CX68N5_FC_EN FLE (Malaysia) Sdn. Bhd. COLOUR TELEVISION MODEL CX68N5 OPERATION MANUAL ON TIMER POWER SAVE Please read this operation manual carefully before using the colour television.
CX68N5_01-05_EN FLE (Malaysia) Sdn. Bhd. Contents Preparation Accessories ................................................................................ 2 Easy setup .................................................................................. 3 Safety precautions ...................................................................... 4 Part names ................................................................................. 5 Installing batteries in the remote control unit ......................
FLE (Malaysia) Sdn. Bhd. ENGLISH CX68N5_01-05_EN Dear SHARP Customer Thank you for buying SHARP's Colour Television. We hope you will have many years of enjoyment from this television set. To ensure proper operation, please read this manual carefully, and keep it in a safe place for future reference. Accessories The following accessories are included with this television.
CX68N5_01-05_EN FLE (Malaysia) Sdn. Bhd. Easy setup To use your TV set, perform the easy setup procedure below. The mark indicates the page numbers with more detailed information. Connect the antenna. • See 25 to connect the antenna. Connect any video equipment. • See 25 , 26 to connect video equipment. • See the operation manual of your video equipment when connecting to the TV set. Insert the batteries into the remote control. • Use the two batteries included with the TV. • See 5 .
CX68N5_01-05_EN FLE (Malaysia) Sdn. Bhd. Damage ENGLISH Safety precautions Water Turn off the power and unplug the power cord from the wall outlet immediately if the TV set begins to make any unusual noises or gives off smoke or an unusual smell. Then call your dealer for service. To prevent fire or electrical shock, do not place the TV set near a bath, swimming pool or other area where it may become wet.
CX68N5_01-05_EN FLE (Malaysia) Sdn. Bhd. Part names The mark indicates the page numbers with more detailed information. Infrared transmitter window Aim this window at the infrared sensor window on your TV set. Remote control 10 7 Turns the TV on or to Standby mode. TV/VIDEO 10 Returns to previously viewed channel. / 7 1 2 3 4 5 6 7 8 9 7 Switches between one- or two-digit mode channel selection. CH 9 AV MODE 11 AV MODE NORMAL 9 CH / CH Selects the channel. Used for MENU setup.
FLE (Malaysia) Sdn. Bhd. ENGLISH CX68N5_06-10_EN TV set TV front POWER ON TIMER SAVE ON TIMER POWER SAVE 7 Power switch Turns on and off the main power. Power indicator 7 Power can be turned on by the remote control when the indicator is red. On timer indicator 22 Power save indicator 19 5 Infrared sensor window Receives the infrared wave from the remote control.
CX68N5_06-10_EN FLE (Malaysia) Sdn. Bhd. Watching TV Watching a TV programme Simple operations for watching a TV programme TV Set ON TIMER POWER SAVE 1 • When the power indicator is off, press . • When the power indicator is red, press on the remote control. The power indicator changes to green and a picture appears. Power indicator 2 Behind the door PRESET /MENU CH 4 5 6 7 8 9 / CH With the number buttons (on remote control) 5 • To select a one-digit channel, such as 5, press .
FLE (Malaysia) Sdn. Bhd. ENGLISH CX68N5_06-10_EN Operating the TV buttons Simple operation of the TV set Behind the door PRESET /MENU Using / Press to increase volume. Press to decrease volume. CH VOLUME 15 CH CH Behind the door Using CH / CH 5 Press CH number. to increase channel Press CH number. to decrease channel PAL Using headphone Insert headphone plug into headphone jack to listen to audio with headphone.
CX68N5_06-10_EN FLE (Malaysia) Sdn. Bhd. Useful features Channel/Timer display Displays the current channel number, the timer, and other settings on the screen. 1 TV/VIDEO 1 2 3 4 5 6 7 8 9 Press . • The time remaining on the Off timer, On timer, and Reminder appears on the screen. • When no Timer is set, the channel number and colour system appear on the screen. Press again to clear these current settings display on the screen.
FLE (Malaysia) Sdn. Bhd. ENGLISH CX68N5_06-10_EN Channel recall Switches back to the channel you were watching just before the current channel. Press TV/VIDEO TV/VIDEO 1 2 3 4 5 6 7 8 9 5 • The channel previously viewed returns to the screen. PAL Example: PAL 7 After switching from channel 5 to channel 7, 0 . 5 is pressed, the channel will PAL change to channel 5. Press CH 7 again to return to channel 7.
C X 6 8 N 5 _ 11 - 1 5 _ E N FLE (Malaysia) Sdn. Bhd. Selecting menu items This TV set allows you to adjust the picture and sound, and set the channels and other features using the On-screen display with the remote control or from the TV set. Select the desired menu item by following the steps below and then refer to the indicated page for details. Selecting a menu item Remote control 0 CH CH CH CH 1 MENU MENU Press MENU / PRESET/MENU to call MENU screen.
