29H-FD1S 29H-FD1S OPERATION MANUAL MODE D’EMPLOI Please read this operation manual carefully before using the colour television. Veuillez lire attentivement ce mode d’emploi avant d’utiliser ce téléviseur couleur.
Contents Preparation Accessories ........................................................... Easy setup ............................................................ Safety precautions ................................................ Part names ............................................................ Installing batteries in the remote control unit ........ 2 3 4 6 7 Watching TV Watching a TV programme .................................... 9 Operating the TV buttons ....................................
ENGLISH FRANÇAIS Dear SHARP Customer РУССКИЙ Thank you for buying SHARP’s Colour Television. We hope you will have many years of enjoyment from this television set. To ensure proper operation, please read this manual carefully, and keep it in a safe place for future reference. Accessories The following accessories are included with this television. Remote control R F A Ç N A IS E G N IS L H Size-AA batteries 29H-FD1S .
Easy setup To use your TV set, perform the easy setup procedure below. The mark indicates the page numbers with more detailed information. Connect the antenna. • See 52 to connect the antenna. Connect any video equipment. • See 52 , 53 to connect video equipment. • See the operation manual of your video equipment when connecting to the TV set. Insert the batteries into the remote control. • Use the two batteries included with the TV. • See 7 . Insert the AC plug to the power outlet.
ENGLISH Safety precautions Damage FRANÇAIS Turn off the power and unplug the power cord from the wall outlet immediately if the TV set begins to make any unusual noises or gives off smoke or an unusual smell. Then call your dealer for service. Servicing РУССКИЙ To reduce the risk of electric shock, do not remove the back of the cabinet. This TV set contains dangerous voltage. Unstable surface and shocks Do not place this TV set on an unstable cart, stand, shelf, or table.
Safety precautions Liquid entry Do not place a flower vase or anything else containing liquid on the TV set, as liquid spilt on the TV set can cause electrical shock or failure. Object entry Never insert or drop any metallic or inflammable objects into the ventilation openings of the TV set, as this can cause fire, electrical shock, or electrical failure. Ventilation Do not place this TV set in a confined area, such as on a bookshelf or in a built-in case.
The ENGLISH Part names mark indicates the page numbers with more detailed information. Infrared transmitter window Aim this window at the infrared sensor window on your TV set. 12 POWER 9 Turns the TV on or to Standby mode. TV/VIDEO Switches between TV broadcast and A/V input programmes. 9 FRANÇAIS Remote control Number buttons 9 Displays the clock, timer and channel settings on the screen. Switches between one- or two-digit mode channel selection.
Part names Installing batteries in the remote control unit With your thumbnail, pull up at the slit to open the battery cover. • • • • E7 Insert two batteries (size AA). Replace the battery cover. Be sure to match the battery j/k terminals with the j/k marks inside the compartment. Remove the batteries if weak or if the unit is not in use for long periods. Do not mix old and new batteries. Incorrect installation of the batteries may damage the remote control.
ENGLISH TV set FRANÇAIS To open the door Using the projection located under the “PULL-OPEN” indication, pull and lift the door open. To close the door Using the projection, lower the door until closed. РУССКИЙ Caution: • When opening or closing the door, do not insert your fingers into the gap between the door and front panel. This may result in an injury. Door Bottom 9 MENU/PRESET 13 MENU/PRESET button Used for MENU setup. Tunes the channels.
Watching TV Watching a TV programme Simple operations for watching a TV programme. TV Set 1 Turn on power. • When the Standby indicator is off, press POWER . • When the Standby indicator is red, press POWER on the remote control. The Standby indicator changes to green and a picture appears. POWER Standby indicator 2 Behind the door Select channel. With CH / CH • Press CH and channels change as shown below. 1 / 2 / ... / 98 / 99 / AV1 (or SAV1) / AV2 (or COMPONENT) / AV3 (or SAV3) / 0 / 1 / 2 ...
ENGLISH Operating the TV buttons Simple operation of the TV set. Using / Press to increase volume. Press volume. to decrease VO L UME FRANÇAIS Behind the door 19 CH Using Press CH number. CH / CH 5 to increase channel to decrease Press CH channel number. Behind the door Using headphone Insert headphone plug into headphone jack to listen to audio with headphone. • The audio from the speakers is turned off. • Select an appropriate volume so as not to injure your hearing.
