TABLE OF CONTENTS I M P O R TA N T INFORMATION 2 2 PREFACE 4 3 SAFETY PRECAUTIONS 4 4 IN THE CARTON 6 5 FRONT/BACK CONNECTIONS OF LCD TV 7 6 7 8 9 10 TV INSTALLATI ON DRAWINGS REMOTE CONTROL MENU OPERATION Power Cord Connection 8 Antenna Connection 8 AV Connection 9 YPbPr (c omponent ) Connection 9 VGA ( PC ) Connection 10 COAX Connection 10 HDMI Connection 11 Service Port Function 11 Remote control instructions in TV mode 12 Remote control setup 13 Setup Wizard 14
IMPORTANT INFORMATION English The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of un-insulated dangerous voltage within the products enclosure that may be of sufficient magnitude to constitute a risk of electric to persons. The exclamation point within an equilateral triangle is interded to aler the user to the presence of important operating and maintenance (servicing) instruction the literature accompanying the appliance.
IMPORTANT INFORMATION 10.Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. 11.Only use attachments / accessories specified by the manufacturer. 12.Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart / apparatus combination to avoid injury from tip-over. English 13.
PREFACE 2. PREFACE Thank you for buying this TV! Please read this manual thoroughly before operating the TV. Make sure the TV was not damaged in transit. Should the TV be damaged, do not install it and contact your dealer. Check that you have all the accessories according to the model. English 3. SAFETY PRECAUTIONS Put the TV on a stable surface. Do not place any material on the TV.
SAFETY PRECAUTIONS English Keep the TV dry and away from humidity. Keep the TV away from heat sources . Unplug the TV before cleaning it. Do not use solvent or liquid to clean the TV. Only clean the TV with a soft and dry cloth. In case of troubleshooting, do not use spare parts other than those suggested by the manufacturer. Using inadequate spare parts can lead to electric shocks, short-circuits , fire or other incidents. Unplug the TV during lightning storms or when unused for long periods of time.
IN THE CARTON 4. IN THE CARTON English LCD TV SET Remote Control 1.5V 1.
FRONT/BACK CONNECTIONS OF LCD TV 5. FRONT/BACK CONNECTIONS OF LCD TV Front View 4 VOL- CH+ 3 CH- 2 MENU 1 SOURCE 5 STANDBY 7 6 Back View and Control Connections 1. AC IN: Main power input. 2. HDMI1/HDMI2: Connect the HDMI output jack of DVD. 3. PC AUDIO: Connect the Audio output jack of PC. 4. VGA ( PC ) : Connect the PC-RGB output jack of PC. 5. YPbPr1/YPbPr2: Connect the YPbPr output jack of DVD or VCR. 6. Y-L/R1,Y-L/R2:For YPbPr audio. 7. VIDEO: Connect the Video input jack of DVD or VCR.
TV INSTALL ATION DRAWINGS 6. TV INSTALL ATION DRAWINGS Power Cord Connection English - Connect the power cord correctly as shown. - Press the STANDBY switch of your LCD TV to switch on the LCD TV. The power indicator on the front panel lights up in green. Antenna Connection To ensure good picture and sound, TV antenna system needs to be installed. The antenna system as shown can be sourced from TV equipment shops, which will provide service for correct installation and connection.
TV INSTALL ATION DRAWINGS AV Connection Connect the VIDEO and AUDIO output jack of the DVD or VCR to the VIDEO jacks on the set using the RCA cable. Match the jack colors: Video is yellow, Audio left is white, and Audio right is red. Select the AV input source using the SOURCE button on the remote control. English TV Back Video Cable VIDEO R L DVD or VCR Back DVD or VCR YPbPr (Component) Connection Connect the YPbPr output of the DVD or VCR to the YPbPr input on the set.
TV INSTALL ATION DRAWINGS VGA(PC) Connection English Connect the RGB output of the PC to the VGA(PC) jack on the set. Connect the AUDIO output of The PC to the PC AUDIO jack on the set . Select the RGB input source with using SOURCE button on the remote control. TV Back VGA Cable Audio Cable AUDIO RGB-PC OUTPUT COAX Connection Connect to Audio Amplifier device to the COAX output jack on the TV.
TV INSTALL ATION DRAWINGS HDMI Connection HDMI plug which replaces the HDMI connection allows transfer of all audio/video/control signals through one cable only. These signals are transferred in digital. English TV Back HDMI Cable DVD Back Service Port Function Service port: (For factory uses only.
REMOTE CONTROL 7 . REMOTE CONTROL Remote control instructions in TV mode English MUTE STANDBY STANDBY Turn the LCD TV ON or OFF. MUTE Press to mute the sound. Press again or press V+ to un-mute the TV. NUMBER BUTTONS Press 0-9 to directly change the TV channel. SOURCE Press SOURCE to display the OSD input source, press ▲▼to select an input source , and then press OK to confirm. DISPLAY - ASPECT Press this button to enter a program number for multiple program channel such as 2-1,etc.
REMOTE CONTROL Remote control setup English 1. Open the cover. 2. Uses three A size batteries.When inserting the batteries, make sure correct polarities “+”and “-” . marks on the batteries line up correctly with compartment markings . 3. Replace the battery cover. To prevent battery leakage which may result in bodily injury or damage to the remote: 1. Install all batteries correctly, and as marked on the remote control. 2.
MENU OPERATION 8.Menu Operation SETUP WIZARD English Select Language Select Language Follow this guide to help you set up your TV. Use the Up and Down arrows on your remote control and select the Language you want to use for menus and message screens. MENU English Enter French Enter Spanish Enter :Return :Select Menu ENTER :Press to Enter Time zone Time zone Use the left or right key to select on your time zone.
MENU OPERATION Channel Scanning AUTO CHANNEL SEARCH - Air Now Searching... Please Wait English Return Analog Channels Found: 0 Digital Channels Found: 0 0% SELECT INPUT SOURCE Source Select TV AV Press SOURCE button to display the input source list. YPbPr1 Press ▼/▲ button to select the input source you want to watch. YPbPr2 Press OK button to enter the selected source.
