Battery Monitor Settings
History Menu
The History menu is a read-only menu that shows the Battery Monitor’s Historical
data. Historical data consists of special events that are stored in internal memory.
This menu can be accessed by following the sequence in “Changing Settings
from the Front Panel” on page 3–27.
The following History menu settings are available.
F3.0 Internal firmware version. (Reserved, Read-only value)
F3.1 Shunt Amp Rating. This Function is linked to F3.2 and represents
the Amp rating of your shunt at the given sensing voltage as set in
F3.2. Included with your Battery Monitor is a 500 Amp/50 mV shunt,
meaning that at 500 A flowing through the shunt, a voltage of 50 mV
is generated across the small ‘Kelvin’ screw terminals of the shunt.
This voltage is used by the Battery Monitor to measure the battery
current.
Default Range Step size
500 A 10 – 9000 A Variable
F3.2 Shunt milliVolt Rating. This value represents the milliVolt rating of your
shunt at the rated current. The Battery Monitor supports 50 mV and
60 mV shunts.
Default Range Step size
50mV 50 – 60 mV 1
F3.3 Backlight mode. Represents the duration of backlight activation in
seconds after key-press. The backlight can also be set to be always
“ON” or always “OFF”. Function setting “AU”, activates the backlight
automatically when charge / discharge current exceeds 1 Amp or
when a key is pressed.
Default Range Step size
30 sec OFF / 5 – 300 / ON Variable
F3.4 Temperature scale selection. Enables selection between degrees
Celsius (°C) and degrees Fahrenheit (°F) in the temperature readout.
Default Range Step size
°C °C/°F N/A
F3.5 Setup lock. When set to “ON”, all functions except the Setup lock
function itself are locked and cannot be altered. The Reset menu is
also locked.
Default Range Step size
OFF OFF/ON N/A
