Use and Care Manual

ManualsBrandsSharp ManualsHeating, Ventilation, and Air Conditioning10,000 BTU Window Air Conditioner with Rest Easy Remote Control

AF-Q100VX

AF-Q120VX

AF-Q100VX, AF-Q120VX)

15%

FOR YOUR PROTECTION............................... 2

CONSUMER LIMITED WARRANTY ................ 3

INSTALLATION INSTRUCTIONS

CHECK WINDOW AREA .............................. 4

LOCATION.................................................... 4

ACCESSORIES ............................................ 5

SUGGESTED TOOLS .................................. 5

INSTALLATION............................................. 6

PRECAUTIONS ................................................ 9

USING YOUR AIR CONDITIONER .................. 11

CLEANING AND MAINTENANCE ................... 16

BEFORE CALLING FOR SERVICE ................. 17

This INSTALLATION AND OPERATION MANUAL explains the proper use of your new Sharp Air Conditioner.

Read these instructions carefully before installing or operating your air conditioner. The INSTALLATION AND

OPERATION MANUAL should be kept in a safe place for handy reference.

Summary of content (20 pages)

PAGE 1
AF-Q100VX AF-Q120VX FOR YOUR PROTECTION ............................... 2 CONSUMER LIMITED WARRANTY ................ 3 INSTALLATION INSTRUCTIONS CHECK WINDOW AREA .............................. 4 LOCATION.................................................... 4 ACCESSORIES ............................................ 5 SUGGESTED TOOLS .................................. 5 INSTALLATION............................................. 6 PRECAUTIONS ................................................
PAGE 2
PAGE 3
AF-Q100VX, AF-Q120VX Room Air Conditioner.
PAGE 4
25 1/4 " (641mm) must be 15 1/2 " (394mm) 68
PAGE 5
Window sash seal Foam top window gasket Right accordion panel Left accordion panel Type A (6) Window locking bracket (1) Frame locking bracket (1) Remote Control
PAGE 6
Use protective material to prevent damage to the surface. 3 Install the accordion panels on each side. A. Locate the accordion panels in the box. B. Gently pull the free end of the accordion panel (See FIG. 1). Do this for both panels. C. Slide the free end of the accordion panel into the slot on the the side panel of the air conditioner (See FIG. 1). Do this for each side. The accordian panel labeled “LEFT” goes on the left side of the air conditioner as you are facing the control panel.
PAGE 7
Keeping a firm grip on the air conditioner carefully place the unit into the window opening so the bottom of the air conditioner frame is against the window sill. Carefully close the window behind the top rail of the unit. Extend the side panels out against the window frame. Front Side Horizontal or inclined about 3° Upper guide rail Lower guide rail Window frame 6 Use 5 Type A screws to secure the frame of the flexible screen to the window frame and sash.
PAGE 8
Plastic window 7 8 To secure the sash in place, attaché the right angle window lock with a Type B screw as shown. Cut Foam Seal to same width as window. Insert foam strip in the space between the upper and lower sashes.
PAGE 9
PAGE 10
PAGE 11
USING YOUR AIR CONDITIONER Electronic Control Panel & Remote Control CONTROL PANEL NOTE: This display always shows the room temperature in Fan Mode except when setting the Set temperature or the Timer Light indicates the unit is in the temperature or delay time Set mode. 2 Temp Time 3 4 Set 8 Filter check 7 Timer 1 Power Cool Auto Energy Saver High Fan Only Med Dry Low Mode Fan Speed indicatorfan 5 6 Air Conditioner Controls 1.
PAGE 12
USING YOUR AIR CONDITIONER Light indicates the unit is in the temperature or delay time Set mode. 2 Temp Time 3 4 Set 8 Filter check 7 Timer Cool Auto Energy Saver High Fan Only Med Dry 1 Power Mode indicatorfan Low Fan Speed 5 6 TIMER button on the unit or remote control. The timer can be set in 0.5 hour increments below 10 hours and in 1 hour increments for 10 hours or above. The Set light will turn on while setting.
PAGE 13
USING YOUR AIR CONDITIONER Remote Control 1. ON/OFF - Press the ON/OFF button to turn the A/C on or off. When the unit is turned off, the Timer and sleep functions will be cancelled. The set temperature will be saved. 2. MODE - Press the MODE button to change the operating mode. You can choose AUTO, COOL, SAVE (energy saver), FAN only, or Dry (Dehumidifier). The temperature will not be displayed when AUTO mode is selected. 3. “—” - Press the “-” button to decrease the temperature when the unit is on.
PAGE 14
USING YOUR AIR CONDITIONER 8. TIMER - Press the TIMER button when the unit is off to set up the Auto-on timer. The Auto-on time can be set between .5 - 24 hours. The icons “T-ON” and “H” will flash for 5 seconds. Start selecting the time using the “+” and “-” buttons before the icons stop flashing. The time will increase/decrease in .5 hour increments with each press of the “+” or “-” buttons. To cancel the Auto-on time, manually press the ON/OFF button to turn the unit on.
PAGE 15
USING YOUR AIR CONDITIONER • Freezing Conditions: This is a cooling only air conditioner. It is not designed for freezing outdoor conditions. It must not be used in freezing outdoor conditions. • Remote Control: To ensure proper operation when using the remote control, aim the remote directly at the signal receiver on the air conditioner. ~ The remote control has a signal range up to 20 feet. ~ Make sure nothing is blocking the remote control signal from being received by the air conditioner.
PAGE 16
PAGE 17
PAGE 18
PAGE 19
PAGE 20