MENU OPERATION Press MENU button to display the MAIN OSD MENU. Press◄/►button to select the MENU you want. Press OK button to enter the sub menu. Press ▼/▲ button to select the option and then press◄/►to adjust the value in the sub menu. English You can press MENU button to go back to the upper menu or EXIT button to close the OSD.
MENU OPERATION Brightness Press ▼/▲ button to select Brightness, then press ◄/► button to adjust. Brightness 25 English Contrast 25 Contrast Press ▼/▲ button to select Contrast, then press ◄/► button to adjust. Color 27 Color Press ▼/▲ button to select Color, then press ◄/► button to adjust. Sharpness 27 Sharpness Press ▼/▲ button to select Sharpness, then press ◄/► button to adjust. Tint 27 Tint Press ▼/▲ button to select Tint, then press ◄/► button to adjust. Screen Settings 1.
MENU OPERATION Auto Wide Press ▼/▲button to select the item Auto Wide, then press ENTER button to adjust. It can set the picture to fit the screen automatically. When the Auto Wide is selected, the symbol will show as: Auto Wide English Color Temperature Press ENTER when the Color Temperature item is highlighted. Then press ◄/► button to adjust. Available color temperature: Cool, Normal, Warm.
MENU OPERATION MPEG Noise Reduction Press ▼/▲ button to select the item MPEG Noise Reduction, then press ◄/► button to adjust. It can improve the quality of the pictures by reducing the block noise. Available MPEG Noise Reduction: Off, Low, Medium, High. MPEG Noise Reduction Off English SOUND MENU SOUND Sound Settings Surround Mode Analog Sound Stereo Digital Sound English Other Settings Equalizer Settings MENU :Return :Select Menu ENTER :Go to Next Menu Sound Settings 1.
MENU OPERATION Bass Press ▼/▲ button to select the item Bass, then press ◄/► button to adjust. Treble Press ▼/▲ button to select the item Treble, then press ◄/► button to adjust. Balance English Press ▼/▲ button to select the item Balance, then press ◄/► button to adjust. Treble 7 Bass 7 Balance 7 Surround Mode Press ▼/▲ button to select the item Surround Mode, then press OK button to adjust. It can set the picture to fit the screen automatically.
MENU OPERATION Other Settings OTHER SETTINGS Off Sepeaker On Digital Audio Output Dolby Digital :Select Menu :Return English MENU AVL :Enable/Disable AVL Press ▼/▲ button to select the item AVL, then press ◄/► button to select ON or OFF. Auto Volume Level can set the volume automatically adjust corresponding to the input audio. Speaker Press ▼/▲ button to select the item Speaker, then press ◄/► button to select ON or OFF. If set to Off, the speaker will be mute.
MENU OPERATION CHANNEL MENU Note: This menu is only shown when the input source is TV. CHANNEL English Channel List Favorite List Channel Setting Signal Type Air Auto Channel Search MENU :Return :Select Menu Enter :Go to Next Menu Channel List Press ▼/▲ button to select Channel List, then press OK button to scan the Channel List. If you select the option “In Channel List” On, the channel label will display in the list.
MENU OPERATION Channel Setting Press ▼/▲ button to select Manual Channel Setting, then press OK button to set the value in the sub menu. English CHANNEL SETTING No Channels Present Please Perform Channel Search First MENU :Return :Select Menu :Se lec t Cha nn el Signal Type Press ▼/▲ button to select Signal Type, then press ◄/► button to select the type you want to set. There are two selections: Air and Cable.
MENU OPERATION PARENTAL CONTROL English MENU PARENTAL CONTROL PARENTAL CONTROL Lock Parental Control Lock Parental Control V-CHIP V-CHIP Change Password Change Password Pront Panel Lock Front Panel Lock Source Lock Source Lock :Return DIGITAL MENU :Enter password :Return DIGITAL :Go to Next Menu Input password to enter,default password is‘‘0000’’. V-CHIP Press ▼/▲ button to select V-CHIP, then press OK button to adjust. A sub menu will appear as below.
MENU OPERATION Movie Rating Press ▼/▲ button to select Movie Rating, then press OK button to adjust. A sub menu will appear as below. Movie Rating English G PG PG-13 R NC-17 X :Select ENTER :Lock/Unlock Press ▼/▲ button to select Rating, then press OK button to lock. TV Rating Press ▼/▲ button to select TV Rating, then press OK button to adjust. A sub menu will appear as below.
MENU OPERATION French Rating G 8ans + 13ans + 16ans + English 18ans + MENU :Return :Select ENTER :Lock/Unlock The operation of CANADA V-CHIP is the same as the operation of US V-CHIP. Block UnRated Show Press ◄/► button to select Block UnRated Show, then press OK button to set the rating locked. Downloadable Rating Press ▼ / ▲ button to select Downloadable Rating, then press OK button to set the rating. If the DTV program doesn’t have this rating information, this option will be in gray.
MENU OPERATION Source Lock Press ▼/▲ button to select Source Lock, then press OK button to enter the sub menu. Press ▼/▲ button to select Source, then press OK button to set the Source Lock . You can’t enter the locked source if you set the Source lock.
MENU OPERATION Caption Display Press ▼/▲ button to select Caption Display, then press ◄/► button to select ON or OFF. Analog Caption Type English Press ▼/▲ button to select Analog Caption Type, then press ◄/► button to select the type. Available type: CC1, CC2, CC3, CC4, TEXT1, TEXT2, TEXT3, TEXT4. Digital Caption Type Press ▼/▲ button to select Digital Caption Type, then press ◄/► button to select the type. Available type: Service1~6.
MENU OPERATION Menu Language Press ▼/▲ button to select the item Menu Language, then press ◄/► button to adjust. Available Language: English, French, Spanish. Clock English Press ▼/▲ button to select the Clock, then press OK to edit. CLOCK Time Zone Alaska Auto Clock Off Setup Time 2009-10-21 20:00:00 Day Of Week :Select Menu Wed :Change Setting Time Zone Press ▼/▲ button to select Timer Zone, then press ◄/► button to set.
