S2901UK OWNER’S GUIDE
IMPORTANT SAFETY INSTRUCTIONS For Household Use Only WHEN USING YOUR SHARK® STEAM MOP, BASIC SAFETY PRECAUTIONS SHOULD ALWAYS BE FOLLOWED, INCLUDING THE FOLLOWING: READ ALL INSTRUCTIONS BEFORE USING YOUR SHARK® MULTI-FUNCTION STEAM POCKET MOP LITE. DANGER OF SCALDING. Please use caution when using the steam mop. The steam emitted from the steam mop is very hot.
13. DO NOT unplug by pulling on power cord. To unplug, grasp the plug not the power cord. Do not use extension cords or outlets with inadequate current carrying capacity. 14. DO NOT put any objects into openings. Do not use with any opening that is blocked. 15. DO NOT put hands or feet under the steam mop. Unit gets very hot. 16. Use ONLY on flat, horizontal surfaces when using in steam mop mode. Do not use on walls, counters or windows when using in steam mop mode. 17.
This appliance complies with the WEEE-Directive 2002/96/EC on the disposal of electrical and electronic equipment (WEEE). This appliance complies with the European directives for electromagnetic compatibility (EMC) 2004/108/EC and its revisions, as well as Low Voltage Directive (LVD) 2006/95/EC and its revisions. This marking indicates that this product should not be disposed with other household wastes throughout the EU.
Contents Thank you for purchasing the Shark® Multi-Function Steam Pocket® Mop Lite.
Getting Started When assembling your steam mop there may be a little water in or around the water tank. This is because we test all our steam mops 100% before you buy them, so you get a quality Shark® Multi-Function Steam Pocket® Mop Lite.
Assembling Your Steam Mop fig. 2 fig. 1 IMPORTANT: Always make sure the mop is UNPLUGGED from the wall when not in use. Never fill the mop, attach the mop head, change or remove the cleaning pocket when the mop is plugged into the wall. To prolong the life of your Shark® Multi-Function Steam Pocket® Mop Lite we recommend using distilled water. Make sure you only add water to the tank. Chemicals or cleaning solution may damage the appliance and could be unsafe for you and your family.
Using Your Steam Mop I MPORTANT: Make sure you do not use the mop without attaching a cleaning pocket and adding water to the tank first. When you are using the mop for the first time, it might take longer than the normal 30 seconds to start steaming. fig. 5 fig. 3 fig. 6 fig. 4 1 Turn the water tank cap counter clockwise and remove from the tank. (fig. 3) NOTE: To prolong the life of your Steam Mop, we recommend using distilled water. 2 Use the filling flask and pour water into the tank.
6 Use the shaggy side of the cleaning pockets to lift up and lock away all the dirt and debris and the scrubbing side to break up the tough stains. (fig. 7) 7 When the water tank is empty, the Steam Mop will stop producing steam. You can refill the water tank at any time as long as the mop is unplugged from the outlet. Follow the instructions from page 4. This applies to switching the mop head or cleaning pocket as well.
Using Your Handheld Steamer Your Shark® Multi-Function Steam Pocket® Mop Lite is designed to clean surfaces that will withstand high heat and moisture. Do not use on unsealed wood surfaces (especially wooden antique furniture), unglazed ceramic tile, painted surfaces or surfaces that have been treated with wax, oils, varnishes, or shellac. The sheen may be removed by the heat, steam, and friction of the cleaning tools.
Using Your Removable Handheld Steamer with the Different Accessories Release Button fig. 11 fig. 12 1 First attach the Accessory Hose to the Handheld Steamer by snapping the Accessory Hose into the main nozzle. (fig. 11) 2 S elect the desired cleaning tool for use. Follow the cleaning tool sub-assembly instructions for the selected tool. (fig. 12) CAUTION: Do not press the power button while attaching or removing the Accessory Hose.
Using Your Removable Handheld Steamer with the Different Accessories - cont. fig. 13 USING THE CONCENTRATOR NOZZLE Cleaning Tip: The Concentrator Nozzle creates direct steam spray to clean and sanitise hard to reach nooks & crannies and other places where germs may build up. Use the Concentrator Nozzle to loosen and dislodge compact dirt often found in corner and tight places where traditional methods and cleaning tools tend to push dirt into, making it tough to reach and clean.
fig. 14 fig. 15 USING THE GROUT SCRUBBER USING THE WINDOW SQUEEGEE Cleaning Tip: The Grout Scrubber is designed for removing stubborn messes in hard-to-reach nooks, corners and in grout where focused scrubbing power may be needed. It can loosen and dislodge compact dirt often found in corners and tight places where traditional methods and cleaning tools tend to push dirt into, making it difficult to reach and clean. Scrub with the Grout Scrubber and wipe clean with a cleaning cloth.
Care of Your Steam Mop fig. 16 AFTER USE AND STORAGE 1 Press the power button to turn the unit off. Unplug the cord from the outlet and place the mop into the upright position. Let the unit cool for 2-3 minutes. 2 When you have finished using the Handheld Steamer, reattach the handle to the handheld steamer. 3 Remove the cleaning pocket from the mop head by releasing the quick fasteners and using the loop on the side of the pocket, avoiding contact with the hot pocket or dirt.
DECALCIFYING YOUR STEAM MOP Calcium and mineral deposits can build up and impact the performance of your steam mop over time. To extend the life of your product we recommend that you use distilled water. 40° fig. 17 fig. 19 fig. 18 CARE OF YOUR CLEANING POCKETS 1 We recommend washing your cleaning pocket separately from other fabrics to avoid picking up lint. For optimal cleaning performance, the pockets may need to be washed up to (3) three times. Only use liquid detergent (no powder detergent).
Troubleshooting Guide PROBLEM POSSIBLE REASONS & SOLUTIONS The Shark® Multi-Function Steam Pocket® Lite Mop will not turn-on. Your steam mop should be securely plugged into an electrical outlet only. Check your fuse or breaker. Is there water in the water tank? If not, add water to your steam mop following instructions on page 4. The unit will not make steam. When using the unit in the handheld mode, ensure that you are holding the handheld unit horizontally to optimise the steam output.
Notes www.sharkclean.
Notes 14 FREEPHONE 0800 862 0453
Notes www.sharkclean.
Euro-Pro Europe Limited 15 Mariner Court Calder Park Wakefield WF4 3FL Freephone 0800 862 0453 www.sharkclean.eu Technical Details Model number: Input: Main unit voltage: S2901UK 11 1250 Watts 220-240V~, 50/60Hz COPYRIGHT© EURO-PRO OPERATING LLC 2014 Euro-Pro, Steam Pocket, and Shark are trademarks of Euro-Pro Operating LLC. All other brand names may be trademarks of their respective owners. PRINTED IN CHINA S2901UK_11_IB_E_141016_2 Illustrations may differ from actual product.