C X 6 8 N 5 _ 11 - 1 5 _ E N FLE (Malaysia) Sdn. Bhd. ENGLISH Settings and adjustments On-screen display language selection The on-screen display language can be set to English, Chinese, French, Russian, Malay or Arabic. Behind the door TV set ENGLISH FRANCAIS 1 PRESET /MENU CH CH PRESET/MENU 2 CH Press PRESET/MENU for more than two seconds. Press CH / CH select desired language. BAHASA MELAYU to • Pressing PRESET/MENU changes the screen as shown below.
C X 6 8 N 5 _ 11 - 1 5 _ E N FLE (Malaysia) Sdn. Bhd. Settings and adjustments Manual channel tuning Enables manual channel tuning to a desired TV station. (e.g. tuning the TV to a VCR, tuning in an additional TV station.) NOTE: This TV is already tuned into 2, 7, 9, 10 and 28. 1 TV/VIDEO 1 2 3 4 5 6 7 8 9 Press PRESET/MENU for more than two seconds. The language select mode appears. ENGLISH Press PRESET/MENU twice to display MANUAL mode screen. MANUAL(B/G) VHF 1 48.
FLE (Malaysia) Sdn. Bhd. ENGLISH C X 6 8 N 5 _ 11 - 1 5 _ E N Auto channel tuning Automatically tunes in and presets receivable TV stations, using consecutive channels numbers (e.g. 2, 7, 9, 10 will be stored as 1, 2, 3, 4). Behind the door PRESET /MENU 1 Press PRESET/MENU for more than two seconds. The language select mode appears. ENGLISH FRANCAIS BAHASA MELAYU CH PRESET/MENU 2 Press PRESET/MENU again to display AUTO mode screen. AUTO(B/G) VHF 1 48.
C X 6 8 N 5 _ 11 - 1 5 _ E N FLE (Malaysia) Sdn. Bhd. Settings and adjustments Channel setting Enables individual channel setting. 1 TV/VIDEO 1 2 3 4 5 6 7 8 9 2 0 CH CH CH 3 CH MENU 4 AV MODE NORMAL POWER SAVE MENU 5 TV Press screen. MENU to call MENU Press CH / CH select “CH-SETTING”. to Press / to display CH-SETTING menu. Press CH / CH select desired setting.
FLE (Malaysia) Sdn. Bhd. ENGLISH CX68N5_16-22_EN Picture adjustment 1 TV/VIDEO 1 2 3 4 5 6 7 8 9 2 CH Press screen. MENU MENU to call MENU Press CH / select “PICTURE”. PICTURE SOUND FEATURE TIMER CH-SETTING to CH CH 0 3 CH Press / display PICTURE menu. to Press CH / CH select adjustment items.
CX68N5_16-22_EN FLE (Malaysia) Sdn. Bhd. Settings and adjustments Sound adjustment 1 TV/VIDEO 1 2 3 4 5 6 7 8 9 2 CH Press screen. MENU MENU to call MENU Press CH / select “SOUND”. CH to Press / display SOUND menu. to Press CH / CH select adjustment items. to PICTURE SOUND FEATURE TIMER CH-SETTING CH 0 3 CH CH MENU MENU 4 AV MODE NORMAL SOUND SURROUND TREBLE BASS BALANCE (STANDARD) ON + 10 - 20 20 NORMAL POWER SAVE 5 Adjust using / (STANDARD) .
FLE (Malaysia) Sdn. Bhd. ENGLISH CX68N5_16-22_EN Blue screen Automatically turns the screen blue if a broadcast signal is not received. 1 TV/VIDEO 1 2 3 4 5 6 7 8 9 2 Press screen. MENU to call MENU Press CH / CH select “FEATURE ”. to MENU PICTURE SOUND FEATURE TIMER CH-SETTING CH 0 SELECT ENTER MENU RETURN CH CH CH CH 3 MENU AV MODE NORMAL MENU POWER SAVE 4 5 TV 6 Press / display FEATURE menu. to Press CH / CH select “BLUE BACK”. to Press / select “ON” or “OFF”.
CX68N5_16-22_EN FLE (Malaysia) Sdn. Bhd. Settings and adjustments Save This function reduces the picture brightness to create a softer image while saving electricity. Using Menu TV/VIDEO 1 2 3 4 5 6 7 8 9 1 2 0 CH Press screen. MENU to call MENU Press CH / select “FEATURE”. CH to CH MENU PICTURE SOUND FEATURE TIMER CH-SETTING CH CH CH SELECT ENTER MENU RETURN MENU AV MODE NORMAL MENU POWER SAVE POWER SAVE 3 4 TV 5 Press / display FEATURE menu.