MENU OPERATION No Signal Power Off Press▼/▲ button to select No Signal Power Off, then press OK button to select it On or Off. When set it On and there is no signal input by 10 minutes, it will turns off the panel and the LED light turns amber. No Operation Power Off English Press ▼/▲ button to select No Operation Power Off, then press OK button to select it On or Off. When set it On and there is no operation input by 3 hours, it will turns off the panel and the LED light turns red.
MENU OPERATION Picture Settings PICTURE SETTINGS Picture Mode User Brightness Contrast Color Tint Sharpness MENU :Return :Select Menu :Change Setting Picture Mode Press ▼/▲ button to select Picture Mode, then press◄/►button to adjust. Available picture mode: Dynamic, Standard, Movie, User. Brightness Press ▼/▲ button to select Brightness, then press ◄/► button to adjust. Contrast Press ▼/▲ button to select Contrast, then press ◄/► button to adjust.
MENU OPERATION Screen Settings English 1.Press ENTER when the Screen Settings item is highlighted. Then you will go to the sub-menu as following. 2.Press▼/▲ to select the desired menu item. Press ENTER to proceed if necessary. 3.Press ◄/► to adjust the item to the desired level. 4.When you have changed the settings, you can exit from the menu by pressing MENU.
MENU OPERATION Auto Adjust Press ▼/▲ button to select Auto Adjust, then press OK button to start auto adjusting. Horizontal Position English Press ▼/▲ button to select Horizontal Position, then press ◄/► button to adjust. Horizontal Position 25 Vertical Position Press ▼/▲ button to select Vertical Position, then press ◄/► button toadjust. Vertical Position 25 Clock Press ▼/▲ button to select Clock, then press ◄/► button to adjust.
TROUBLESHOOTING 9. Troubleshooting Please check if you can solve problems by troubleshooting yourself . English Troubleshooting No signal No color shades Stain on the screen Double or multiple display image 34 Control Please check that all cables are correctly plugged in. Adjust the contrast, the color and the brightness. May be the result from a lighting signal from car, motor, neon light and other electrical devices or appliances.
SPECIFICATIONS 10. SPECIFICATIONS This manual is only for your reference, any change to the design and specification will not be advised. 31.
À écran plat Téléviseur LCD Manuel d’Instruction Fr Lisez toutes les instructions attentivement avant l’utilisation de cette télévision. Conservez ces instructions dans une place en sécurité pour la référence future.
TABLE DES MATIÈRES INFORMATIONS IMPORTANTES 2 PREFACE 3 PRECAUTIONS DE SECURITE 4 DANS LA CAISSE 5 Français 1 CONNEXIONS FRONT/ARRIERE DU TELEVISEUR LCD Connexion du cordon d'alimentation Connexion de l'antenne 6 DES SI NS A L' INSTALLA TI ON DE TV Connexion AV Connexion YPbPr(composante) Connexion VGA(PC) Connexion COAX Connexion HDMI Fonction Port Service 7 TELECOMMANDE Instructions de la télécommande dans la mode TV Configuration de la télécommande Configuration Wizard Source d'entrée
INFORMATIONS IMPORTANTES Avertissement Risque de choc électrique Ne pas ouvrir ! Français Le symbole de l'éclair fléché dans un triangle équilatéral, est destiné à alerter l'utilisateur de la présence de « tension» dangereuse non-isolée dans le boîtier du produit qui peut être d'une ampleur suffisante pour constituer un risque d'électrocution.
INFORMATIONS IMPORTANTES 10.Assurez vous que le cordon d'alimentation ne soit pas écrasé ou pincé, particulièrement au niveau des prises de commodité, et le point où ils sortent de l'appareil. 11.Utilisez uniquement les fixations / accessoires spécifiés par le fabricant. 12.Utilisez uniquement le chariot, trépied, console ou table spécifiée par le fabricant ou vendu avec l'appareil.
PREFACE 2. PREFACE Merci d'avoir acheté ce téléviseur! S'il vous plaît lisez attentivement ce manuel avant de faire fonctionner le téléviseur. Assurez-vous que la télévision n'a pas été endommagée pendant le transport. Si le téléviseur est endommagé, ne l'installez pas, et contactez votre revendeur. Vérifiez que vous avez tous les accessoires selon le modèle. 3. PRECAUTIONS DE SECURITE Français Placer le téléviseur sur une surface stable. Ne pas placer de matériels sur le téléviseur.
PRECAUTIONS DE SECURITE Garder le téléviseur dans une condition sèche et éloignée de l'humidité. Français Garder le téléviseur loin de toute source de chaleur . Débrancher le téléviseur avant de le nettoyer. Ne pas utiliser de solvants ou de liquides pour nettoyer le téléviseur. Il faut nettoyer le téléviseur avec un chiffon doux et sec. En cas de dépannage, ne pas utiliser les pièces de rechange autre que celles suggérées par le fabricant.
DANS LA CAISSE 4. DANS LA CAISSE Français Télevision à écran LCD Télécommande 1.5V 1.
CONNEXIONS FRONT / ARRIERE DU TELEVISEUR LCD 5.CONNEXIONS FRONT / ARRIERE DU TELEVISEUR LCD Vue Frontale 4 VOL+ VOL- 3 CH+ 2 MENU 1 SOURCE 5 STANDBY MARCHE/ ARRET LED 7 6 Vue Arrière et Connexions de Contrôle 1. AC IN: Entrée d'alimentation principale. 2. HDMI1/HDMI2: Connecter la prise de sortie HDMI du DVD. 3. PC AUDIO: Connecter la prise de sortie audio du PC. 4. VGA( PC) : Relier la prise de sortie PC-RGB du PC. 5. YPbPr1/YPbPr2: Connecter la prise de sortie YPbPr de DVD ou VCR. 6.
DESSINS A L'INSTALLATION DE TV 6. DESSINS A L'INSTALLATION DE TV Connexion du cordon d'alimentation - Raccorder le cordon d'alimentation correctement comme indiqué. - Appuyer sur la prise d'ALIMENTATION de votre LCD TV pour brancher le LCDTV. L'indicateur d'alimentation sur le panneau frontal s'affiche en couleur vert. Français Connecxion de l'Antenne Pour assurer la bonne image et le son, le système d'antenne TV doit être installé.
