Manual

• 1 x wireless outdoor/indoor color camera with wall-mount bracket
• 1 x 8VDC power adapter
• Mounting screws
1) Connect the adapter (DC 8V 300mA) to the camera.
Power Outlet
Wi-Fi interference free Outdoor/Indoor 900MHz wireless bullet color camera
SecurityMan
®
Specifications of Camera (SM-302T)
1/4-inch CMOS
510 X 492 (NTSC)
NTSC
0 lux (IR on)
Up to 23ft
Internal, f=3.6mm fish eye lens
902~928MHz
2 Channels Selection_906MHz/924MHz_
FM
40dB(AGCO ff)
2~30mW
4.5MHz
Built-in
up to 20ft
200mA(IR ON)/80mA(IR OFF)
SMA
up to 330ft
8V 300mA(Positive inside)
IP54
Image Sensor
Total Pixels
Video Format
Minimum Illumination
Night Vision Range
Lens
Transmission Frequency
Channel Options
Modulation Type
S/N
Transmission Power
Audio Frequency Band
Microphone
Voice Monitoring Distance
Power Consumption
Antenna
Transmission Distance
Power
Weatherproof
2) Set the camera to desired channel. This camera has 2 selectable channels to avoid
possible interference from other nearby wireless devices.
Note: This product is intended for SM-302R receiver, and compliant with all SecurityMan’s wireless receiver.
Package Contents
Product Basics
Installation Diagram
