For inquiries, call: Contents Customer Service Center For general information and charges From fixed-line phones: (toll free) From au cell phones: Safety Precautions area code not required TAPPING DIAL AND ZERO WILL CONNECT YOU TO AN OPERATOR Basic Manual AFTER CALLING 157 ON YOUR au CELLPHONE.
is16sh_e.book ii ページ 2012年6月1日 金曜日 午後8時47分 Preface Thank you for buying the “AQUOS PHONE SERIE ISW16SH” (simply called the “ISW16SH” or the “product” from here on). Before using the product, be sure to read the “Basic Manual” (this PDF manual) on the au homepage to ensure correct use. After you have finished reading this PDF manual, be sure to store it and the printed manuals (Accessories) in safe places so that you can retrieve them whenever you need them.
is16sh_e.book 1 ページ 2012年6月1日 金曜日 午後8時47分 When Using the Product • Communication is not possible even inside the service area in places where the signal does not reach (e.g. tunnels and basements). Also, communication may not be possible in poor reception areas. Communication may be interrupted if you move into poor reception areas during a communication.
is16sh_e.book 2 ページ 2012年6月1日 金曜日 午後8時47分 List of Packaged Items Before you start using the product, make sure that you have all the following packaged items with the product. Warranty (Japanese) Battery pack (SHI16UAA) Using au Disaster Countermeasure Application au Disaster Countermeasure is an application in which you can use Disaster Message Board, Early warning mail (earthquake early warnings, disaster/evacuation information and tsunami warnings) and Disaster Voice Delivery Service.
is16sh_e.book 3 ページ 2012年6月1日 金曜日 午後8時47分 A From the au disaster countermeasure menu, [災害用 伝言板] (Disaster Message Board). 設定 (Settings) Follow the on-screen instructions for registration/confirmation. memo ◎ To register the safety information, an e-mail address (~ezweb.ne.jp) is required. Set the mail address in advance. ◎ It is unavailable while connecting via Wi-Fi®. ◎ The Company does not guarantee the quality of this service.
is16sh_e.book 4 ページ 2012年6月1日 金曜日 午後8時47分 ◎ Information intended for the areas of other than your present location may be received. ◎ As for this service, the Company shall not be liable for any damage incurred on the users resulted from failure or delay of information delivery due to communication disturbance or system failure, contents of the information or other problems that are not supposed to be blamed on the Company.
is16sh_e.book 5 ページ 2012年6月1日 Contents Safety Precautions Illustrations and Descriptions in This Manual ... 7 Exemptions ........................................................... 8 Safety Precautions (Observe Strictly) ................ 8 Handling Precautions......................................... 17 Available Security Codes................................... 21 Security Codes ..................................................... 21 Functions to Protect Your Privacy.........................
is16sh_e.book 6 ページ 2012年6月1日 Contents Mobile Update (Software Update) ........................64 Major Update (OS Update) ...................................66 After-Sales Service .............................................66 Available Data Formats ......................................68 Main Specifications.............................................69 Specific Absorption Rate (SAR) of Cell Phones ..............................................................................
is16sh_e_02.fm 7 ページ 2012年6月4日 月曜日 午後3時31分 Illustrations and Descriptions in This Manual ■ Note on Key Illustrations In this manual, the key illustrations are simplified as shown below. ■ Notes on Illustrations/Screenshots The screenshots in this manual are simplified and may look different from the actual screens. Also, part of the screen may be abbreviated. Actual screen In this manual In this manual, part of the screen such as icons are abbreviated.
is16sh_e.book 8 ページ 2012年6月1日 金曜日 午後8時47分 Exemptions Safety Precautions • The Company is not liable for any damages arising from earthquakes, lightning, storms, floods or other natural disasters, as well as fires, actions by third parties, other accidents, intentional or mistaken operation by the customer, or use under other unusual conditions outside the responsibility of the Company.
is16sh_e.book Wet hands prohibited Disassembly prohibited 2012年6月1日 金曜日 午後8時47分 Indicates that handling with wet hands is not allowed. Indicates that disassembly is not allowed. Do not put the product in a cooking apparatus such as microwave oven or a pressure vessel. Doing so might cause leakage of liquid, ignition, rupture, fault, fire or injury. Indicates that use in a place where the product is likely to get wet or allowing the product to get wet is not allowed.
