1.0 Introduction This manual describes the functional, mechanical and interface specifications for the following Seagate® Momentus®5400.2 drives: • ST9120821A • ST9100824A • ST98823A • ST96812A • ST94813A • ST93811A These drives provide the following key features: • 5,400-RPM spindle speed and 8-Mbyte buffer combine for superior performance. • Quiet operation. Fluid Dynamic Bearing (FDB) motor. • High instantaneous (burst) data transfer rates (up to 100 Mbytes per second) using Ultra DMA mode 5.
2 Momentus 5400.2 PATA Product Manual, Rev.
2.0 Drive specifications Unless otherwise noted, all specifications are measured under ambient conditions, at 25°C, and nominal power. For convenience, the phrases the drive and this drive are used throughout this manual to indicate ST9120821A, ST9100824A, ST98823A, ST96812A, ST94813A and ST93811A model drives. 2.1 Specification summary The specifications listed in this table are for quick reference. For details on specification measurement or definition, see the appropriate section of this manual.
Table 1: Specifications Drive specification ST9120821A ST9100824A ST98823A Average seek time (msec typical) 12.5 Average seek, read (msec typical) 12.5 Average seek, write (msec typical) 14.5 Full-stroke seek (msec) 22 (typical); 24 (max) Seek power (typical) 2.0 watts Read/write power (typical) Read: 1.8 watts; Write: 1.8 watts Idle mode (typical, low power) 0.80 watts Standby mode 0.26 watts (typical)** Sleep mode 0.
Table 1: Specifications Drive specification ST9120821A ST9100824A ST98823A ST96812A ST94813A ST93811A Service life 5 years Warranty 5 years on distribution units. To determine the warranty for a specific drive, use a web browser to access the following web page: www.seagate.com/support/service/ From this page, click on the “Verify Your Warranty” link. You will be asked to provide the drive serial number, model number (or part number) and country of purchase.
2.5 Recording and interface technology Technology Specification Interface Parallel ATA Recording method RLL 0,11 Recording density BPI (bits/inch typical) 778k Track density TPI (tracks/inch typical) 126k Areal density (Gbits/inch2 max) 98.2 Spindle speed (RPM) (± 0.2%) 5,400 Internal data-transfer rate OD (Mbytes/sec max) 42 I/O data-transfer rate (Mbytes/sec max) 100 (Ultra DMA mode 5) Interleave 1:1 Cache buffer 8 Mbytes (8,192 kbytes) 2.
2.7 Seek time Seek measurements are taken with nominal power at 25°C ambient temperature. All times are measured using drive diagnostics. The specifications below are defined as follows: • Track-to-track seek time is an average of all possible single-track seeks in both directions. • Average seek time is a true statistical random average of at least 5,000 measurements of seeks between random tracks, less overhead. Typical seek times (msec)* Read Write Track-to-track 1.0 1.5 Average 12.5 14.
2.9 Power specifications The drive receives DC power (+5V) through the interface connector. 2.9.1 Power consumption Power requirements for the drives are listed in the table on page 8. Typical power measurements are based on an average of drives tested, under nominal conditions, at 25°C ambient temperature. • Spinup power Spinup power is measured from the time of power-on to the time that the drive spindle reaches operating speed.
2.9.1.1 Typical current profile Figure 2. Typical 5V startup and operation current profile 2.9.2 Conducted noise Input noise ripple is measured at the host system power supply across an equivalent 15-ohm resistive load on the +5 volt line. Using 5-volt power, the drive is expected to operate with a maximum of 100 mV peak-to-peak square-wave injected noise at up to 10 MHz. Note. Equivalent resistance is calculated by dividing the nominal voltage by the typical RMS read/write current. 2.9.
2.9.4 Power-management modes The drive provides programmable power management to provide greater energy efficiency. In most systems, you can control power management through the system setup program.
2.10 Environmental specifications 2.10.1 Ambient temperature Ambient temperature is defined as the temperature of the environment immediately surrounding the drive. Actual drive case temperature should not exceed 65°C (149°F) within the operating ambient conditions. Above 1,000 feet (305 meters), the maximum temperature is derated linearly by 1°C every 1000 feet. Operating Nonoperating 2.10.
2.10.5 Shock All shock specifications assume that the drive is mounted securely with the input shock applied at the drive mounting screws. Shock may be applied in the X, Y or Z axis. 2.10.5.1 Operating shock These drives comply with the performance levels specified in this document when subjected to a maximum operating shock of 250 Gs based on half-sine shock pulses of 2 msec. Shocks should not be repeated more than two times per second. 2.10.5.
2.11 Acoustics Drive acoustics are measured as overall A-weighted acoustic sound power levels (no pure tones). All measurements are consistent with ISO document 7779. Sound power measurements are taken under essentially free-field conditions over a reflecting plane. For all tests, the drive is oriented with the cover facing upward. Note. For seek mode tests, the drive is placed in seek mode only. The number of seeks per second is defined by the following equation: (Number of seeks per second = 0.
2.13 Reliability Measurement type Specification Nonrecoverable read errors 1 per 1014 bits read, max. Annualized Failure Rate (AFR) 0.
Korean RRL If these drives have the Korea Ministry of Information and Communication (MIC) logo, they comply with paragraph 1 of Article 11 of the Electromagnetic Compatibility control Regulation and meet the Electromagnetic Compatibility (EMC) Framework requirements of the Radio Research Laboratory (RRL) Ministry of Information and Communication Republic of Korea. These drives have been tested and comply with the Electromagnetic Interference/Electromagnetic Susceptibility (EMI/EMS) for Class B products.
