POWER PERFORMANCE PA S S I O N 2012 Catalogue
In this catalogue... About Selectronic The Selectronic Advantage 4 Founded in 1964 by the Scott family, Selectronic Australia quickly established itself as a major manufacturer of custom made transformers and inductors for the local electronics industry. In 1981 the company’s electronics products division was established to meet a need for quality power conversion products in the emerging renewable energy market.
Our product development process The Selectronic Advantage Our long experience in manufacturing inverters and dedication to innovation has allowed Selectronic to develop one of the world’s most versatile inverter power management systems. With an uncompromising commitment to quality, the Selectronic SP PRO series comprises the ultimate inverter solution that manages the seamless transition between renewable, grid, generator and battery-backup power.
What is an SP PRO? The SP PRO is a bi-directional low distortion sine wave inverter capable of interacting with a number of different types of AC Sources, be they utility grid, diesel grid or diesel generators or even SWER grids. The SP PRO Series: Alternative Power Welcome to a world where electricity has no boundaries... A world where reliable and cost efficient electricity should not be considered as a luxury, but as an essential part of life today and into the future.
Charge battery with RENEWABLE POWER Beyond power security Once BATTERY is fully charged, renewable energy is self-consumed by the home The SP PRO is the versatile solution. It can be used with any combination of grid, solar, wind, or generator backup power.
Solar Hybrid An inverter that provides smarter energy 24/7. Reliable electricity should not be considered a luxury but as an essential part of life today. We need electricity 24/7, not just when grid supply is available. Renewable energy plus extra benefits. An SP PRO inverter will convert electricity stored in batteries from Solar, Wind or Hydro (Renewable Energy) to operate your normal electrical appliances.
SP PRO SERIES SPECS HEB8')% HEB8')& HEB8)-& HEB8)-' HEB8&'%& SPLC1202 3 kW 3.2 kW 7.5 kW 4.5 kW 4.7 kW 10.5 kW 5 kW 5.3 kW 12 kW 7.
Mobile / Marine Power Stylish and powerful Our desire to get out and enjoy the wide open spaces on land or on the high seas can now be complimented with a powerful and intelligent power system. From large caravans, motor homes, houseboats or sailing vessels, an SP PRO based system can bring the comforts of home to your mobile lifestyle. SP PRO SERIES SPECS HEB8')% HEB8')& HEB8)-& 3 kW 3.2 kW 7.5 kW 4.5 kW 4.7 kW 10.5 kW 5 kW 5.
Grid Power Boost performance and reliability with one smart inverter. When you need increased capacity, reliability or functionality of your electricity grid, the Selectronic SP PRO series of battery based Inverters will have the answers. Boost customer supply capacity In “fringe of grid” situations, a property may require more power than the grid can supply, but upgrading lines may not be practical or economical. In this situation an SP PRO is placed at the customer’s premises with a battery bank.
Meteorologial data Environmental data Power measurement Inverter Monitoring & Software End User Analog Ambient Module temperature sensor temperature sensor Analog Powador Argus Analog Customers with battery based systems will receive SP LINK software free of charge. Powador link RS485 RS485 Ethernet 1 2 RS485 Insolation sensor Analog / Digital Inverters are normally placed away from living or production areas.
SP PRO Specs SP PRO INVERTER MODEL HEB8')% HEB8')& HEB8)-& Continuous Power and Charge Current at nominal DC & AC voltage @ 25 ˚C 3 kW / 125 A 4.5 kW / 188 A 5 kW / 104 A kW 3 Continuous Ratings at 25 ˚C 30 seconds 1 minute A 125 7.5 kW 5.4 kW 30 minute 60 minutes Nominal battery voltage DC input voltage range (V d.c.) DC consumption: idle Peak Efficiency – all modes kW 4.5 HEB8)-' HEB8&'%& SPLC1202 A kW A 188 5 104 Short Term Ratings @ 25 ˚C 10.5 kW 12 kW 7.6 kW 8.7 kW 7.5 kW / 156 A 7.
SP PLUS Energy Centre To simplify the process of installing an SP PRO in either a Battery Backup or Grid connect solar system with battery backup, Selectronic provides a simple and cost effective solution. The SP PLUS Energy Centre includes everything you need except for your Solar Panels and associated mounting frames.
Solar Systems Project — diesel grid in Outback Australia This pioneering project used parabolic dish concentrators to focus sunlight on high efficiency photovoltaic solar cells to produce electrical energy that supplemented remote diesel grids. Selectronic Australia developed a custom designed 70kW interactive inverter to feed the power generated by the dish concentrators into the local power grid.