is16sh_e.book 10 ページ 2012年6月1日 金曜日 午後8時47分 Do not use outside when you can hear thunder. Doing so might risk lightning strikes and electric shock. Do not let your hands, fingers and other parts of the body touch the external connection jack or earphone/microphone jack. Doing so might cause electric shock, injury or a fault.
is16sh_e.book 11 ページ 2012年6月1日 金曜日 午後8時47分 When inserting an earphone, etc. into the product, adjust the volume to the proper level. Setting too loud a volume or using the earphone Instruction continuously for a long period of time might adversely affect your ears. Also, raising the volume too high might prevent you from hearing sounds around you, which might in turn lead to a traffic accident at a railroad crossing or pedestrian crossing. When adjusting the volume with an earphone, etc.
is16sh_e.book 12 ページ 2012年6月1日 金曜日 午後8時47分 Do not send data by infrared communication with the infrared port pointing toward eyes. Doing so might affect eyes. Also, sending data with the infrared port pointing toward some other infrared device might cause false operation, etc. Safety Precautions Do not point the illuminated light directly at someone’s eyes. Be especially careful not to shoot small children from a very close distance. Do not use Mobile light near people’s faces.
is16sh_e.book 13 ページ 2012年6月1日 金曜日 午後8時47分 The materials of parts used on the desktop holder are as follows. Part Outer case (front/rear) Switching knob Contact lever Contact terminal Connection jack (microUSB) Screw Carbon steels for cold heading Polyurethane resin POM resin Surface treatment None None None Gold plating Tin plating Trivalent chromate None None Do not bring the product close to magnetized objects such as cash cards, floppy disks, credit cards, and prepaid cards.
is16sh_e.book 14 ページ 2012年6月1日 DANGER 金曜日 午後8時47分 Be sure to read the following hazards before use. Do not short-circuit the contact terminal of the battery pack. Safety Precautions Do not fail to connect the battery pack to the product in the correct orientation. Connecting in an incorrect orientation might cause rupture, fire or overheating. Do not try to forcibly connect the battery pack, instead thoroughly check the contact terminal before connection.
is16sh_e.book 15 ページ 2012年6月1日 金曜日 午後8時47分 If the fuse in the common DC adapter 01/03 (sold separately) blows, replace it with a fuse of the specified type (250 V, 1 A). Replacing Instruction with a different type of fuse might cause overheating or ignition. (For information about fuse replacement, carefully read the manual for the common DC adapter 01/03 (sold separately).) Do not damage, modify, twist, pull or place a heavy object on the cable of the specified charger (sold separately).
is16sh_e.book 16 ページ 2012年6月1日 金曜日 午後8時47分 Do not leave the specified charger (sold separately) connected to the main unit with the battery pack removed. Doing so might cause ignition or electric shock. Do not touch the IC (metal) part of the micro au IC-Card or short-circuit it. Doing so might cause loss of data or a fault. When you use the desktop holder to charge, do not connect it to the external connection jack of the main unit.
is16sh_e.book 17 ページ 2012年6月1日 金曜日 午後8時47分 Handling Precautions These precautions are provided to ensure that performance can be fully demonstrated. Thoroughly read these precautions to ensure correct use. ■ Precautions common to the main unit, battery pack, charger, micro au IC-Card, peripheral devices ● To ensure waterproof property (equivalent to IPX5 and IPX7) of the product, use the product with the battery cover and external connection jack cover tightly closed.
is16sh_e.book 18 ページ 2012年6月1日 金曜日 午後8時47分 ● Never use modified au cell phones. Use of a modified device violates the Radio Law. The product has acquired the certification of conformity with technical regulations for the specified radio station based on the Radio Law, and the “Technical Conformity Mark ” is printed on the nameplate of the product as a certificate.
is16sh_e.book 19 ページ 2012年6月1日 金曜日 午後8時47分 ● Attach the battery cover securely. NFC/FeliCa function may not work properly. Also, if you deform the battery cover, forcefully press the inside of the battery cover on which the sheet is pasted or remove the sheet, NFC/FeliCa communications may be hindered. ● Do not cover the light sensor with your finger or put a sticker on it. Doing so may hinder the light sensor from detecting the ambient brightness and functioning correctly.
