P22 Mobile Payment Terminal User Guide
Introduction SecuX Crypto Payment Solution is designed for the mobile payment operators to establish an offline payment solution in the digital money era, which is easy-to-setup, cashier friendly and low deployment cost SecuX Crypto Payment Solution includes three mayor components, P22 mobile payment terminal, App SDK and server container for merchant portal.
Knowing the device How to use 1. Connect to an USB power source or insert AA batteries P22 supports dual power sources, USB power as primary one and AA battery as backup one. - Connect provided type-C USB cable to both ends of USB power adapter and P22 USB-C port. - Open P22 battery cap (on the device bottom) and insert 3 pcs AA batteries by following the direction. Note: From mechant-facing LCD, it will shows the current operating power source is USB or battery. 2.
After consuers use payment App to scan check-out QR code, the data of merchant ID, coin type and amount will be shown. Then users press Pay on their App to proceed the payment. Before payment is done, merchants also can cancel the check-out QR code for some reason by pressing C button. 4. Confim the payment result Once the payment is completed successfully, consumers’ App and both of the consumer-facing and merchant-facing LCDs will show the information of payment is done successfully.
Specifications Features No. of LCD display P22 2 Yes 1. Display checkout data (1) Merchant-facing 2. Payment confirmation notice display 3. Payment history 4. Customized features Yes (2) Consumer-facing Payment confirmation notice by display QR code Keypad 4x4 keypad Coin type selection Yes Beeper alert for payment result Yes Communication interface with mobile phone Bluetooth/QR code Operation temperature Power source Dimension Weight 0℃ ~ 45℃ 1. USB power 2. AA battery x 3 17.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
