Thank you for purchasing this SHARP product. To obtain the best performance from this product, please read this manual carefully. It will guide you in operating your SHARP product. Nous vous remercions d’avoir porté votre choix sur ce produit SHARP. Pour en tirer le meilleur parti, veuillez lire ce mode d’emploi très attentivement. MUSIC SYSTEM FOR iPod® & iPhone® SYSTÈME MUSICAL POUR iPod et iPhone MEMORY MODEL MODÈLE DK-CL3P ENGLISH FRANÇAIS Please refer to pages E-1 to E-21.
ENGLISH DK-CL3P ENGLISH SPECIAL NOTES Important Instruction CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. E-1 WARNING : TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
IMPORTANT SAFETY INSTRUCTIONS DK-CL3P 12) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over. 13) Unplug this apparatus during lightning storms or when unused for long periods of time. 14) Refer all servicing to qualified service personnel.
DK-CL3P IMPORTANT SAFETY INSTRUCTIONS (continued) ENGLISH Important Instruction 18) Damage Requiring Service - Unplug this product from the wall outlet and refer servicing to qualified service personnel under the following conditions: a) When the AC cord or plug is damaged, b) If liquid has been spilled, or objects have fallen into the product, c) If the product has been exposed to rain or water, d) If the product does not operate normally by following the operating instructions.
SPECIAL NOTES Contents DK-CL3P ENGLISH Page Program Information Products that have earned the ENERGY STAR® are designed to protect the environment through superior energy efficiency. ENERGY STAR® is a U.S. registered mark. ■ General Information Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Controls and indicators . . . . . . . . . . . . . . . . . . 6 - 7 ■ Preparation for Use System connections . . . . . . . . . . . . . . . . . . . .
DK-CL3P ENGLISH Precautions ■ General ● Hold the AC/DC adaptor by the ● Please ensure that the equipment is positioned in a well-ventilated area and ensure that there is at least 4" (10 cm) of free space along the sides, top and back of the equipment. 4" (10 cm) 4" (10 cm) General Information ● Use the unit on a firm, level surface head when removing it from the AC outlet, as pulling the cord can damage internal wires.
Controls and indicators DK-CL3P ENGLISH ■ Top panel 1. 2. 3. 4. 5. 6. 7. Reference page iPod and iPhone Dock . . . . . . . . . . . . . . . . . . . . . . . 13 DISPLAY (TV OUT)/ALARM Button . . . . . . . . . . . 8, 14 ON/STAND-BY/Alarm Reset/ FUNCTION Button . . . . . . . . . . . . 8, 10, 13, 14, 15, 18 Snooze/Dimmer Button . . . . . . . . . . . . . . . . . . . . . . 10 Previous/Next/Tuning Up/Down Button . . . 11, 14, 15 Volume Up/Down Button . . . . . . . . . . . . . . . . . . . . .
DK-CL3P Controls and indicators (continued) ENGLISH General Information OPEN 1 ■ Bottom view Reference page 1. Battery Compartment . . . . . . . . . . . . . . . . . . . . . . . . 9 1 2 3 4 ■ Rear panel 1. 2. 3. 4. Reference page AUDIO IN Jack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 FM Antenna Wire (fixed). . . . . . . . . . . . . . . . . . . . . . 15 Video Out Jack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 DC Input Jack . . . . . . . . . . . . . . . . .
System connection DK-CL3P ■ Connecting iPod or iPhone to TV Video files from iPod or iPhone can be viewed by connecting the system to TV/ monitor. If the TV/monitor has a video input, connect it to the VIDEO OUT jack at the back of the unit and set the TV Out on the iPod or iPhone unit to “ON” position. VIDEO OUT Video cable (not supplied) TV ● Please make sure to set iPod unit to either NTSC or PAL to ■ AC/DC adaptor connection 1 Plug the AC/DC adaptor cable into the DC IN jack on the unit.
DK-CL3P ENGLISH System connections (continued) ■ Install/Replace backup batteries Use 4 “AA” size batteries (UM/SUM-3, R6, HP-7 or similar). Batteries are not included. Note: Battery life may vary depending on the temperature, battery types and usage conditions. Open the battery cover. ● Installing the batteries incorrectly may cause the unit to 2 Insert the batteries according to the direction indicated in the battery compartment.
General control DK-CL3P ■ Display brightness control (DIMMER) ENGLISH MEMORY Dimmer 1 (Display is dim) Dimmer 2 (Display gets dimmer) Dimmer off (Display is bright) Notes: ● Setting dimmer to display in the brightest mode during battery operation will affect battery life. ● During battery operation in standby mode, the brightness of the display will automatically go to the lowest mode (dim OFF) after 5 seconds.
DK-CL3P Setting the time and date ENGLISH 2 Press the or button to adjust the hour and then press the CLOCK button. MON Press the or button once to advance the time by 1 hour. Hold it down to advance continuously. “AM” or “PM” indicator will interchange after each 12 hour cyclic in 12-H clock format. Basic Operation 3 Press the or button to adjust the minutes and then press the CLOCK button. MON MEMORY Press the or button once to advance the time by 1 minute.
