Technical data
Reliable electricity should not be
considered a luxury but as an
essential part of life today. We
need electricity 24/7, not just when
grid supply is available.
Renewable energy plus extra benefits.
An SP PRO inverter will convert electricity stored in batteries
from Solar, Wind or Hydro (Renewable Energy) to operate
your normal electrical appliances.
Renewable electricity not required to keep the batteries
charged is then exported to the electricity grid to effectively
run your meter backwards. It is then likely that your
electricity retailer is then able to buy this excess electricity
from you. This is called a “Feed In Tariff”.
Power outages are not uncommon these days. Bushfires
or floods can cause outages for hours, days or even
weeks. For safety reasons conventional Solar Power Grid
systems must turn off when the grid fails. This means your
investment of Renewable Energy will be wasted during grid
outages. The advanced technology inside the SP PRO allows
your electricity supply to seamlessly continue by switching
to battery backup mode, allowing you to power your 240
volt loads using the electricity stored in the batteries plus any
available Renewable Energy.
The complete process is seamless as the SP PRO takes
care of everything, including ensuring that your batteries
remain fully charged at all times in preparation for the next
power outage. Battery charging will first happen using the
Renewable Energy. If more charging is needed it will come
from the electricity grid when available.
In the event your batteries have become discharged during
a prolonged outage, an optional Generator Controller can
start an automatic generator to provide power for the home
and charge the batteries. When grid power returns the
generator will be turned off automatically. With an SP PRO
you’ll never know when the grid has failed except when all
your neighbours are in the dark.
With electricity prices increasing
rapidly your investment will
continue to increase in value.
Solar Hybrid
An inverter that provides
smarter energy 24/7.
SP PRO SERIES SPECS
HEB8')% HEB8')& HEB8)-& HEB8)-' HEB8&'%& SPLC1202
BVm^bjbHdaVg"688djeaZY 6.0 kW 9.0kW 10kW 15kW 15kW 30 kw
BVm^bjbHdaVg"988djeaZY 3.3 kW 5.0 kW 5.5kW 8.3kW 8.3kW 22 kw
Solar Panel Voltage Charge controller dependent
GRID FEED POWER
24/7 3 kW 4.5 kW 5 kW 7.5 kW 7.5 kW 20 kW
BACKUP POWER
24/7 3 kW 4.5 kW 5 kW 7.5 kW 7.5 kW 20 kW
1 hour 3.2 kW 4.7 kW 5.3kW 8kW 8kW 24 kW
30 seconds 7.5kW 10.5kW 12kW 18kW 18kW 44 kW
Battery voltage 24 V 24 V 48 V 48 V 120 V 120 V
Battery capacity required 100 Ah - 10,000 Ah
Battery recharge capacity from Grid 125 amps 188 amps 104 amps 156 amps 63 amps 167 amps
Time to transfer to backup mode 0 - 0.03 seconds
Peak efficiency 95% 95% 96% 96% 97% 97.2%
Dimensions in mm 690 H x 375 W x 220 D 870 H x 540 W x 290 D
Weight 35 kg 39 kg 40 kg 42 kg 42 kg 115 kg
Warranty 5 years standard. 7 years when installed by an SP PRO Accredited Installer, 8 years as part of an SP PLUS Energy Kit
Approvals AS/NZS 61000–6–3 2007, AS 62040.1.1–2003, AS 4777 2005 (grid connect)