DESSINS A L'INSTALLATION DE TV Connexion AV Connecter la prise de sortie VIDEO et AUDIO du DVD ou du VCR aux prises VIDEO du téléviseur en utilisant le câble RCA. Faites correspondre les couleurs de prise: La vidéo est jaune, l'audio gauche est blanc, et l'audio est bien rouge. Sélectionnez la source d'entrée AV en utilisant la touche SOURCE sur la télécommande.
DESSINS A L'INSTALLATION DE TV Connexion VGA(PC) Connectez la sortie RGB du PC à la prise VGA (PC) sur le téléviseur. Reliez la sortie audio de PC à la prise AUDIO PC sur le téléviseur. Sélectionnez la source d'entrée RGB avec l'aide du bouton SOURCE sur la télécommande. Arrière de TV Français Câble VGA Câble Audio AUDIO RGB-PC OUTPUT Connexion COAX Connecter l'amplificateur audio à la prise de sortie COAX sur le téléviseur.
DESSINS A L'INSTALLATION DE TV Connexion HDMI La prise HDMI qui remplace la connexion HDMI permet de transférer tous les signaux audio / vidéo / commande via un seul câble. Ces signaux sont transmis en numérique. Arrière de TV Français Câble HDMI Arrière de DVD DVD ouVCR Fonction de Port Service Port service: (Pour l'utilisation exclusive en usine.
TELECOMMANDE 7. TELECOMMANDE Instructions de la télécommande en mode TV STANDBY MUTE STANDBY Français Allumez le téléviseur LCD Marche/ Arrêt. MUTE Appuyez sur la touche MUET pour couper le son. Appuyez sur la touche de nouveau ou appuyez sur VOL + pour enlever la sourdine du téléviseur. NUMBER BUTTONS Appuyez sur les touches 0-9 pour modifier directement la chaîne de télévision.
TELECOMMANDE Configuration de la télécommande 1. Enlevez le couvercle. 2. Placez trois piles A. Lors de l'insertion des piles, assurez-vous de faire correspondre les extrémités “ + ” et “ - ” sur les piles, mettez en rang correctement avec la section de marques. 3. Remettez le couvercle de la pile. 1. Installez toutes les piles correctement, comme indiqué sur la télécommande. 2. Ne mélangez pas de piles: (ANCIENS et NOUVEAUX au carbone et alcalines, etc.
MENU D'OPÉRATION 8.Menu d'Opération CONFIGURATION WIZARD Sélectionner laLangue Select Language Français Follow this guide to help you set up your TV. Use the Up and Down arrows on your remote control and select the Language you want to use for menus and message screens. MENU English Enter French Enter Spanish Enter :Return :Select Menu ENTER :Press to Enter Fuseau horaire Time zone Use the left or right key to select on your time zone.
MENU D'OPÉRATION Balayage des Canaux AUTO CHANNEL SEARCH - Air Now Searching... Please Wait Return 0 Digital Channels Found: 0 Français Analog Channels Found: 0% SELECTIONNER LA SOURCE D'ENTREE Source Select TV AV Appuyez sur la touche SOURCE pour afficher la liste de source d'entrée. YPbPr1 Appuyez sur ▼ / ▲ pour sélectionner la source que vous voulez regarder. Appuyez sur la touche OK pour entrer dans la source sélectionnée.
MENU D'OPÉRATION Appuyez sur la touche MENU pour afficher le menu principal OSD. Appuyer sur la touche ◄ / ► pour sélectionner le menu que vous voulez. Appuyez sur la touche OK pour entrer dans le sous-menu. Appuyez sur la touche ▼/▲ pour sélectionner l'élément et appuyez sur ◄ / ► pour régler la valeur dans le sous-menu. Vous pouvez appuyer sur la touche MENU pour revenir au menu précédent ou SORTIR pour fermer le menu OSD.
MENU D'OPÉRATION Luminosité Appuyez sur la touche ▼ / ▲ pour sélectionner la Luminosité, puis appuyez sur la touche◄ / ► pour ajuster. Brightness 25 Contraste Appuyez sur la touche ▼ / ▲ pour sélectionner le Contraste, puis appuyez sur la touche◄ / ► pour ajuster. Contrast 25 Français Couleur Color 27 Appuyez sur la touche ▼ / ▲ pour sélectionner la couleur, puis appuyez sur la touche◄ / ► pour ajuster.
MENU D'OPÉRATION Largeur Auto. Appuyez sur la touche ▼ / ▲ pour sélectionner l'élément de Largeur Auto., puis appuyez sur la touche ENTRER pour ajuster. On peut définir l'image pour remplir l'écran automatiquement. Lorsque le Largeur Auto. est sélectionné, le symbole s'affichera comme suit: Auto Wide Température de Couleur Français Appuyez sur la touche ENTRER lorsque l'élément de température de couleur met en surbrillance. Ensuite, appuyez sur la touche ◄ / ► pour ajuster.
MENU D'OPÉRATION Réduction de Bruit MPEG Appuyez sur la touche ▼ / ▲ pour sélectionner l'élément de Réduction de Bruit MPEG, puis appuyez sur la touche ◄ / ► pour ajuster. Elle peut améliorer la qualité d'image en réduisant le bloc de bruit. Disponible de réduction de bruit MPEG: Arrêt, Faible, Moyen, Haut.
MENU D'OPÉRATION Basse Appuyez sur la touche ▼ / ▲ pour sélectionner l'élément Bass, puis appuyez sur la touche ◄ / ► pour ajuster. Aigus Appuyez sur la touche ▼ / ▲ pour sélectionner l'élément aigus, puis appuyez sur la touche ◄ / ► pour ajuster. Balance Français Appuyez sur la touche ▼ / ▲ pour sélectionner l'élément de balance, puis appuyez sur la touche ◄ / ► pour ajuster.
MENU D'OPÉRATION Autre Réglage OTHER SETTINGS AVL Off Sepeaker On Digital Audio Output Dolby Digital Français MENU :Return :Select Menu :Enable/Disable AVL Appuyez sur la touche ▼ / ▲ pour sélectionner l'élément AVL, puis appuyez sur ◄ / ► pour sélectionnerMarche ou ARRET. Le Niveau de Volume Auto. Peut régler le volume automatiquement en correspondant à l'audio d'entrée.
