7-17
Simplified Menu Operation
7
[2] Setting the position evaluation conditions
Set the X and Y coordinates for the image to be measured, and the OK range that will be used for the
degree of match.
ËË
ËË
Ë Setting procedure
1. Move the cursor to the "POSI-EVAL." item on the MAIN OPS MENU using the left and right keys,
and press the SET key.
- The position evaluation conditions will be displayed.
2. Move the cursor to the item you want to set or change using the up and down keys, and press the
SET key.
3. Move the cursor to the minimum and maximum values using the left and right keys, and press the
SET key
4. Move the cursor to each digit using the left and right keys, and increase or decrease the value
using the up and down keys. Then, press the SET key.
5. Press the ESC key.
6. Press the ESC key again. That completes the setting of the position evaluation conditions.
F.IMG C1 L
VX.XX
(TYPE00)
MEAS XXXXms 2000-08-01 10:30
MEASURE 0 CAM1 POSITIONING
CHG-TYPE
POSI-COND
POSI-EVAL. SEL-CAMERA
OPS-CND
SYS-CND
ADJ-CONTRAST
SAVE
SHUTTER
X0~7 Y0~7 READY
①
X COORD.(MDL0) 000.0~511.0 X0=
②
Y COORD.(MDL0) 000.0~479.0 Y0=
③
MATCH LVL(MDL0)
-10000~+10000 M0=
④
X COORD.(MDL1) 000.0~511.0 X1=
⑤
Y COORD.(MDL1) 000.0~479.0 Y1=
⑥
MATCH LVL(MDL1)
-10000~+10000 M1=
