-028 Conventional cylinder 29-003 Orbit knob 20-752 Primus cylinder 29-005 Accent and Flair levers 20-552 Primus UL437 Listed high security cylinder only Available 429 (to match 626) and 430 (to match 606) finish. 5-pin C keyway only.
CYLINDERS, KEYS AND KEY CONTROL Cylinders for Schlage Locksets Cylinder Only Compr.
CYLINDERS, KEYS AND KEY CONTROL Cabinet Locks and Padlocks CL-Series Cabinet Locks CL1000 CL2000 Door Application Complete Lock Cylinder Only Conventional Primus Primus UL Conventional Primus Primus UL Bolt 1” (std) Door CL1000PB CL1740PB CL1540PB /2” CL1009PB CL1749PB CL1549PB /2” (std) CL2000PB CL2740PB CL2540PB CL2009PB CL2749PB CL2549PB 1 1 Drawer Drawer 3 /4” 20-172 20-772 20-572 20-174 20-774 20-574 Available 606 and 626 finish. Everest C123 keyway standard.
CYLINDERS, KEYS AND KEY CONTROL Cylinders for Exit Devices, Aluminum Doors, etc. Rim Cylinders Number Description 20-022 Conventional cylinder 20-710 Primus cylinder 20-716 Primus lockout cylinder 20-510 Primus UL437 Listed cylinder 20-516 Primus UL437 Listed lockout cylinder Available 605, 606, 612, 613, 625 and 626 finish. Everest C123 keyway standard. Cylinders for Adams Rite MS, 4500 and 4700 Series, Lori 4500 Series and Corbin Russwin DL3000 Series.
CYLINDERS, KEYS AND KEY CONTROL Full Size Interchangeable Core A-Series D-Series Lever ORBIT DESIGN ALL DESIGNS AL-Series H-Series Knob SATURN DESIGN ORBIT DESIGN BC100-Series B250-Series L-Series B600 / 700-Series S-Series ALL DESIGNS ALL DESIGNS EXCEPT FLAIR D-Series Knob S200-Series ORBIT DESIGN ALL DESIGNS FOR S210.
CYLINDERS, KEYS AND KEY CONTROL Full Size Interchangeable Core Cylinders for Schlage Locksets Full Size Core Only Number Mechanism 23-030 Conventional core 30-120 Conventional core for hotel function (specify hand) 20-730 Primus core (not available in hotel function) Available 606 and 626 finish only. Everest C123 keyway standard. Order control keys separately.
CYLINDERS, KEYS AND KEY CONTROL Full Size Interchangeable Core Mortise Cylinders 1-1/2” Cylinders for Schlage L-Series Mortise Locks Core Mechanism Function Conventional Primus Housing Less Core All Except Below 30-008 20-798 30-007 Design L&N Escutcheons (cylinders with compression ring) Sectional Trim (cylinder with compression ring, spring and 3/8˝ blocking ring) L583-255 L9060P Outside 30-030 20-782 30-032 + 36-083 L9485P, L9486P Hotel Funtions 30-010* N/A 30-007 All Except Below
CYLINDERS, KEYS AND KEY CONTROL Full Size Interchangeable Core Cylinders for Exit Devices, Aluminum Doors, etc. Interchangeable Core Rim Cylinders for Exit Devices Number Core Mechanism 20-057 Conventional core 20-757 Primus core 20-079 Housing only, less core Available 605, 606, 612, 613, 625 and 626 finish. Everest C123 keyway standard. Cylinders for Adams Rite MS and 4700 Series, Lori 4500 Series and Corbin Russwin DL3000 Series.
CYLINDERS, KEYS AND KEY CONTROL Small Format (Best Style) Interchangeable Core AL-Series D-Series Lever SATURN DESIGN ALL DESIGNS BC100-Series B250-Series L400-Series B600 / 700-Series L9000-Series ALL DESIGNS 14
CYLINDERS, KEYS AND KEY CONTROL Small Format Interchangeable Core Cylinders for Schlage Locksets Small Format Core Only Number Mechanism 80-036 7-pin Everest B Family restricted keyway core, uncombinated 80-037 7-pin Everest B Family restricted keyway core, uncombinated 80-043 6-pin Best keyway core, uncombinated 80-033 7-pin Best keyway core, uncombinated Notes 1. Available 606 and 626 finish only. 2. Suffix keyway, e.g. 80-036 B235, 80-043 AB, etc. 3.
CYLINDERS, KEYS AND KEY CONTROL Small Format Interchangeable Core Mortise Cylinders Cylinder Only Compr.
CYLINDERS, KEYS AND KEY CONTROL Small Format Interchangeable Core Cylinders for Exit Devices, Aluminum Doors, etc. Interchangeable Core Rim Cylinders for Exit Devices Number Core Mechanism 20-057 Conventional core 20-757 Primus core 20-079 Housing only, less core Available 605, 606, 612, 613, 625 and 626 finish. Everest C123 keyway standard. Cylinders for Adams Rite MS and 4700 Series, Lori 4500 Series and Corbin Russwin DL3000 Series.
CYLINDERS, KEYS AND KEY CONTROL Cams for Schlage Mortise Cylinders in Other Manufacturers’ Mortise Locks Classic Conventional 20-001 B520-295 Corbin Russwin DL4000 Series (Old Corbin 420 and Russwin 1503) ® Interchangeable Core 20-061, 20-771, 26-094, 80-102, 80-110, 80-132, 80-302 B520-254 Everest & Primus Non-IC 20-001 Everest 20-500 and 20-700 Primus B520-366 B520-253 B520-309 B520-360 B520-367 B520-296 B520-329 X Y Dim. X = .155 Y = .
