7-22
Simplified Menu Operation
7
15. Press the ESC key to display all of the measurement condition items.
16. Move the cursor to the "OPS-MENU" item using the up and down keys, and press the SET key.
- The screen will return to the MAIN OPS MENU. That completes the setting of the
measurement conditions.
[2] Setting the evaluation conditions
Set the OK range for a measured area.
ËË
ËË
Ë Operating procedure
1. Move the cursor to the "EXIST-EVAL." item on the MAIN OPS MENU using the left and right
keys, and press the SET key.
- The evaluation conditions will be displayed.
2. Move the cursor to the item you want to set using the up and down keys, and press the SET key.
3. Move the cursor to the minimum and maximum value entries using the left and right keys, and
press the SET key
4. Move the cursor to each digit using the left and right keys, and increase or decrease the values
using the up and down keys. Then, press the SET key.
5. Press the ESC key.
6. Press the ESC key again. That completes the setting of the evaluation conditions.
1REGISTER NO. 0(0~7) NO YES
2MEAS AREA MOVE UP.L(107,208) LO.R(198,295)
3THRESHOLD U.LM255 L.LM100(0~255)
4INVERT B/W NO YES
F.IMG C1 L
OPS-MENU
F.IMG C1 L
VX.XX
(TYPE00)
MEAS XXXXms 2000-08-01 10:30
MEASUREMENT1 EXISTENCE
CHG-TYPE EXIST-COND EXIST-EVAL. SEL-CAMERA
OPS-CND SYS-CND ADJ-CONTRAST SAVE SHUTTER
X0~7 Y0~7
READY
①
REG00 000000~245760 A00=
②
REG01 000000~245760 A01=
③
REG02 000000~245760 A02=
④
REG03 000000~245760 A03=
⑤
REG04 000000~245760 A04=
⑥
REG05 000000~245760 A05=
⑦
REG06 000000~245760 A06=
⑧
REG07 000000~245760 A07=