MENU D'OPÉRATION MENU CHAINE Note: Ce menu ne s'affiche que lorsque la source de sortie est TV. CHANNEL Channel List Favorite List Channel Setting Français Signal Type Air Auto Channel Search MENU :Return :Select Menu Enter :Go to Next Menu Liste des Chaînes Appuyez sur la touche ▼ / ▲ pour sélectionner la liste de chaîne, puis appuyez sur la touche OK pour numériser la liste de chaînes.
MENU D'OPÉRATION Réglage de Chaînes Appuyez sur la touche ▼ / ▲ pour sélectionner le Réglage de Chaînes Manuel, puis appuyez sur la touche OK pour définir la valeur dans le sous-menu. CHANNEL SETTING Français No Channels Present Please Perform Channel Search First MENU :Return :Select Menu :Se lec t Cha nn el Type de Signal Appuyez sur la touche ▼ / ▲ pour sélectionner le Type de Signal, puis appuyez sur la touche ◄ / ► pour sélectionner le type que vous souhaitez définir.
MENU D'OPÉRATION CONTROLE PARENTAL Français MENU PARENTAL CONTROL PARENTAL CONTROL Lock Parental Control Lock Parental Control V-CHIP V-CHIP Change Password Change Password Pront Panel Lock Front Panel Lock Source Lock Source Lock :Return DIGITAL MENU :Enter password :Return DIGITAL :Go to Next Menu Entrer le mot de passe pour entrer, le mot de passe par défaut est ‘‘0000’’. V-CHIP Appuyez sur la touche ▼ / ▲ pour sélectionner V-Chip, puis appuyez sur la touche OK pour régler.
MENU D'OPÉRATION Rating Film Appuyez sur la touche ▼ / ▲ pour sélectionner le Rating Film, puis appuyez sur la touche OK pour régler. Un sous-menu apparaîtra comme suit. Movie Rating G PG PG-13 Français R NC-17 X :Select ENTER :Lock/Unlock Appuyez sur la touche ▼/▲ pour sélectionner le Rating, puis appuyez sur la touche OK pour verrouiller. Rating TV Appuyez sur la touche ▼ / ▲ pour sélectionner le Rating TV, puis appuyez sur la touche OK pour régler. Un sous-menu apparaîtra comme suit.
MENU D'OPÉRATION French Rating G 8ans + 13ans + 16ans + 18ans + Français MENU :Return :Select ENTER :Lock/Unlock Le fonctionnement du V-CHIP CANADIEN est le même que le fonctionnement du V-CHIP US. Affichage Sans Block Appuyer sur la touche ◄ / ► pour sélectionner l'Affichage Sans Block, puis appuyez sur la touche OK pour définir le rating verrouillé. Rating téléchargeable Appuyez sur la touche ▼ / ▲ pour sélectionner le Rating téléchargeable, puis appuyez sur la touche OK pour régler le rating.
MENU D'OPÉRATION Verrouillage de Source Appuyer sur la touche ▼/▲ pour sélectionner le Verrouillage de Source, puis appuyez sur la touche OK pour entrer dans le sous-menu. Appuyer sur la touche ▼/▲ pour sélectionner la Source, ensuite appuyez sur la touche OK pour définir le Verrouillage de Source, vous ne pouvez pas entrer la source verrouillée si vous avez défini le Verrouillage de Source.
MENU D'OPÉRATION Affichage de Sous-titrage PAppuyez sur la touche ▼ / ▲ pour sélectionner l'Affichage de Sous-titrage, puis appuyez sur la touche ◄ / ► pour sélectionner MARCHE ou ARRET. Type de Sous-titrage Analogique Appuyez sur la touche ▼ / ▲ pour sélectionner le Type de Sous-titrage Analogique, puis appuyez sur la touche ◄ / ► pour sélectionner le type. Type Disponible: CC1, CC2, CC3, CC4, texte1, texte2, Text3, TEXT4.
MENU D'OPÉRATION Menu Langue Appuyez sur la touche ▼ / ▲ pour sélectionner l'élément de Menu Langue, puis appuyez sur la touche ◄ / ► pour ajuster. Disponible Langue: Anglais, français, espagnol. Horloge Appuyez sur la touche ▼ / ▲ pour sélectionner l'horloge, puis appuyez sur OK pour modifier.
MENU D'OPÉRATION Pas de Signal Arrêt Appuyez sur la touche ▼ / ▲ pour sélectionner l'élement de Pas de Signal Arrêt, puis appuyez sur la touche OK pour sélectionner Marche ou Arrêt. Lorsque placez-le sur Marche, et il n'y a aucune entrée de signal dans 10 minutes, il s'éteint le panneau et le voyant LED devient ambre. Pas d'Opération Arrêt Appuyez sur la touche ▼ / ▲ pour sélectionner l'élement de Pas d'Opération Arrêt, puis appuyez sur la touche OK pour sélectionner Marche ou Arrêt.
MENU D'OPÉRATION Régalge d'Image 1. Appuyez ENTRER lorsque l'élément de Réglage d'image est mis en surbrillance. Puis vous irez à la sous-menu suivant. 2. Appuyez ▼ / ▲ pour sélectionner la rubrique souhaitée. Appuyez sur la touche ENTRER pour procéder si nécessaire. 3. Appuyez ◄ / ► pour régler l'élément au niveau désiré. 4. Lorsque vous avez modifié le réglage, vous pouvez quitter le menu en appuyant sur MENU.
MENU D'OPÉRATION Réglage d'Ecran 1. Appuyez ENTRER lorsque l'élément de Réglage d'Ecran est mis en surbrillance. Puis vous irez à la sous-menu suivant. 2. Appuyez ▼ / ▲ pour sélectionner la rubrique souhaitée. Appuyez sur la touche ENTRER pour procéder si nécessaire. 3. Appuyez ◄ / ► pour régler l'élément au niveau désiré. 4. Lorsque vous avez modifié le réglage, vous pouvez quitter le menu en appuyant sur MENU.
