Cycle Gear BiLT DWO-5 Bluetooth Communication Kit www.cyclegear.
DWO-5 CONTENTS 1 GETTING STARTED..................................................4 1.1 1.2 1.3 1.4 1.5 1.6 2 Button Operation.............................................................. 4 Powering On and Off....................................................... 4 Charging.......................................................................... 5 Checking the Battery Level.............................................. 5 Volume Adjustment..........................................................
DWO-5 8.9 Delete All Bluetooth Pairing Information........................ 27 8.10 Factory Reset ................................................................ 27 8.11 Exit Voice Configuration Menu....................................... 28 9 FIRMWARE UPGRADE...........................................29 10 TROUBLESHOOTING.............................................29 10.1 10.2 10.3 10.4 Intercom Failure............................................................. 29 Intercom Reconnection.............
DWO-5 1 GETTING STARTED 1.1 Button Operation (+) Button Center Button (-) Button Fault Reset Button Status LED 4 DC Power Charging & Firmware upgrade Port 1.2 Powering On and Off To power on the headset, press the Center Button and the (+) Button at the same time while hearing ascending beeps and a voice prompt, “Hello”. To power off the headset, press the Center Button and the (+) Button at the same time while hearing descending beeps and a voice prompt, “Goodbye”.
DWO-5 1.3 Charging You can charge the headset by connecting the supplied USB power & data cable into a computer’s USB port or USB wall charger. You can use any standard micro USB cable to charge the unit. You can also charge them on the road using the cigarette charger. The charging LED turns red while charging and turns blue when fully charged. It takes about 2.5 hours to be completely charged. 1.4 Checking the Battery Level 1.4.
DWO-5 1.5 Volume Adjustment 1.6 Sena Device Manager You can easily adjust the volume by pressing the (+) Button or the (-) Button. You will hear a beep when the volume reaches the maximum or minimum level. The volume is set and maintained independently at different levels for each audio source even when you reboot the headset. For example, once you set the volume for mobile phone handsfree, it will not change even if you adjust the volume for your Bluetooth MP3 music.
DWO-5 2 PAIRING THE HEADSET WITH BLUETOOTH DEVICES Before using the BiLT DWO-5 Bluetooth headset with any other Bluetooth devices for the first time, you will need to pair them together. You can pair the DWO-5 with Bluetooth mobile phones, Bluetooth stereo devices such as MP3 players, or motorcycle specific Bluetooth GPS navigation, and with other Sena Bluetooth headsets. The pairing operation is required only once for each Bluetooth device.
DWO-5 6. If the pairing process is not completed within three minutes, the headset will return to stand-by mode. Note: 1. If the Bluetooth connection between the headset and a mobile phone is disconnected, press the Center Button for 3 seconds to recover the Bluetooth connection immediately. 2. If the Bluetooth connection between the headset and a media player is disconnected, press the Center Button for 1 second to recover the Bluetooth connection and play. 2.
DWO-5 Note: 1. The Sena SR10 is a Bluetooth two-way radio adapter for group communication, and uses Hands-Free Profile. The incoming audio from the two-way radio via SR10 is heard in the background while having an intercom conversation or a mobile phone call. 2. The GPS navigation or a radar detector could be connected to the SR10 by wire. The GPS voice instruction or the radar detector alarm is also heard in the background via SR10 while having an intercom conversation or a phone call.
DWO-5 2.3.1 A2DP Stereo Music Only 2.3.2 HFP for Phone Call Only 1. Press and hold the Center Button for 12 seconds until you hear a voice prompt, “Configuration menu”. 1. Press and hold the Center Button for 12 seconds until you hear a voice prompt, “Configuration menu”. 2. Tap the (+) Button until you hear a voice prompt, “Media selective pairing”. 2. Tap the (+) Button until you hear a voice prompt, “Phone selective pairing”. 3. Search for Bluetooth devices on your smartphone.
DWO-5 2.4 Intercom Pairing 2.4.1 Pairing with Other BiLT DWO5 Headsets for Intercom Conversation The headset can be paired with up to three other headsets for Bluetooth intercom conversation. 1. Turn on the two headsets (A and B) that you would like to pair with each other. 2. Press and hold the Center Button of the headset A and B for 5 seconds until red LEDs of the both units start to flash rapidly. You will hear a voice prompt, “Intercom pairing”. 3.
