7-24
Simplified Menu Operation
7
[4] Setting the evaluation conditions for correcting a position
Set the X and Y coordinates of the image used for making the correction, and the OK range that will be
used for determining the degree of match.
ËË
ËË
Ë Operating procedure
1. Move the cursor to the "AUX-EVAL" item on the MAIN OPS MENU using the left and right keys,
and press the SET key.
- The evaluation conditions will be displayed.
2. Move the cursor to the item you want to set using the up and down keys, and press the SET key.
3. Move the cursor to the minimum and maximum value entries using the left and right keys, and
press the SET key
4. Move the cursor to each digit using the left and right keys, and increase or decrease the values
using the up and down keys.
5. Press the ESC key.
6. Press the ESC key again. That completes the setting of the evaluation conditions.
F.IMG C1 L
VX.XX
(TYPE00)
MEAS XXXXms 2000-08-01 10:30
MEASURE0 CAM1 POSITION CORRECTION
CHG-TYPE AUX-COND AUX-EVAL. EXIST-COND EXIST-EVAL. SEL-CAMERA
OPS-CND SYS-CND ADJ-CONTRAST SAVE SHUTTER
X0~7 Y0~7
READY
①
X COORD. (MDL0) 000.0~511.0 X0=
②
Y COORD. (MDL0) 000.0~479.0 Y0=
③
MATCH LVL (MDL0) -10000~+10000 M0=