MENU D'OPÉRATION Réglage Auto. Appuyez sur la touche ▼ / ▲ pour sélectionner le Réglage Auto., puis appuyez sur la touche OK pour commencer le réglage auto. Position Horizontale Appuyez sur la touche ▼ / ▲ pour sélectionner la Position Horizontale, puis appuyez sur la touche ◄ / ► pour ajuster. Horizontal Position 25 Position Verticale Vertical Position 25 Français Appuyez sur la touche ▼ / ▲ pour sélectionner la Position Verticale, puis appuyez sur la touche ◄ / ► pour ajuster.
DÉPANNAGE 9. Dépannage Vérifiez si vous pouvez résoudre les problèmes à travers le dépannage par vous-même. Dépannage Français Aucun signal Vérifiez que tous les câbles sont correctement branchés. Aucun nuances de couleurs Réglez le contraste, la couleur et la luminosité. Teinté à l'écran Il peut être le résultat d'un éclairage de la signalisation de la voiture, moteur, lampe au néon et d'autres dispositifs ou appareils électriques.
SPECIFICATIONS 10. SPECIFICATIONS Ce manuel ne sert de référence, tout changement sur le design et les spécifications ne sera pas informé.
Imprimé en Chine
Pantalla plana Televisión LCD Manual de instrucciones Es Lea todas estas instrucciones antes de usar la televisión. Guarde estas instrucciones en un lugar seguro para referencia futura.
TABLA DE CONTENIDO INFORMACIÓN IMPORTANTE 2 PROLÓGO 3 PRECAUCIONES Y SEGURIDAD 4 EN EL CARTON 5 CONEXIÓN FRONTAL/ TRASERA DE LCD TV Español 1 conexión del cable de alimentación conexión de antena conexión de AV 6 DIBUJO DE conexión Ypbpr( componente) INSTALA CIÓN DE TV conexión VGA (PC) conexión COAX Conexión HDMI Servicio de función de puerto 7 MANDO A DISTANCIA instrucciones del mando a distancia distancia en TV modo Configuración de mando Asistente de configuración Seleccione la fuent
INFORMACIÓN IMPORTANTE PRECAUCIÓN RIESGO DE DESCARGA ELÉCTRICA NO ABRIR El símbolo del rayo con punta de flecha dentro de un triángulo equilátero alerta al usuario de la presencia de un-"voltaje peligroso" dentro del gabinete del producto, que puede tener la magnitud suficiente para constituir un peligro de descarga eléctrica.
INFORMACIÓN IMPORTANTE 10.Proteja el cable de alimentación de ser pisado o pinchado, especialmente los enchufes, tomas de corriente y el punto en donde salen del aparato. 11.Utilice sólo los accesorios especificados por el fabricante. 12.Utilice únicamente la carretilla, plataforma, trípode, soporte o mesa especificados por el fabricante, o suministrados juntos con el aparato. Cuando utilice un carro, tenga cuidado al mover la combinación carro / aparato para evitar lesiones por vuelco. Español 13.
PRÓLOGO 2. PRÓLOGO Gracias por comprar este TV. Por favor, lea este manual atentamente antes de hacer las operaciones. Asegúrese de que este TV no ha recibido ningún daño en el transporte. Si este TV ha sido dañado, deje de instalarlo y consulte a su comerciante. Compruebe que tiene todos los accesorios de acuerdo con el modelo. 3. PRECAUCIONES Y SEGURIDAD Español Ponga el TV en una superficie estable. No ponga ningún material arriba del TV.
PRECAUCIONES Y SEGURIDAD Mantega el TV seco y lejos de la humedad. Español Mantenga el TV lejos de un calentador . Desenchufe el TV antes de limpiarlo. No utilice el solvente O líquido para limpiarlo. Sólo limpie el TV con un paño seco y limpio. En caso de solución de problemas, no utilice las piezas de respuestos que no sean sugeridas por el fabricante. Utilizando las piezas de respuestos no adecuadas pueden dar lugar a descargas eléctricas, cortos circuitos, incendio u otros accidentes.
EN EL CARTON 4. En el carton Español LCD TV SET Mando a distancia 1.5V 1.
CONEXIONES FRONTALES / TRASERAS DE LCD TV 5. Conexiones frontales / traseras de LCD TV Vista delantera 4 VOL+ VOL- 3 CH+ CH- 2 MENU 1 SOURCE 5 STANDBY Encendido/apagadoLED 7 6 Back View and Control Connections 1. AC IN: Fuente de la energía de entrada principal. 2. HDMI1/HDMI2: Conecta la toma de salida de HDMI del DVD. 3. PC AUDIO: Conecta toma de salida de Audio de PC. 4. VGA(PC): Conecta la toma de salida de PC-RGB de PC. 5. YPbPr1/YPbPr2: Conecta la toma de salida de Ypbpr de DVD o VCR. 6.
DIBUJOS DE INSTALACIÓN DE TV 6. Dibujos de instalación de TV Conexión del cable de alimentación - conecte el cable de alimentación correctamente como se muestra. - presione el botón POWER de su LCD TV para encender el TV. el indicador de encendido del panel frontal se ilumina en verde . Español Conexión de Antena para garantizar la buena imagen y sonido, el sistema de antena de TV debe ser instalada.
DIBUJOS DE INSTALACIÓN DE TV CONEXIÓN DE AV Conecta la toma de salida de VIDEO y AUDIO de DVD o VCR con la toma de VIDEO en el set utilizando el cable RCA. Coincide color con la toma: Video es amarillo, audio izquierdo es blanco y audio derecho es rojo. Selecciona la fuente de entrada de AV utilizando el botón de SOURCE en el mando a distancia.
DIBUJOS DE INSTALACIÓN DE TV CONEXIÓN VGA(PC) Conecta la salida de RGB de PC con la toma VGA(PC) en el set. Conecta la salida de audio de PC con la toma AUDIO PC en el set. Seleccione la fuente de entrada RGB utilizando el botón SOURCE en el mando a distancia. Parte atras de TV Español Audio Cable VGA Cable CONEXIÓN COAX Conecta el dispositivo amplificador de audio con la toma de salida COAX en el TV.