is16sh_e.book 20 ページ 2012年6月1日 金曜日 午後8時47分 ● Do not wrap the power cord of the specified charger (sold separately) around the power plug or desktop holder. Doing so might cause electric shock, overheating or fire. ● Do not forcibly bend the charger’s plug or the connection between the connector and power cord. Doing so might cause electric shock, overheating or fire. ■ micro au IC-Card Safety Precautions ● The micro au IC-Card is lent to you by au.
is16sh_e.book 21 ページ 2012年6月1日 金曜日 午後8時47分 Available Security Codes Security Codes The product has various security codes that you can use. The available security codes are as follows. Do not forget the various security codes that are set as they are necessary for various operations and contracts.
is16sh_e.book 22 ページ 2012年6月1日 金曜日 午後8時47分 Notes on Waterproof and Dustproof Properties Safety Precautions Before using the product, thoroughly read the contents of “Notes on Waterproof and Dustproof Properties” to ensure correct use. Failure to follow the contents described in these sections may cause intrusion of water, sand or other foreign material, resulting in overheating, ignition, electric shock, injury or fault.
is16sh_e.book 23 ページ 2012年6月1日 金曜日 午後8時47分 ■ Notes on Using the Product is16sh_e_02.fm [23/29] • Do not use the product in heavy rain. • Do not leave the product wet. Doing so may let the liquids freeze on the product in cold places or otherwise cause fault. • Do not drop or otherwise subject the product to strong impact or jab the mouthpiece, earpiece, speaker, etc. with a cotton swab or any sharp object. Doing so may cause scratching, deformation, etc.
is16sh_e.book 24 ページ 2012年6月1日 金曜日 午後8時47分 ■ Maintaining the Waterproof and Dustproof Properties Safety Precautions ■ Rubber seals The rubber seals on the external connection jack cover and battery cover are important to maintain the waterproof property. Be sure to observe the following items. • Do not remove or scratch them. • When closing the external connection jack cover and battery cover, do not get the rubber seals caught.
is16sh_e.book 25 ページ 2012年6月1日 金曜日 午後8時47分 • Never put the product in a microwave oven for drying it. Doing so may cause the battery pack to leak liquid, overheat, rupture or ignite. Also, doing so may cause the product to overheat, emit smoke, ignite or cause destruction of circuit components. • Do not expose the product to hot air from a hair dryer or leave it in a high temperature environment for drying it. Doing so may cause the product to deform, discolor, get out of order, etc.
is16sh_e.book 26 ページ 2012年6月1日 金曜日 午後8時47分 C Wipe off water remaining in the grooves of each section by gently putting the product against a dry and clean cloth etc. • Since water is sometimes left in the grooves of each section, clear them of water by putting a cloth against their openings and gently patting them. Make sure that there is no more water or foreign objects remaining in them. Safety Precautions D Lay out a dry cloth etc.
is16sh_e.book 27 ページ 2012年6月1日 金曜日 午後8時47分 Notes on Using Bluetooth®/Wireless LAN (Wi-Fi®) Functions Frequency Band Bluetooth® and wireless LAN (Wi-Fi®) functions (2.4 GHz band) of the product use frequencies in the 2.4 GHz band ranging from 2.402 GHz to 2.480 GHz. • Bluetooth® function: 2.4FH1 The product uses the 2.4 GHz band. DS-SS and OFDM are used as the modulation schemes. The interference distance is about 40 m or less. Bands of mobile unit identification devices can be avoided.
is16sh_e.book 28 ページ 2012年6月1日 金曜日 午後8時47分 3. If you are unclear on any points or are troubled by anything, contact an au shop or Customer Service Center. Precautions about Wireless LAN (Wi-Fi®) Safety Precautions • The 2.4 GHz band wireless LAN (Wi-Fi®) function of the product conforms to the domestic standards of Japan, FCC standards and EC directives, and has been certified. Use of the 2.4 GHz band wireless LAN (Wi-Fi®) function is restricted in some countries/ regions such as France.