Useful features Clock/Timer/Channel display Displays the clock, the timer, the current channel number and other settings on the screen. 1 . Press • The clock and the time on the On timer, Off timer, View timer and the remaining time of the Reminder appears on the screen. 2 again. Press • The channel number appear on the screen. 3 once again. Press • The display disappears. Mute Silences the sound. 1 Press . • “ ” appears on the screen, and the sound is silenced. 2 Press again.
ENGLISH Sound mode Number buttons MOV I E MUS I C MOVIE: Movie mode MUSIC: Music mode NEWS: News mode CUSTOM: Custom mode FRANÇAIS TV/VIDEO Each time you press the SOUND MODE , the mode switches between MOVIE, MUSIC, NEWS and CUSTOM. N EWS C US T OM + – 100 300 1K 3K 8K Channel recall Switches back to the channel you were watching just before the current channel. Press . 5 • The channel previously viewed returns to the screen.
Selecting menu items This TV set allows you to adjust the picture and sound, and set the channels and other features using the On-screen display with the remote control or from the TV set. Select the desired menu item by following the steps below and then refer to the indicated page for details. Selecting a menu item Remote control CH CH 1 Press MENU / MENU/PRESET to call MENU screen.
ENGLISH Menu item FRANÇAIS ME NU P I C T URE SOUND F E A T URE T I ME R CH - S E T T I NG R E TURN : ME NU ENT ER : РУССКИЙ S E L E C T : CH Operation guide PICTURE menu............................ 22 – 23 SOUND P I C T URE V I DE O MOD E CON T RAS T CO L OUR BR I GH TN E S S T I NT SHARPNE SS P I C T URE NR WH I T E T EMP S E L E C T : CH SOUND menu............................... 24 – 25 DYNAM I C 60 + 6 0 0 + 6 OF F AD J US T : RE TURN : ME NU FEATURE menu............................
Settings and adjustments On-screen display language selection The on-screen display language can be set to English, Chinese, French, Malay or Arabic. Behind the door TV set 1 FRA S • The language select mode appears. CH MENU/PRESET E NG L I SH Press MENU/PRESET for more than two seconds during normal screen. CH S E L E C T : CH • In order to enter to language select mode, press MENU/PRESET during normal screen. 2 Press / CH • Pressing changes the screen as shown below.
ENGLISH Auto channel tuning Automatically tunes in and presets receivable TV stations. 1 Press MENU/PRESET for more than two seconds during normal screen. E NG L I SH FRA S FRANÇAIS Behind the door • The language select mode appears. S E L E C T : CH 2 Press MENU/PRESET again to display AUTO mode screen. AU T O РУССКИЙ • In order to enter to language select mode, press MENU/PRESET during normal screen. MENU/PRESET 1 4 8 . 2 5MH z • Pressing MENU/PRESET changes the screen as shown below.
Settings and adjustments Manual channel tuning Enables manual channel tuning to a desired TV station. Behind the door 1 Press MENU/PRESET for more than two seconds during normal screen. E NG L I SH FRA S • The language select mode appears. S E L E C T : CH • In order to enter to language select mode, press MENU/PRESET during normal screen. MENU/PRESET CH CH 2 Press MENU/PRESET twice to display MANUAL mode screen. MANUA L 1 4 8 .
ENGLISH Channel setting Enables individual channel setting. ME NU to call MENU MENU P I C T UR E SOUND F E A T UR E Press CH / CH to select “CH-SETTING”. T I ME R CH - S E T T I NG S E L E C T : CH CH CH 3 4 MENU 5 ENT ER : R E T U RN : ME NU CH - S E T T I NG Press / to display CH-SETTING menu. POS I T I ON POS I T I ON NAME CO L OUR - S Y S T EM SOUND - S Y S T EM SK I P AU T O MA NU A L SOR T L A NGUAG E Press CH / CH to select desired setting.
Settings and adjustments Channel setting (continued) SOUND-SYSTEM B/G AUTO M D/K I SKIP ON OFF When set “SKIP” to “ON”, the channel number are set to SKIP. To turn off SKIP, press the number buttons to select the desired channel and then set “SKIP” to “OFF”. AUTO • Press / and Auto Channel Tuning is started. Auto tuning bar will shown during Auto Search only. (Please see page 16 for details on Auto Channel Tuning.
