R ESPAÑOL PURIFICATEUR D’AIR MANUEL D’UTILISATION FRANÇAIS AIR PURIFIER OPERATION MANUAL ENGLISH FP-P40CX This product earned the ENERGY STAR by meeting strict energy efficiency guidelines set by the US EPA. US EPA does not endorse any manufacturer claims of healthier indoor air from the use of this product. The energy efficiency of this ENERGY STAR qualified model is measured based on a ratio between the model’s CADR for Dust and the electrical energy it consumes, or CADR/Watt.
Please read before operating your new Air Purifier The air purifier draws in room air from its air intake, lets the air pass through a Active Carbon Filter (deodorization filter) and a True HEPA Filter (dust collection filter) inside of the unit, then discharges the air from its air outlet. The air purifier unit repeats this process by moving its internal fan. As air passes through, a new True HEPA Filter can remove 99.97% of dust particles, of as small as 0.3 microns.
ENGLISH • Clean Mode Approximately the same numbers of positive and negative ions are discharged. • Ion Control Mode Plenty of negative ions exist in natural surroundings such as waterfalls or forests. In this mode, negative ions will be released at an increased rate. • AUTO Plasmacluster Ion Mode FOR CUSTOMER ASSISTANCE(U.S) .... E-2 CONSUMER LIMITED WARRANTY(U.S) E-3 FOR CUSTOMER ASSISTANCE(CANADA) ... E-4 LIMITED WARRANTY(CANADA) ........ E-5 IMPORTANT SAFETY INSTRUCTIONS .... E-6 • WARNING ........
FOR CUSTOMER ASSISTANCE (the United States) To aid in answering questions if you call for service or for reporting loss or theft, please use the space below to record the model and serial number located on the back side of the unit.
CONSUMER LIMITED WARRANTY CONSUMER LIMITED WARRANTY FOR U.S.
FOR CUSTOMER ASSISTANCE (Canada) To aid in answering questions if you call for service or for reporting loss or theft, please use the space below to record the model and serial number located on the back side of the unit.
R LIMITED WARRANTY (VALID IN CANADA ONLY) Consumer Electronics Products Congratulations on your purchase! Sharp Electronics of Canada Ltd.
IMPORTANT SAFETY INSTRUCTIONS When using electrical appliances, basic safety precautions should be followed, including the following: WARNING - To reduce the risk of electrical shock, fire or injury to persons: • Read all instructions before using the air purifier. • Use only a 120-volt outlet with a polarized receptacle. • The air purifier has a polarized plug (one blade is wider than the other is). This plug will fit in a polarized outlet only one way.
IMPORTANT SAFETY INSTRUCTIONS • Do not block the intake and air outlet. • Do not use the unit near or on hot objects, such as range or where it may come into contact with steam. • Do not use the unit on its side. • Always hold the handle on the back of the unit when moving it. Holding the front panel when carrying may cause it to detach, thus dropping the unit and resulting in bodily injury. • Do not operate the unit without the filter. • Do not wash and reuse HEPA filter .
PART NAMES MAIN UNIT DISPLAY Odor Sensor OFF Timer Display Indicator Lights AUTO Operation Indicator Light CLEAN FILTER Indicator Light QUICK CLEAN operation Indicator Light POLLEN Mode Indicator Light Remote Control Receiver Plasmacluster Fan Speed Indicator Lights Indicator Light CLEAN-SIGN Light Odor Sensor POWER ON/OFF Button See Page E-12 MODE Selection Button See Page E-12 Main Unit Filter Frame Band See Page E-11 True HEPA Filter (white) See Page E-10,17 Washable Active Carbon Filter (black) See Pa
PREPARATION INSERTING BATTERIES IN THE REMOTE CONTROL uster Light the back cover 1 Remove Press and slide the back cover to remove. as 3 Close the back cover Battery Information • The battery life is about 1 year. • The batteries for this remote control are for initial use only . Change the batteries when necessary. • Incorrect usage of the batteries may cause battery fluid leakage and/or damage.
PREPARATION Be sure to remove the power plug from the wall outlet. FILTER INSTALLATION To maintain the quality of the filters, they are installed in the main unit within plastic bags. Be sure to remove the filters from the plastic bags before using the unit. 1 Remove the filters 1 Remove the Front Panel. Pull the bottom of the Front Panel. Front Panel out the Filter Frame and remove 2 Pull the Pre-Filter, Active Carbon Filter and True HEPA Filter.