CYLINDERS, KEYS AND KEY CONTROL Cylinders for Other Manufacturers’ Products Corbin Russwin CL3400, CL3600 Series Corbin Russwin CK4200, UT5200 Series Sargent 7, 8, 10, 65 Line Levers Sargent 7, 8 Line Knobs Yale 5300LN, 5400LN, 6400LN Levers Yale 5300, 5400, 6200 Knobs Conventional Cylinder Primus Primus UL437 Description 24-139 20-739 20-539 Corbin Russwin CL3400, CL3600 24-127 20-727 20-527 Corbin Russwin CK4200, UT5200 24-126 20-726 20-526 Sargent 6 Line (Except B Knobs) 24-120 20
CYLINDERS, KEYS AND KEY CONTROL Everest Full Size Key Blanks Numbers shown are for key blanks. For cut keys, change “35” prefix to “48” for change keys and “49” for master keys. Suffix key section, e.g. 35-009 C123. See facing page for available key sections. Conventional DO NOT DUPLICATE PAT. 5,715,717 PAT. 5,715,717 Standard Front for C Family 35-009 6-Pin Control DO NOT DUPLICATE PAT. 5,715,717 DO NOT DUPLICATE PAT. 5,715,717 Standard for Control Keys and all D Family keys.
CYLINDERS, KEYS AND KEY CONTROL Everest Keyways for New Key Systems C Family Keyways for Everest conventional cylinders and Primus Levels 7, 8, and 9 All-Section Key C000 Multi-Section Keys C100 C200 Multi-Section Keys Multi-Section Keys C150 C134 C145 C135 C120 C125 New master key systems begin here and expand to the right. C124 C230 C123 C234 C235 C245 C345 Stock keyway for commercial sales. By definition, all Primus keys are restricted.
CYLINDERS, KEYS AND KEY CONTROL Classic Key Blanks Numbers shown are for key blanks. For cut keys, change “35” prefix to “48” for change keys and “49” for master keys. Suffix key section, e.g. 35-101 E. See facing page for available key sections. Conventional Standard Front and Back 35-100 5-Pin 35-101 6-Pin 35-056 Control Plain Both Sides 35-130 5-Pin 35-131 6-Pin 35-076 Control Primus 5-Pin 6-Pin Control PRIMUS DO NOT DUPLICATE PAT. NO.
CYLINDERS, KEYS AND KEY CONTROL Classic Keyways for Older Key Systems Obverse Keyways for Classic Conventional cylinders All-Section Key L Multi-Section Keys H CE C K J E EF F FG G R I MU R I MU Keyways and Single Section Keys Keyway to accept all key sections P Stainless Steel All-Section Key Cut at Factory Only Obverse Keyways for Classic Primus cylinders Levels 1 through 4 LP EP EFP FP P P P R I MU S CEP R I MU S R I MU P JP S P HP S CP Multi-Section Keys S R I M
CYLINDERS, KEYS AND KEY CONTROL Small Format Key Blanks For cut keys, change “35” prefix to “48” for change keys and “49” for master keys. Suffix key section, e.g. 35-009 C123. See facing page for available key sections. Everest B Family Patented Restricted Key Blanks ID Number 35-401 Standard Front and Back Plain Both Sides 35-021 B235 Dealer Keyway Available to locksmiths and service-oriented contract hardware dealers, this keyway is controlled similar to Primus Levels 1+ and 7.
CYLINDERS, KEYS AND KEY CONTROL Cylinder Service Equipment and Tools 40-119 BLU 40-070 E PU O SI R O -L O OOLS K IT ORIES Q UAL ACCESS67 & LS CA 926 , K TOO -LO NGE PRO ORA P201 #B NCH NAL P PR OFES YT 9 8 5 9 8 7 5 2 6 3 1 4 1 0 2 0 K O -L O PR 40-075 Pin Kits 40-119 40-074 Blue Punch Key Machine For full size conventional cylinders Contains bottom, top and master pins, springs, cap pins, cap pin springs, caps, follower, tweezers, key gauge, shims, cap removal tool 40-075 Classi
CYLINDERS, KEYS AND KEY CONTROL Bulk Pack Cylinder Kit Bulk Packs are 10-packs that contain the components you need to quickly build 10 cylinders. All shells are pre-loaded with top pins and springs. Classic Everest Conventional Conventional Primus Description 09-409 09-751 09-764 Key-in-knob / lever 09-412 09-754 09-767 Mortise (specify length) 09-410 09-752 09-765 Rim 09-411 09-753 20-766 Full size interchangeable core Specify keyway and finish.
CYLINDERS, KEYS AND KEY CONTROL Primus I.D. Cards Primus Authorization Forms Primus I.D. cards are used as authorization credentials for Primus Level 1, 1+, 2, and 8 keys. Cards have a signature panel on the back and are issued by the servicing locksmith or dealer who directly supports the system owner. The owner must present the I.D. card to obtain duplicate keys or additions to his system. The signature will be validated by the dealer.
CYLINDERS, KEYS AND KEY CONTROL Security Levels The Primus system features multiple levels of security. Primus systems with Classic keyways (Levels 1 through 4) are ideal for upgrading older key systems. All new systems should be specified with Everest keyways (Levels 7 - 9) for maximum patent life, durability, and master keying capacity. Each level requires an appropriate I.D card and/or signature verification for key duplication.
CYLINDERS, KEYS AND KEY CONTROL Schlage Cylinder Terminology Over the last few years Schlage has introduced a varietyof new keyways and cylinder types. This chart illustrates our cylinder terms and how they are related. The definitions below provide additional information. Keyway Type Keyways (Best Style) Conventional (Non-Primus) Interchangeable Core Even to Open Keyways PR IM US PA OT T. NO DUP . 4 LIC ,75 6,1 ATE 77 DO N Classic Primus DO PR I NO Pat T D .