is16sh_e.book 29 ページ 2012年6月1日 金曜日 午後8時47分 memo Notes on Packet Communication Charge Notes on Google Play/au Market/ Applications • Be sure to check the security of the application, then install it at your own risk. Some applications might cause virus infection, damage various data, and send out your location information, usage history or personal information stored in your cell phone via the Internet.
is16sh_e.book 30 ページ 2012年6月1日 金曜日 午後8時47分 Names and Functions of Parts ■ Left Side/Right Side ■ Front Getting Ready A Earpiece (Receiver) Emits voice of the other party during a call, messages in Answering memo, etc. B Proximity sensor/Light sensor Proximity sensor prevents operating the touch panel incorrectly during a call. Light sensor detects the ambient brightness and adjusts the brightness of display.
is16sh_e.book 31 ページ 2012年6月1日 金曜日 午後8時47分 ■ Top/Bottom Getting Ready J Earphone/Microphone jack K TV antenna Extend and use it to watch 1Seg. It has no influence on calls or data communications if you extend the TV antenna when talking on the product, using browser, etc.
is16sh_e.book 32 ページ 2012年6月1日 金曜日 午後8時47分 R FeliCa mark Hold it over a reader/writer when using NFC/Osaifu-Keitai®. Sends and receives data via IC communication. S Battery cover T Mobile light U Speaker Emits ringtones, alarm tones, etc. ■ Back (Inside the Battery Cover) memo ◎ Do not remove the cover etc. put inside the battery cover. ◎ When you connect the common AC adapter 03 (sold separately), the microUSB cable 01 (sold separately), etc.
is16sh_e.book 33 ページ 2012年6月1日 金曜日 午後8時47分 B After making sure that the PULL tab is closely attached to the battery pack, align the contacts on the battery pack with those of the product and then insert the battery pack securely. PULL tab Removing the Battery Pack Before removing the battery pack, turn the product off and remove the battery cover. A Remove the battery pack. Remove the battery pack by pulling up the PULL tab in the direction of the arrow.
is16sh_e.book 34 ページ 2012年6月1日 金曜日 午後8時47分 C Make sure that the strap does not come off and attach Using a Strap the battery cover. You can put a commercially available strap on the product. Depending on how to put the strap, the battery cover may come off, and that causes the strap to come off. Put the strap after removing the battery cover. A Put the string of the strap through the strap eyelet on the side of the main unit.
is16sh_e.book 35 ページ 2012年6月1日 金曜日 午後8時47分 memo ◎ Note the following points, which may cause malfunction or damage, when handling the micro au IC-Card. • Do not touch the IC (metal) part of the micro au IC-Card or the IC card terminal inside the product. • Insert the micro au IC-Card in the correct direction. • Do not use force to attach or remove the micro au IC-Card. ◎ Do not lose the micro au IC-Card after it has been removed.
is16sh_e.book 36 ページ 2012年6月1日 金曜日 午後8時47分 C Attach the battery pack and the battery cover. memo microSD Memory Card ◎ Inserting the micro au IC-Card and the tray not deeply enough may prevent the product from functioning properly. ◎ When the tray comes off, insert the tray straightly. Removing the micro au IC-Card Before removing the micro au IC-Card, turn the product off and remove the battery pack.
is16sh_e.book 37 ページ 2012年6月1日 金曜日 午後8時47分 ■ Handling Precautions • Do not turn off the product or subject it to impact while microSD memory card data is being accessed. Doing so creates the risk of data corruption. • The following microSD memory cards have been confirmed for operation based on the criteria by the Company. For operation confirmation results of other microSD memory cards, contact each microSD memory card manufacturer.
is16sh_e.book 38 ページ 2012年6月1日 金曜日 午後8時47分 Removing the microSD Memory Card Before removing the microSD memory card, turn the product off and remove the battery pack. A Remove slowly the microSD memory card in the direction of the arrow. Pull slowly the microSD memory card straight out. Charging Charging When you purchase the product, the battery pack is not fully charged. Be sure to charge the battery pack before use. The usage times are as follows.