DIBUJOS DE INSTALACIÓN DE TV CONECIÓN HDMI Conector HDMI, que sustituye la conexión HDMI permite la transferencia de audio / vídeo / señales de control a través de cable. estas señales se transmiten en formato digital.
MANDO A DISTANCIA 7. Mando a distancia Instrucciones de mando a distancia en modo TV STANDBY Encender o apagar el LCD TV. MUTE STANDBY MUTE Pulse para silenciar el sonido. pulse de nuevo o pulse VOL+ para anular el silenciamiento de la TV. Español TECLADO ALFANUMÉRICO Pulse directamente 0-9 para cambiar los canales. SOURCE pulse source para mostrar la fuente de entrada OSD, pulse ▲▼ para seleccionar una fuente de entrada, despúes pulse OK para confirmarlo.
MANDO A DISTANCIA Configuración de mando a distancia 1. Abra la cubierta. 2. Utilice tres pilas con tamaño A. Al insertar las pilas, asegúrese que la polaridad con . con las marcas del compartimiento. marcas + y - en la línea de pilas de forma correcta 3. Vuelva a colocar la cubierta. Para evitar fugas de las pilas que puede resultar en lesiones corporales o daños en el mando a distancia: 1. Instale todas las pilas correctamente según lo que indican en el mando a distancia . 2. No mezcle las pilas.
OPERACIÓN MENÚ 8.Operación Menú Asistente de configuración Seleccione el idioma Select Language Follow this guide to help you set up your TV. Use the Up and Down arrows on your remote control and select the Language you want to use for menus and message screens. Español MENU English Enter French Enter Spanish Enter :Return :Select Menu ENTER :Press to Enter Huso horario Time zone Use the left or right key to select on your time zone.
OPERACIÓN MENÚ ESCANEO DE CANALES AUTO CHANNEL SEARCH - Air Now Searching... Please Wait Return Analog Channels Found: 0 Digital Channels Found: 0 0% Español Seleccione la fuente de entrada Source Select TV AV YPbPr1 Pulse el botón Source para mostrar la lista de fuente de entrada. Pulse el botón▼/▲para seleccionar la fuente de entrada que quieres ver. Pulse el botón OK para entrar en la fuente seleccionada.
OPERACIÓN MENÚ Pulse el botón menu para mostrar el principal OSD menú. Pulse el botón ◄/► para seleccionar el menú que quiere ver. Pulse el botón OK para entrar el submenú. Pulse el botón▼/▲ para seleccionar la opción y despúes pulse ◄/►para ajustar el valor en el submenú. Puede pulsar el botón de MENU para volver al menú anterior o pulsar el botón EXIT para cerrar OSD.
OPERACIÓN MENÚ Brillo Pulse el botón ▼/▲ para seleccionar el brillo, despúes pulse el botón ◄/► para ajustarlo. Brightness 25 Contraste Pulse el botón ▼/▲ para seleccionar el contraste, despúes pulse el botón ◄/► para ajustarlo. Contrast 25 Color Nitidez Español Color 27 Pulse el botón ▼/▲ para seleccionar el color, despúes pulse el botón, ◄/► para ajustarlo. Sharpness 27 Pulse el botón ▼/▲ para seleccionar el nitidez, despúes pulse el botón ◄/► para ajustarlo.
OPERACIÓN MENÚ Ancho automático Pulse el botón ▼/▲ para seleccionar el item de ancho automático, despúes pulse el botón ENTER para ajustarlo. se puede configurar para que la imagen se adapte a la pantalla automáticamente. Cuando el ancho automático está seleccionado, el símbolo se verá como: Auto Wide Temperatura de color Pulse ENTER cuando la temperatura de color está marcada. Despúes pulse el botón ◄/► para ajustarlo. Temperatura de color disponible: fresco, normal, cálido.
OPERACIÓN MENÚ Reducción de ruido MPEG Pulse el botón ▼/▲ para seleccionar la reducción De ruido MPEG, despúes pulse el botón ◄/► para ajustarlo.pueden mejorar la calidad de imágenes mediante la reducción del ruido de bloque.reducción de ruido MPEG disponible: apagado, bajo, medio, alto.
OPERACIÓN MENÚ BASS Pulse el botón ▼/▲ para seleccionar BASS, despúes pulse el botón ◄/► para ajustarlo. Triple Pulse el botón ▼/▲ para seleccionar triple, despúes pulse el botón ◄/► para ajustarlo. Balance Pulse el botón ▼/▲ para seleccionar Balance, despúes pulse el botón ◄/► para ajustarlo. Español Treble 7 Bass 7 Balance 7 Modo de sonido envolvente Pulse el botón ▼/▲ para seleccionar el modo de sonido envolvente, despúes pulse el botón OK para ajustarlo.
OPERACIÓN MENÚ Otras configuraciones OTHER SETTINGS Off Sepeaker On Digital Audio Output Dolby Digital :Return :Select Menu Español MENU AVL :Enable/Disable AVL Pulse el botón ▼/▲ para seleccionar AVL, despúes pulse el botón ◄/► para seleccionar encendido o apagado. nivel de auto volumen puede ajustar el volumen automáticamente correspondiente a la entrada de audio. ALTA VOZ Pulse el botón ▼/▲ para seleccionar alta voz, despúes pulse el botón ◄/► para seleccionar encendido o apagado.
OPERACIÓN MENÚ Menú de canal Menú de canal este menú aparece cuando la fuente de entrada es TV. CHANNEL Channel List Favorite List Channel Setting Signal Type Air Auto Channel Search Español MENU :Return :Select Menu Enter :Go to Next Menu Lista de canal Pulse el botón▼/▲ para seleccionar la lista de canal, y pulse OK para explorar la lista de canales. si seleccione la opción ¨in channel list¨, la etiqueta de canal aparecerá en la lista.
