Assembly & Owner's Manual

10
Tools
Included Not Included
(recommended)
Item Qty Description Item Qty Description
A 4 SocketHeadHexScrew,M8x50 D
10
SelfTappingScrew,M4.2x16
B 8 SocketHeadHexScrew,M8x16 E
12
LockWasher,M8
C
2
PhillipsHeadScrew,M5x14 F
12
FlatWasher,M8
A B D
C E F
Before Assembly
Select the area where you are going to set up and operate your machine. For safe operation, the location must be on a
hard,levelsurface.Allowaworkoutareaofaminimum83.2”x151.2”(211.3cmx384cm).Besurethattheworkoutspace
youareutilizinghasadequateheightclearance,takingintoconsiderationtheheightoftheuserandthemaximuminclineof
the machine.
Basic Assembly Tips
Followthesebasicpointswhenyouassembleyourmachine:
• Readandunderstandthe“ImportantSafetyInstructions”beforeassembly.
• Collect all the pieces necessary for each assembly step.
• Usingtherecommendedwrenches,turntheboltsandnutstotheright(clockwise)totighten,andtheleft(counterclock-
wise)toloosen,unlessinstructedotherwise.
• Whenattaching2pieces,lightlyliftandlookthroughtheboltholestohelpinserttheboltthroughtheholes.
• Theassemblycanrequire2people.
HardWare / Tools / before assembly
#2
6mm
6mm