DWO-5 Note: For example, after the pairing procedures listed above, headset D is the first intercom friend of headset A. Headset C is the second intercom friend of headset A, and headset B is the third intercom friend of headset A. 3 MOBILE PHONE, GPS, SR10 3.1 Mobile Phone Call Making and Answering 2.4.2 Pairing with Other Sena Headset Models for Intercom Conversation 1. When you have an incoming call, simply tap the Center Button to answer the call.
DWO-5 • Enter numbers on your mobile phone’s keypad and make a call. Then the call is automatically transferred to the headset. • Press the Center Button for 3 seconds in stand-by mode to activate the voice dialer of your mobile phone. For this, the voice dialing function must be available on the mobile phone. Refer to your mobile phone manual for further instruction. Note: 1.
DWO-5 4. After selecting the last number redial menu, you will hear a voice prompt, “Last number redial”. Then, to redial the last phone call number, tap the Center Button. 5. To call one of the speed dials, tap the (+) Button or the (-) Button to navigate between the menus until you hear a voice prompt, “Speed dial (#)”. Then, tap the Center Button. 6. If you want to exit the speed dial immediately, tap the (+) Button or the (-) Button until you hear voice prompt, “Cancel”, and tap the Center Button.
DWO-5 3.4 Sena SR10, Two-Way Radio Adapter You can use a two-way radio and the headset Bluetooth intercom simultaneously by using the Sena SR10, a Bluetooth Two-way Radio Adapter (please refer to section 2.2, “Multipoint Pairing - Second Mobile Phone, GPS, and SR10”). Incoming audio from the two-way radio will not interrupt an intercom conversation but is heard in the background.
DWO-5 1. To play or pause music, press the Center Button for 1 second until you hear a double beep. 2. To adjust the volume, tap the (+) Button or the (-) Button. 3. To track forward or track back, press and hold the (+) Button or the (-) Button for 1 second until you hear a mid-tone single beep. 4.2 Music Sharing You can start sharing music with an intercom friend using Bluetooth stereo music during a two-way intercom conversation (please refer to section 5.1, “Starting Two-way Intercom”).
DWO-5 5 INTERCOM Please make sure your intercom devices are paired as described in section 2.4, “Intercom Pairing”. 5.1 Starting Two-way Intercom You can start an intercom conversation with one of any intercom friends by tapping the Center Button: Tap the Center Button once to intercom with the first intercom friend, tap the Center Button twice to intercom with the second intercom friend, and tap the Center Button three times to intercom with the third intercom friend.
DWO-5 5.2 Ending Two-way Intercom To terminate an intercom conversation, single tap the Center Button. Any intercom connection with any intercom friend will be terminated by a single tapping. A double or triple tapping will do nothing in this case. End Two-way Intercom Conversation 18 5.3 Intercom and Mobile Phone Call 1. When you have an incoming mobile phone call during an intercom conversation, you will hear a ring tone.
DWO-5 Unlike other motorcycle Bluetooth headsets, this prevents a user from being dropped out of an intercom conversation by an incoming mobile call. 2. When you have an incoming intercom call during a mobile phone call, you will hear double high toned beeps, alerting you that there is an incoming intercom call. You will also hear a voice prompt, “Intercom requested”. In this case, the intercom call does not override the mobile call because intercom has lower priority than mobile call.
DWO-5 6.1 Universal Intercom Pairing 6.2 Two-way Universal Intercom The headset can be paired with non-Sena Bluetooth headsets for Bluetooth intercom conversation. You can pair the headset with only one non-Sena Bluetooth headset so if you pair with a different non-Sena Bluetooth headset, the previous pairing will be removed. You can initiate the Universal Intercom connection with non-Sena Bluetooth headsets using the same intercom connection method as you would between other Sena headsets.
DWO-5 7 FUNCTION PRIORITY The BiLT DWO-5 operates in the following order of priority: (highest) Mobile phone Intercom Music sharing by Bluetooth stereo music (lowest) Bluetooth stereo music A lower priority function is always interrupted by a higher priority function. For example, stereo music is interrupted by intercom call, and an intercom conversation is interrupted by an incoming mobile phone call.