SP PRO / KACO AC Coupling The Selectronic advantage. Continuing to advance the highly acclaimed SP PRO technology, Selectronic in co-operation with KACO Germany are pleased to release a further development to our AC Coupling methodology, now appropriate for Off Grid and Diesel Grid use as well as Solar Hybrid (Grid Backup).
Configuration Diagrams Off Grid AC Coupled By connecting and communicating with up to 5 x KACO 02 series inverters to the load side of the SP PRO system, it is possible to utilise efficient high voltage PV arrays that are located remotely from the battery bank. SP PRO ensures minimal Diesel Generator running whilst maximising use of PV and extended battery life.
Off Grid DC Coupled Cost effective integration of low voltage PV or wind. This method will allow safer PV array voltage to be used. Solar Hybrid AC Coupled KACO A brilliant method to add Battery Backup to a KACO Grid Tie system. The PV can be distributed for best utilisation.
Solar Hybrid Independent Import/Export Solar Hybrid AC Coupled, Generic Grid Inverter With innovative programming options, the system designer can set Connecting any brand of Grid Inverter using the optional electronic controller. the SP PRO to any size grid from 0kW to the maximum output of the This method will maintain a stable frequency at all times. SP PRO inverter. It is also possible to independently set the maximum export power from 0kW to the SP PRO’s maximum output.
Did you know? The SP PRO/KACO RS485 link provides the same precise control over the AC Coupled EK Vh 98 8djeaZY ELB# GZ\VgYaZhh d[ charging source your batteries will enjoy maximum life with SP PRO charging.
Data sheet Powador 2002 | 3002 | 4202 Data sheet 5002 | 6002 Powador 2002 | 3002 | 4202 5002 | 6002 Powador 2002 | 3002 | 4202 5002 | 6002 High flexibility. Easy installation. The galvanically isolated string inverters Powador 2002 – 6002. 3D efficiency diagram for Powador 6002 Capable of reactive power, conforms to the German Low Voltage Directive 93 94 500 Degree of efficiency up to 96.
Technical data Powador 2002 | 3002 | 4202 | 5002 | 6002 Electrical data 2002 3002 4202 5002 6002 Max. recommended PV generator power 2 000 W 3 000 W 4 200 W 5 000 W 6 000 W MPP range 125 V … 510 V 200 V … 510 V 200 V … 510 V 200 V … 510 V 200 V … 510 V No-load voltage 600 V* 600 V* 600 V* 600 V* 600 V* Max. input current 14.3 A 13.5 A 18.5 A 22.4 A 26.
Data sheet Powador 10.0 TL3 12.0 TL3 14.0 TL3 18.0 TL3 NEW Data sheet Powador 10.0 TL3 12.0 TL3 14.0 TL3 18.0 TL3 NEW Powador 10.0 TL3 | 12.0 TL3 14.0 TL3 | 18.0 TL3 The power plants of the future. The transformerless three-phase inverters Powador 10.0 TL3 to 18.0 TL3. 3D efficiency diagram for Powador 14.
Technical data Powador 10.0 TL3 | 12.0 TL3 | 14.0 TL3 | 18.0 TL3 Electrical data 10.0 TL3 12.0 TL3 Input variables 14.0 TL3 18.0 TL3 NEW Max. recommended PV generator power 10 000 W 12 000 W Max. recommended PV generator power 14 000 W 18 000 W MPP range 200 V ... 800 V* 200 V ... 800 V* MPP range 200 V ... 800 V* 200 V ... 800 V** Starting voltage 250 V 250 V Starting voltage 250 V 250 V No-load voltage 1 000 V 1 000 V No-load voltage 1 000 V 1 000 V Max.
ON O S NG I M Powador COPowador 48.0sheet TL3Park Park Data 48.0 TL3 72.0 TL3 Park Inverters Inverters 98.0 % efficiency 98.0 % efficiency NEW NEW NEW NEW 3 MPP trackers, symmetrical 3and MPPasymmetrical trackers, symmetrical loading possible and asymmetrical loading possible 72.0 TL3 Park Powador 30.0 TL3 | 33.0 TL3 36.0 TL3 | 39.0 TL3 60.
Selectronic Accredited Integrator Program What is the SP PRO Accredited Integrator Program? Who can become an SP PRO Accredited Integrator? The SP PRO Accredited Integrator (SPAI) program is an initiative set up by Selectronic to train and support system integrators working in the field of energy storage.
Selectronic Australia tel fax +61 3 9727 6600 +61 3 9727 6601 www.selectronic.com.
