System Instructions

SES-imagotag GmbH I Kalsdorfer Straße 12 I A-8072 Fernitz-Mellach - AUSTRIA
CR: FN350927w I Commercial court: Graz I UID : ATU65936017
T. [phone] I E. [e-mail] I www.ses-imagotag.com
VUSION – Electronic Shelf Labels
Read all documents and system instructions carefully to minimize the risk of injuring
persons and to avoid damage to the system or damage to the environment.
Always keep all documents and guidance accessible.
If necessary, the content of this document will be updated. You can request the latest version
of the document via [e-mail].
Register at the https://portal.imagotag.com to get access to the latest software and
documentation.
An electronic shelf label is a device that shows article data and price information on
its display. In comparison to printed labels the information is automatically updated if price or
article data changes.
The SES-imagotag electronic shelf label family offers high-quality display options, operating
with a replaceable battery, thus working without any external power supply.
The SES-imagotag VUSION (2.4GHz) electronic shelf label family can change all pixels to
black, white or red/yellow. The current line-up has display sizes from 1.6 inch to 12.2 inch.
They may be used in landscape and portrait mode and can be configured in terms of radio,
theft protection, display protection and LED flash.
General Key Features
2.4 GHz proprietary radio protocol
Radio coverage: up to 25 meters
Bi-directional communication
11 available communication channels
Ultra-low power consumption
Customer-replaceable battery
Full graphical e-Ink display with paper-like readability
e-ink displays are available (Black/White, Black/White/Red, Black/White/Yellow)
Different configurations available (theft protection, display protection, LED flash)
Label versions for deep-freezing environments
Super wide viewing angle (nearly 180 degrees)
Flexible mounting options available
May be used in landscape and portrait mode
Fast response time
128-bit AES encryption with secure key exchange
Multiple pages support with preloading and fast page switching
Integrated Passive NFC tag
The installation instructions are intended for trained electricians who can exhibit the following
qualifications:
Knowledge of the use of tools and work instructions.
Knowledge of the usable conditions of the tool.
Knowledge of the electrical safety instructions.
Knowledge of the electrical building regulations.
Knowledge of the relevant standards.
Knowledge of the assembly schedule.