is16sh_e.book 39 ページ 2012年6月1日 金曜日 午後8時47分 Connection jack Protruding edges Common AC adapter 03 (sold separately) B Place the main unit on the desktop holder. Insert the main unit with the locking tabs of the desktop holder fitted into the concave portions of the main unit. Charging with the Desktop Holder and the Specified AC Adapter (Sold Separately) The followings are the explanation of how to connect the desktop holder and the common AC adapter 03 (sold separately) to charge.
is16sh_e.book 40 ページ 2012年6月1日 金曜日 午後8時47分 C Plug the common AC adapter 03 (sold separately) power plug into a 100 V AC power outlet. Common AC adapter 03 (sold separately) The charging/incoming indicator illuminates in red, and the battery icon appears with superimposed. When charging is finished, the charging/incoming indicator goes out.
is16sh_e.book 41 ページ 2012年6月1日 金曜日 午後8時47分 B Confirm the direction of the microUSB plug of the common AC adapter 03 (sold separately)/the common DC adapter 03 (sold separately) and insert it in the direction of the arrow to the external connection jack of the product. C Plug the common AC adapter 03 (sold separately) power plug into a 100 V AC power outlet/Plug the common DC adapter 03 (sold separately) plug into a cigarette lighter socket.
is16sh_e.book 42 ページ 2012年6月1日 金曜日 午後8時47分 memo ◎ If you use the microUSB cable to charge the battery pack, it may take the battery pack longer to be fully charged than if you use the specified AC adapter (sold separately). ◎ The product supports two microUSB plug shapes. ◎ Turn the protruding side of the microUSB plug up and insert the microUSB plug to the external connection jack of the product straightly.
is16sh_e.book 43 ページ 2012年6月1日 金曜日 午後8時47分 Welcome Sheet(Lock Screen) The Welcome Sheet(Lock Screen) is displayed if you disable sleep mode. B Owner info key When you tap with “Owner info” in “Lock & Security” set, the owner info is displayed in the Info Area. Tap “ ” to hide it. C Info Area Flick to the left/right to switch the weather, stock prices information, music operation keys and date and time.
is16sh_e.book 44 ページ 2012年6月1日 金曜日 午後8時47分 Using the Touch Panel The display on the product is a touch panel operated by touching it with your finger. • The touch panel is designed to be touched lightly by your finger. Do not exert too much pressure with your finger or press sharp-pointed objects (fingernails, ballpoint pens, pins, etc.) against it. • In the following cases, the touch panel may not work even if you touch it. It may also cause a malfunction.
is16sh_e.book 45 ページ 2012年6月1日 金曜日 午後8時47分 ■ Flick Operate the screen by quickly moving (flicking) your finger up, down, right, or left. • Switch pages, enter characters by flick input, etc. Using the Touch Keys The following icons appear on the Navigation Bar and can be used as touch keys. Icon ^ # e $ Description Returns to a previous screen. Displays the home screen. Displays an option menu. Displays recent applications.
is16sh_e.book 46 ページ 2012年6月1日 金曜日 午後8時47分 A Status bar B Sheet Switcher Tap it to switch the Apps Sheet, the Widget Sheet and the Shortcut Sheet. C Apps Sheet/Widget Sheet/Shortcut Sheet D Navigation Bar E Separator Pinch out vertically on the home screen to add the separator. To delete the separator, pinch in vertically. Using Menu on the Home Screen A Slide down at the top of each sheet. memo ◎ When the 3-Line Home is displayed for the first time, its operation guide is displayed.
is16sh_e.book 47 ページ Add shortcut Back to Welcome Sheet 2012年6月1日 金曜日 午後8時47分 Pastes the selected shortcut on the Shortcut Sheet. Displays the Welcome Sheet(Lock Screen). Main Application List Icon Name of icon Phone E-mail SMS(C-mail) Settings * Instruction Manual NFC Menu Name of icon Description au Wi-Fi接続ツー Use Wi-Fi® easily in the spot where au ル (au Wi-Fi Wi-Fi SPOT is available.
is16sh_e.book Icon 48 ページ 2012年6月1日 Name of icon リモートサポー ト (Remote Support) ウイルスバス ター (VirusBuster) auサービスリス ト (au service list) GREE MARKET (GREE Market) 金曜日 午後8時47分 Description Call for technical supports on the phone operations by sharing the screen that you are watching with au operators. Blocks improper applications and sites in order to protect young people. Use services and applications of au/ KDDI easily from lists.