FLE (Malaysia) Sdn. Bhd. ENGLISH CX68N5_16-22_EN VM (Velocity Modulation) This function emphasizes the picture outline. 1 TV/VIDEO 1 2 3 4 5 6 7 8 9 2 Press screen. MENU to call MENU Press CH / select “FEATURE”. CH to MENU PICTURE SOUND FEATURE TIMER CH-SETTING CH 0 SELECT ENTER MENU RETURN CH CH CH CH 3 MENU AV MODE NORMAL MENU POWER SAVE 4 5 TV 6 Press / display FEATURE menu. to Press CH select “VM”. CH to Press / select “ON” or “OFF”.
CX68N5_16-22_EN FLE (Malaysia) Sdn. Bhd. Settings and adjustments Off timer Automatically turns power off after a set length of time has passed. 1 TV/VIDEO 1 2 3 4 5 6 7 8 9 2 0 CH CH 3 CH CH 4 MENU AV MODE NORMAL Press screen. MENU to call MENU Press CH / select “TIMER”. CH to Press / display TIMER menu. to Press CH select “OFF to / CH PICTURE SOUND FEATURE TIMER CH-SETTING TIMER --:---:-- OFF ON POSITION VOLUME --:-- ”.
FLE (Malaysia) Sdn. Bhd. ENGLISH CX68N5_16-22_EN On timer Automatically turns power on after a set length of time has passed. 1 TV/VIDEO 1 2 3 4 5 6 7 8 9 2 Press screen. MENU to call MENU Press CH / select “TIMER”. CH to MENU PICTURE SOUND FEATURE TIMER CH-SETTING CH 0 CH CH 3 CH 4 MENU AV MODE NORMAL POWER SAVE MENU NORMAL 5 Press / display TIMER menu. to Press CH select “ON to / CH 6 7 8 9 TV Set Press / set time for TV to turn on.
CX68N5_23-26_EN FLE (Malaysia) Sdn. Bhd. Settings and adjustments Reminder on-screen timer Lets you know when a preset length of time has passed by displaying a countdown timer on the screen. This is useful for timer cooking while you watch TV. 1 TV/VIDEO 1 2 3 4 5 6 7 8 9 2 0 CH CH CH 3 CH MENU 4 AV MODE NORMAL Press screen. MENU to call MENU Press CH / select “TIMER”. CH to Press / display TIMER menu. to Press CH select “ ”.
CX68N5_23-26_EN FLE (Malaysia) Sdn. Bhd. ENGLISH Connections Connecting to a DVD player The DVD input terminals (COMPONENT-IN) on the rear of the TV can be used to input high-quality images from a DVD player.
CX68N5_23-26_EN FLE (Malaysia) Sdn. Bhd. Connecting to an antenna To enjoy a clearer picture, use an outdoor antenna. The following is a brief explanation of the types of connections that are used for coaxial and feeder cables. If your outdoor antenna uses a 75-ohm coaxial cable with a standard DIN45325 plug (IEC 169-2), plug it into the antenna jack at the rear of the set.
FLE (Malaysia) Sdn. Bhd. ENGLISH CX68N5_23-26_EN Connections Connecting to video equipment Enjoy playback from a video disc player, VCR or other video equipment by connecting them to this TV set using the Audio/Video in terminals.
CX68N5_27-30_EN FLE (Malaysia) Sdn. Bhd. Troubleshooting No picture or sound Picture OK, sound poor. Sound OK, picture poor. Picture blurred. Picture ghosting Picture lines or streaks Picture weak. Poor reception on some channels No colour Picture rolls vertically. Picture distorted. Bars on screen Possible Causes/Remedies Remote control does not work. Quick Service Check List Problems The following problems do not always indicate a hardware failure.
CX68N5_27-30_EN FLE (Malaysia) Sdn. Bhd. MODEL ENGLISH Specifications CX68N5 Receiving System TV Broadcasts/ VCR Playback VCR Playback (Using Video-in terminals) Laserdisc Player Playback (Using RF-in terminals) VCR Playback (Using S-Video terminal) Special VCR and VDP Playback Reception Channels PAL-B/G VHF UHF CATV Receiving Frequency Channel Tuning Picture Tube Terminals Sound Output Power Source Power Consumption Dimensions Weight PAL-B/G PAL 60 Hz NTSC 3.58 MHz NTSC 4.43 MHz PAL 5.
CX68N5_27-30_EN FLE (Malaysia) Sdn. Bhd.
CX68N5_27-30_EN FLE (Malaysia) Sdn. Bhd.
CX68N5_BC_EN FLE (Malaysia) Sdn. Bhd. WARRANTY Consumer Electronic Products Congratulations on Your Purchase! This Sharp product is warranted against faults in materials and manufacture for a period of twelve (12)* months from the date of original purchase. If service is required during the warranty period, please contact your nearest Sharp Approved Service Centre. These repairs would be carried out at no charge to the owner, subject to the conditions specified herein.
