Service Manual

Use and Operation
Once started, the ice machine will automatically
make ice until the bin or dispenser is full of ice.
When ice level drops, the ice machine will resume
making ice.
Caution: Do not place anything on top of the ice
machine, including the ice scoop. Debris and
moisture from objects on top of the machine can
work their way into the cabinet and cause serious
damage. Damage caused by foreign material is not
covered by warranty.
There are four indicator lights at the front of the
machine that provide information on the condition
of the machine.
Indicator Lights:
·
Power
·
Status
·
Water
De-scale & Sanitize
Indicator Lights & Their Meanings
Power Status Water De-Scale & Sanitize
Steady Green Normal Normal – bin full or making ice - -
Blinking Green Self Test
Failure
Switching on or off - -
Blinking Red - Diagnostic shutdown or, if making ice,
temperature sensor failure
Lack of
water
-
Yellow - - - Time to de-scale and
sanitize
Blinking Yellow - - - In Cleaning mode
Light off No power Switched off Normal Normal
All Blinking Unit remotely locked out – check with leasing company
If the Water light is on, the machine has sensed a
lack of water. Check the water supply to the
machine. The water could have been shut off or
the water filter cartridges might need to be
changed.
If the De-Scale light is on, the machine has
determined that it needs to be cleaned. Contact an
authorized Scotsman service agent and have the
machine cleaned, de-scaled and sanitized.
Prodigy Eclipseä 1200, 1400, 1800, 2000
August 2008
Page 29
Note: A Component Indicator Light switches ON to
indicate that the component is operating.
Note: There are two Curtain Switch lights, SW1 and
SW2. A curtain switch light is ON when a curtain is
either open or not present.