is16sh_e.book Icon 49 ページ 2012年6月1日 金曜日 午後8時47分 ■ Examples of Status Icon Icon ~ ~ ~ Description Time Alarm set Battery level ~ : Battery level display : No battery • While charging, the battery icon appears with superimposed. Airplane mode set Signal strength (Receiving electric field) ~ : Level display : Out of service area • The icon indicating network appears at the upper left. • During a communication, the icon appears with superimposed.
is16sh_e.book Icon ~ 50 ページ 2012年6月1日 金曜日 午後8時47分 Description WiMAX signal strength ~ : Level display : Out of service area/Not connecting : Powering down : Idling • During a communication, the icon appears with superimposed.
is16sh_e.book 51 ページ 2012年6月1日 金曜日 午後8時47分 Switching Software Keyboards Viewing the Character Input Screen To display the software keyboard, tap a character input field in the character entry screen for adding contacts, creating a message, etc. The following software keyboards are available for the product. 12Key QWERTY Characters are arranged in the same order as of the keyboard on a conventional cell phone.
is16sh_e.book 52 ページ 2012年6月1日 金曜日 午後8時47分 Character Input D Character entry key You can enter a character assigned to each key. E Cursor key Moves the cursor to the left and right. Enters a space by moving the cursor to the right at the end of a text. Change the range of the characters for character input and conversion. F Emoji, Symbol and Facemark key/Kana and Alphanumeric key : Displays the emoji/symbol/facemark list.
is16sh_e.book 53 ページ 2012年6月1日 金曜日 午後8時47分 memo ◎ While the prediction candidates list/relational prediction candidates list/ normal conversion candidates list is not displayed, tap “^” to hide the keyboard. ◎ Perform the following operations with a software keyboard to switch input methods.
is16sh_e.book 54 ページ 2012年6月1日 金曜日 Entering Emoji/Symbol/Facemark A On the character entry screen, [ ]. 午後8時47分 A Character switching tab Switches the emoji/symbol/facemark. B Emoji/Symbol/Facemark list Displays the emoji/symbol/facemark list for each category. • Long touch a facemark to edit it. However, facemarks in the “History” field cannot be edited. Character Input 《Emoji/Symbol/Facemark list screen》 C Close key Returns to the character entry screen.
is16sh_e.book 55 ページ 2012年6月1日 金曜日 午後8時47分 Making Calls Entering a Phone Number and Making a Call A On the home screen, [APPS] [[Phone]. F Delete key Deletes one digit on the left of the cursor. If you long touch the key, all the numbers on the left of the cursor are deleted and all the numbers are deleted when there is no number on the left of the cursor. B Enter a phone number. When calling to a fixed-line phone, enter the phone number starting with the area code even if you are in the same area.
is16sh_e.book 56 ページ 2012年6月1日 金曜日 午後8時47分 Dial services available from au phones ◎ The following dial services are available.
is16sh_e.book 57 ページ 2012年6月1日 金曜日 午後8時47分 Using Menu on the Phone Number Entry Screen A On the home screen, [APPS] [[Phone] [[e]. B Create SMS Add Prefix Restrict Calls Setting Create an SMS (C-mail). Add a prefix to the phone number. Set whether to restrict making a call. • Even while Restrict Calls Setting is set to ON, you can make a call to emergency call numbers and 157 (Customer Service Center). Even in roaming, you can make a call to emergency call numbers. Perform call settings.
is16sh_e.book 58 ページ 2012年6月1日 金曜日 午後8時47分 memo ◎ The monthly limit fee is set for the au International Call Service. The au International Call Service is unavailable from when the limit fee is confirmed to be exceeded until the end of the same month. ◎ Even if you cannot use the service by exceeding the limit fee, you can use from the first day of the next month. Also, you can use the domestic call as usual while the service is stopped.
is16sh_e.book 59 ページ 2012年6月1日 金曜日 午後8時47分 B Select a message to send. You can create and send an SMS (C-mail) by tapping “Custom message...”. The incoming call is disconnected. The other party will hear voice guidance stating that “こちらはauです。 おかけになった電話をお呼び しましたが、 お出になりません。” (This is au. We called the number you have dialed, but no response). memo ◎ If the other party’s phone number is not notified, Quick responses is not available.