ENGLISH Channel setting (continued) SORT CH Moving a program TV2 (at program number 2) to program number 5 1. When you press / in step 5 on page 18 , SORT menu will be displayed. CH SOR T 1 2 3 4 5 6 7 8 9 S T A RWL D TV2 HA L LMRK HBO D I S COVR L E A RN S E L E C T : CH 2. Press / CH or / to select program number 2 (e.g. TV2) to be moved. CH 1 2 3 4 5 6 7 8 9 S T A RWL D TV2 HA L LMRK HBO D I S CO VR L E A RN / CH or / to select program number 5 (e.g. DISCOVR).
Settings and adjustments Channel setting (continued) Deleting a program (Delete TV2 at program number 2) 1. Repeat step 1 on page 20 . 2 2. Press CH / CH or / to select program number 2 (e.g. TV2) to be deleted. CH CH SOR T 1 2 3 4 5 6 7 8 9 S T ARWL D TV2 HA L LMRK HBO D I S CO VR L E ARN 10 11 12 13 14 15 16 17 18 S E L E C T : CH 2 3. Press and program number 2 (e.g. TV2) will be set as program to be deleted. MENU MO V E : 1 • TV will tune to program number 2 having HALLMRK program.
ENGLISH Picture adjustment MENU to call MENU ME NU P I C T UR E SOUND F E A T UR E / CH Press CH to select “PICTURE”. T I ME R CH - S E T T I NG S E L E C T : CH CH CH 3 Press / to display PICTURE menu. 4 Press CH / CH to select adjustment items.
Settings and adjustments Picture adjustment (continued) The following table lists the adjustment items shown in the PICTURE menu and how they change as you / .
ENGLISH Sound adjustment 3 CH CH MENU MENU to call MENU F E A T UR E / CH Press CH to select “SOUND”. T I ME R CH - S E T T I NG SOUND Press / to display SOUND menu. Press CH / CH to select adjustment items. 5 Adjust using . E QUA L I Z E R SURROUND BBE B A L ANC E AVL SUP E R B A S S EPS ON 15 ON ON / • Wait for approximately five seconds to return to SOUND menu. 6 7 P I C T UR E SOUND 4 NORMAL ME NU FRANÇAIS 2 Press screen.
Settings and adjustments Equalizer 1 2 Press screen. MENU to call MENU ME NU P I C T UR E SOUND / CH Press CH to select “SOUND”. F E A T UR E T I ME R CH - S E T T I NG S E L E C T : CH CH CH 3 4 Press / to display SOUND menu. Press CH / CH to select “EQUALIZER”. SOUND E QUA L I Z E R SURROUND BBE B A L A NC E AVL SU P E R B A S S S E L E C T : CH MENU 5 Press / to display EQUALIZER menu. 6 Press CH / CH to select “MOVIE”, “MUSIC”, “NEWS” or “CUSTOM”.
ENGLISH Surround sound Produces a virtual surround sound from the TV’s speakers. SURROUND , the mode changes in the following FRANÇAIS Each time you press order: • Receiving signal stereo SURROUND ESS SURROUND OF F SURROUND S RS • Receiving signal monaural SURROUND SURROUND EPS SURROUND OF F CH РУССКИЙ CH Blue screen Automatically turns the screen blue if a broadcast signal is not received. MENU 1 2 Press screen.
Settings and adjustments Auto select When video equipment, such as a video game system or camcorder, is connected to the front (AV-3 IN) terminals, this TV set automatically selects the input mode (AV3). 1 2 Press screen. MENU to call MENU ME NU P I C T UR E SOUND F E A T UR E / CH Press CH to select “FEATURE”. T I ME R CH - S E T T I NG S E L E C T : CH CH CH MENU 3 Press / to display FEATURE menu. 4 Press CH / CH to select “AUTO SELECT”. 5 Press / to select “ON” or “OFF”.
FRANÇAIS The TV set will automatically adjust the contrast according to the environment brightness. User may select own preference by select COMFY VIEW to “OFF”, “DARK”, “MID” or “LIGHT”. ENGLISH Comfy view Using MENU screen 2 CH CH Press screen. MENU to call MENU ME NU P I C T UR E SOUND / CH Press CH to select “FEATURE”. F E A T UR E T I ME R CH - S E T T I NG S E L E C T : CH 3 Press / to display FEATURE menu. 4 Press CH / CH to select “COMFY VIEW”.
