Installation Manual

About This Guide
ii 975-0691-01-01 Revision B
Conventions Used
The following conventions are used in this guide.
Abbreviations and Acronyms
Related Information
For more information about related products, refer to:
Conext Battery Monitor Quick Start Guide
Conext XW+ Inverter/Charger Owner’s Guide
Conext XW+ Inverter/Charger Installation Guide
Conext ComBox Owner’s Guide
Conext Configuration Tool Owner’s Guide
Conext AGS Owner’s Guide
Conext SCP Owner’s Guide
You can find more information about Schneider Electric as well as its products
and services at www.schneider-electric.com.
For specific information on Solar products go to www.SEsolar.com.
DANGER
DANGER indicates an imminently hazardous situation, which, if not avoided,
will result in death or serious injury.
WARNING
WARNING indicates a potentially hazardous situation, which, if not avoided,
can result in death or serious injury.
CAUTION
CAUTION indicates a potentially hazardous situation, which, if not avoided,
can result in moderate or minor injury.
NOTICE
NOTICE indicates important information that you need to read carefully.
BTS Battery Temperature Sensor
CEF Charge Efficiency Factor
CSA Canadian Standards Association
LCD Liquid Crystal Display
SOC State-of-charge
UL Underwriters Laboratories
VDC Volts DC