If necessary, you should consult your dealer or an experienced radio/television technician for additional suggestions. You may find helpful the following booklet prepared by the Federal Communications Commission: How to Identify and Resolve Radio-Television Interference Problems. This booklet is available from the Superintendent of Documents, U.S. Government Printing Office, Washington, DC 20402. Refer to publication number 004-000-00345-4. 2.
3.0 Configuring and mounting the drive This section contains the specifications and instructions for configuring and mounting the drive. 3.1 Handling and static discharge precautions After unpacking, and before installation, the drive may be exposed to potential handling and electrostatic discharge (ESD) hazards.
3.2 Jumper settings 3.2.1 Master/slave configuration Use the options jumper block shown in Figure 3 to configure the drive for operation. This jumper block is the 4-pin header adjacent to pins 1 and 2 of the I/O signal pins. For additional information about using the Cable select option, see Section 3.2.2. The “Master or single drive” option is the factory default setting. Drive is master (or single drive) Drive is slave Cable select Figure 3. Jumper settings 3.2.
3.3 Drive mounting You can mount the drive using four screws in the side-mounting holes or four screws in the bottom-mounting holes. See Figure 4 for drive mounting dimensions (dimensions in inches with mm in parentheses). Follow these important mounting precautions when mounting the drive: • Allow a minimum clearance of 0.030 inches (0.76 mm) around the entire perimeter of the drive for cooling. • Use only M3 x 0.5 mounting screws. • Do not overtighten the mounting screws (maximum torque: 4.0 inch-lb).
20 Momentus 5400.2 PATA Product Manual, Rev.
4.0 ATA interface These drives use the industry-standard ATA task file interface that supports 16-bit data transfers. It supports ATA programmed input/output (PIO) modes 0–4; multiword DMA modes 0–2, and Ultra DMA modes 0–5. The drive also supports the use of the IORDY signal to provide reliable high-speed data transfers.
4.1.1 Supported ATA commands The following table lists ATA-standard commands that the drive supports. For a detailed description of the ATA commands, refer to the Draft ATA-6 Standard...
Table 7: Supported commands Command name Command code (in hex) Security Unlock F2H Seek 70H Set Drive Parameters 91H Set Features EFH Set Max Address F9H Note: Individual Set Max commands are identified by the value placed in the Set Max Features register as defined to the right. Address Password Lock Unlock Freeze Lock Set Multiple Mode C6H Sleep 99H, E6H S.M.A.R.T.
Table 7: Supported commands Command name Command code (in hex) Security Freeze Lock F5H Security Disable Password F6H 24 Momentus 5400.2 PATA Product Manual, Rev.
4.1.2 Identify Device command The Identify Device command (command code ECH) transfers information about the drive to the host following power up. The data is organized as a single 512-byte block of data, whose contents are shown in Table 7 on page 22. All reserved bits or words should be set to zero. Parameters listed with an “x” are drive-specific or vary with the state of the drive. See Section 2.0 on page 3 for default parameter settings.
Word Description Value 57–58 Current capacity in sectors xxxxH 59 Number of sectors transferred during a Read Multiple or Write Multiple command xxxxH 60–61 Total number of user-addressable LBA sectors available (see Section 2.
Word Description Value 129–159 Seagate-reserved xxxxH 160–254 ATA-reserved 0000H 255 Integrity word xxA5H Note. See the bit descriptions below for words 63, 88, 93 and 94 of the Identify Drive data. Description (if bit is set to 1) Bit Word 63 0 Multiword DMA mode 0 is supported. 1 Multiword DMA mode 1 is supported. 2 Multiword DMA mode 2 is supported. 8 Multiword DMA mode 0 is currently active. 9 Multiword DMA mode 1 is currently active.
4.1.3 Set Features command This command controls the implementation of various features that the drive supports. When the drive receives this command, it sets BSY, checks the contents of the Features register, clears BSY and generates an interrupt. If the value in the register does not represent a feature that the drive supports, the command is aborted. Power-on default has the read look-ahead and write caching features enabled.
5.0 Compatibility summary 5.1 Installation considerations Many of today’s mobile computers have been designed to make it possible for the end user to replace the hard drive. Refer to your system’s user manual for the location of the hard drive compartment and the specific instructions regarding replacement. Refer to your system manufacturer’s support website for the most up-todate information. Read and follow all instructions regarding the proper steps to be taken when replacing the system hard drive.
System Compatibility Seagate Product Assurance has tested Momentus drives in the systems listed in Table 9. Testing included multiple BIOS versions and operating systems. This testing was done to demonstrate compatibility with various hardware and software configurations. Hardware and software combinations, other than those tested, may also be compatible with this drive.
5.2 BIOS versions tested The following list indicates the types of BIOS Seagate tested during the compatibility testing process. The list highlights the major BIOS manufacturers. Individual systems contain variations of these BIOS versions and were tested with regard to their implementation in the individual systems. Table 10: Vendor Tested BIOS versions Release Revision ACER 1.01 ACPI Ver. 1.20 AMI Various Apple 4.71F1 Apple 4.8.4F1 Award Various Various Compal 38118 v2.
5.3 Operating system versions tested This list indicates the types of Operating Systems Seagate tested during the compatibility testing process and highlights the major OS manufacturers. Several variations of the major operating systems have been tested. Table 11: Operating systems tested Manufacturer Version/Release Apple MacOS 9.22 Apple MacOS X 10.2.3 Microsoft MSDOS 6.