Settings and adjustments 16:9 mode Selects the width of the picture. 1 2 Press screen. MENU to call MENU ME NU P I C T UR E SOUND F E A T UR E / CH Press CH to select “FEATURE”. T I ME R CH - S E T T I NG S E L E C T : CH CH CH MENU 3 Press / to display FEATURE menu. 4 / CH Press CH to select “16:9 MODE”. 5 / Press to select “ON” or “OFF”.
ENGLISH Child lock Preventing children from watching TV, certain channels or playing game. 2 Press screen. MENU to call MENU Press CH / CH to select “FEATURE”. CH ME NU P I C T UR E SOUND F E A T UR E T I ME R CH - S E T T I NG S E L E C T : CH ENT ER : R E T U RN : ME NU РУССКИЙ 1 FRANÇAIS Setting the CHILD LOCK mode (For the first time) CH MENU 3 Press / to display FEATURE menu. 4 Press CH / CH to select “CHILD LOCK”.
Settings and adjustments Child lock (continued) POSITION/LOCK STATUS / or (i) Press Number buttons (0~9) to set the position. (e.g. 25) Number buttons CH I L D L OC K LOCK T V PO S I T I ON L OC K S T A T US L O C K GAME P A S SWORD OF F 25 ON OF F 0000 (ii) Press / to SW I T C H O F F T V T O A C T I V A T E C H I L D L O C K select “LOCK STATUS” to S E L E C T : CH AD J U S T : R E T U RN : ME NU “ON” or “OFF”. • ON: Channel position set above (e.g. 25) will be locked.
ENGLISH Child lock (continued) 1 Number buttons While “CHILD LOCK ON” screen appear. FRANÇAIS To turn OFF or to change setting of CHILD LOCK mode C H I L D L OC K ON P L E A S E I N PU T P A S SWORD 2 Enter 4 digits PASSWORD using Number buttons (0~9) on the remote control. (For example: 0000) РУССКИЙ –––– C H I L D L OC K ON P L E A S E I N PU T P A S SWORD **–– • Press to clear the entered number. • If the wrong PASSWORD is entered, “PASSWORD INCORRECT” screen will appear.
Settings and adjustments Demo To learn more about TV set. 1 2 Press screen. MENU to call MENU ME NU P I C T UR E SOUND / CH Press CH to select “FEATURE”. F E A T UR E T I ME R CH - S E T T I NG S E L E C T : CH CH CH MENU 3 Press / to display FEATURE menu. 4 / Press CH to select “DEMO”. 5 / Press to select “ON” or “OFF”.
ENGLISH Clock 2 Number buttons CH CH Press screen. MENU to call MENU ME NU P I C T UR E SOUND / Press CH to select “TIMER”. CH F E A T UR E T I ME R CH - S E T T I NG S E L E C T : CH 3 Press / to display TIMER menu. 4 Press CH / CH to select “CLOCK”. MENU Press Number buttons (0~9) to set clock. Press / to select “AM” or “PM”. • As soon as the clock is entered, the clock starts running.
Settings and adjustments Day This function allow to set the day. 1 2 Number buttons CH MENU to call MENU ME NU P I C T UR E SOUND / Press CH to select “TIMER”. F E A T UR E CH T I ME R CH - S E T T I NG S E L E C T : CH 3 Press / to display TIMER menu. 4 Press CH / to select “DAY”. CH MENU Press screen. 5 Press to set DAY.
ENGLISH On timer (continued) Press CH / CH to select “STATUS”. 6 / Press to set the status. T I ME R C L OC K DA Y ON S T A T US P OS I T I ON V O L UME OF F V I EW B E E P R EM I ND E R • STATUS can be select in the following order: CH ONCE CH TUE SUN S E L E C T : CH WED SAT 7 Press CH / CH to select “POSITION”. 8 Press / to set the position. (e.g. 78) MENU NORMAL MON DAILY 10 TV Set ON TIMER indicator (Red) Press CH / CH to select “VOLUME”. Press to set volume.