DWO-5 5. If you want to exit the configuration immediately, Tap the (+) Button or the (-) Button until you hear a voice prompt, “Exit configuration”, and tap the Center Button.
DWO-5 8.1 Mobile Phone Pairing Voice Prompt “Phone pairing” Factory Default N/A To go into mobile phone pairing mode, tap the (+) Button or the (-) Button until you hear the voice prompt, “Phone pairing”. Please refer to section 2.1 for details on mobile phone pairing. If you tap the (+) Button or the (-) Button, you can exit from the phone pairing mode. 8.
DWO-5 8.4 Media Selective Pairing Voice Prompt "Media selective pairing" Factory Default N/A To go into media selective pairing mode, tap the (+) Button or the (-) Button until you hear the voice prompt, “Media selective pairing”. Please refer to section 2.3.1 for details on media selective pairing. If you tap the (+) Button or the (-) Button, you can exit from the media selective pairing mode. 8.5 Assigning Speed Dial Voice Prompt "Speed dial" Factory Default N/A Execute Tap the Center Button 1.
DWO-5 4. Call a phone number you want to assign and you will hear a voice prompt, “Save speed dial (#)”. The phone number is automatically assigned to the selected speed dial number. Then the phone call will hang up before being connected. 5. To exit the menu, tap the (+) Button or the (-) Button until you hear a voice prompt, “Cancel”, and tap the Center Button to confirm. You will then hear a voice prompt, “Cancel”.
DWO-5 8.7 Enabling/Disabling Sidetone Voice Prompt “Sidetone” Factory Default Disable Enable/Disable Tap the Center Button Sidetone is audible feedback of your own voice. It helps you to naturally speak at the correct level according to varying helmet noise conditions. If this feature is enabled, you can hear what you are speaking during an intercom conversation or a phone call. 26 8.
DWO-5 8.9 Delete All Bluetooth Pairing Information Voice Prompt “Delete all pairings” Factory Default N/A Execute Tap the Center Button To delete all Bluetooth pairing information of the headset, tap the (+) Button or the (-) Button until you hear a voice prompt, “Delete all pairings”, and tap the Center Button to confirm. 8.
DWO-5 8.11 Exit Voice Configuration Menu Tap (+) Button or (-) Button Tap Center Button Voice Prompt “Exit configuration” Phone Pairing None Factory Default N/A None Execute Tap the Center Button Second Mobile Phone Pairing Phone Selective Pairing None Media Selective Pairing None To exit voice configuration menu and get back to stand-by mode, tap the (+) Button or the (-) Button until you hear a voice prompt, “Exit configuration”, and tap the Center Button to confirm.
DWO-5 9 FIRMWARE UPGRADE The BiLT DWO-5 supports firmware upgrades. You can update the firmware using the Sena Device Manager (please refer to section 1.6, “Sena Device Manager”). Please visit Sena Bluetooth website at www.sena.com to check the latest software downloads. 10 TROUBLESHOOTING 10.
DWO-5 10.2 Intercom Reconnection 10.4 Factory Reset If your intercom friend goes out of range while having an intercom conversation, you may hear static noise and eventually the intercom will be disconnected. In this case, the BiLT DWO-5 automatically tries to reconnect the intercom every 8 seconds and you will hear high tone double beeps until the intercom is reestablished. If you do not want to make a reconnection, tap the Center Button to stop the attempt.
DWO-5 11 OPERATION QUICK REFERENCE Type Basic Function Mobile Phone Function Button Command LED Beep Power on Press the Center Button and the (+) Button for 1 second Solid blue Ascending beeps Power off Tap the Center Button and the (+) Button Solid red Descending beeps Volume adjustment Tap the (+) Button or the (-) Button - - Answer mobile phone call Tap the Center Button - - End mobile phone call Press the Center Button for 2 seconds - - Voice dial Press the Center Button for 3
DWO-5 Type Intercom Function Intercom pairing Button Command Press the Center Button for 5 seconds LED Red flashing Beep Mid-tone single beep Tap the Center Button of any one of the two headsets Music 32 Start/End each intercom Tap the Center Button - - Play/Pause Bluetooth music Press the Center Button for 1 second - Mid-tone double beep Track forward/back Press the (+) Button or the (-) Button for 1 second - -
DWO-5 CERTIFICATION AND SAFETY APPROVALS FCC Compliance Statement This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to part 15 of the FCC rules.
