ENGLISH Plasmacluster Ion Generator OPERATION MANUAL Device of this mark is a trademark of Sharp Corporation. Plasmacluster is a registered trademark or a trademark of Sharp Corporation. IG-CH2J IG-CH2J.EN_A515.indd 1 11.11.
IG-CH2J.EN_A515.indd 2 11.11.
ENGLISH IMPORTANT SAFETY INSTRUCTIONS................ E-2 • WARNING................................................................ E-2 • CAUTIONS CONCERNING OPERATION....................... E-3 • INSTALLATION GUIDELINES...................................... E-3 PARTS NAME......................................................... E-4 •. ......... MAIN UNIT. .......................................................................... E-4 •.............. CONTROL PANEL.............................................
IMPORTANT SAFETY INSTRUCTIONS Please read instructions carefully before using this unit as below. When using electrical appliances, basic safety precautions should be followed, including the following: WARNING - To reduce the risk of electric shock, fire or injury : • ������������������������ Use 220-240 volt outlet. • Be sure to use the included AC adapter. • Insert the AC adapter into the end of outlet surely. • When you carry out the maintenance, be sure to pull out the AC adapter from the outlet.
• ������������������������������������������������������������������������������������������� Do not ride the main unit and do not sit on or lean it, it may cause injury or malfunction. • ���������������������������������������������� DO NOT block the air intake and/or air outlet. • �������������������������������������������������������������������������������������� DO NOT use the unit near or on hot objects, such as stoves or heaters or where it may come into contact with steam.
PARTS NAME MAIN UNIT Louver Suction port CONTROL PANEL OPERATION light FILTER CLEAN light (orange) (blue) ON/OFF button AC ADAPTER AC plug DC plug (Unit Connection Plug) E-4 IG-CH2J.EN_A515.indd 6 11.11.
BACK ENGLISH Air outlet Plasmacluster Ion Generating Unit Сleaning brush DC jack REAR Filter E-5 IG-CH2J.EN_A515.indd 7 11.11.
INSTALLATION GUIDE Connection of AC adapter and installation of main unit 1 Insert the DC plug of AC adapter in the DC jack of the main unit. DC jack DC plug 2 3 Insert the AC plug of AC adapter in the outlet. AC plug AC adapter Place the main unit at the level place in the room. Precautions on installation • .e sure to place the product on a stable surface. • Do not block the suction port and the air outlet.
T ENGLISH Do not block the suction port when setting the helmet. Suction port Suction port OPERATION Press the ON/OFF button to turn on. If you press the ON/OFF button, the OPERATION light (blue) lights up and the operation is started. ON/OFF button OPERATION light In order to obtain the effect of Plasmacluster ion, operate the product for 8 hours* or more. * Varies depending on the condition of the helmet.
CLEANING AND MAINTENANCE At the cleaning or maintenance, stop the operation and pull out the plug of AC adapter for connecting the main unit. CABINET At least once a month Wipe off the taint with a soft cloth. Using clean soapy water, wipe o ff t h e c l e a n i n g s u b s t a n c e completely. GRILL At least once a week Remove the dust with a vacuum cleaner. E-8 IG-CH2J.EN_A515.indd 10 11.11.
FILTER If the FILTER CLEAN light is (orange) Even if the FILTER CLEAN light (orange) does not light, it is recommended to carry out the cleaning once a week. 2 1 The filter is attached to the rear of the main unit. Clip the tabs on both sides of the filter and pull it out. ENGLISH 1 2 Remove the filter. 1 Tabs Clean up the filter. Gently remove the dust attached to the filter with a vacuum cleaner. Do not press the filter with force with a vacuum cleaner. Otherwise, it is damaged.
PLASMACLUSTER ION GENERATING UNIT It is recommended to carry out the cleaning once every 6 months. 1 Remove the louver. Hold the main unit with a hand and then pull out the louver. Louver 2 Remove the cleaning brush. Remove the cleaning brush attached to the main unit. Сleaning brush 3 Clean up the needle electrode of the Plasmacluster Ion Generating Unit. Remove the dust from the needle electrode with using the cleaning brush. Сleaning brush Needle electrode E-10 IG-CH2J.EN_A515.indd 12 11.11.
Attach the cleaning brush. ENGLISH 4 Attach the cleaning brush to the pin of the cabinet. Pin 5 Attach the louver. Hold the main unit with a hand and attach the louver to the cabinet. Louver Cabinet Do not operate the product while the louver is removed. The strip of the helmet or other item touches the electrode of the Plasmacluster Ion Generating Unit and it may cause a failure. E-11 IG-CH2J.EN_A515.indd 13 11.11.
SPECIFICATIONS Model IG-CH2J Power supply AC adapter Rated input AC220V-240V • 50/60Hz • 0.3A Rated output DC12V • 1A Power consumption (W) 3 Outer dimensions (mm) 165 (W) × 233 (D) × 121 (H) (Not including AC adapter) Power cord length (m) (AC adapter) 1.8 0.57 (Not including AC adapter) Weight (kg) ACCESSORIES AC Adapter / Operation manual E-12 IG-CH2J.EN_A515.indd 14 11.11.
TROUBLESHOOTING WHAT TO DO • The OPERATION light (blue) does not light up. (The Plasmacluster Ion Generator does not work.) • Is the AC adapter installed correctly? Connect correctly. (See page E-6) ENGLISH Problem OPERATION light • The FILTER CLEAN light (orange) is lighting. • Filter is getting dirty. Clean the filter. (See E-9) After cleaning the ��lter, press ON/OFF button for 3 seconds.
E-14 IG-CH2J.EN_A515.indd 16 11.11.
ENGLISH IG-CH2J.EN_A515.indd 17 11.11.
MEMO IG-CH2J.EN_A515.indd 18 11.11.
ENGLISH IG-CH2J.EN_A515.indd 19 11.11.
SHARP CORPORATION OF AUSTRALIA PTY.LTD. A. B. N. 40 003 039 405 1 HUNTINGWOOD DRIVE, HUNTINGWOOD, N.S.W. 2148 P.O.BOX 6827, BLACKTOWN. N.S.W. 2148 www.sharp.net.au SHARP CORPORATION OF NEW ZEALAND LIMITED 59 HUGO JOHNSTON DRIVE, PENROSE, AUCKLAND www.sharp.net.nz Printed in China TINS-A515KKRZ 11K- CN 1 IG-CH2J.EN_A515.indd 20 11.11.