Settings and adjustments Off timer Automatically switches the TV to standby mode when preset time has been reached. 1 2 Number buttons CH Press screen. MENU to call MENU ME NU P I C T UR E SOUND / Press CH to select “TIMER”. CH F E A T UR E T I ME R CH - S E T T I NG S E L E C T : CH 3 Press / to display TIMER menu. 4 Press CH to select “OFF CH / CH ”.
2 Press screen. MENU to call MENU ME NU P I C T UR E SOUND / Press CH to select “TIMER”. F E A T UR E CH T I ME R CH - S E T T I NG S E L E C T : CH CH CH 3 / Press to display TIMER menu. 4 Press CH to select “ ”. / CH S E L E C T : CH Press to set time. 0:10 – – : – – AM SUN – – : – – AM ONC E –– –– – – : – – AM –– : –– 0:20 AD J US T : OF F R E T URN : ME NU T I ME R / • The Timer can be set in 10 minute intervals.
Settings and adjustments Reminder on-screen timer (continued) 6 MENU NORMAL Press MENU until normal screen appears. • Five minutes before the preset length of time expires (in the example, after one hour and 45 minutes) and each minute thereafter, the remaining time appears on the screen for several seconds with the beeping sound. (When BEEP REMINDER is set to “ON”) • When the preset length of time has passed, “ 0:00” flashes in red with the beeping sound.
ENGLISH View timer It is a function of limiting TV viewing time for children by muting sound and video when View Timer has passed. MENU ME NU to call MENU FRANÇAIS 2 Press screen. P I C T UR E SOUND / Press CH to select “TIMER”. F E A T UR E CH T I ME R CH - S E T T I NG S E L E C T : CH CH CH 3 / Press to display TIMER menu. 4 Press CH / CH to select “VIEW ”.
Settings and adjustments View timer (continued) Number buttons 8 Press CH / select “LOCK”. CH to 9 Press / select “ON” or “OFF”. to • ON: To lock the TV after View Timer has expired.(Please see page 42 for details on “To watch the TV programme again”.) • OFF: LOCK is deactivated. CH CH 10 Press CH / CH to select “PASSWORD”. 11 Enter 4 digits PASSWORD using Number buttons (0~9) on the remote control.
ENGLISH View timer (continued) 1 Turn on power. • “VIEWING TIME OVER” will appear. If you do nothing, the TV will turn off in approximately 30 seconds. 2 Enter 4 digits PASSWORD using Number buttons (0~9) on the remote control. (For example: 0000) • Press to clear the entered number. • When you choose the correct PASSWORD, the VIEWING TIME is cancelled. If the wrong PASSWORD is entered, “PASSWORD INCORRECT” screen will appear for approximately 5 seconds. Repeat step 2 to input the PASSWORD again.
Settings and adjustments Beep reminder It is a function to alert with beeping sound that the Reminder and View Timer are expiring soon with the remaining time OSD displays. 1 2 Press screen. MENU to call MENU ME NU P I C T UR E SOUND / Press CH to select “TIMER”. CH F E A T UR E T I ME R CH - S E T T I NG S E L E C T : CH CH CH MENU 3 Press / to display TIMER menu. 4 / CH Press CH to select “BEEP REMINDER”. 5 / Press to select “ON” or “OFF”.
1 2 Colour buttons Press CH / CH to select your favourite channel. (e.g. Channel 12) ENGLISH 12 Displayed in green or yellow , for Press A example, until channel number turns white. • The display will disappear after three seconds, and then the selected channel is preset. CH CH 3 To watch favourite channel, press . A 12 Turns to white • The preset favourite channel will be displayed. (e.g. Channel 12) 4 To preset another favourite channel, repeat steps 1 and 2 above.
Settings and adjustments FM radio Allow users to listen FM Radio from the TV speakers. Connecting a FM Radio Antenna To listen FM Radio on TV set, plug FM antenna into FM antenna jack at the rear of the TV. Number buttons TV CH CH 2 * (Please refer to for accessories included.) FM * FM Radio antenna 1 2 FM RAD I O Press to display FM FM Radio setting menu. PO S I T I ON F R E QU E N C Y SK I P AU T O VO L UME / CH Press CH to select desired setting.