is16sh_e.book 60 ページ 2012年6月1日 金曜日 午後8時47分 Displaying Setting Menu From Settings, set up and manage functions. You can personalize the wallpaper or ringtone, set up security, initialize data, etc. A On the home screen, [APPS] [[Settings].
is16sh_e.
is16sh_e_18.fm 63 ページ 2012年6月4日 月曜日 午後3時33分 ■ Answering Calls A Press the switch of the earphone/microphone with Trouble Cannot operate the touch panel as intended. switch during an incoming call. B Press the switch of the earphone/microphone with switch to end the call. Troubleshooting Before you assume that the product is malfunctioning, check the following: Trouble Cannot turn on the power. Cannot charge the battery. • • • • • • • • • • • auIC card(UIM) error. is displayed.
is16sh_e.book 64 ページ Trouble Cannot recognize a microSD memory card/ Cannot find target data. The power is turned off automatically. The power is turned off while the wake-up logo is displayed. (out of service area indicator) appears. Appendix/Index Wi-Fi® cannot be connected. WiMAX cannot be connected. A message indicating that charging is necessary appears. When making a call, a beeping sound is heard from the earpiece and a connection cannot be established.
is16sh_e.book B 65 ページ Update Auto Setup Reserve Time 金曜日 午後8時47分 Check whether software update is necessary or not (manual update). The confirmation starts when you tap “Execute”. When it is necessary, you can choose whether to update immediately or to update later (update reservation). • If you want to update immediately, tap “Execute” to start the download of data needed for software update. When the download has completed and the product has restarted, software will be updated.
is16sh_e.book 66 ページ 2012年6月1日 金曜日 午後8時47分 The following operations are not available during the mobile update • Operations are not available during software update. Making a call to 110 (Police), 119 (Fire and Ambulance), 118 (Regional Coast Guard Headquarters) or 157 (Customer Service Center) is not available either. Also, the alarm etc. does not function.
is16sh_e.book 67 ページ 2012年6月1日 金曜日 午後8時47分 ◎ Old au phones collected via Replacement cell phone delivery service will be reused as cell phones for replacement after they are recovered and repaired. Also, old mechanical parts replaced via the au after-sales service will be collected and recycled by the Company and cannot be returned to the customer.
is16sh_e.
is16sh_e.book 69 ページ 2012年6月1日 金曜日 午後8時47分 ■ Audio Data format Audio: AMR-Narrow band Audio: 3GPP (AAC LC/LTP, HE-AACv1 (AAC+), HE-AACv2 (enhanced AAC+)), Chaku-Uta® (AAC, HE AAC), Voice (only AMR) Voice (AMR), Chaku-Uta® (AAC, HE AAC) Audio: MPEG4 (AAC LC/LTP, HE-AACv1 (AAC+), HE-AACv2 (enhanced AAC+)) Audio: MP3 (8 to 320 kbps CBR or VBR) Audio: WMA PlayReady music: PYA PlayReady music: ISMA Audio: MIDI Audio: Adjustable audio file format developed by Xiph.
is16sh_e.book Picture size of video/ Magnification and its steps/ Recording time*5 Bluetooth® Function Mobile light source LED characteristics Appendix/Index Network environment Interface 70 ページ 2012年6月1日 金曜日 午後8時47分 Out camera QVGA: 320×240/4.00-fold and 13 steps/Max. approx 90 min VGA: 640×480/4.00-fold and 13 steps/Max. approx 90 min HD: 1,280×720/4.00-fold and 13 steps/Max. approx 44 min FULL HD: 1,920×1,080/4.00-fold and 13 steps/Max. approx 16 min In camera QVGA: 320×240/No zoom/Max.
is16sh_e.book 71 ページ 2012年6月1日 金曜日 午後8時47分 memo ◎ The number of e-mails which can be sent per day is up to 1,000 (including the number of carbon copies). ■ SMS (C-mail) Newly compose SMS (C-mail) center Mail Filters Inbox Outbox Message: 70 full-width/140 half-width characters Number of savable SMSs (C-mails): No limit Saving duration: Up to 72 hours after the SMS (C-mail) is stored to the SMS (C-mail) center Number of SMSs (C-mails) which you can specified: 10 Number of savable SMSs (C-mails): Max.