Listening to the iPod and iPhone Caution: ● Please update your iPod and iPhone unit to the latest software version before using it. Please visit Apple’s homepage to download the latest version for your iPod and iPhone. Notes: ● Once the iPod or iPhone is connected to the unit it will begin charging. ● If you have an iPod or iPhone that does not have an iPod 30 Pin connector, you can use an auxillary cable to connect it to the AUDIO IN jack.
DK-CL3P ENGLISH Listening to the iPod and iPhone (continued) ■ To insert iPod or iPhone adaptor 1. Insert the iPod or iPhone adaptor into unit and connect your iPod or iPhone. iPhone (bottom) ■ iPod or iPhone playback 1 2 Press the ON/STAND-BY button to turn the power on. 3 Insert iPod or iPhone unit in the dock of main unit. iPhone iPhone Dock connector iPod and iPhone Press the FUNCTION button on main unit to select the iPod function.
Listening to the radio DK-CL3P ENGLISH ■ Various iPod or iPhone functions Function Play Main unit Operation Press in the pause mode. MEMORY Press in the playback mode. MEMORY Track up/ down Fast forward/ reverse TV OUT Press in the playback or pause mode. If you press the button in the pause mode, press the / button to start the desired track. Press and hold down in the playback mode. Release the button to resume playback.
DK-CL3P Listening to the radio (continued) ENGLISH 3 Tune to the desired station. Manual tuning: Press the TUNING ( or ) button as many times as required to tune in to the desired station. Auto tuning: When the TUNING ( or ) button is pressed for more than 0.5 seconds, scanning will start automatically and the tuner will stop at the first receivable broadcast station. Notes: ● After 5 seconds the tuner frequency will change to time display. To preview the tuner frequency, press DISPLAY(TV OUT) button.
Alarm operation DK-CL3P ENGLISH The unit turns on and play desired source (iPod, iPhone or TUNER) or Buzzer sound for 1 hour alarm cycle. Before setting the alarm: 1 Check that the clock is set to the correct time. (refer page 11) If it is not set, you cannot use the alarm function. 2 For iPod playback: Insert iPod or iPhone to the unit. (refer page 13) 3 For TUNER: Set preset memory. (refer page 15) 3 Press the or button to adjust the minutes and then press the ALARM button.
DK-CL3P Alarm operation (continued) Enhancing your system Note: If wake up source is set to iPod, and iPod is not present, the alarm source will change to default Buzzer. The auxiliary cable is not included. Purchase a separate auxiliary cable as shown below. ENGLISH Advanced Features ■ Activate and deactivate the alarm 1 During standby mode, press ALARM button to deactivate current alarm times and wake up source. 2 Press ALARM button again to reactivate the last alarm function.
Troubleshooting chart 1 Use the auxiliary cable to connect the portable audio player, computer etc. to the AUDIO IN jack. When using video equipment, connect the audio output to this unit and the video output to a television. 2 3 4 Press the ON/STAND-BY button to turn the power on. Press the FUNCTION button to select AUX function. Play the connected equipment.
DK-CL3P Troubleshooting chart (continued) ENGLISH ■ iPod and iPhone ■ Condensation Symptom ● No sound is produced. Possible cause ● The iPod or iPhone unit No image appears on the TV/monitor. ● ● References ● ● ● ● iPod or iPhone will not charge. software version is not update to the latest version. Please visit Apple’s homepage. The iPod or iPhone is not playing. The iPod or iPhone is not properly connected to the unit.
Maintenance ■ Cleaning the unit Periodically wipe the unit with a clean soft cloth. DK-CL3P ENGLISH Caution: ● Do not use chemicals for cleaning (gasoline, paint thinner, etc.). It may damage the unit finishing. ● Do not apply oil to the inside of the unit. It may cause malfunctions. Specifications ■ General Power source DC IN 5.9V 2A: AC/DC adaptor (AC 100 - 240 V ~ 50/60 Hz) 6V (UM-3/SUM-3, R6/AA) x 4 Power consumption 11 W Output power Front speakers: 0.
CONSUMER LIMITED WARRANTY SHARP ELECTRONICS CORPORATION warrants to the first consumer purchaser that this Sharp brand product (the “Product”), when ship in its original container, will be free from defective workmanship and materials, and agrees that it will, at its option, either repair the defect or replace the defective Product or part thereof with a new or remanufactured equivalent at no charge to the purchaser for parts or labor for the period(s) set forth below.
VALID IN CANADA ONLY LIMITED WARRANTY Consumer Electronics Products Congratulations on your purchase! Sharp Electronics of Canada Ltd. (hereinafter called “Sharp”) gives the following express warranty to the first consumer purchaser for this Sharp brand product, when shipped in its original container and sold or distributed in Canada by Sharp or by an Authorised Sharp Dealer: Sharp warrants that this product is free, under normal use and maintenance, from any defects in material and workmanship.