ENGLISH FM radio (continued) / is pressed less than 2 seconds, FREQUENCY • If will be changed by step 50 KHz. • If / will be started. is pressed more than 2 seconds, MANUAL tuning FRANÇAIS FREQUENCY SKIP OFF MENU AUTO FM • When / is pressed, Auto tuning bar will appear and Auto Tuning start. • While the Auto tuning is completed, Auto tuning bar will disappear and back to POSITION 1. FM R AD I O PO S I T I ON F R E QU E N C Y SK I P AU T O VO L UME S E L E C T : CH 25 9 4 .
Settings and adjustments Game The game mode allow you to enjoy 6 various games. 1 Press GAME GAME menu. to display G A M E B D S B B R O X N A R O M E N U X A L A C M B K L I K A N A L L E O O N N S E L E C T : 2 3 GAME E N T E R : Press / to select a desired game. Press / to enter the selected game. • The TITLE menu will appear. MENU 4 Press GAME to return to TV mode. BOXMAN ENTER Rules • • • • Move several boxes located in the map to a target point.
ENGLISH DX-BALL РУССКИЙ MENU • Break blocks using a ball. Once you have broken all blocks, you can proceed to the next stage. • At the beginning of the game, you have three balls (lives). If you fail to receive a ball with the paddle, resulting in the ball falling to the ground, the number of your lives decreases by one. The game is over if you lose all your lives. • Breaking a particular block causes a special diamond icon to appear.
Settings and adjustments Key functions during Game screen: 1. / : To move the snake up or down. 2. / : To move the snake to left or right. 3. 4. ENTER : To pause the game. MENU : To return to the GAME menu. BALLOON MENU ENTER Rules • There is a hunter at the top left corner of the screen. You can move the hunter up or down. • You finish the game when the hunter shoots all the balloons rising from the bottom of the screen. • The hunter cannot shoot bricks.
ENGLISH Key functions during Title menu: 1. ENTER : To start the game. 2. MENU : To return to the GAME FRANÇAIS menu. 1. / : To move the cursor up or down. 2. / : To move the cursor to left or right. MENU 3. 4. ENTER : To turn cards over. MENU : To return to the GAME РУССКИЙ Key functions during Game screen: menu. ENTER Stage 1 screen THE ROCK Rules • Move the rocks and get apples. You finish the game when you get all the apples.
Connections Connecting to a DVD player The DVD input terminals (COMPONENT-IN) on the rear of the TV can be used to input high-quality images from a DVD player.
ENGLISH Connecting to an antenna If your outdoor antenna uses a 75-ohm coaxial cable with a standard DIN45325 plug (IEC 169-2), plug it into the antenna jack at the rear of the set. If your outdoor antenna uses a 300-ohm twin-lead flat feeder, connect a 300-ohm to 75-ohm impedance converter and plug it into the antenna jack at the rear of the set. FRANÇAIS To enjoy a clearer picture, use an outdoor antenna.
Connections Connecting to video equipment Enjoy playback from a video disc player, VCR or other video equipment by connecting them to this TV set using the Audio/Video in terminals.
FRANÇAIS РУССКИЙ No picture or sound Picture OK, sound poor. Sound OK, picture poor. Picture blurred. Picture ghosting Picture lines or streaks Picture weak. Poor reception on some channels No colour Picture rolls vertically. Picture distorted. Bars on screen Possible Causes/Remedies Remote control does not work. Quick Service Check List Problems The following problems do not always indicate a hardware failure.
Specifications MODEL 29H-FD1S Receiving System World multi 28 system TV Broadcasts/ VCR Playback PAL-I PAL-B/G PAL-D/K SECAM-B/G SECAM D/K, K1 NTSC-M (NTSC standard) VCR Playback NTSC NTSC NTSC NTSC NTSC NTSC VCR Playback (Using Video-in terminals) SECAM-L (French SECAM) Laserdisc Player Playback (Using RF-in terminals) PAL 5.5 MHz/60 Hz PAL 6.0 MHz/60 Hz PAL 6.5 MHz/60 Hz NTSC 3.58/4.
The Incredible Mono module (I-Mono) generates two channels from one mono input signal. When the sound of the mono input signal is processed, the listener gets the impression that the sound is essentially a stereo signal. Extended Spatial Stereo (ESS) The listener gets the impression of a sound reproduced by two virtual speakers, positioned at a larger distance between each other than between the actual speakers. So, the stereo image is expanded by this widening sound effect.