is16sh_e.book 72 ページ 2012年6月1日 金曜日 午後8時47分 The World Health Organization has stated that “a large number of studies have been performed over the last two decades to assess whether mobile phones pose a potential health risk. To date, no adverse health effects have been established as being caused by mobile phone use.” If you would like to know more detailed information, please refer to the WHO website. (http://www.who.int/docstore/peh-emf/publications/facts_press/ fact_english.
is16sh_e.book 73 ページ 2012年6月1日 金曜日 午後8時47分 Mobile light source LED characteristics a) Continuous illumination b) Wavelength White: 400-700 nm Red: 600-670 nm c) Maximum output White: 580 μW (inside cell phone 1.8 mW) Red: 103 μW (inside cell phone 240 μW) ■ Loudness Warning ■ AC Adapter ■ European RF Exposure Information Any AC adapter used with this handset must be suitably approved with a 5Vdc SELV output which meets limited power source requirements as specified in EN/ IEC 60950-1 clause 2.5.
is16sh_e.book 74 ページ 2012年6月1日 金曜日 午後8時47分 FCC Notice - - This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the manufacturer responsible for compliance could void the user’s authority to operate the equipment.
is16sh_e.book 75 ページ 2012年6月1日 金曜日 午後8時47分 Export Administration Regulations The product and its accessories may be subject to the Japan Export Administration Regulations (“Foreign Exchange and Foreign Trade Law” and its related laws). In addition, U.S. Re-export Regulations (Export Administration Regulations) may apply to the product and its accessories. To export and re-export the product and its accessories, take the required measures on your responsibility and at your expenses.
is16sh_e.book 76 ページ 2012年6月1日 金曜日 午後8時47分 • Music recognition technology and related data are provided by Gracenote®. Gracenote is a business standard for music recognition technology and related contents delivery. For details, refer to the following web page: www.gracenote.com CD and music data provided by Gracenote: Copyright © 2000 - present Gracenote. Gracenote Software: Copyright 2000 - present Gracenote. This product and services may include one or several of the following US Patent.
is16sh_e.book 77 ページ 2012年6月1日 金曜日 午後8時47分 • “VeilView”, “Best select photo”, “Chase focus”, “Egao focus shutter”, “Furimuki shutter”, “AQUOS”, “AQUOS PHONE”, “SERIE”, “ファミリンク”, “FAMILINK”, the “エコ技” symbol and “エコ技”, “OneTouch Shutter”, “GALAPAGOS”, “SH SHOW”, “CGSillicon”, “LCフォント”, “LCFONT” and the LC logo symbol are registered trademarks or trademarks of Sharp Corporation. • aptX is a registered trademark of CSR plc.
is16sh_e.book 78 ページ 2012年6月1日 金曜日 午後8時47分 THIS SOFTWARE IS PROVIDED BY THE OpenSSL PROJECT “AS IS” AND ANY EXPRESSED OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED.
is16sh_e.book 79 ページ 2012年6月1日 金曜日 午後8時47分 The Gracenote Software and each item of Gracenote Data are licensed to you “AS IS.” Gracenote makes no representations or warranties, express or implied, regarding the accuracy of any Gracenote Data from in the Gracenote Servers. Gracenote reserves the right to delete data from the Gracenote Servers or to change data categories for any cause that Gracenote deems sufficient.
is16sh_e.book 80 ページ 2012年6月1日 金曜日 午後8時47分 Out camera ................................. 31 Light sensor.................................. 30 Long touch.................................... 44 Index Drag............................................... 45 A Absence Memo ............................. 59 Add Call ......................................... 57 Add P ............................................. 56 Add Prefix...................................... 57 Add shortcut ...............................
For inquiries, call: Contents Customer Service Center For general information and charges From fixed-line phones: (toll free) From au cell phones: Safety Precautions area code not required TAPPING DIAL AND ZERO WILL CONNECT YOU TO AN OPERATOR Basic Manual AFTER CALLING 157 ON YOUR au CELLPHONE.