2 1 True HEPA Filter Install the filters Place the True HEPA Filter within the Filter Frame. Please make sure that the True HEPA Filter is placed in proper orientation. Filter Frame ENGLISH Do not install the filter backwards or the unit will not operate properly. Band Active Carbon Filter True HEPA Filter Filter Frame the Pre-filter through 3 Place the bands (2 places) located in the corners of the Tabs (4 places) ESPAÑOL Band Active Carbon Filter.
OPERATION Main Unit Controls MAIN UNIT OPERATION Plasmacluster Indicator Light CLEAN Filter Indicator Light CLEAN-SIGN Light • • • • • • AUTO QUICK CLEAN POLLEN SILENT MEDIUM MAX MODE Selection Button Power ON/OFF Button 1 Power ON/OFF Button • Used to start operation (short beep) and stop operation (long beep) • Plasmacluster Indicator Light and Fan Speed Indicator Light turn on/off. • Unless the power cord is unplugged, the operation starts in the previous mode the unit was operated in.
DETERMINING THE BASE IMPURITY RATE For the first 30 seconds after the power plug is inserted into the wall outlet, the unit will check the conditions of the air. If operation is set to ON during this time, the CLEAN-SIGN LIGHT will alternately flash in green, orange and red. PLASMACLUSTER INDICATOR LIGHT Plasmacluster ion operation is selected using the remote control.
OPERATION REMOTE CONTROL OPERATION POWER ON/OFF Button • When you press the POWER ON/OFF Button, a short beep will sound and operation will start in AUTO Mode. • Unless the power cord has been unplugged, the operation starts in the previous mode the unit was operated in. • To stop, press the POWER ON/OFF Button again. A long beep will sound and operation will stop.
CARE AND MAINTENANCE To maintain optimum performance of this air purifier, please clean the unit including the sensor and filters periodically. When cleaning the unit, be sure to unplug the power cord, and never handle the plug with wet hands. Electrical shock and/or bodily injury may occur as a result. Odor Sensor Main Unit True HEPA Filter Do not wash the True HEPA Filter. Washing will not improve filter performance, and it may even cause electric shock or malfunction.
CARE AND MAINTENANCE WASHABLE ACTIVE CARBON FILTER CARE 5 HAND WASH ONLY! DO NOT TUMBLE DRY! Dry the filter outdoors if possible in a well ventilated area. Care Cycle When the CLEAN FILTER Indicator Light lights up, this indicates that the filter needs to be cleaned. If the unit is kept on 24 hours a day then the Filter Indicator Light will activate in about 2 months. The CLEAN FILTER Indicator Light is for reference. Clean the filter as often as necessary when odor persists.
FILTER REPLACEMENT GUIDELINES The replacement period differs depending on the room environment, the usage hours and location of Air Purifier. If dust or odors persists, replace the filters. (Refer to “Please read before operating your new Air Purifier”) Guide for filter replacement timing • Filter life can be greatly reduced in poor environments. The presence of cigarette smoke, pet dander and other concentrations of airborne particles will cause filters to become clogged in less time.
TROUBLESHOOTING Before calling for repair, please review the list below, since the problem may not be a unit malfunction. SYMPTOM REMEDY (not a malfunction) The Remote Control does not work • Have the batteries been depleted? • Are the batteries inserted correctly? • Is a fluorescent light in the room flickering due to service life? Odors and smoke are not removed • Clean or replace the filters if they appear to be heavily soiled.
SPECIFICATIONS 120V / 60Hz SILENT MED 3.5 W 7.5 W 17 (0.5) 70 (2.0) 2 253 sq.ft.* (23.5m ) 157 / 163 / 156 8.3 ft (2.5m) 16-3/8 in.(W)x7-7/8 in.(D)x22-7/16 in(H) 415mm(W)x200mm(D)x570mm(H) MAX 50 W 177 (5.0) 14.8 lbs (6.7kg) Weight * The applicable floor surface area is appropriate for operating the unit at maximum fan speed. Standby Power ESPAÑOL In order to operate the electrical circuits while the power plug is inserted in the wall outlet, this product consumes about 0.3W of standby power.
R R SHARP ELECTRONICS CORPORATION SHARP ELECTRONICS OF CANADA LTD. Sharp Plaza, Mahwah, New Jersey 07430-2135 U.S.A.