DWO-5 • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/ TV technician for help. FCC RF Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End users must follow the specific operating instructions for satisfying RF exposure compliance.
DWO-5 (2) This device must accept any interference, including interference that may cause undesired operation of the device. Bluetooth License The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Sena is under license. Other trademarks and trade names are those of their respective owners. The product is compliant with and adopts the Bluetooth® Specification 3.
DWO-5 SAFETY INFORMATION Please ensure that the product is properly used by observing the warnings and cautions below to prevent any risk and/or damage to property. Product Storage and Management • Keep the product free of dust. It may damage mechanical and electronic parts of the product. • Do not store the product in high temperatures as this may reduce the life span of electronic devices, damage the battery, and/or melt plastic parts of the product. • Do not store the product in cold temperatures.
DWO-5 • Do not cause impact to the product or touch it with sharp tools as this may damage the product. • Do not use the product in high-temperatures or apply heat to the product as this may cause damage, explosion, or fire. • Keep the product dry and away from water. It may damage the product. • Keep product away from pets or small children. It may damage the product or cause accidents.
DWO-5 Battery This product has an irreplaceable rechargeable battery inside. Therefore, when using the product, make sure to adhere to the following: • Never separate the battery from the product as this may damage the product. • The battery performance may be reduced over time with usage. • In recharging the battery, make sure to use an approved charger provided by the manufacturer.
DWO-5 PRODUCT WARRANTY DISCLAIMER AND Limited Warranty Limited Warranty Sena Technologies, Inc. (“Sena”) guarantees the product quality based on the technical specification stated in the product manual, and data regarding product warranty. Here, product warranty extends to the product only. Sena will not be liable for any loss, damage of human life, or loss of property which may result from using the product beyond defective parts or flaws that occur due to problems in manufacture.
DWO-5 Notice and Waiver By buying and using this product, you relinquish considerable legal rights including any claim for compensation for damages. Therefore, be certain to read and understand the following terms and conditions before using the product. Use of this product will constitute consent to this agreement, and forfeiture of rights to all claims. If you do not consent to all the terms and conditions of this agreement, return the product for a refund. (Refer to the section “Return for Full Refund”.
DWO-5 • Sena; together with employees, managers, partners, subsidiaries, representatives, agents, supporting firms and suppliers, sole sellers of Sena (collectively referred to as "the company") recommend that, before using the product and similar devices of any brands including its derivative models, you collect any relevant information in advance and be entirely prepared in terms of weather, traffic situation, and road conditions.
DWO-5 Warranty Exclusions Reasons for Limited Liabilities If you do not return the product after purchasing it, you relinquish all rights to liabilities, loss, claims, and claims for reimbursement of expenses (including attorney's fees). Therefore, Sena will not be liable for physical injury, death, or any loss or damage of transportation means, possessions, or assets which belong to you or third parties that may have occurred while you use the product.
DWO-5 REMEDY PROVIDED HEREIN SHALL FAIL OF ITS ESSENTIAL PURPOSE. IN ANY CASE, THE TOTAL COMPENSATION LIABILITIES OF SENA OR ITS SALES AGENTS SHALL NOT EXCEED THE PRICE PAID FOR THE PRODUCT BY THE PURCHASER. Liabilities Disclaimer In addition to damages which may occur due to the use of the product, Sena will not be liable for damages of the product which occur due to the following events. • In the event the product is misused or used for purposes other than its intended purposes.
DWO-5 Warranty Service To obtain product warranty service, send the defective product, at your expense, to the manufacturer or the seller along with proof of purchase (a receipt that shows the purchase date, a product registration certificate of the Website, and other relevant information). Take necessary measures to protect the product. In order to get a refund or replacement, you must include the whole package as it was purchased.