OPERACIÓN MENÚ Configuración de canales Pulse el botón ▼/▲ para seleccionar configuración manual de canales, y pulse el botón OK para establecer el valor en el submenú. CHANNEL SETTING No Channels Present Please Perform Channel Search First Español MENU :Return :Select Menu :Sel ec t Cha nn el Tipo de señal Pulse el botón ▼/▲ para seleccionar tipo de señal, despúes pulse el botón ◄/► para seleccionar el tipo deseado hay dos selecciones: el aire y cable.
OPERACIÓN MENÚ Control parental Español MENU PARENTAL CONTROL PARENTAL CONTROL Lock Parental Control Lock Parental Control V-CHIP V-CHIP Change Password Change Password Pront Panel Lock Front Panel Lock Source Lock Source Lock :Return DIGITAL MENU :Enter password :Return DIGITAL :Go to Next Menu ontraseña de entrada para introducir, contraseña por defecto es 0000. V-CHIP Pulse el botón ▼/▲ ara seleccionarV-CHIP, y pulse el botón OK para ajustarlo.
OPERACIÓN MENÚ Clasificación de cine Pulse el botón ▼/▲ para seleccionar clasificación de cine, y pulse el botón OK para ajustarlo. un submenú aparecerá como lo siguiente. Movie Rating G PG PG-13 R NC-17 X ENTER Español :Select :Lock/Unlock Pulse el botón ▼/▲ para seleccionar clasificación, y pulse el botón OK para bloquearlo. Clasificación de TV Pulse el botón ▼/▲ para seleccionar clasificación de cine, y pulse el botón OK para ajustarlo. Un submenú aparecerá como lo siguiente.
OPERACIÓN MENÚ French Rating G 8ans + 13ans + 16ans + 18ans + MENU :Return :Select ENTER :Lock/Unlock Español La operación de CANADA V-CHIP es igual que la operación de US V-CHIP. Bloque sin muestra de calificación Pulse el botón ◄/► para seleccionar el bloque sin muestra de clasificación, y pulse OK para establecer la clasificación bloqueada. Clasificación descargable Pulse el botón ▼/▲ para seleccionar la clasificación descargable, y pulse OK para establecer la clasificación.
OPERACIÓN MENÚ Fuente bloqueda Pulse el botón ▼/▲ para seleccionar fuente bloqueada y pulse el botón OK para entrar en el submenu. Pulse el botón ▼/▲ para seleccionar la fuente, y pulse el botón OK para establecer el bloqueo de fuente. Usted no puede entrar en la fuente bloqueada si establece la fuente bloqueada.
OPERACIÓN MENÚ Pantalla de título Pulse el botón ▼/▲ para seleccionar pantalla de subtítulo, despúes pulse el botón ◄/► para seleccionar encendido o apagado. Tipo de título analógico Pulse el botón ▼/▲ para seleccionar tipo de título analógico, despúes pulse el botón ◄/► para seleccionar el tipo.Tipo disponible: CC1,CC2,CC3,CC4,TEXT1, TEXT2, TEXT3, TEXT4.
OPERACIÓN MENÚ Ldioma del menú Pulse el botón ▼/▲ para seleccionar idioma del menú, despúes pulse el botón ◄/► para ajustarlo. Idioma disponible: inglés, francés, español. RELOJ Pulse el botón ▼/▲ para seleccionar el reloj, y pulse OK para editarlo. CLOCK Alaska Auto Clock Off Setup Time 2009-10-21 20:00:00 Day Of Week :Select Menu Español Time Zone Wed :Change Setting Huso horario Pulse el botón ▼/▲ para seleccionar huso horario, despúes pulse el botón ◄/► para establecerlo.
OPERACIÓN MENÚ Apagar la energía sin señal Pulse el botón▼/▲ para seleccionar apagar la energía sin señal, despúes pulse el botón OK para seleccionar encenderlo o apagarlo.cuando se puso encendido y no hay señal de entrada por 10 minutos, se apaga el panel y la luz LED se ilumina en ámbar. apagar la energía sin operación Pulse el botón ▼/▲ para seleccionar apagar la energía sin operación, despúes pulse el botón OK para seleccionar encenderlo o apagarlo.
OPERACIÓN MENÚ Configuración de imagen 1.Pulse ENTER cuando la configuración de imagen está marcada, y puede ir a la sub-menú como lo siguiente. 2.Pulse ▼/▲ para seleccionar el menú deseado. Pulse ENTER para proceder si es necesario. 3.Pulse◄/► para ajustarlo al nivel deseado. 4.Cuando se haya cambiado la configuración, puede salir del menú pulsando MENÚ.
OPERACIÓN MENÚ CONFIGURACIÓN DE LA PANTALLA 1.Pulse ENTER cuando la configuración de la pantalla está marcada, y luego irá a la sub-menú como lo siguiente. 2.Pulse▼/▲ para seleccionar el menú deseado. Pulse ENTER para proceder si es necesario. 3.Pulse ◄/► para ajustarlo al nivel deseado. 4.Cuando se haya cambiado la configuración, puede salir del menú pulsando MENÚ.
OPERACIÓN MENÚ Ajuste automático Pulse ▼/▲ para seleccionar el ajuste automático, pulse OK para empezar el ajuste automático. Posici ón horizontal Pulse el botón ▼/▲ para seleccionar la posición horizontal, Pulse el botón ◄/► para ajustarlo. Horizontal Position 25 Posición vertical Vertical Position 25 Español Pulse el botón ▼/▲para seleccionar la posición vertical, Pulse el botón ◄/► para ajustarlo. Reloj Pulse el botón ▼/▲ para seleccionar el reloj, Pulse el botón ◄/► para ajustarlo.
RESOLUCIÓN DE PROBLEMAS 9. Resolución de problemas compruebe si pueda solucionar los problemas por sí mismo. Resolución de probelmas Control Sin señal Por favor, compruebe que todos los cables están correctamente conectados. Español Sin matices de color Ajuste de contraste, color y brillo. Mancha en la pantalla Tal vez el resultado de una señal de iluminación del coche, motor, luz de neón y otros dispositivos eléctricos o aparatos.
ESPECIFICACIONES 10. Especificación Este manual es sólo para su referencia, cualquier cambio en el diseño y la especificación no contará con el asesoramiento. Tamaño de pantalla 31.
Impreso en China
